The ELEC 424 final project involves programming an autonomous RC/toy car. This project is inspired by raja_961's Instructable titled “Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV”. The primary task is to enable a small toy car, equipped with electronics, to autonomously navigate a track. The car must be capable of lane keeping, stopping at a red stop box on the ground. The project focuses on adapting existing Python scripts for a Raspberry Pi 4 or BeagleBone AI-64 and implementing modifications to achieve these functionalities. The project's success is evaluated based on the car's performance on a specified track. Acknowledgement: In this project, we were inspired by several references as specified in References section.
Our VehicleOur team took a page from Team ReaLlY BaD Idea's playbook for our car's proportional and derivative gains. We stuck with their proportional gain of 0.085 and kept the derivative gain to just 10% of that, avoiding the problems they ran into with higher values. Our PWM range was also in line with theirs, from 6 to 9, to keep the car's responses manageable. We limited the car's turning error to about 45 degrees, just like they did, striking that sweet spot between being responsive and not overdoing it.
We went for the lowest resolution of 160x120 pixels, trading off a bit of precision for speedier frame processing. But in hindsight, maybe a higher resolution could have given us a sharper edge. For the stop box, we cooked up a Python script to spot reds in the image, setting it off if more than 0.3% of the frame matched. This was to make sure it always stopped at the red, despite the inconsistent lighting we had to deal with. After each stop, we put in a brief 4-second pause to make sure the car didn't mistake the same sign for a new one and to smoothly get it moving again. It was all about mixing tried-and-tested methods with our own tweaks to suit what we needed for our project.
Stop BoxIn our script, we handle stop box detection by filtering specific colors using OpenCV, a method inspired by Team ReaLly BaD Idea's practical experiments with color thresholds. We've fine-tuned this to account for the color distortions that our camera tends to pick up. This approach helps us accurately spot the stop boxes and trigger the car's brakes effectively.
PD PlotSteer and Speed Voltage Plot
[1] User raja_961, “Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV”. Instructables. URL: https://www.instructables.com/Autonomous-Lane-Keeping-Car-U sing-Raspberry-Pi-and/
[2] Team ReaLly BaD Idea, "Autonomous path following car". URL: https://www.hackster.io/really-bad-idea/autonomous-path-following-car-6c4992
[3] Team Access Code, "Access Code Cybertruck'. URL: https://www.hackster.io/497395/access-code-cybertruck-9f8b8c
"""
This file has code taken from and influenced by the following sources:
User raja_961, “Autonomous Lane-Keeping Car Using Raspberry
Pi and OpenCV”. Instructables. URL:
https://www.instructables.com/Autonomous-Lane-Keeping-Car-U
sing-Raspberry-Pi-and
Team ReaLly BaD Idea, "Autonomous path following car". URL:
https://www.hackster.io/really-bad-idea/autonomous-path-following-car-6c4992
Team Access Code, "Access Code Cybertruck'. URL:
https://www.hackster.io/497395/access-code-cybertruck-9f8b8c
Adjustments had to be made to get our respective car to function correctly.
"""
import cv2
import numpy as np
import math
import sys
import time
import RPi.GPIO as GPIO
import board
import busio
import adafruit_mcp4728
import matplotlib.pyplot as plt
i2c = busio.I2C(board.SCL, board.SDA)
mcp4728 = adafruit_mcp4728.MCP4728(i2c, 0x64)
go_faster_tick_delay = 80
go_faster_tick = 0
current_speed = int(65535 / 2)
def getRedFloorColorBoundary():
return getBoundaries("redboundaries.txt")
