MAX7219 Conquers Old-School 16-Segment Displays

Not fancy, just functional. The UNO is the engine for this old-school display, switching inner and outer display segments via MAX7219's.

AdvancedShowcase (no instructions)2,584
MAX7219 Conquers Old-School 16-Segment Displays
Ad

Things used in this project

Hardware components

MAX7219/MAX7221 LED Display Drivers
Maxim Integrated MAX7219/MAX7221 LED Display Drivers
×4
Texas Instruments 74LS08 Quad AND Gate
×1
Texas Instruments 1N914 or 1N4148 Diodes
×32
LED Display, 16-Segment, Common Cathode
×16

Hand tools and fabrication machines

Wire Wrap Tool, Gun
Wire Wrap Tool, Gun

Story

Read more

Schematics

16-Segment Display Circuitry

Steering Logic on Sheet1, Drivers on Sheet2

16-Segment Common Cathode Display

This is what I used, however, any generic common cathode device should work as well.

74LS08 Quad AND Gate

Any generic brand should work just fine.

MAX7219 Display Driver

This is the workhorse of the project

16-Segment Wire Table

Provides the complete interconnection list for all components. This project uses 30AWG wire-wrap wire on wire-wrap IC sockets, all on a 17" x 4" perf board; somewhat primitive in today's world, but works for the Caveman.

Code

16-Segment Display

Arduino
The Arduino UNO is the engine driving this project, powered from the USB connection to a desktop computer. The actual display circuitry is powered by a 5V, 5A desktop power supply. Interconnection between the Uno and display board requires 5 wires (clock, data, load, and two steering logic signals, LdOuter and LdInner). A ground is also required between the display board and Uno.
#include <avr/pgmspace.h>
#include <stdlib.h>
const int NUMBER_OF_ELEMENTS = 96;
const int MAX_SIZE = 10;
const char OSeg [NUMBER_OF_ELEMENTS] [MAX_SIZE] PROGMEM = { //Outer Segment Codes
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //*
{"00000000"},  //+
{"00000000"},  //
{"00000000"},  //-
{"00000000"},  //
{"00000000"},  ///
{"00111100"},  //0
{"00011000"},  //1
{"00110100"},  //2
{"00111100"},  //3
{"00011000"},  //4
{"00101100"},  //5
{"00101100"},  //6
{"00111000"},  //7
{"00111100"},  //8
{"00111100"},  //9
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"11110111"},  //@
{"11111001"},  //A
{"01111110"},  //B
{"11100111"},  //C
{"01111110"},  //D
{"11100111"},  //E
{"11100001"},  //F
{"11101111"},  //G
{"10011001"},  //H
{"01100110"},  //I
{"00011111"},  //J
{"10000001"},  //K
{"10000111"},  //L
{"10011001"},  //M
{"10011001"},  //N
{"11111111"},  //O
{"11110001"},  //P
{"11111111"},  //Q
{"11110001"},  //R
{"11101110"},  //S
{"01100000"},  //T
{"10011111"},  //U
{"10000001"},  //V
{"10011001"},  //W
{"00000000"},  //X
{"10011110"},  //Y
{"01100110"},  //Z
{"00100100"},  //[
{"00000000"},  //\
{"01000010"},  //]
{"00000000"},  //^
{"00000110"},  //_
{"00000000"},  //`
{"00000111"},  //a
{"10000011"},  //b
{"00000011"},  //c
{"00000011"},  //d
{"00000011"},  //e
{"00100000"},  //f
{"11000010"},  //g
{"10000001"},  //h
{"00000000"},  //i
{"00000011"},  //j
{"00000000"},  //k
{"00000000"},  //l
{"00001001"},  //m
{"00000001"},  //n
{"00000011"},  //o
{"11000001"},  //p
{"11000000"},  //q
{"00000001"},  //r
{"11000010"},  //s
{"10000011"},  //t
{"00000011"},  //u
{"00000001"},  //v
{"00001001"},  //w
{"00000000"},  //x
{"10000010"},  //y
{"00000010"},  //z
{"00100100"},  //{
{"00000000"},  //|
{"01000010"},  //}
{"00000000"},  //~
{"00000000"},  //


 };

