Smart wearable is becoming popular nowadays. However, these devices are not elderly friendly. The idea is to make a simple smart wearable using ultra small SensorTile to detect simple events (like a simple tap on the wearable) and send an ALERT email to the caretaker/neighbour. Is can also send an alert message if the temperature in the home has increased to an alarming level, indicating a potential threat such as Fire.
Apart from this we can also monitor the activities of elderly based on the accelerometer values which can be seen on IBM Watson dashboard.
Devices and Technologies needed:
- Basic smartphone with Bluetooth
- ST blueMS mobile application
- IBM Watson IOT platform
Step 1: Download the ST BlueMS app from playstore/app store.
- Link for Android: https://play.google.com/store/apps/details?id=com.st.bluems&hl=en
Step 2: For testing connect the SensorTile to the Cradle Expansion board in the small socket provided. Make sure that you hear a “click” sound when you insert. Power the expansion board using micro USB. At this stage you will see a blue led on the SensorTile blinking.
Step 3: In the app press “START SCANNING” and connect to your SensorTile board(requires Bluetooth). If the connection is successful then the led will stop blinking. You can see all the sensor values on the app.
Step 4: Create an account on IBM Watson IOT platform
Link: https://internetofthings.ibmcloud.com/#/
After you create an account you must create an organization and space.
- After the initial setup in complete navigate to DEVICES on the left of dashboard.
- Click +Add device and create a new device.
- It is better to give the sensorTile MAC address as the device ID
- Finally note down the Device Credentials- Organization ID, Device Type, Device ID and Authentication Token.
- Detailed instruction of how to add device can be found here-
https://developer.ibm.com/recipes/tutorials/how-to-register-devices-in-ibm-iot-foundation/
Step 5: In the App navigate to Cloud logging. In the drop down menu select “IBM Watson IoT”. Enter the device credentials which were noted earlier. To start cloud logging press the red cloud icon at the bottom and select the suitable parameters for sending to cloud.
You can see the sensor information under the devices in you IBM dashboard.
Step 6: To Send Alert you need to create schema. Click on Add Schema select the he device type and then select suitable parameters, e.g.: temperature and events.
Next navigate to Rules create a new cloud rule. Add name the description and device type it applies to (your device type). Specify the conditions of when you want to trigger the action. Then create the action like sending email. After creating action save it and activate it.
Detailed instruction of how to create alter is here: https://developer.ibm.com/recipes/tutorials/using-rules-and-actions-with-ibm-watson-iot-platform-cloud-analytics/
In the above project, if the elderly person taps on the sensortile then the alert message is send. And if the temperature is very high it sends an alert message. And also we can monitor the person based on the accelerometer values.
Source code of demo application
C/C++note:This is just the main program.
/**
******************************************************************************
* @file main.c
* @author Central LAB
* @version V1.0.0
* @date 21-Nov-2016
* @brief Main program body
******************************************************************************
* @attention
*
* <h2><center>© COPYRIGHT(c) 2016 STMicroelectronics</center></h2>
*
* Licensed under MCD-ST Liberty SW License Agreement V2, (the "License");
* You may not use this file except in compliance with the License.
* You may obtain a copy of the License at:
*
* http://www.st.com/software_license_agreement_liberty_v2
*
* Redistribution and use in source and binary forms, with or without modification,
* are permitted provided that the following conditions are met:
* 1. Redistributions of source code must retain the above copyright notice,
* this list of conditions and the following disclaimer.
* 2. Redistributions in binary form must reproduce the above copyright notice,
* this list of conditions and the following disclaimer in the documentation
* and/or other materials provided with the distribution.
* 3. Neither the name of STMicroelectronics nor the names of its contributors
* may be used to endorse or promote products derived from this software
* without specific prior written permission.
