Senbon Zakura (團長超大聲)

A tempo game with Senbon Zakura.

IntermediateShowcase (no instructions)5,259

Things used in this project

Hardware components

Arduino UNO

Breadboard (generic)

LED (generic)

Buzzer

SparkFun Pushbutton switch 12mm

Texas Instruments Shift Register- Serial to Parallel

Jumper wires (generic)

100

Resistor 4.75k ohm

Resistor 1k ohm

SparkFun 7-Segment Serial Display - Red

Story

Music Spectrum:

Music Spectrum

Circuits:

We use:

Arduino UNO x1

LEDs x32

7-Segment display x1

Buzzer x2

Switch (Button) x2

IC74HC595 (Shift Register) x6

It is a little bit hard to connect the components.

Four IC74HC595 connect to the thirty-two LEDs. The other two IC74HC595 connect to the 7-segment display. And the buzzers are put on the corner of breadboard.

We put the button on the other breadboard.

Full Circuits

Buttons

Buzzer and IC74HC595

LEDs and 7-Segment

概念:

這個概念源自於音樂節奏遊戲，我們使用 Arduino 加上電子元件來實現此音樂節奏遊戲。

我們選的曲目是千本櫻，使用發光二極體來呈現音樂節奏，用蜂鳴器來產生音樂，而七段顯示器則是來顯示分數。

玩法:

當音樂播放後發光二極體會跟著音樂顯示節奏，當打擊(按按鈕)在正確節奏上就會得分，分數會顯使在七段顯示器上。

Concept:

This concept comes from the music tempo game, and we use hardware to display the game.

We selected the music (Senbon Zakura), LEDs to show the music tempo, buzzer to produce music and a seven-segment display to show your scores.

How to play the game?

When the music plays, LEDs will follow the music tempo.

You have to press the button on the correct tempo.

If you follow the tempo correctly, you will get the points and your score will be displayed on the seven-segment display.

Demo:

Arduino Final Demo

PPT:

https://drive.google.com/file/d/171SrQr_9oOZ5ICAjKwTYwuoTjwrXmia-/view?usp=sharing

https://drive.google.com/open?id=1vFtyZMW80XaqZvF7VIK3dFG8iORTO3Fj

Final

#include <Tone.h>

// 接 74HC595 的第 12 支接腳
int latchPin = 9;
// 接 74HC595 的第 11 支接腳
int clockPin = 8;
// 接 74HC595 的第 14 支接腳
int dataPin = 10;
const int buzzer = 7;
const int sym = 6;
const int btn = 5;
const int Rbtn = 4;
Tone freq1;
Tone freq2;

void setup() {
  Serial.begin(250000);
  pinMode(latchPin, OUTPUT);
  pinMode(clockPin, OUTPUT);
  pinMode(dataPin, OUTPUT);
  pinMode(btn,INPUT);
  pinMode(Rbtn,INPUT);
  freq1.begin(buzzer);
  freq2.begin(sym);
}
const int toneTable[]={
  131,
  147,
  165,
  175,
  196,
  220,
  247,
  0,
  264,
  294,
  330,
  349,
  392,
  440,
  494,
  0,
  524,
  588,
  660,
  698,
  784,
  880,
  932
};
char toneName[]="cdefgabNCDEFGAB";

char MainTone[]="NNNNNNNNNNNNNNNCCCCbbbbaaaagggNggaaeeddeeeeeeeNeeggaaaaDDDDbbbbCCCCbbggaaaaaaaaCCCCbbbbaaaagggNggaaeeddeeeNeeggaNaaaNaaCCCCDDDDbbbbbbbbbbbNaaCCDDNDDNENEEEEENEEGGAAEEDDEEEEaaCCDDNDDNENEEEEENEEFFEEDDCNCCCCaaCCDDNDDNENEEEEENEEGGAAEEDDEEEEaaCCFFFFEEEEDDDDCCCCDDEEbbggaaaNaaCCDDNDDDENEEEEENEEGGAAEEDDEEEEaaCCDDNDDNENEEEEENEEFFEEDDCNCCCCaaCCDDNDDNENEEEEENEEGGAAEEDDEEEEaaCCFFFFEEEEDDDDCCCCDDCCEEGGAAAAAAAA";