const char ISeg [NUMBER_OF_ELEMENTS] [MAX_SIZE] PROGMEM = {  // Inner Segment Codes
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"11111111"},  //*
{"10100101"},  //+
{"00000000"},  //
{"10000001"},  //-
{"00000000"},  //
{"00010010"},  ///
{"00100100"},  //0
{"00010000"},  //1
{"10000100"},  //2
{"10000000"},  //3
{"10100000"},  //4
{"10100000"},  //5
{"10100100"},  //6
{"00000000"},  //7
{"10100100"},  //8
{"10100000"},  //9
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"00000000"},  //
{"10100000"},  //@
{"10000001"},  //A
{"10100100"},  //B
{"00000000"},  //C
{"00100100"},  //D
{"00000001"},  //E
{"00000001"},  //F
{"10000000"},  //G
{"10000001"},  //H
{"00100100"},  //I
{"00000000"},  //J
{"00011001"},  //K
{"00000000"},  //L
{"01010000"},  //M
{"01001000"},  //N
{"00000000"},  //O
{"10000001"},  //P
{"00001000"},  //Q
{"10001001"},  //R
{"10000001"},  //S
{"00100100"},  //T
{"00000000"},  //U
{"00010010"},  //V
{"00001010"},  //W
{"01011010"},  //X
{"10000001"},  //Y
{"00010010"},  //Z
{"00100100"},  //[
{"01001000"},  //\
{"00100100"},  //]
{"00001010"},  //^
{"00000000"},  //_
{"01000000"},  //`
{"00000101"},  //a
{"00000101"},  //b
{"00000001"},  //c
{"00100101"},  //d
{"00000011"},  //e
{"10100101"},  //f
{"00100101"},  //g
{"00000101"},  //h
{"00000100"},  //i
{"00100100"},  //j
{"00111100"},  //k
{"00100100"},  //l
{"10000101"},  //m
{"00000101"},  //n
{"00000101"},  //o
{"00100001"},  //p
{"00100101"},  //q
{"00000001"},  //r
{"00000101"},  //s
{"00000001"},  //t
{"00000100"},  //u
{"00000010"},  //v
{"00001010"},  //w
{"01011010"},  //x
{"00100101"},  //y
{"00000011"},  //z
{"00100101"},  //{
{"00100100"},  //|
{"10100100"},  //}
{"10010011"},  //~
{"00000000"},  //

};


#define Interval_Message 1200
#define MAX7219_DATA 5
#define MAX7219_CLOCK 7
#define MAX7219_LOAD 6
#define LdInner 9
#define LdOuter 8

unsigned long time1 = 0; // timer function
int x = 0; // message counter


// Various 16 character strings to display
const char string_0[] PROGMEM = " PERSISTANCE OF ";
const char string_1[] PROGMEM = "   VISION DEMO  ";
const char string_2[] PROGMEM = "USES Arduino Uno";
const char string_3[] PROGMEM = " Some AND gates ";
const char string_4[] PROGMEM = "MAX7219 and 16- ";
const char string_5[] PROGMEM = "Segment displays";
const char string_6[] PROGMEM = "                ";

// Load the above strings into progmem
const char *const string_table[] PROGMEM = {string_0,string_1,string_2,string_3,string_4,string_5,string_6};
char buffer[17];  // 16 characters + 1 null


void initialize()
  {
    pinMode(MAX7219_LOAD,OUTPUT);
    pinMode(MAX7219_CLOCK,OUTPUT);
    pinMode(MAX7219_DATA,OUTPUT);
    pinMode(LdInner,OUTPUT);
    pinMode(LdOuter,OUTPUT);
    digitalWrite(MAX7219_LOAD,LOW);
    digitalWrite(LdInner, LOW);
    digitalWrite(LdOuter,LOW);
  }

 // -------------------------------------------------------------------------------------------------------------------------------------------
void OuterSegments(byte address, word data) // Note: the 'data' is 16 bits which are split into highByte (for U6) and lowByte (for U2)
  {
    digitalWrite(LdOuter, HIGH); // AND Gate U1 sections A (clock signal) and D (load signal)

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U2 first gets the high byte (Upper 8 Displays Outer Segments) from the UNO
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, highByte(data));

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U2 now shifts the high byte into U6 while U2 gets the low byte (Lower 8 Displays Outer Segments)
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, lowByte(data));

    digitalWrite(MAX7219_LOAD, HIGH); // Load U2 and U6
    digitalWrite(MAX7219_LOAD, LOW);
    digitalWrite(LdOuter, LOW);
  }

void InnerSegments(byte address, word data) // Note: the 'data' is 16 bits which are split into highByte (for U9) and lowByte (for (U5)
  {
    digitalWrite(LdInner, HIGH); // AND Gate U1 sections B (clock signal) and C (load signal)

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U5 first gets the high byte (Upper 8 Displays Inner Segments) from the UNO
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, highByte(data));

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U5 now shifts the high byte into U9 while U5 gets the low byte (Lower 8 Displays Inner Segments)
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, lowByte(data));

    digitalWrite(MAX7219_LOAD, HIGH); // Load U5 and U9
    digitalWrite(MAX7219_LOAD, LOW);
    digitalWrite(LdInner, LOW);
  }


void CmdO(byte address, byte data) // these are U2 and U6 Control Register Commands (data is 8 bits)
  {
    digitalWrite(LdOuter, HIGH); // AND Gate U1 sections A (clock signal) and D (load signal)

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U2 first gets the address and data from the UNO
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, data);

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U2 shifts into U6 (Note: U2 and U6 get the identical address and data)
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, data);

    digitalWrite(MAX7219_LOAD, HIGH); // Load U2 and U6
    digitalWrite(MAX7219_LOAD, LOW);
    digitalWrite(LdOuter, LOW);
  }
void CmdI(byte address, byte data) // these are U5 and U9 Control Register Commands (data is 8 bits)
  {
    digitalWrite(LdInner, HIGH); // AND Gate U1 sections B (clock signal) and C (load signal)