*
* THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS"
* AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE
* IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
* DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR CONTRIBUTORS BE LIABLE
* FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL
* DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR
* SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
* CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
* OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE
* OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
*
******************************************************************************
*/
/* Includes ------------------------------------------------------------------*/
#include <stdio.h>
#include <math.h>
#include <limits.h>
#include "TargetFeatures.h"
#include "main.h"
#include "sensor_service.h"
#include "bluenrg_utils.h"
/* Private typedef -----------------------------------------------------------*/
/* Private define ------------------------------------------------------------*/
/* Imported Variables -------------------------------------------------------------*/
extern uint8_t set_connectable;
extern int connected;
extern TIM_HandleTypeDef TimHandle;
extern void CDC_TIM_PeriodElapsedCallback(TIM_HandleTypeDef *htim);
/* Exported Variables -------------------------------------------------------------*/
uint32_t ConnectionBleStatus =0;
uint8_t BufferToWrite[256];
int32_t BytesToWrite;
TIM_HandleTypeDef TimCCHandle;
uint8_t bdaddr[6];
/* Private variables ---------------------------------------------------------*/
static volatile uint32_t HCI_ProcessEvent=0;
static volatile uint32_t SendEnv =0;
/* Private function prototypes -----------------------------------------------*/
static void SystemClock_Config(void);
static void Init_BlueNRG_Custom_Services(void);
static void Init_BlueNRG_Stack(void);
static void InitTimers(void);
static void SendEnvironmentalData(void);
//uint8_t CDC_Fill_Buffer(uint8_t* Buf, uint32_t TotalLen){}
/**
* @brief Main program
* @param None
* @retval None
*/
int main(void)
{
uint32_t StartTime;
/* STM32L4xx HAL library initialization:
- Configure the Flash prefetch, instruction and Data caches
- Configure the Systick to generate an interrupt each 1 msec
- Set NVIC Group Priority to 4
- Global MSP (MCU Support Package) initialization
*/
HAL_Init();
/* Configure the System clock */
SystemClock_Config();
/* Configure and disable all the Chip Select pins */
Sensor_IO_SPI_CS_Init_All();
InitTargetPlatform(TARGET_SENSORTILE);
STLBLE_PRINTF("\t(HAL %ld.%ld.%ld_%ld)\r\n"
"\tCompiled %s %s"
#if defined (__IAR_SYSTEMS_ICC__)
" (IAR)\r\n"
#elif defined (__CC_ARM)
" (KEIL)\r\n"
#elif defined (__GNUC__)
" (openstm32)\r\n"
#endif
"\tSend Every %4dmS Temperature/Humidity/Pressure\r\n",
HAL_GetHalVersion() >>24,
(HAL_GetHalVersion() >>16)&0xFF,
(HAL_GetHalVersion() >> 8)&0xFF,
HAL_GetHalVersion() &0xFF,
__DATE__,__TIME__,
uhCCR1_Val/10);
#ifdef ENABLE_USB_DEBUG_CONNECTION
STLBLE_PRINTF("Debug Connection Enabled\r\n");
#endif /* ENABLE_USB_DEBUG_CONNECTION */
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
STLBLE_PRINTF("Debug Notify Trasmission Enabled\r\n");
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
/* Initialize the BlueNRG */
Init_BlueNRG_Stack();
/* Initialize the BlueNRG Custom services */
Init_BlueNRG_Custom_Services();
/* initialize timers */
InitTimers();
StartTime = HAL_GetTick();
/* Infinite loop */
while (1){
/* Led Blinking when there is not a client connected */
if(!connected) {
if(!TargetBoardFeatures.LedStatus) {
