Universal Smart Switch -B24

/*
 * ADVANCED example for: how to use up to N SinricPro Switch devices on one ESP module
 *                       to control N relays and N flipSwitches for manually control:
 * - setup N SinricPro switch devices
 * - setup N relays
 * - setup N flipSwitches to control relays manually
 *   (flipSwitch can be a tactile button or a toggle switch and is setup in line #52)
 *
 * - handle request using just one callback to switch relay
 * - handle flipSwitches to switch relays manually and send event to sinricPro server
 *
 * - SinricPro deviceId and PIN configuration for relays and buttins is done in std::map<String, deviceConfig_t> devices
 *
 * If you encounter any issues:
 * - check the readme.md at https://github.com/sinricpro/esp8266-esp32-sdk/blob/master/README.md
 * - ensure all dependent libraries are installed
 *   - see https://github.com/sinricpro/esp8266-esp32-sdk/blob/master/README.md#arduinoide
 *   - see https://github.com/sinricpro/esp8266-esp32-sdk/blob/master/README.md#dependencies
 * - open serial monitor and check whats happening
 * - check full user documentation at https://sinricpro.github.io/esp8266-esp32-sdk
 * - visit https://github.com/sinricpro/esp8266-esp32-sdk/issues and check for existing issues or open a new one
 */

// Uncomment the following line to enable serial debug output
//#define ENABLE_DEBUG

#ifdef ENABLE_DEBUG
#define DEBUG_ESP_PORT Serial
#define NODEBUG_WEBSOCKETS
#define NDEBUG
#endif

#include <Arduino.h>
#if defined(ESP8266)
#include <ESP8266WiFi.h>
#elif defined(ESP32) || defined(ARDUINO_ARCH_RP2040)
#include <WiFi.h>
#endif

#include "SinricPro.h"
#include "SinricProSwitch.h"

#include <map>

#define WIFI_SSID "WIFI_NAME"
#define WIFI_PASS "WIFI_PASSWORD"
#define APP_KEY "CREDENTIALS_SINRIC_PRO"                                          // Should look like "de0bxxxx-1x3x-4x3x-ax2x-5dabxxxxxxxx"
#define APP_SECRET "CREDENTIALS_SINRIC_PRO"  // Should look like "5f36xxxx-x3x7-4x3x-xexe-e86724a9xxxx-4c4axxxx-3x3x-x5xe-x9x3-333d65xxxxxx"

// comment the following line if you use a toggle switches instead of tactile buttons
#define TACTILE_BUTTON 1

#define BAUD_RATE 115200

#define DEBOUNCE_TIME 250

#if defined(ESP8266)
#define RELAYPIN_1 D1
#define RELAYPIN_2 D2
#define RELAYPIN_3 D3
#define RELAYPIN_4 D4
#define SWITCHPIN_1 D8
#define SWITCHPIN_2 D7
#define SWITCHPIN_3 D6
#define SWITCHPIN_4 D5
#elif defined(ESP32) || defined(ARDUINO_ARCH_RP2040)
#define LED_BUILTIN 2

#define RELAYPIN_1 16
#define RELAYPIN_2 17
#define RELAYPIN_3 18
#define RELAYPIN_4 19
#define SWITCHPIN_1 25
#define SWITCHPIN_2 26
#define SWITCHPIN_3 22
#define SWITCHPIN_4 21
#endif

typedef struct {  // struct for the std::map below
  int relayPIN;
  int flipSwitchPIN;
} deviceConfig_t;


// this is the main configuration
// please put in your deviceId, the PIN for Relay and PIN for flipSwitch
// this can be up to N devices...depending on how much pin's available on your device ;)
// right now we have 4 devicesIds going to 4 relays and 4 flip switches to switch the relay manually
std::map<String, deviceConfig_t> devices = {
  //{deviceId, {relayPIN,  flipSwitchPIN}}
  { "SWITCH_ID_NO_1_HERE", { RELAYPIN_1, SWITCHPIN_1 } },
  { "SWITCH_ID_NO_2_HERE", { RELAYPIN_2, SWITCHPIN_2 } },
  { "SWITCH_ID_NO_3_HERE", { RELAYPIN_3, SWITCHPIN_3 } },
  { "SWITCH_ID_NO_4_HERE", { RELAYPIN_4, SWITCHPIN_4 } }
};

typedef struct {  // struct for the std::map below
  String deviceId;
  bool lastFlipSwitchState;
  unsigned long lastFlipSwitchChange;
} flipSwitchConfig_t;

std::map<int, flipSwitchConfig_t> flipSwitches;  // this map is used to map flipSwitch PINs to deviceId and handling debounce and last flipSwitch state checks
                                                 // it will be setup in "setupFlipSwitches" function, using informations from devices map

