Smart Plug

Smart plug with remote monitoring (current, voltage, energy), control (automatic, manual), and notification

Now control appliances remotely. No matter where you are, integrate your device with the web server

Set the Schedules/Timer for turning ON and OFF your devices automatically, saving power and time

This 16A smart plug helps you monitor your devices energy consumption for the entire day and is suitable for connecting electrical appliances like Geysers, Motors for Water Tanks, Heaters, Microwave Ovens, ACs, etc

Steps to Configure Smart Plug

STEP 1:

Turn On Smart Plug. Blue LED Toggles 5 Seconds.

STEP 2:

Connect WiFI access point named DEVxxxx. Open Chrome and type 192.168.4.1. You'll get the WiFi Manager page. Click Configure WiFI. You'll get available WiFi which is nearby.

STEP 3:

Configure your home network SSID and PASSWORD as shown above. Once your configuration is done it'll automatically change from access point to station and tries to connect to your home access point network.

Once you have given the SSID and PASSWORD your web page will notify as given below

STEP 4:

Once ESP is connected to your network it'll try to connect to broker.mqttdashboard.com:1883 and start sending device Data(voltage, current, Power, and Energy).

STEP 5:

Open MQTTBOX to check your device is posting. Configure your MQTT client setting as shown below

username               : 1
password               : 1
Topic to Publish       : DEVxxxx/Data
Topic to Subscribe     : DEVxxxx/Relay

In my case device id is DEVxxxx - DEV0001. You are done with this all things good to go for remote controlling your home appliances. Please make ensure the device status connected as shown below.

Finally your device is ready and the information is sent to the webserver. You can see the data in MQTTBOX as well.