if(HAL_GetTick()-StartTime > 1000) {
LedOnTargetPlatform();
TargetBoardFeatures.LedStatus =1;
StartTime = HAL_GetTick();
}
} else {
if(HAL_GetTick()-StartTime > 50) {
LedOffTargetPlatform();
TargetBoardFeatures.LedStatus =0;
StartTime = HAL_GetTick();
}
}
}
/* handle BLE event */
if(HCI_ProcessEvent) {
HCI_ProcessEvent=0;
HCI_Process();
}
/* Update the BLE advertise data and make the Board connectable */
if(set_connectable){
setConnectable();
set_connectable = FALSE;
}
/* Environmental Data */
if(SendEnv) {
SendEnv=0;
SendEnvironmentalData();
}
/* Wait for Interrupt */
__WFI();
}
}
/**
* @brief Output Compare callback in non blocking mode
* @param htim : TIM OC handle
* @retval None
*/
void HAL_TIM_OC_DelayElapsedCallback(TIM_HandleTypeDef *htim)
{
uint32_t uhCapture=0;
/* TIM1_CH1 toggling with frequency = 2Hz */
if(htim->Channel == HAL_TIM_ACTIVE_CHANNEL_1)
{
uhCapture = HAL_TIM_ReadCapturedValue(htim, TIM_CHANNEL_1);
/* Set the Capture Compare Register value */
__HAL_TIM_SET_COMPARE(&TimCCHandle, TIM_CHANNEL_1, (uhCapture + uhCCR1_Val));
SendEnv=1;
}
}
/**
* @brief Period elapsed callback in non blocking mode for Environmental timer
* @param htim : TIM handle
* @retval None
*/
void HAL_TIM_PeriodElapsedCallback(TIM_HandleTypeDef *htim)
{
if(htim == (&TimHandle)) {
CDC_TIM_PeriodElapsedCallback(htim);
}
}
/**
* @brief Send Environmetal Data (Temperature/Pressure/Humidity) to BLE
* @param None
* @retval None
*/
static void SendEnvironmentalData(void)
{
uint8_t Status;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
BytesToWrite = sprintf((char *)BufferToWrite,"Sending: ");
Term_Update(BufferToWrite,BytesToWrite);
} else {
STLBLE_PRINTF("Sending: ");
}
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
/* Pressure,Humidity, and Temperatures*/
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_ENV)) {
float SensorValue;
int32_t PressToSend=0;
uint16_t HumToSend=0;
int16_t Temp2ToSend=0,Temp1ToSend=0;
int32_t decPart, intPart;
if(TargetBoardFeatures.HandlePressSensor) {
if(BSP_PRESSURE_IsInitialized(TargetBoardFeatures.HandlePressSensor,&Status)==COMPONENT_OK) {
BSP_PRESSURE_Get_Press(TargetBoardFeatures.HandlePressSensor,(float *)&SensorValue);
MCR_BLUEMS_F2I_2D(SensorValue, intPart, decPart);
PressToSend=intPart*100+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
BytesToWrite = sprintf((char *)BufferToWrite,"Press=%ld ",PressToSend);
Term_Update(BufferToWrite,BytesToWrite);
} else {
STLBLE_PRINTF("Press=%ld ",PressToSend);
}
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
}
}
if(TargetBoardFeatures.HandleHumSensor) {
if(BSP_HUMIDITY_IsInitialized(TargetBoardFeatures.HandleHumSensor,&Status)==COMPONENT_OK){
BSP_HUMIDITY_Get_Hum(TargetBoardFeatures.HandleHumSensor,(float *)&SensorValue);
MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
HumToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
BytesToWrite = sprintf((char *)BufferToWrite,"Hum=%d ",HumToSend);
Term_Update(BufferToWrite,BytesToWrite);
} else {
STLBLE_PRINTF("Hum=%d ",HumToSend);
}
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
}
}
if(TargetBoardFeatures.NumTempSensors==2) {
if(BSP_TEMPERATURE_IsInitialized(TargetBoardFeatures.HandleTempSensors[0],&Status)==COMPONENT_OK){
BSP_TEMPERATURE_Get_Temp(TargetBoardFeatures.HandleTempSensors[0],(float *)&SensorValue);
MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
Temp1ToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
BytesToWrite = sprintf((char *)BufferToWrite,"Temp=%d ",Temp1ToSend);
Term_Update(BufferToWrite,BytesToWrite);
} else {
STLBLE_PRINTF("Temp=%d ",Temp1ToSend);
}
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