def isRedFloorVisible(frame):
"""
Detects whether or not the floor is red
:param frame: Image
:return: [(True is the camera sees a red on the floor, false otherwise), video output]
"""
boundaries = getRedFloorColorBoundary()
return isMostlyColor(frame, boundaries)
def isMostlyColor(image, boundaries):
"""
Detects whether or not the majority of a color on the screen is a particular color
:param image:
:param boundaries: [[color boundaries], [success boundaries]]
:return: boolean if image satisfies provided boundaries, and an image used for debugging
"""
# Convert to HSV color space
hsv_img = cv2.cvtColor(image, cv2.COLOR_BGR2HSV)
# parse out the color boundaries and the success boundaries
color_boundaries = boundaries[0]
percentage = boundaries[1]
lower = np.array(color_boundaries[0])
upper = np.array(color_boundaries[1])
mask = cv2.inRange(hsv_img, lower, upper)
output = cv2.bitwise_and(hsv_img, hsv_img, mask=mask)
# Calculate what percentage of image falls between color boundaries
percentage_detected = np.count_nonzero(mask) * 100 / np.size(mask)
# If the percentage percentage_detected is betweeen the success boundaries, we return true, otherwise false for result
result = percentage[0] < percentage_detected <= percentage[1]
if result:
print(percentage_detected)
return result, output
def getBoundaries(filename):
"""
Reads the boundaries from the file filename
Format:
[0] lower: [H, S, V, lower percentage for classification of success]
[1] upper: [H, S, V, upper percentage for classification of success]
:param filename: file containing boundary information as above
:return: [[lower color and success boundaries], [upper color and success boundaries]]
"""
default_lower_percent = 50
default_upper_percent = 100
with open(filename, "r") as f:
boundaries = f.readlines()
lower_data = [val for val in boundaries[0].split(",")]
upper_data = [val for val in boundaries[1].split(",")]
if len(lower_data) >= 4:
lower_percent = float(lower_data[3])
else:
lower_percent = default_lower_percent
if len(upper_data) >= 4:
upper_percent = float(upper_data[3])
else:
upper_percent = default_upper_percent
lower = [int(x) for x in lower_data[:3]]
upper = [int(x) for x in upper_data[:3]]
boundaries = [lower, upper]
percentages = [lower_percent, upper_percent]
return boundaries, percentages
## speed control:
def stop():
"""
Activates the protocol for complete cessation of all active movement.
Returns:
None: Signifies completion of stop operation.
"""
mcp4728.channel_a.value = 0 # Cease forward progression
mcp4728.channel_b.value = 0 # Halt directional change
return
def move():
"""
Engages the system to begin motion, setting initial parameters for movement.
Returns:
None: Marks the commencement of motion.
"""
initial_forward_velocity = int(65535 / 1.6) # Initialize forward velocity
initial_lateral_velocity = int(65535 / 2.7) # Initialize lateral velocity
mcp4728.channel_a.value = initial_forward_velocity
mcp4728.channel_b.value = initial_lateral_velocity
return
def accelerate():
"""
Adjusts the speed parameters to increase velocity, if not at peak capacity.
Returns:
None: Provides update on velocity adjustments.
"""
current_speed = mcp4728.channel_a.value
if current_speed < 65535:
current_speed += 1000 # Enhance speed
mcp4728.channel_a.value = min(65535, current_speed)
print(f"Velocity increment: Now at {current_speed}")
else:
print("Peak velocity achieved.")
def decelerate():
"""
Modulates the speed parameters to reduce velocity, unless fully stopped.
Returns:
None: Delivers update on velocity reduction.
"""
current_speed = mcp4728.channel_a.value
if current_speed > 0:
current_speed -= 1000 # Reduce speed
mcp4728.channel_a.value = max(0, current_speed)
print(f"Velocity decrement: Now at {current_speed}")
else:
print("Complete standstill reached.")
