CCTV Sederhana Tanpa Memakan Penyimpanan

// Enter your WiFi ssid and password
const char* ssid     = "********";   //WIFI SSID
const char* password = "********";   //WIFI password
String token = "************";
String chat_id = "**********";

#include <WiFi.h>
#include <WiFiClientSecure.h>
#include "soc/soc.h"
#include "soc/rtc_cntl_reg.h"
#include "esp_camera.h"

//CAMERA_MODEL_AI_THINKER
#define PWDN_GPIO_NUM     32
#define RESET_GPIO_NUM    -1
#define XCLK_GPIO_NUM      0
#define SIOD_GPIO_NUM     26
#define SIOC_GPIO_NUM     27
#define Y9_GPIO_NUM       35
#define Y8_GPIO_NUM       34
#define Y7_GPIO_NUM       39
#define Y6_GPIO_NUM       36
#define Y5_GPIO_NUM       21
#define Y4_GPIO_NUM       19
#define Y3_GPIO_NUM       18
#define Y2_GPIO_NUM        5
#define VSYNC_GPIO_NUM    25
#define HREF_GPIO_NUM     23
#define PCLK_GPIO_NUM     22

int gpioPIR = 13;

void setup()
{
  WRITE_PERI_REG(RTC_CNTL_BROWN_OUT_REG, 0);

  Serial.begin(115200);
  delay(10);
  WiFi.mode(WIFI_STA);
  Serial.println("");
  Serial.print("Connecting to ");
  Serial.println(ssid);
  WiFi.begin(ssid, password);
  long int StartTime=millis();
  while (WiFi.status() != WL_CONNECTED)
  {
    delay(500);
    if ((StartTime+10000) < millis()) break;
  }

  Serial.println("");
  Serial.println("STAIP address: ");
  Serial.println(WiFi.localIP());
  Serial.println("");

  if (WiFi.status() != WL_CONNECTED) {
    Serial.println("Reset");

    ledcAttach(4, 255, 15);
    ledcWrite(3,10);
    delay(200);
    ledcWrite(3,0);
    delay(200);
    ledcDetach(3);
    delay(1000);
    ESP.restart();
  }
  else
  {
    ledcAttach(4, 255, 15);
    for (int i=0;i<5;i++) {
      ledcWrite(3,10);
      delay(200);
      ledcWrite(3,0);
      delay(200);
    }
    ledcDetach(3);
  }

  camera_config_t config;
  config.ledc_channel = LEDC_CHANNEL_0;
  config.ledc_timer = LEDC_TIMER_0;
  config.pin_d0 = Y2_GPIO_NUM;
  config.pin_d1 = Y3_GPIO_NUM;
  config.pin_d2 = Y4_GPIO_NUM;
  config.pin_d3 = Y5_GPIO_NUM;
  config.pin_d4 = Y6_GPIO_NUM;
  config.pin_d5 = Y7_GPIO_NUM;
  config.pin_d6 = Y8_GPIO_NUM;
  config.pin_d7 = Y9_GPIO_NUM;
  config.pin_xclk = XCLK_GPIO_NUM;
  config.pin_pclk = PCLK_GPIO_NUM;
  config.pin_vsync = VSYNC_GPIO_NUM;
  config.pin_href = HREF_GPIO_NUM;
  config.pin_sscb_sda = SIOD_GPIO_NUM;
  config.pin_sscb_scl = SIOC_GPIO_NUM;
  config.pin_pwdn = PWDN_GPIO_NUM;
  config.pin_reset = RESET_GPIO_NUM;
  config.xclk_freq_hz = 20000000;
  config.pixel_format = PIXFORMAT_JPEG;

  if(psramFound())
{
    config.frame_size = FRAMESIZE_VGA;
    config.jpeg_quality = 10;  //0-63 lower number means higher quality
    config.fb_count = 2;
  }
else
{
    config.frame_size = FRAMESIZE_QQVGA;
    config.jpeg_quality = 12;  //0-63 lower number means higher quality
    config.fb_count = 1;
  }

  // camera init
  esp_err_t err = esp_camera_init(&config);
  if (err != ESP_OK)
{
    Serial.printf("Camera init failed with error 0x%x", err);
    delay(1000);
    ESP.restart();
  }

sensor_t * s = esp_camera_sensor_get();
 s->set_framesize(s, FRAMESIZE_XGA);

}

void loop()
{

  pinMode(gpioPIR, INPUT_PULLUP);
  int v = digitalRead(gpioPIR);
  Serial.println(v);
  if (v==1)
  {
    alerts2Telegram(token, chat_id);
    delay(10000);
  }
  delay(1000);

}

String alerts2Telegram(String token, String chat_id)
{
  const char* myDomain = "api.telegram.org";
  String getAll="", getBody = "";

  camera_fb_t * fb = NULL;
  fb = esp_camera_fb_get();
  if(!fb)
{
    Serial.println("Camera capture failed");
    delay(1000);
    ESP.restart();
    return "Camera capture failed";
  }


WiFiClientSecure client_tcp;
client_tcp.setInsecure();   //run version 1.0.5 or above

  if (client_tcp.connect(myDomain, 443))
{
    Serial.println("Connected to " + String(myDomain));

    String head = "--India\r\nContent-Disposition: form-data; name=\"chat_id\"; \r\n\r\n" + chat_id + "\r\n--India\r\nContent-Disposition: form-data; name=\"photo\"; filename=\"esp32-cam.jpg\"\r\nContent-Type: image/jpeg\r\n\r\n";
    String tail = "\r\n--India--\r\n";

    uint16_t imageLen = fb->len;
    uint16_t extraLen = head.length() + tail.length();
    uint16_t totalLen = imageLen + extraLen;

    client_tcp.println("POST /bot"+token+"/sendPhoto HTTP/1.1");
    client_tcp.println("Host: " + String(myDomain));
    client_tcp.println("Content-Length: " + String(totalLen));
    client_tcp.println("Content-Type: multipart/form-data; boundary=India");
    client_tcp.println();
    client_tcp.print(head);

    uint8_t *fbBuf = fb->buf;
    size_t fbLen = fb->len;


    for (size_t n=0;n<fbLen;n=n+1024)
 {

      if (n+1024<fbLen)
{
        client_tcp.write(fbBuf, 1024);
        fbBuf += 1024;
      }
      else if (fbLen%1024>0)
{
        size_t remainder = fbLen%1024;
        client_tcp.write(fbBuf, remainder);
      }
    }

    client_tcp.print(tail);

    esp_camera_fb_return(fb);

    int waitTime = 10000;   // timeout 10 seconds
    long startTime = millis();
    boolean state = false;

    while ((startTime + waitTime) > millis())
    {
      Serial.print(".");
      delay(100);
      while (client_tcp.available())
      {
          char c = client_tcp.read();
          if (c == '\n')
          {
            if (getAll.length()==0) state=true;
            getAll = "";
          }
          else if (c != '\r')
            getAll += String(c);
          if (state==true) getBody += String(c);
          startTime = millis();
       }
       if (getBody.length()>0) break;
    }
    client_tcp.stop();
    Serial.println(getBody);
  }
  else {
    getBody = "Connection to telegram failed.";
    Serial.println("Connection to telegram failed.");
  }

  return getBody;
}
