ESP32 Dev Board with GPS and OLED Display

Front of PCB

This PCB is a GPS position tracking device, which shows all the relevant data on an OLED display. The Pcb uses:

• ESP32 as the microcontroller
• Reyax GPS module
• OLED SSD13086 0.96' display
• Other basic components.

So, in short, this project has an ESP32 which can give WiFi/Bluetooth functionality, OLED display and GPS module. Possibilities with the code are endless. I have also added a prototyping area where you can add sensors or other components to the ESP32 which is also accessible.

Back of PCB

Ordering the PCB

I would also recommend to get your PCB manufactured. You can order your PCBs from PCBWAY as they offer 10 PCBs for just $5. Check out their online Gerber viewer function. With reward points you can get free stuff from their gift shop.

Schematic