def detect_edges(frame):
# filter for blue lane lines
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
# cv2.imshow("HSV",hsv)
lower_blue = np.array([90, 120, 0], dtype="uint8")
upper_blue = np.array([150, 255, 255], dtype="uint8")
mask = cv2.inRange(hsv, lower_blue, upper_blue)
# cv2.imshow("mask",mask)
# detect edges
edges = cv2.Canny(mask, 50, 100)
# cv2.imshow("edges",edges)
return edges
def region_of_interest(edges):
height, width = edges.shape
mask = np.zeros_like(edges)
# only focus lower half of the screen
polygon = np.array([[
(0, height),
(0, height / 2),
(width, height / 2),
(width, height),
]], np.int32)
cv2.fillPoly(mask, polygon, 255)
cropped_edges = cv2.bitwise_and(edges, mask)
cv2.imshow("roi", cropped_edges)
return cropped_edges
def detect_line_segments(cropped_edges):
rho = 1
theta = np.pi / 180
min_threshold = 10
line_segments = cv2.HoughLinesP(cropped_edges, rho, theta, min_threshold,
np.array([]), minLineLength=5, maxLineGap=150)
return line_segments
def average_slope_intercept(frame, line_segments):
lane_lines = []
if line_segments is None:
print("no line segments detected")
return lane_lines
height, width, _ = frame.shape
left_fit = []
right_fit = []
boundary = 1 / 3
left_region_boundary = width * (1 - boundary)
right_region_boundary = width * boundary
for line_segment in line_segments:
for x1, y1, x2, y2 in line_segment:
if x1 == x2:
print("skipping vertical lines (slope = infinity")
continue
fit = np.polyfit((x1, x2), (y1, y2), 1)
slope = (y2 - y1) / (x2 - x1)
intercept = y1 - (slope * x1)
if slope < 0:
if x1 < left_region_boundary and x2 < left_region_boundary:
left_fit.append((slope, intercept))
else:
if x1 > right_region_boundary and x2 > right_region_boundary:
right_fit.append((slope, intercept))
left_fit_average = np.average(left_fit, axis=0)
if len(left_fit) > 0:
lane_lines.append(make_points(frame, left_fit_average))
right_fit_average = np.average(right_fit, axis=0)
if len(right_fit) > 0:
lane_lines.append(make_points(frame, right_fit_average))
return lane_lines
def make_points(frame, line):
height, width, _ = frame.shape
slope, intercept = line
y1 = height # bottom of the frame
y2 = int(y1 / 2) # make points from middle of the frame down
if slope == 0:
slope = 0.1
x1 = int((y1 - intercept) / slope)
x2 = int((y2 - intercept) / slope)
return [[x1, y1, x2, y2]]
def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6):
line_image = np.zeros_like(frame)
if lines is not None:
for line in lines:
for x1, y1, x2, y2 in line:
cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)
line_image = cv2.addWeighted(frame, 0.8, line_image, 1, 1)
return line_image
def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
heading_image = np.zeros_like(frame)
height, width, _ = frame.shape
steering_angle_radian = steering_angle / 180.0 * math.pi
x1 = int(width / 2)
y1 = height
x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
y2 = int(height / 2)
cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
heading_image = cv2.addWeighted(frame, 0.8, heading_image, 1, 1)
return heading_image
def get_steering_angle(frame, lane_lines):
height, width, _ = frame.shape
if len(lane_lines) == 2:
_, _, left_x2, _ = lane_lines[0][0]
_, _, right_x2, _ = lane_lines[1][0]
mid = int(width / 2)
x_offset = (left_x2 + right_x2) / 2 - mid
y_offset = int(height / 2)
elif len(lane_lines) == 1:
x1, _, x2, _ = lane_lines[0][0]
x_offset = x2 - x1
y_offset = int(height / 2)
elif len(lane_lines) == 0:
x_offset = 0
y_offset = int(height / 2)
angle_to_mid_radian = math.atan(x_offset / y_offset)
angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / math.pi)
steering_angle = angle_to_mid_deg + 90
return steering_angle
def plot_pd(p_vals, d_vals, error, show_img=False):
# Plot the PD
fig, ax1 = plt.subplots()
t_ax = np.arange(len(p_vals))
ax1.plot(t_ax, p_vals, '-', label="P values")
ax1.plot(t_ax, d_vals, '-', label="D values")
ax2 = ax1.twinx()
ax2.plot(t_ax, error, '--r', label="Error")
ax1.set_xlabel("Frames")
ax1.set_ylabel("PD Value")
ax2.set_ylim(-90, 90)
ax2.set_ylabel("Error Value")
plt.title("PD Values over time")
fig.legend()
fig.tight_layout()
plt.savefig("pd_plot.png")
if show_img:
plt.show()
plt.clf()
def plot_pwm(speed_pwms, turn_pwms, error, show_img=False):
# Plot the PWM
fig, ax1 = plt.subplots()
t_ax = np.arange(len(speed_pwms))
ax1.plot(t_ax, speed_pwms, '-', label="Speed PWM")
ax1.plot(t_ax, turn_pwms, '-', label="Steering PWM")
ax2 = ax1.twinx()
ax2.plot(t_ax, error, '--r', label="Error")
ax1.set_xlabel("Frames")
ax1.set_ylabel("PWM Values")
ax2.set_ylabel("Error Value")
plt.title("PWM Values over time")
fig.legend()
plt.savefig("pwm_plot.png")
if show_img:
plt.show()
plt.clf()
# set up video
video = cv2.VideoCapture(2)
video.set(cv2.CAP_PROP_FRAME_WIDTH, 160)
video.set(cv2.CAP_PROP_FRAME_HEIGHT, 120)
time.sleep(5)
# PD variables
kp = 0.0225
kd = kp * 0.1
lastTime = 0
lastError = 0
# counter for number of ticks
counter = 0
# arrays for making the final graphs
p_vals = []
d_vals = []
err_vals = []
speed_pwm = []
steer_pwm = []
# Booleans for handling stop light
passedFirstStopSign = False
secondStopLightTick = 0
# See if we've check the stop sign
stopSignCheck = 1
# Sight debuging
sightDebug = True
# Check if it is a stop sting
isStopSignBool = False
move()
print("Start moving.")