char  SymTone[]="NNNNNNNNNNNNNNNffNNffNNffNNffNNCCNNCCNNCCNNCCNNffNNffNNggNNggNNaNaaggaaDDCCbbfNffNNffNNffNNffNNCCNNCCNNCCNNCCNNDNDNNNDNDNNNEEDDEENNENEENNNNNNNNaaNgaagNfNffCCffggDDGGDDccggCCggaaNgaagNfNffCCffggDDGGDDccggCCggaaNgaagNfNffCCffggDDGGDDccggCCggffNfffFNeebbEEbbffFFggGGaNagaaCCaaNgaagNfNffCCffggDDGGDDccggCCggaaNgaagNfNffCCffggDDGGDDccggCCggaaNgaagNfNffCCffggDDGGDDccggCCggffNfNfFNeebbEEbbffFFggGGaaNNaaaa";

int getTone(char symbol,int pos) {
    int toneNo = 0;
    for ( int ii=0; ii<15; ii++ ) {
        if ( toneName[ii]==symbol ) {
            toneNo = ii;
            break;
        }
    }
    return toneNo+pos;
}

uint8_t L[] = {1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,1,0,0,0,1,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,1,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,1,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,1,0,0,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,1,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,1,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,1,0,0,0,1,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0};

uint8_t R[] = {1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,0,0,1,0,0,0,0,0,0,0,1,0,0,0,0,0,1,0,0,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,1,0,1,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,1,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,1,0,0,1,0,0,1,0,1,0,0,0,0,0,0,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,1,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0};

byte sevenNumber [] = {
  254,//0
  48,//1
  109,//2
  121,//3
  51,//4
  91,//5
  95,//6
  114,//7
  255,//8
  123,//9
  0,//NULL
};
int number;
int SevenCounter = 0;
int MusicCounter = 0;
int PlayCounter = 0;
int TempleCounter = 0;
int BtnCounter = -50;
int numberTen;
int numberZero;
const int Musicdelay = 100;
int MaintoneNo, SymtoneNo;
bool trigger = false;
bool Rtrigger = false;
uint16_t Ldis = 0;
uint16_t Rdis = 0;

void loop()
{
  int score = 0;

  for(int i=0;i<sizeof(L)*Musicdelay;i++){
    if(PlayCounter == sizeof(L)) PlayCounter = 0;
    if(PlayCounter == 0) score = 0;
    if(MusicCounter < Musicdelay){
      MusicCounter++;
    }
    else if(MusicCounter == Musicdelay){

        Ldis = Ldis << 1;
        Rdis = Rdis << 1;
        Ldis += L[PlayCounter];
        Rdis += R[PlayCounter];
        number = score;
        if(SevenCounter <10){
          numberTen =10;
          numberZero = score/100;
        }
        else if(SevenCounter <40){
          numberTen = (number-100*(score/100))/10;
          numberZero = number-10*(score/10);
        }
        else if(SevenCounter == 40){
          SevenCounter = -1;
        }
        SevenCounter++;
        MaintoneNo = getTone(MainTone[PlayCounter],8);
        SymtoneNo = getTone(SymTone[PlayCounter],0);
        freq1.play(toneTable[MaintoneNo]);
        freq2.play(toneTable[SymtoneNo]);

        // 送資料前要先把 latchPin 拉成低電位
        digitalWrite(latchPin, LOW);
        shiftOut(dataPin, clockPin, LSBFIRST, (~sevenNumber[numberZero]));
        shiftOut(dataPin, clockPin, LSBFIRST, (~sevenNumber[numberTen]));
        shiftOut(dataPin, clockPin, LSBFIRST, lowByte(Rdis));
        shiftOut(dataPin, clockPin, LSBFIRST, highByte(Rdis));
        shiftOut(dataPin, clockPin, LSBFIRST, lowByte(Ldis));
        shiftOut(dataPin, clockPin, LSBFIRST, highByte(Ldis));
        // 送出第一位元組給最近的 74HC595
        // 送完資料後要把 latchPin 拉回成高電位
        digitalWrite(latchPin, HIGH);
        MusicCounter = 1;
        PlayCounter++;
    }
  int switchStatus = digitalRead(btn);
  int RswitchStatus = digitalRead(Rbtn);

  if(TempleCounter == sizeof(L)) TempleCounter = 0;
  if(BtnCounter<Musicdelay){
      if(switchStatus==1){
        trigger = true;
      }
      else {
        trigger = trigger;
      }
      if(RswitchStatus==1){
        Rtrigger = true;
      }
      else {
        Rtrigger = Rtrigger;
      }
      BtnCounter++;
   }
   else if(BtnCounter == Musicdelay){
      if(Ldis/32768==1){
        if(trigger) score++;
        else score--;
    }
    else{
      score = score;
    }
    if(Rdis/32768==1){
        if(Rtrigger) score++;
        else score--;
    }
    else{
        score = score;
    }
    if(score < 0) score = 0;
      TempleCounter++;
      BtnCounter = 1;
      trigger = false;
      Rtrigger = false;
    }
    delay(1);
  }
}
