DIY | RGB LED Shades Controlled By Arduino

Here is how you can build your own RGB LED Glasses very easily and cheap.

AdvancedFull instructions provided10 hours10,960
DIY | RGB LED Shades Controlled By Arduino

Things used in this project

Hardware components

Arduino Nano R3
Arduino Nano R3
×1

Software apps and online services

Arduino IDE
Arduino IDE

Hand tools and fabrication machines

Soldering iron (generic)
Soldering iron (generic)

Story

Read more

Schematics

Schematics of the PCB

PCB Design

Code

Arduino Code

Arduino
Code to manually control the LED's.
#include "FastLED.h"

// How many leds in your strip?
#define NUM_LEDS 68

byte pixelType = 0;
byte drawIn[4];
byte frameIn[NUM_LEDS*3];


// For led chips like Neopixels, which have a data line, ground, and power, you just
// need to define DATA_PIN.  For led chipsets that are SPI based (four wires - data, clock,
// ground, and power), like the LPD8806 define both DATA_PIN and CLOCK_PIN
#define DATA_PIN 3
//#define CLOCK_PIN 13

// The bluetooth module pins
#define RX_PIN 0
#define TX_PIN 1

// Define the array of leds
CRGB leds[NUM_LEDS];

void setup() {
  // Uncomment/edit one of the following lines for your leds arrangement.
  // FastLED.addLeds<TM1803, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<TM1804, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<TM1809, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<WS2811, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<WS2812, DATA_PIN, RGB>(leds, NUM_LEDS);
  FastLED.addLeds<WS2812B, DATA_PIN, GRB>(leds, NUM_LEDS);
  // FastLED.addLeds<NEOPIXEL, DATA_PIN>(leds, NUM_LEDS);
  // FastLED.addLeds<APA104, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<UCS1903, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<UCS1903B, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<GW6205, DATA_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<GW6205_400, DATA_PIN, RGB>(leds, NUM_LEDS);

  // FastLED.addLeds<WS2801, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<SM16716, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<LPD8806, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<P9813, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<APA102, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<DOTSTAR, RGB>(leds, NUM_LEDS);

  // FastLED.addLeds<WS2801, DATA_PIN, CLOCK_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<SM16716, DATA_PIN, CLOCK_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<LPD8806, DATA_PIN, CLOCK_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<P9813, DATA_PIN, CLOCK_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<APA102, DATA_PIN, CLOCK_PIN, RGB>(leds, NUM_LEDS);
  // FastLED.addLeds<DOTSTAR, DATA_PIN, CLOCK_PIN, RGB>(leds, NUM_LEDS);
  Serial.begin(9600);

  pinMode(TX_PIN, OUTPUT);
  pinMode(RX_PIN, INPUT);
}

void loop() {

}

void serialEvent() {
  pixelType = Serial.read();

  switch (pixelType) {
    case 0:
    //draw mode
      while (!Serial.available()) {}
      Serial.readBytes(drawIn, 4);

      leds[drawIn[0]] = CRGB(drawIn[1], drawIn[2], drawIn[3]);

      FastLED.show();
      Serial.flush();
      break;

    case 1:
      //clear mode
      for (int i = 0; i < NUM_LEDS; i++)
      {
        leds[i] = CRGB::Black;
      }

      FastLED.show();
      Serial.flush();
      break;

    case 2:
    //frame in mode
      while (!Serial.available()) {}
      Serial.readBytes(frameIn, (NUM_LEDS * 3));
      for (int i = 0; i < NUM_LEDS; i++)
      {
        leds[i] = CRGB(frameIn[i * 3], frameIn[(i * 3) + 1], frameIn[(i * 3) + 2]);
      }

      FastLED.show();
      Serial.flush();
      break;

    case 3:
      while (!Serial.available()) {}
      int brightnessLED = Serial.read();
      FastLED.setBrightness(brightnessLED);
      Serial.flush();

      break;
  }
}

Software to control the shades

Java
Click the .bat to run the software.
No preview (download only).