}
if(BSP_TEMPERATURE_IsInitialized(TargetBoardFeatures.HandleTempSensors[1],&Status)==COMPONENT_OK){
BSP_TEMPERATURE_Get_Temp(TargetBoardFeatures.HandleTempSensors[1],(float *)&SensorValue);
MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
Temp2ToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
BytesToWrite = sprintf((char *)BufferToWrite,"Temp2=%d ",Temp2ToSend);
Term_Update(BufferToWrite,BytesToWrite);
} else {
STLBLE_PRINTF("Temp2=%d ",Temp2ToSend);
}
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
}
} else if(TargetBoardFeatures.NumTempSensors==1) {
if(BSP_TEMPERATURE_IsInitialized(TargetBoardFeatures.HandleTempSensors[0],&Status)==COMPONENT_OK){
BSP_TEMPERATURE_Get_Temp(TargetBoardFeatures.HandleTempSensors[0],(float *)&SensorValue);
MCR_BLUEMS_F2I_1D(SensorValue, intPart, decPart);
Temp1ToSend = intPart*10+decPart;
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
BytesToWrite = sprintf((char *)BufferToWrite,"Temp1=%d ",Temp1ToSend);
Term_Update(BufferToWrite,BytesToWrite);
} else {
STLBLE_PRINTF("Temp1=%d ",Temp1ToSend);
}
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
}
}
Environmental_Update(PressToSend,HumToSend,Temp2ToSend,Temp1ToSend);
}
#ifdef ENABLE_USB_DEBUG_NOTIFY_TRAMISSION
if(W2ST_CHECK_CONNECTION(W2ST_CONNECT_STD_TERM)) {
BytesToWrite = sprintf((char *)BufferToWrite,"\r\n");
Term_Update(BufferToWrite,BytesToWrite);
} else {
STLBLE_PRINTF("\r\n");
}
#endif /* ENABLE_USB_DEBUG_NOTIFY_TRAMISSION */
}
/**
* @brief Function for initializing timers for sending the information to BLE:
* - 1 for sending MotionFX/AR/CP and Acc/Gyro/Mag
* - 1 for sending the Environmental info
* @param None
* @retval None
*/
static void InitTimers(void)
{
uint32_t uwPrescalerValue;
/* Timer Output Compare Configuration Structure declaration */
TIM_OC_InitTypeDef sConfig;
/* Compute the prescaler value to have TIM3 counter clock equal to 10 KHz */
uwPrescalerValue = (uint32_t) ((SystemCoreClock / 10000) - 1);
/* Set TIM1 instance (Motion)*/
/* Set TIM1 instance */
TimCCHandle.Instance = TIM1;
TimCCHandle.Init.Period = 65535;
TimCCHandle.Init.Prescaler = uwPrescalerValue;
TimCCHandle.Init.ClockDivision = 0;
TimCCHandle.Init.CounterMode = TIM_COUNTERMODE_UP;
if(HAL_TIM_OC_Init(&TimCCHandle) != HAL_OK)
{
/* Initialization Error */
Error_Handler();
}
/* Configure the Output Compare channels */
/* Common configuration for all channels */
sConfig.OCMode = TIM_OCMODE_TOGGLE;
sConfig.OCPolarity = TIM_OCPOLARITY_LOW;
/* Output Compare Toggle Mode configuration: Channel1 */
sConfig.Pulse = uhCCR1_Val;
if(HAL_TIM_OC_ConfigChannel(&TimCCHandle, &sConfig, TIM_CHANNEL_1) != HAL_OK)
{
/* Configuration Error */
Error_Handler();
}
}
/** @brief Initialize the BlueNRG Stack
* @param None
* @retval None
*/
static void Init_BlueNRG_Stack(void)
{
const char BoardName[8] = {NAME_STLBLE,0};
uint16_t service_handle, dev_name_char_handle, appearance_char_handle;
int ret;
uint8_t hwVersion;
uint16_t fwVersion;
#ifdef STATIC_BLE_MAC
{
uint8_t tmp_bdaddr[6]= {STATIC_BLE_MAC};
int32_t i;
for(i=0;i<6;i++)
bdaddr[i] = tmp_bdaddr[i];
}
#endif /* STATIC_BLE_MAC */
/* Initialize the BlueNRG SPI driver */
BNRG_SPI_Init();
/* Initialize the BlueNRG HCI */
HCI_Init();
/* Reset BlueNRG hardware */
BlueNRG_RST();
/* get the BlueNRG HW and FW versions */
getBlueNRGVersion(&hwVersion, &fwVersion);
if (hwVersion > 0x30) {
/* X-NUCLEO-IDB05A1 expansion board is used */
TargetBoardFeatures.bnrg_expansion_board = IDB05A1;
} else {
/* X-NUCLEO-IDB0041 expansion board is used */
TargetBoardFeatures.bnrg_expansion_board = IDB04A1;
}
/*
* Reset BlueNRG again otherwise it will fail.
