#include "TM1637.h"
TM1637 tm1637(39,38);
const int maxNumPlayers = 4;
const int leftButtonPin = PUSH1; // the number of the pushbutton pin
const int rightButtonPin = PUSH2; // the number of the pushbutton pin
const int redLedPin = RED_LED; // the number of the LED pin
const int greenLedPin = GREEN_LED; // the number of the LED pin
const int blueLedPin = BLUE_LED; // the number of the LED pin
const int buzzer = 40;
const int audioSensor = 23;
int leftButtonState = 0; // variable for reading the pushbutton status
int rightButtonState = 0; // variable for reading the pushbutton status
int audioLevel = 0;
int buzzDuration = 200;
int buzzDelayMultiplier = 1000;
int curPlayer = 0;
int curRound = 1;
int numPlayers = 1;
int players[9][2];
const float patterns[20][4] = {
{0.57, 0.42, 0.66, 0.43},
{0.51, 0.43, 0.86, 0.59},
{0.84, 0.48, 0.31, 0.44},
{0.45, 0.97, 0.42, 0.33},
{0.79, 0.27, 0.31, 0.00},
{0.39, 0.61, 0.93, 0.15},
{0.52, 0.55, 0.63, 0.81},
{0.32, 0.12, 0.99, 0.34},
{0.63, 0.79, 0.32, 0.72},
{0.07, 0.20, 0.08, 0.28},
{0.76, 0.13, 0.34, 0.78},
{0.14, 0.91, 0.08, 0.07},
{0.40, 0.77, 0.78, 0.82},
{0.75, 0.71, 0.47, 0.34},
{0.81, 0.62, 0.62, 0.53},
{0.11, 0.64, 0.35, 0.83},
{0.97, 0.61, 0.18, 0.71},
{0.50, 0.54, 0.67, 0.57},
{0.99, 0.41, 0.63, 0.24},
{0.45, 0.46, 0.90, 0.56}};
void setup() {
// 4 Digit 7 Segment Display Initialization
tm1637.init();
tm1637.set(BRIGHTEST);//BRIGHT_TYPICAL = 2,BRIGHT_DARKEST = 0,BRIGHTEST = 7;
// Setting Buttons
pinMode(leftButtonPin, INPUT_PULLUP);
pinMode(rightButtonPin, INPUT_PULLUP);
pinMode(redLedPin, OUTPUT);
pinMode(greenLedPin, OUTPUT);
pinMode(blueLedPin, OUTPUT);
Serial.begin(9600);
// Writing __ 01 to Display
segmentDisplay(0x12,0x12,0x00,0x01);
// Prompting selection for number of players
numPlayers = promptNumPlayer();
// Setting score to 0 and in-game to 1
for (int i=0; i < numPlayers; i++) {
players[i][0] = 0; // Score
players[i][1] = 1; // Alive
}
}
int nextPlayer() {
/***
* Returns the ID of the next player. If no other players are alive, then returns 0.
*/
int nextPlayerID = curPlayer;
while(true) {
nextPlayerID += 1;
if(nextPlayerID > numPlayers) {
nextPlayerID = 1;
curRound += 1;
}
if(nextPlayerID == curPlayer) {
// We have a champion. Returns 0 so that the game knows that it has concluded.
return 0;
}
if(players[nextPlayerID-1][1] == 1) {
return nextPlayerID;
}
}
}
void nextRound() {
/***
* Plays the next round for the current player.
*/
int lenPatterns = int(curRound/10) + 1;
lenPatterns = 1;
int currentPattern[lenPatterns];
delay(2000);
for (int i=0; i < lenPatterns; i++) {
currentPattern[i] = random(0, 20);
buzzPattern(currentPattern[i]);
}
int score = listenClaps(currentPattern[0]);
if(score == 0) {
players[curPlayer-1][1] = 0;
} else {
players[curPlayer-1][0] += score;
segmentDisplay(curPlayer,0x12,(players[curPlayer-1][0] / 10) % 10,players[curPlayer-1][0] % 10);
}
delay(2000);
}
int listenClaps(int patternNum) {
int curinterval = 0;
int prevSoundLevel;
int curSoundLevel;
int delta;
while(true) {
curSoundLevel = soundLevel();
if(curSoundLevel > 1800) {
prevSoundLevel = curSoundLevel;
break;
}
}
delay(200);
float timeintervals[4] = {0, 0, 0, 0};
while(true) {
int timecounter = 0;
while(true) {
timecounter += 1;
curSoundLevel = soundLevel();
delta = abs(curSoundLevel - prevSoundLevel);
if(delta < 200) {
prevSoundLevel = curSoundLevel;
break;
}
}
timeintervals[curinterval] = timecounter;
curinterval += 1;
if(curinterval >= 4) {
break;
}
delay(200);
}
int scorecounter;
for(int i=0; i<4; i++)
{
scorecounter += abs(timeintervals[i] - patterns[patternNum][i]);
}
int score = 10000/scorecounter;
if(score >= 10) {
score = 10;
}
return score;
}
void finishGame() {
/***
* We have a champion. Finish the freaking game.
*/
segmentDisplay(8,8,8,8);
while(true) {
delay(10000);
}
}
void segmentDisplay(int sig1, int sig2, int sig3, int sig4) {
/***
* Displays the number on the 4 Digit Display:
*/
int8_t LedDisp[] = {sig1,sig2,sig3,sig4};
tm1637.display(LedDisp);
}
void toggleBuzz(){
/***
*
*/
digitalWrite(buzzer, HIGH);
delay(buzzDuration);
digitalWrite(buzzer, LOW);
}
void toggleLongBuzz(){
/***
*
*/
digitalWrite(buzzer, HIGH);
delay(buzzDuration * 6);
digitalWrite(buzzer, LOW);
}
void buzzPattern(int pattern) {
/***
* Plays the pattern with the index patern.
*/
for(int i = 0; i < 4; i++ ) {
toggleBuzz();
delay(patterns[pattern][i] * buzzDelayMultiplier);
}
toggleBuzz();
}
void writeLed(int LED, int STATE) {
/***
* Does LED stuff.
*/
digitalWrite(LED, STATE);
}
int soundLevel() {
/***
* Listens the enviornment.
* > 1800 means a clap.
*/
long sum = 0;
for(int i=0; i<32; i++)
{
sum += analogRead(audioSensor);
}
sum >>= 5;
return sum;
}
int promptNumPlayer() {
/***
* Prompts number of player selection and
* returns the inputted number of players.
*/
writeLed(greenLedPin, HIGH);
int numPlayers = 1;
while(true) {
leftButtonState = digitalRead(leftButtonPin);
rightButtonState = digitalRead(rightButtonPin);
if(leftButtonState == LOW) {
break;
}
if(rightButtonState == LOW) {
numPlayers += 1;
if(numPlayers > maxNumPlayers) {
numPlayers = 1;
}
segmentDisplay(0x12,0x12,0x00,numPlayers);
delay(250);
}
}
writeLed(greenLedPin, LOW);
return numPlayers;
}
void loop() {
// put your main code here, to run repeatedly:
curPlayer = nextPlayer();
if(curPlayer == 0) {
finishGame();
} else {
segmentDisplay(curPlayer, 0x12, (players[curPlayer-1][0] / 10) % 10, players[curPlayer-1][0] % 10);
Serial.println("Player "); Serial.println(curPlayer);
Serial.println("Score: "); Serial.println(players[curPlayer-1][0]);
//Serial.println("Display: "); Serial.println((players[curPlayer-1][0] / 10) % 10); Serial.println(players[curPlayer-1][0] % 10);
delay(500);
nextRound();
}
}
