Innovation Lab #13 Temperature, Humidity Sensor

Bongilcheon High School_Innovation Lab Project.

BeginnerProtip5 minutes1,057

Innovation Lab #13 Temperature, Humidity Sensor

Things used in this project

Hardware components

Arduino UNO

Breadboard (generic)

DHT11 Temperature & Humidity Sensor (4 pins)

Software apps and online services

Arduino IDE

Story

Innovation Lab (170821)

Temperature and humidity were measured with temperature and humidity sensor.

Temperature and humidity values appear on the serial monitor.

The temperature was 28 and the humidity was 63.

Code

Temperature, Humidity Sensor

#include <DHT11.h>

DHT11 dht11(A0);
void setup()
{
  Serial.begin(9600);
}

void loop()
{
  float temp, humi;
  int result = dht11.read(humi, temp);

  if (result == 0)
  {
    Serial.print("temperature:");
    Serial.print(temp);
    Serial.print(" humidity:");
    Serial.print(humi);
    Serial.println();
  }
  else
  {
    Serial.println();
    Serial.print("Error No :");
    Serial.print(result);
    Serial.println();
  }


  delay(DHT11_RETRY_DELAY);
}