*/
BlueNRG_RST();
#ifndef STATIC_BLE_MAC
/* Create a Unique BLE MAC */
{
bdaddr[0] = (STM32_UUID[1]>>24)&0xFF;
bdaddr[1] = (STM32_UUID[0] )&0xFF;
bdaddr[2] = (STM32_UUID[2] >>8)&0xFF;
bdaddr[3] = (STM32_UUID[0]>>16)&0xFF;
bdaddr[4] = (((STLBLE_VERSION_MAJOR-48)*10) + (STLBLE_VERSION_MINOR-48)+100)&0xFF;
bdaddr[5] = 0xC0; /* for a Legal BLE Random MAC */
}
#else /* STATIC_BLE_MAC */
ret = aci_hal_write_config_data(CONFIG_DATA_PUBADDR_OFFSET,
CONFIG_DATA_PUBADDR_LEN,
bdaddr);
if(ret){
STLBLE_PRINTF("\r\nSetting Pubblic BD_ADDR failed\r\n");
goto fail;
}
#endif /* STATIC_BLE_MAC */
ret = aci_gatt_init();
if(ret){
STLBLE_PRINTF("\r\nGATT_Init failed\r\n");
goto fail;
}
if (TargetBoardFeatures.bnrg_expansion_board == IDB05A1) {
ret = aci_gap_init_IDB05A1(GAP_PERIPHERAL_ROLE_IDB05A1, 0, 0x07, &service_handle, &dev_name_char_handle, &appearance_char_handle);
} else {
ret = aci_gap_init_IDB04A1(GAP_PERIPHERAL_ROLE_IDB04A1, &service_handle, &dev_name_char_handle, &appearance_char_handle);
}
if(ret != BLE_STATUS_SUCCESS){
STLBLE_PRINTF("\r\nGAP_Init failed\r\n");
goto fail;
}
#ifndef STATIC_BLE_MAC
ret = hci_le_set_random_address(bdaddr);
if(ret){
STLBLE_PRINTF("\r\nSetting the Static Random BD_ADDR failed\r\n");
goto fail;
}
#endif /* STATIC_BLE_MAC */
ret = aci_gatt_update_char_value(service_handle, dev_name_char_handle, 0,
7/*strlen(BoardName)*/, (uint8_t *)BoardName);
if(ret){
STLBLE_PRINTF("\r\naci_gatt_update_char_value failed\r\n");
while(1);
}
ret = aci_gap_set_auth_requirement(MITM_PROTECTION_REQUIRED,
OOB_AUTH_DATA_ABSENT,
NULL, 7, 16,
USE_FIXED_PIN_FOR_PAIRING, 123456,
BONDING);
if (ret != BLE_STATUS_SUCCESS) {
STLBLE_PRINTF("\r\nGAP setting Authentication failed\r\n");
goto fail;
}
STLBLE_PRINTF("SERVER: BLE Stack Initialized \r\n"
"\t\tBoard type=%s HWver=%d, FWver=%d.%d.%c\r\n"
"\t\tBoardName= %s\r\n"
"\t\tBoardMAC = %x:%x:%x:%x:%x:%x\r\n\n",
"SensorTile",
hwVersion,
fwVersion>>8,
(fwVersion>>4)&0xF,
(hwVersion > 0x30) ? ('a'+(fwVersion&0xF)-1) : 'a',
BoardName,
bdaddr[5],bdaddr[4],bdaddr[3],bdaddr[2],bdaddr[1],bdaddr[0]);
/* Set output power level */
aci_hal_set_tx_power_level(1,4);
return;
fail:
return;
}
/** @brief Initialize all the Custom BlueNRG services
* @param None
* @retval None
*/
static void Init_BlueNRG_Custom_Services(void)
{
int ret;
ret = Add_HWServW2ST_Service();
if(ret == BLE_STATUS_SUCCESS) {
STLBLE_PRINTF("HW Service W2ST added successfully\r\n");
} else {
STLBLE_PRINTF("\r\nError while adding HW Service W2ST\r\n");
}
ret = Add_ConfigW2ST_Service();
if(ret == BLE_STATUS_SUCCESS) {
STLBLE_PRINTF("Config Service W2ST added successfully\r\n");
} else {
STLBLE_PRINTF("\r\nError while adding Config Service W2ST\r\n");
}
}
/**
* @brief System Clock Configuration
* @param None
* @retval None
*/
void SystemClock_Config(void)
{
RCC_ClkInitTypeDef RCC_ClkInitStruct = {0};
RCC_OscInitTypeDef RCC_OscInitStruct = {0};
RCC_PeriphCLKInitTypeDef PeriphClkInitStruct = {0};
__HAL_RCC_PWR_CLK_ENABLE();
HAL_PWR_EnableBkUpAccess();
/* Enable the LSE Oscilator */
RCC_OscInitStruct.OscillatorType = RCC_OSCILLATORTYPE_LSE;
