Don't Talk About Dana Ball

A hyperpersonal design of "Dana Ball", a combination of wrestling and basketball.

BeginnerWork in progress294

Things used in this project

Hardware components

Arduino UNO

Piezo Buzzer

Ultrasonic Sensor

RGB LED Strip

12V 1 Amp Power Supply

Transistor

Story

What is Dana Ball?

Dana Ball is a game with no rules that merges wrestling with basketball. It is played with a plastic toddlers basketball hoop in a carpeted living room. Our team discovered this unique game upon interviewing Issac Yi, whom our project is specifically designed for. This project is a part of an assignment in which our team was asked to create a hyper personal product for a specific person that meets his or her individual needs.

Finding a Client

We posted on UC Berkeley's Free & For Sale page, a Facebook group of +28,000 people. Our first post listed time commitments, but was vague about the end product --it received almost no responses. The second lost took a different approach by using catchy buzz words and listing no time commitments --it was a success! We received 22+ likes and countless messages. The first person to confirm 2 interview times with us became our client.

1 / 2

Interview

Issac Yi is a 4th year Computer Science student at UC Berkeley. In our 1st interview with him, we found out that Issac is perpetually late, likes to work out, enjoys the outdoors, and works at a start up in Berkeley. We also found out that his friends and him play a sport called Dana Ball. This game fascinated us and we wanted to create a product that would legitimize this fight-club-esque - indoor - wrestling-basketball game.

In the 2nd interview, we focused on Dana Ball. We learned that the sport is been played by 5-6 of Issac's friends since 2012 when they first moved to college. It is played in one of Issac's friends living rooms and they regularly get carpet burns from the game (which they do not mind). Not many points are scored during each game, and the duration of each game varies.

Prototyping

1 / 2 • Design Sketch

We wanted to create a basketball hoop that reacts with light and sound when scored. Our beginning circuit included a RGB LED, Piezo Buzzer, Ultrasonic Sensor, and an Arduino Uno. The Arduino was programmed to play a Daft Punk song while flashing light when the proximity sensor senses an object closer than the set distance (35cm).

Our initial design involved 30+ RGB LEDs, but we decided to use a RGB LED strip instead because of problems with wiring and powering. We also added a 12V 1 Amp Power supply to power the RGB LED strip.

Prototype with a RGB LED strip

Step-by-Step Making

1. Get one Arduino Uno, one Piezo Buzzer, one Ultrasonic Sensor, five feet long RGB LED Strip, three transistors, and one 12V 1A Power Supply.

2. Follow the Circuit diagram and connect all parts.

3. Drill and cut parts of the hoop to install the electronics inside.

4. Attach the RGB LED strip onto the hoop.

5. Upload the Arduino project.

6. Plug in the power source.

7. and Dana Ball!

Additional Design and Final Product

1 / 5

Code

/*

  featuring music by Daft Punk

*/
#include "pitches.h" //Be sure that pitches.h is in the same directory
#define REDPIN 5
#define GREENPIN 6
#define BLUEPIN 3
#define FADESPEED 5
#define LO 255
#define HI 0

const byte noteLength = 125;
const byte speakerPin = 8;
const byte RED_PIN = 5;
const byte GREEN_PIN = 10;
const byte BLUE_PIN = 11;
const byte trigPin = 7;
const byte echoPin = 13;

void white() {
  analogWrite(REDPIN, HI);
  analogWrite(GREENPIN, HI);
  analogWrite(BLUEPIN, HI);
}

void red() {
  analogWrite(REDPIN, LO);
  analogWrite(GREENPIN, LO);
  analogWrite(BLUEPIN, LO);
}

void setup() {
  Serial.begin (9600);
  pinMode(trigPin, OUTPUT);
  pinMode(echoPin, INPUT);
  pinMode(speakerPin, OUTPUT);
  pinMode(RED_PIN, OUTPUT);
  pinMode(GREEN_PIN, OUTPUT);
  pinMode(BLUE_PIN, OUTPUT);

}

//Plays the keyboard solo to Daft Punk's "Aerodynamic" while flashing LED
void aerodynamicMelody(){
  for(byte i = 0; i <= 1; i++){
    for(byte i = 0; i <= 3; i++){
      tone(speakerPin, NOTE_D5, noteLength);
      //Flash red
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_FS4, noteLength);
      //Flash cyan
      white();
      delay(noteLength);

      tone(speakerPin, NOTE_B5, noteLength);
      //Flash yellow
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_FS4, noteLength);
      //Flash purple
      white();
      delay(noteLength);
    }
    for(byte i = 0; i <= 3; i++){
      tone(speakerPin, NOTE_D5, noteLength);
      //Flash blue
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_GS4, noteLength);
      //Flash purple
      white();
      delay(noteLength);