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U5 first gets the address and data from the UNO
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, data);

    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, address); // U5 shifts into U9 (Note: U5 and U9 get the identical address and data)
    shiftOut(MAX7219_DATA, MAX7219_CLOCK, MSBFIRST, data);

    digitalWrite(MAX7219_LOAD, HIGH); // Load U5 and U9
    digitalWrite(MAX7219_LOAD, LOW);
    digitalWrite(LdInner, LOW);
  }

 // --------------------------------------------------------------------------------------------------------------------------

void setup() {
  // MAX7219 Control Register Set-Up

  initialize();

  // Outer Segment Set-Up (U2 and U6 - See MAX7219 Data Sheet page 7)
  CmdO(0x0C, 0x00); // shutdown register
  CmdO(0x0F, 0x00); // display test register - test mode off
  CmdO(0x0B, 0x07); // scan limit register - display digits 0-7
  CmdO(0x0A, 0x08); // intensity register - set display brightness
  CmdO(0x09, 0x00); // decode mode register - set individual segments
  CmdO(0x00, 0000); // No-Op

  // Inner Segment Set-Up (U5 and U9 - See Max7219 Data Sheet page 7)
  CmdI(0x0c, 0x00); // shutdown register
  CmdI(0x0f, 0x00); // display test register - test mode off
  CmdI(0x0b, 0x07); // scan limit register - display digits 0-7
  CmdI(0x0a, 0x08); // intensity register - set display brightness
  CmdI(0x09, 0x00); // decode mode register - set individual segments
  CmdI(0x00, 0000); // No-Op
}


// ---------------------------------------------------------------------------------------------------------------------------------------------------

void get_message(int msg)
  {
   strcpy_P(buffer, (char *)pgm_read_word(&(string_table[msg])));  // get message string from progmem
   String tempString = buffer;
   char outSeg [MAX_SIZE];
   char inSeg [MAX_SIZE];

    for (int z = 0; z < 8; z++)
      {
        int get_asciiHOO = tempString.charAt(z);
        memcpy_P (&outSeg, &OSeg [get_asciiHOO-32], sizeof outSeg); // Get the high order (Displays 9 thru 16) Outer Segment Codes from progmem
        char *Lo1;
        int OuterHigh = strtol(outSeg,&Lo1,2);

        int get_asciiLOO = tempString.charAt(z+8);
        memcpy_P (&outSeg, &OSeg [get_asciiLOO-32], sizeof outSeg); // Get the low order (Displays 1 thru 8) Outer Segment Codes from progmem
        char *Lo2;
        int OuterLow = strtol(outSeg,&Lo2,2);

       word OUTERdata = 0; // create the 16 bit word where 'high' is display 16, 'low' is display 8; each iteration thru this loop decrements until 'high' is display 9 and 'low' is display 1
       OUTERdata = word(OuterHigh,OuterLow);
       OuterSegments(8-z,OUTERdata);

  }
   for (int z = 0; z < 8; z++)
     {
       int get_asciiHOI = tempString.charAt(z);
       memcpy_P (&inSeg, &ISeg[get_asciiHOI-32], sizeof inSeg); // Get the high order (Displays 9 thru 16) Inner Segment Codes from progmem
       char *Li1;
       int InnerHigh = strtol(inSeg, &Li1,2);

      int get_asciiLOI = tempString.charAt(z+8);
      memcpy_P(&inSeg, &ISeg[get_asciiLOI-32],sizeof inSeg); // Get the low order (Displays 1 thru 8) Inner Segment Codes from progmem
      char *Li2;
      int InnerLow = strtol(inSeg, &Li2,2);

      word INNERdata = 0;  // create the 16 bit word where 'high' is display 16, 'low' is display 8; each iteration thru this loop decrements until 'high' is display 9 and 'low' is display 1
      INNERdata = word(InnerHigh,InnerLow);
      InnerSegments(8-z,INNERdata);
  }
}

void loop() {
  // alternate inner segment chips (U5 and U9) and outer segment chips (U2 and U6) shutdown modes
  // the human eye cannot perceive the switch between inner and outer segments
    CmdO(0x0c,0001); // U2 and U6 exit Shutdown Mode
    delay(10);
    CmdO(0x0c,0000); // U2 and U6 enter Shutdown Mode
    CmdI(0x0c,0001); // U5 and U9 exit Shutdown Mode
    delay(10);
    CmdI(0x0c,0000); // U5 and U9 enter Shutdown Mode

       if(millis() > time1 + Interval_Message){
        time1 = millis();
        get_message(x);
        x++;
        if (x==7) x = 0;
    }
}

Credits

OriginalCaveman
0 projects • 1 follower
Contact

Comments

Please log in or sign up to comment.

Related channels and tags
  • Maxim Integrated
  • Texas Instruments