while counter < 5000:
speed = mcp4728.channel_a.value
steer = mcp4728.channel_b.value
# Capture current video frame
ret, original_frame = video.read()
# Check for valid video frame
if original_frame is None:
print("No frame")
# Adjust frame size
frame = cv2.resize(original_frame, (160, 120))
# Detect stop signs periodically
if ((counter + 1) % stopSignCheck) == 0:
# First stop sign detection logic
if not passedFirstStopSign:
isStopSignBool, floorSight = isRedFloorVisible(frame)
# Handling first stop sign detection
if isStopSignBool:
print("detected first stop sign, stopping")
stop()
time.sleep(4)
passedFirstStopSign = True
# Delay subsequent stop sign checks
secondStopSignTick = counter + 4
stopSignCheck = 10
go_faster_tick = counter + go_faster_tick_delay
print("first stop finished!")
go()
# Second stop sign detection logic
elif passedFirstStopSign and counter > secondStopSignTick:
print(secondStopSignTick)
print(counter)
isStop2SignBool, _ = isRedFloorVisible(frame)
if isStop2SignBool:
# Exit loop on second stop sign detection
print("detected second stop sign, stopping")
stop()
break
# Frame processing for steering
edges = detect_edges(frame)
roi = region_of_interest(edges)
line_segments = detect_line_segments(roi)
lane_lines = average_slope_intercept(frame, line_segments)
lane_lines_image = display_lines(frame, lane_lines)
steering_angle = get_steering_angle(frame, lane_lines)
heading_image = display_heading_line(lane_lines_image, steering_angle)
# PD controller calculations
now = time.time()
dt = now - lastTime
deviation = steering_angle - 90
# Error and PD adjustments
error = -deviation
base_turn = 0.75
proportional = kp * error
derivative = kd * (error - lastError) / dt
# Data for graphing
p_vals.append(proportional)
d_vals.append(derivative)
err_vals.append(error)
# Steering adjustments
turn_amt = base_turn + proportional + derivative
print("turn amnt: " + str(turn_amt))
# Adjust steering based on calculated turn amount
if 7.2 < turn_amt < 7.8:
turn_amt = 7.6
mcp4728.channel_b.value = int(65535 / 2.7)
elif turn_amt > left:
turn_amt = left
mcp4728.channel_b.value = int(65535 / 13.5)
elif turn_amt < right:
turn_amt = right
mcp4728.channel_b.value = int(65535 / 1.65)
# Speed and steering updates
steer_pwm.append(turn_amt)
speed_pwm.append(current_speed)
# Read encoder data for speed adjustments
time_diff = 5.5
with open("/sys/module/gpiod_driver/parameters/elapsed_ms", "r") as r:
time_diff = int(r.read())
# Adjust speed based on encoder feedback
if time_diff >= 120:
accelerate()
elif 110 >= time_diff > 5.5:
decelerate()
# Update error values for PD control
lastError = error
lastTime = time.time()
key = cv2.waitKey(1)
# Exit on specific key press
if key == 27:
print("key 27")
break
# Increment loop counter
counter += 1
video.release()
##out.release()
##out2.release()
cv2.destroyAllWindows()
stop()
plot_pd(p_vals, d_vals, err_vals, True)
plot_pwm(speed_pwm, steer_pwm, err_vals, True)
//This file has code taken from and influenced by the following sources:
//User raja_961, “Autonomous Lane-Keeping Car Using Raspberry
//Pi and OpenCV”. Instructables. URL:
//https://www.instructables.com/Autonomous-Lane-Keeping-Car-U
//sing-Raspberry-Pi-and
//Team ReaLly BaD Idea, "Autonomous path following car". URL:
//https://www.hackster.io/really-bad-idea/autonomous-path-following-car-6c4992
//Team Access Code, "Access Code Cybertruck'. URL:
//https://www.hackster.io/497395/access-code-cybertruck-9f8b8c
//Adjustments had to be made to get our respective car to function correctly.