RCC_OscInitStruct.LSEState = RCC_LSE_ON;
if (HAL_RCC_OscConfig(&RCC_OscInitStruct) != HAL_OK){
while(1);
}
/* Enable the CSS interrupt in case LSE signal is corrupted or not present */
HAL_RCCEx_DisableLSECSS();
/* Enable MSI Oscillator and activate PLL with MSI as source */
RCC_OscInitStruct.OscillatorType = RCC_OSCILLATORTYPE_MSI;
RCC_OscInitStruct.MSIState = RCC_MSI_ON;
RCC_OscInitStruct.HSICalibrationValue = RCC_MSICALIBRATION_DEFAULT;
RCC_OscInitStruct.MSIClockRange = RCC_MSIRANGE_11;
RCC_OscInitStruct.PLL.PLLState = RCC_PLL_ON;
RCC_OscInitStruct.PLL.PLLSource = RCC_PLLSOURCE_MSI;
RCC_OscInitStruct.PLL.PLLM = 6;
RCC_OscInitStruct.PLL.PLLN = 40;
RCC_OscInitStruct.PLL.PLLP = 7;
RCC_OscInitStruct.PLL.PLLQ = 4;
RCC_OscInitStruct.PLL.PLLR = 4;
if (HAL_RCC_OscConfig(&RCC_OscInitStruct) != HAL_OK){
while(1);
}
/* Enable MSI Auto-calibration through LSE */
HAL_RCCEx_EnableMSIPLLMode();
/* Select MSI output as USB clock source */
PeriphClkInitStruct.PeriphClockSelection = RCC_PERIPHCLK_USB;
PeriphClkInitStruct.UsbClockSelection = RCC_USBCLKSOURCE_MSI;
HAL_RCCEx_PeriphCLKConfig(&PeriphClkInitStruct);
/* Select PLL as system clock source and configure the HCLK, PCLK1 and PCLK2
clocks dividers */
RCC_ClkInitStruct.ClockType = (RCC_CLOCKTYPE_SYSCLK | RCC_CLOCKTYPE_HCLK | RCC_CLOCKTYPE_PCLK1 | RCC_CLOCKTYPE_PCLK2);
RCC_ClkInitStruct.SYSCLKSource = RCC_SYSCLKSOURCE_PLLCLK;
RCC_ClkInitStruct.AHBCLKDivider = RCC_SYSCLK_DIV1;
RCC_ClkInitStruct.APB1CLKDivider = RCC_HCLK_DIV1;
RCC_ClkInitStruct.APB2CLKDivider = RCC_HCLK_DIV1;
if (HAL_RCC_ClockConfig(&RCC_ClkInitStruct, FLASH_LATENCY_4) != HAL_OK){
while(1);
}
}
/**
* @brief This function provides accurate delay (in milliseconds) based
* on variable incremented.
* @note This is a user implementation using WFI state
* @param Delay: specifies the delay time length, in milliseconds.
* @retval None
*/
void HAL_Delay(__IO uint32_t Delay)
{
uint32_t tickstart = 0;
tickstart = HAL_GetTick();
while((HAL_GetTick() - tickstart) < Delay){
__WFI();
}
}
/**
* @brief This function is executed in case of error occurrence.
* @param None
* @retval None
*/
void Error_Handler(void)
{
/* User may add here some code to deal with this error */
while(1){
}
}
/**
* @brief EXTI line detection callback.
* @param uint16_t GPIO_Pin Specifies the pins connected EXTI line
* @retval None
*/
void HAL_GPIO_EXTI_Callback(uint16_t GPIO_Pin)
{
switch(GPIO_Pin){
case BNRG_SPI_EXTI_PIN:
HCI_Isr();
HCI_ProcessEvent=1;
break;
}
}
#ifdef USE_FULL_ASSERT
/**
* @brief Reports the name of the source file and the source line number
* where the assert_param error has occurred.
* @param file: pointer to the source file name
* @param line: assert_param error line source number
* @retval None
*/
void assert_failed(uint8_t* file, uint32_t line)
{
/* User can add his own implementation to report the file name and line number,
ex: STLBLE_PRINTF("Wrong parameters value: file %s on line %d\r\n", file, line) */
/* Infinite loop */
while (1){
}
}
#endif
/******************* (C) COPYRIGHT 2016 STMicroelectronics *****END OF FILE****/
Comments