      tone(speakerPin, NOTE_B5, noteLength);
      //Flash white
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_GS4, noteLength);
      //Flash green
      white();
      delay(noteLength);
    }
    for(byte i = 0; i <= 3; i++){
      tone(speakerPin, NOTE_G6, noteLength);
      //Flash cyan
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_E6, noteLength);
      //Flash red
      white();
      delay(noteLength);

      tone(speakerPin, NOTE_B6, noteLength);
      //Flash green
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_E6, noteLength);
      //Flash blue
      white();
      delay(noteLength);
    }
    for(byte i = 0; i <= 3; i++){
      tone(speakerPin, NOTE_E5, noteLength);
      //Flash yellow
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_A6, noteLength);
      //Flash white
      white();
      delay(noteLength);

      tone(speakerPin, NOTE_CS6, noteLength);
      //Flash blue
      red();
      delay(noteLength);

      tone(speakerPin, NOTE_A6, noteLength);
      //Flash red
      white();
      delay(noteLength);
    }
  }
}
void loop(){
   long duration, distance;
   digitalWrite(trigPin, LOW);
   delayMicroseconds(2);
   digitalWrite(trigPin, HIGH);
   delayMicroseconds(5);
   digitalWrite(trigPin, LOW);
   duration = pulseIn(echoPin, HIGH);
   distance = (duration/2) / 1; //gives you the distance in cm
   if (distance <= 100){
     analogWrite(RED_PIN, 255);
     digitalRead(RED_PIN);
     aerodynamicMelody();
   }
   delay(100);
   if else (distance = else){
     analogWrite(RED_PIN, LOW);
     digitalRead(RED_PIN,LOW);
     aerodynamicMelody(LOW);
   }
}

/*************************************************
 * Public Constants
 *************************************************/

#define NOTE_B0  31
#define NOTE_C1  33
#define NOTE_CS1 35
#define NOTE_D1  37
#define NOTE_DS1 39
#define NOTE_E1  41
#define NOTE_F1  44
#define NOTE_FS1 46
#define NOTE_G1  49
#define NOTE_GS1 52
#define NOTE_A1  55
#define NOTE_AS1 58
#define NOTE_B1  62
#define NOTE_C2  65
#define NOTE_CS2 69
#define NOTE_D2  73
#define NOTE_DS2 78
#define NOTE_E2  82
#define NOTE_F2  87
#define NOTE_FS2 93
#define NOTE_G2  98
#define NOTE_GS2 104
#define NOTE_A2  110
#define NOTE_AS2 117
#define NOTE_B2  123
#define NOTE_C3  131
#define NOTE_CS3 139
#define NOTE_D3  147
#define NOTE_DS3 156
#define NOTE_E3  165
#define NOTE_F3  175
#define NOTE_FS3 185
#define NOTE_G3  196
#define NOTE_GS3 208
#define NOTE_A3  220
#define NOTE_AS3 233
#define NOTE_B3  247
#define NOTE_C4  262
#define NOTE_CS4 277
#define NOTE_D4  294
#define NOTE_DS4 311
#define NOTE_E4  330
#define NOTE_F4  349
#define NOTE_FS4 370
#define NOTE_G4  392
#define NOTE_GS4 415
#define NOTE_A4  440
#define NOTE_AS4 466
#define NOTE_B4  494
#define NOTE_C5  523
#define NOTE_CS5 554
#define NOTE_D5  587
#define NOTE_DS5 622
#define NOTE_E5  659
#define NOTE_F5  698
#define NOTE_FS5 740
#define NOTE_G5  784
#define NOTE_GS5 831
#define NOTE_A5  880
#define NOTE_AS5 932
#define NOTE_B5  988
#define NOTE_C6  1047
#define NOTE_CS6 1109
#define NOTE_D6  1175
#define NOTE_DS6 1245
#define NOTE_E6  1319
#define NOTE_F6  1397
#define NOTE_FS6 1480
#define NOTE_G6  1568
#define NOTE_GS6 1661
#define NOTE_A6  1760
#define NOTE_AS6 1865
#define NOTE_B6  1976
#define NOTE_C7  2093
#define NOTE_CS7 2217
#define NOTE_D7  2349
#define NOTE_DS7 2489
#define NOTE_E7  2637
#define NOTE_F7  2794
#define NOTE_FS7 2960
#define NOTE_G7  3136
#define NOTE_GS7 3322
#define NOTE_A7  3520
#define NOTE_AS7 3729
#define NOTE_B7  3951
#define NOTE_C8  4186
#define NOTE_CS8 4435
#define NOTE_D8  4699
#define NOTE_DS8 4978