#include <linux/module.h>
#include <linux/kernel.h>
#include <linux/gpio.h>
#include <linux/interrupt.h>
#include <linux/ktime.h>
#include <linux/platform_device.h>
#include <linux/of.h>
#define DRIVER_NAME "encoder_driver"
#define ENCODER_GPIO_LABEL "rotary_encoder"
// Structure to hold encoder device information
struct encoder_dev {
struct gpio_desc *gpio;
unsigned int irq_num;
ktime_t last_event_time;
s64 interval_ns;
bool is_idle;
};
static struct encoder_dev my_encoder;
// Sysfs attribute show function to display the speed of the encoder
static ssize_t encoder_speed_show(struct device *dev, struct device_attribute *attr, char *buffer) {
if (my_encoder.is_idle) {
return sprintf(buffer, "0\n"); // Return 0 when encoder is idle
}
my_encoder.is_idle = true;
return sprintf(buffer, "%lld\n", my_encoder.interval_ns); // Return the time interval of the last encoder event
}
static DEVICE_ATTR(speed, S_IRUGO, encoder_speed_show, NULL);
// Interrupt handler for the encoder GPIO
static irqreturn_t encoder_interrupt_handler(int irq, void *dev_id) {
ktime_t current_time = ktime_get_real();
ktime_t time_diff = ktime_sub(current_time, my_encoder.last_event_time);
my_encoder.interval_ns = ktime_to_ns(time_diff);
my_encoder.last_event_time = current_time;
my_encoder.is_idle = false;
// Log the encoder event with the interval time
printk(KERN_INFO DRIVER_NAME ": Encoder event. Interval: %lld ns\n", my_encoder.interval_ns);
return IRQ_HANDLED;
}
// Probe function called when the device is initialized
static int encoder_device_probe(struct platform_device *pdev) {
printk(KERN_INFO DRIVER_NAME ": Initializing encoder device.\n");
// Acquire the GPIO assigned to the encoder
my_encoder.gpio = devm_gpiod_get(&pdev->dev, ENCODER_GPIO_LABEL, GPIOD_IN);
if (IS_ERR(my_encoder.gpio)) {
printk(KERN_ALERT DRIVER_NAME ": Failed to acquire GPIO.\n");
return PTR_ERR(my_encoder.gpio);
}
// Request an IRQ for the GPIO
my_encoder.irq_num = gpiod_to_irq(my_encoder.gpio);
if (request_irq(my_encoder.irq_num, encoder_interrupt_handler, IRQF_TRIGGER_FALLING, DRIVER_NAME, NULL)) {
printk(KERN_ALERT DRIVER_NAME ": IRQ request failed.\n");
return -EIO;
}
// Initialize the encoder's last event time and set it to idle
my_encoder.last_event_time = ktime_get_real();
my_encoder.is_idle = true;
sysfs_create_file(&pdev->dev.kobj, &dev_attr_speed.attr); // Create a sysfs file for speed
printk(KERN_INFO DRIVER_NAME ": Device initialized successfully.\n");
return 0;
}
// Remove function called when the device is removed
static int encoder_device_remove(struct platform_device *pdev) {
free_irq(my_encoder.irq_num, NULL); // Free the IRQ
sysfs_remove_file(&pdev->dev.kobj, &dev_attr_speed.attr); // Remove the sysfs file
printk(KERN_INFO DRIVER_NAME ": Device removed.\n");
return 0;
}
// Match table for device tree compatibility
static const struct of_device_id encoder_of_match[] = {
{ .compatible = "custom,rotary-encoder" },
{},
};
MODULE_DEVICE_TABLE(of, encoder_of_match);
// Platform driver structure
static struct platform_driver encoder_platform_driver = {
.driver = {
.name = DRIVER_NAME,
.of_match_table = encoder_of_match,
},
.probe = encoder_device_probe,
.remove = encoder_device_remove,
};
// Register the platform driver
module_platform_driver(encoder_platform_driver);
MODULE_AUTHOR("Modified Author");
MODULE_DESCRIPTION("Custom Rotary Encoder Driver");
MODULE_LICENSE("GPL");
Comments
Please log in or sign up to comment.