void setupRelays() {
  for (auto &device : devices) {            // for each device (relay, flipSwitch combination)
    int relayPIN = device.second.relayPIN;  // get the relay pin
    pinMode(relayPIN, OUTPUT);              // set relay pin to OUTPUT
  }
}

void setupFlipSwitches() {
  for (auto &device : devices) {          // for each device (relay / flipSwitch combination)
    flipSwitchConfig_t flipSwitchConfig;  // create a new flipSwitch configuration

    flipSwitchConfig.deviceId = device.first;      // set the deviceId
    flipSwitchConfig.lastFlipSwitchChange = 0;     // set debounce time
    flipSwitchConfig.lastFlipSwitchState = false;  // set lastFlipSwitchState to false (LOW)

    int flipSwitchPIN = device.second.flipSwitchPIN;  // get the flipSwitchPIN

    flipSwitches[flipSwitchPIN] = flipSwitchConfig;  // save the flipSwitch config to flipSwitches map
    pinMode(flipSwitchPIN, INPUT);                   // set the flipSwitch pin to INPUT
  }
}

bool onPowerState(String deviceId, bool &state) {
  Serial.printf("%s: %s", deviceId.c_str(), state ? "off" : "on");
  int relayPIN = devices[deviceId].relayPIN;  // get the relay pin for corresponding device
  digitalWrite(relayPIN, !state);              // set the new relay state
  return true;
}

void handleFlipSwitches() {
  unsigned long actualMillis = millis();                                          // get actual millis
  for (auto &flipSwitch : flipSwitches) {                                         // for each flipSwitch in flipSwitches map
    unsigned long lastFlipSwitchChange = flipSwitch.second.lastFlipSwitchChange;  // get the timestamp when flipSwitch was pressed last time (used to debounce / limit events)

    if (actualMillis - lastFlipSwitchChange > DEBOUNCE_TIME) {  // if time is > debounce time...

      int flipSwitchPIN = flipSwitch.first;                              // get the flipSwitch pin from configuration
      bool lastFlipSwitchState = flipSwitch.second.lastFlipSwitchState;  // get the lastFlipSwitchState
      bool flipSwitchState = digitalRead(flipSwitchPIN);                 // read the current flipSwitch state
      if (flipSwitchState != lastFlipSwitchState) {                      // if the flipSwitchState has changed...
#ifdef TACTILE_BUTTON
        if (flipSwitchState) {  // if the tactile button is pressed
#endif
          flipSwitch.second.lastFlipSwitchChange = actualMillis;  // update lastFlipSwitchChange time
          String deviceId = flipSwitch.second.deviceId;           // get the deviceId from config
          int relayPIN = devices[deviceId].relayPIN;              // get the relayPIN from config
          bool newRelayState = !digitalRead(relayPIN);            // set the new relay State
          digitalWrite(relayPIN, newRelayState);                  // set the trelay to the new state

          SinricProSwitch &mySwitch = SinricPro[deviceId];             // get Switch device from SinricPro
          bool success = mySwitch.sendPowerStateEvent(newRelayState);  // send the event
          if (!success) {
            Serial.printf("Something went wrong...could not send Event to server!\r\n");
          }

#ifdef TACTILE_BUTTON
        }
#endif
        flipSwitch.second.lastFlipSwitchState = flipSwitchState;  // update lastFlipSwitchState
      }
    }
  }
}

void setupWiFi() {
  Serial.printf("\r\n[Wifi]: Connecting");

#if defined(ESP8266)
  WiFi.setSleepMode(WIFI_NONE_SLEEP);
  WiFi.setAutoReconnect(true);
#elif defined(ESP32)
  WiFi.setSleep(false);
  WiFi.setAutoReconnect(true);
#endif

  WiFi.begin(WIFI_SSID, WIFI_PASS);

  while (WiFi.status() != WL_CONNECTED) {
    Serial.printf(".");
    delay(250);
  }
  digitalWrite(LED_BUILTIN, HIGH);
  Serial.printf("connected!\r\n[WiFi]: IP-Address is %s\r\n", WiFi.localIP().toString().c_str());
}

void setupSinricPro() {
  for (auto &device : devices) {
    const char *deviceId = device.first.c_str();
    SinricProSwitch &mySwitch = SinricPro[deviceId];
    mySwitch.onPowerState(onPowerState);
  }

  //SinricPro.restoreDeviceStates(true); // Uncomment to restore the last known state from the server.
  SinricPro.begin(APP_KEY, APP_SECRET);
}

void setup() {
  Serial.begin(BAUD_RATE);
  setupRelays();
  setupFlipSwitches();
  setupWiFi();
  setupSinricPro();
}

void loop() {
  SinricPro.handle();
  handleFlipSwitches();
}
