#define TEMP_PIN A0
#define RED_PIN 9
#define GREEN_PIN 10
#define BLUE_PIN 11
int adc = 0;
int blue = 0, red = 0;
double ReadThermistor(int adc) {
double resistance = ((1024.0/adc) - 1); //calculate from voltage divider, for 10k resistor
double Temp = log(resistance);
// calculate the temperature, in K, using 4 thermistor model/material specific parameters A, B, C, D
// here we use the values for the Sparkfun/Hactronics version of the Vishay 10k NTC thermistor
Temp = 1 / (0.003354016 + 0.0002569850 * Temp + 0.000002620131 * Temp * Temp + 0.00000006383091 * Temp * Temp * Temp);
Temp = Temp - 273.15; // Convert Kelvin to Celsius
return Temp;
}
void setLED(int blue, int red){
analogWrite(BLUE_PIN, blue);
analogWrite(RED_PIN, red);
}
void setup(){
Serial.begin(9600);
pinMode(BLUE_PIN, OUTPUT);
pinMode(RED_PIN, OUTPUT);
pinMode(GREEN_PIN, OUTPUT);
pinMode(TEMP_PIN, INPUT);
}
void loop(){
adc = analogRead(TEMP_PIN);
int temp = ReadThermistor(adc);
Serial.println(temp);
red = map(temp, 20, 40, 0, 255);
blue = 255 - red;
setLED(blue, red);
}
