Controlling Game with arduino UNO!! with python

We will Learn how to control a Game with joystick ( 1 ) plus 1 button ( 2nd currently in progress.

BeginnerWork in progress1,100
Controlling Game with arduino UNO!! with python

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
Analog joystick (Generic)
×1
Pushbutton switch 12mm
SparkFun Pushbutton switch 12mm
×1

Software apps and online services

Arduino IDE
Arduino IDE
Arduino Web Editor
Arduino Web Editor
Python Idle

Story

Read more

Schematics

Schematic

Sorry for bad drawing

Code

IDE editor code

Arduino
const int JoyStick_pin = 8; //plug Joystick 'Button' into pin 8
const int X_pin = A0;       //plug joystick X direction into pin A0
const int Y_pin = A1;       //plug joystick Y direction into pin A1
int xc;
int yc;
int JSButton;

void setup() {
  for (int i = 0; i < 2; i++) {
    pinMode(JoyStick_pin, INPUT);
  }

  Serial.begin(115200);
  Serial.print(X_pin);
  Serial.println(Y_pin);
}

void loop() {
  int x = analogRead(X_pin) - 521;  //read x direction value and -517 to bring back to around 0
  int y = analogRead(Y_pin) - 528;  //read y direction value and -512 to bring back to around 0

  if (x <-10) {         //joystick has off set of +/-8 so this negates that
    xc = 0;             //turn analogue value into integer. 0, 1 or 2 depending on state
  } else if (x >10) {
    xc = 2;
  } else {
    xc = 1;
  }

  if (y < -10) {
    yc = 0;
  } else if (y >10) {
    yc = 2;
  } else {
    yc = 1;
  }

  int buttonStates = analogRead(A5);   //set starting value of Joystick button
  if (buttonStates > 0) {
    buttonStates = 1;
  } else {
    buttonStates = analogRead(A5);
  }
  Serial.print("S");  //start printing the data, format is Sxc,yc,buttonStates > S1,1,0
  Serial.print(xc);
  Serial.print(",");
  Serial.print(yc);
  Serial.print(",");
  Serial.println((buttonStates));

  delay(40);

}

Python IDLE code

Python
Go to idle after installing python from link click on file select new copy paste code and save to your preferred location then click on run and run module . it will run. make sure not to have serial monitor opened. the enjoy socwars on crazygames or customized keys for your own uses
import serial           # import using pip
import pydirectinput

arduino = serial.Serial('COM3', 115200, timeout=.1)     #serial input from arduino. change COM port to wherever your arduino is connected

pydirectinput.PAUSE = 0

keysDown = {}   #list of currently pressed keys


def keyDown(key):               #what to do if key pressed. takes value from handleJoyStickAsArrowKeys
    keysDown[key] = True        #adds key to KeysDown list
    pydirectinput.keyDown(key)  #runs pydirectinput using key from (argument)
    #print('Down: ', key)       #remove '#' from print to test data stream


def keyUp(key):                     #what to do if key released. takes value from handleJoyStickAsArrowKeys
    if key in keysDown:
        del (keysDown[key])         #remove key from KeysDown
        pydirectinput.keyUp(key)    #runs pydirectinput using key from (argument)
        #print('Up: ', key)         #remove '#' from print to test data stream


def handleJoyStickAsArrowKeys(x, y, z):      #note that the x and y directions are swapped due to the way I orient my thumbstick
    if x == 0:          #0 is up on joystick
        keyDown('down')   #add up key to keyDown (argument)
        keyUp('up')   #add down key to keyUp (argument), as you can't press up and down together
    elif x == 2:        #2 is down on joystick
        keyDown('up')
        keyUp('down')
    else:               #1 is neutral on joystick
        keyUp('up')
        keyUp('down')

    if y == 2:          #2 is right on joystick
        keyDown('right')
        keyUp('left')
    elif y == 0:        #0 is left on joystick
        keyDown('left')
        keyUp('right')
    else:               #1 is neutral on joystick
        keyUp('left')
        keyUp('right')

    if z == 1:          #z argument is JSButton in this case. 1 is button pressed
        keyDown('space')    #key to be pressed with Joystick button. Change to any key
    else:
        keyUp('space')      #0 is button not pressed


while True:
    rawdata = arduino.readline()            #read serial data from arduino one line at a time
    data = str(rawdata.decode('utf-8'))     #decode the raw byte data into UTF-8
    if data.startswith("S"):                #make sure the read starts in the correct place
        dx = int(data[1])                   #X direction is second digit in data (data[0] is 'S')
        dy = int(data[3])                   #Y direction is fourth digit in data
        JSButton = int(data[5])             #JSButton is sixth digit in data
        #print(dx, dy, JSButton)            #remove '#' from print to test data stream
        handleJoyStickAsArrowKeys(dx, dy, JSButton)     #run body of code using dx, dy and JSButton as inputs
