Arduino Programming Via Mobile || Arduinodroid ||

This is the tutorial which will teach you how to upload code in arduino with smartphone or android. So need to carry laptop everywhere.

BeginnerFull instructions provided15,841

Arduino Programming Via Mobile || Arduinodroid ||

Things used in this project

Hardware components

Arduino UNO

Software apps and online services

Arduino IDE

Story

Please subscribe my youtube channel for more videos.....

Arduino is board,

It is very simple and cheap for college and school projects or even in products prototype.

Many of products firstly build on it for initial testing.

So in all these application sometime you need to change the code instantly and you don't have much time to turn on laptop and change it... Or may be you forgot the laptop at home.

This tutorial will help you a lot, in this tutorial we will learn how to upload code via your smartphone.

Yes!!!! With smartphone, which you are carry every where with you.

As you sticked with you smartphone let's make arduino as well as sticked with your smartphone.

Advantage :-

This tutorial will help you to program arduino with your Smartphone so you no need to carry your laptop anywhere, things are more easy and portable for projects.

Step 1: Requirements

1 / 3

There is some Requirements according to your application

Smartphone
arduino uno
Arduino cable
OTG cable or adaptor

Download Arduinodroid app from play store or you can click on link below

https://play.google.com/store/apps/details?id=name...

Step 3: Connections

1 / 3

Connect OTG with arduino cable
Connect Arduino with Arduino cable
Connect OTG with you smartphone

Step 4: Upload the Code

1 / 4

Here I am uploading blink code but you can upload any code..

Transfer file from your pc to in your device and open it in arduino ide or copy paste it.

Click on sketch >> example >> basic >> blink
Compile the code via clicking on thunder button above.
Click on download button to upload
May be you will get permission to access USB device, click on OK.
Now boom!!!!

Your code is uploaded in arduino............

Code

Blink

/*
  Blink

  Turns an LED on for one second, then off for one second, repeatedly.

  Most Arduinos have an on-board LED you can control. On the UNO, MEGA and ZERO
  it is attached to digital pin 13, on MKR1000 on pin 6. LED_BUILTIN is set to
  the correct LED pin independent of which board is used.
  If you want to know what pin the on-board LED is connected to on your Arduino
  model, check the Technical Specs of your board at:
  https://www.arduino.cc/en/Main/Products

  modified 8 May 2014
  by Scott Fitzgerald
  modified 2 Sep 2016
  by Arturo Guadalupi
  modified 8 Sep 2016
  by Colby Newman

  This example code is in the public domain.

  http://www.arduino.cc/en/Tutorial/Blink
*/

// the setup function runs once when you press reset or power the board
void setup() {
  // initialize digital pin LED_BUILTIN as an output.
  pinMode(LED_BUILTIN, OUTPUT);
}

// the loop function runs over and over again forever
void loop() {
  digitalWrite(LED_BUILTIN, HIGH);   // turn the LED on (HIGH is the voltage level)
  delay(1000);                       // wait for a second
  digitalWrite(LED_BUILTIN, LOW);    // turn the LED off by making the voltage LOW
  delay(1000);                       // wait for a second
}
