This plug-in is called Chicken Shot! and it plays two different bird calls from the THETA internal speaker. It is intended for having use in a chicken pen or maybe outdoors in order to catch chickens or birds doing interesting things. The plug-in is controlled by a webpage with two buttons for the bird calls and one button for taking a picture. This makes it super simple and obvious to use, which is useful when you're trying to take bird pictures.
Basically, there are three things you can do with this plug-in.
* Play two different pre-recorded bird calls using the THETA speaker. Grab the bird's attention!* Take a 360° picture. Candid shots are the best!* Record your own voice using the mic in your THETA and use it the same way you were using the bird calls, to attract attention and take pictures.
You can also make bird sounds with your hands and then take the 360 picture manually.
This plug-in is a modification of Meow Shot! by Hideki Shiro. I built it as practice to learn RICOH THETA Plug-in development and Kotlin. This is my first experience with Kotlin.
To build this project, start with Meow Shot! and open it in Android Studio. To customize this for your favorite animal, you'll only need to edit a few files.
# Web GUI
The web GUI file is in [assets/index.html](https://github.com/shrhdk/meowshot/blob/master/app/src/main/assets/index.html)
Create functions for the different sounds.
override fun onChickenRequest() {
playChicken()
}
Play the sound on a thread.
private fun playChicken() {
executor.submit {
if (!crowSoundManager!!.isRecording) {
crowSoundManager!!.play()
}
}
}
Set the sound file path.
val soundFilePath = "${filesDir}${File.separator}mySound.wav"mSoundManager = SoundManager(applicationContext, R.raw.rooster, soundFilePath)crowSoundManager = SoundManager(applicationContext, R.raw.crow, soundFilePath)
# Sound Files
The sound files are mp3 files in `app/res/raw`
index.html modifications
HTMLThe images are in svg. I used InkScape to convert PNG or JPG files to svg.
<html>
<head>
<title>Chicken Shot!</title>
<meta name="viewport" content="width=device-width,initial-scale=1.0">
</head>
<body>
<style>
.container {
display: flex;
flex-flow: column;
justify-content: center;
height: 100%;
text-align: center;
}
svg {
box-sizing: border-box;
width: 80%;
padding: 2em 5em;
margin: 1em auto;
border: 2px gray solid;
border-radius: 3em;
}
</style>
<script>
function post(path) {
const req = new XMLHttpRequest();
req.open('POST', path);
req.send();
}
</script>
<div class="container">
<svg onclick="post('/meow')" version="1.1" xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512"
style="background-color: #ffe0ff"
xml:space="preserve">
<style type="text/css">
.st0{fill:#4B4B4B;}
</style>
<g>
<path d="m469.609375 249.960938c-13.269531-36.859376-44.386719-72.898438-80.421875-70.210938-12.414062-48.707031-41.472656-94.503906-85.757812-119.347656l9.695312-41.328125c3.265625-13.921875-12.566406-24.46875-24.15625-16.101563-23.316406 16.835938-102.464844 50.269532-104.550781 51.402344-52.871094 28.722656-86.386719 70.835938-99.824219 125.34375-35.769531-2.285156-66.617188 33.296875-79.917969 70.242188-17.328125 48.144531 18.980469 102.851562 20.535157 105.160156 3.789062 5.617187 10.769531 8.105468 17.226562 6.199218 1.023438-.300781 10.902344-3.289062 23.671875-9.570312 13.09375 47.726562 41.875 81.160156 81.96875 99.742188l-2.226563 29.519531h-29.769531c-8.554687 0-15.492187 6.9375-15.492187 15.496093 0 8.554688 6.9375 15.492188 15.492187 15.492188h44.140625c8.109375 0 14.84375-6.246094 15.453125-14.328125l2.675781-35.503906c33.816407 8.632812 75.050782 8.847656 107.652344 2.265625l2.503906 33.234375c.605469 8.085937 7.34375 14.332031 15.449219 14.332031h36.3125c8.554688 0 15.492188-6.9375 15.492188-15.492188 0-8.558593-6.9375-15.496093-15.492188-15.496093h-21.9375l-1.910156-25.371094c45.238281-17.515625 77.640625-52.464844 91.753906-103.890625 12.765625 6.28125 22.648438 9.269531 23.671875 9.570312 6.476563 1.910157 13.449219-.597656 17.226563-6.199218 1.554687-2.308594 37.863281-57.015625 20.535156-105.160156zm-270.585937-168.25c4.855468-2.296876 39.574218-16.40625 75.839843-35.234376l-4.390625 18.722657c-1.695312 7.230469 1.980469 14.648437 8.757813 17.679687 39.222656 17.542969 69.78125 59.160156 81.222656 109.871094-8.308594 8-14.253906 19.246094-17.328125 32.863281l-50.253906 29.828125-46.871094-32.667968c-5.304688-3.703126-12.382812-3.722657-17.71875 0l-46.871094 32.667968-50.253906-29.828125c-3.117188-13.839843-9.195312-25.210937-17.699219-33.230469 10.472657-48.808593 38.539063-85.074218 85.566407-110.671874zm-154.0625 245.652343c-7.773438-15.082031-19.480469-43.699219-11.128907-66.90625 12.207031-33.914062 37.535157-54.496093 52.816407-49 16.539062 5.957031 19.597656 38.253907 11.417968 65.519531-7.570312 25.085938-28.730468 40.050782-53.105468 50.386719zm192.179687 110.671875c-79.164063 0-128.53125-35.703125-143.34375-103.414062 20.789063-16.277344 34.605469-36.578125 38.863281-72.078125l41.515625 24.640625c5.226563 3.101562 11.78125 2.863281 16.765625-.613282l46.199219-32.199218 46.199219 32.199218c4.925781 3.433594 11.515625 3.730469 16.769531.613282l41.515625-24.640625c4.09375 34.15625 16.695312 54.722656 38.863281 72.078125-14.824219 67.710937-64.191406 103.414062-143.347656 103.414062zm192.238281-110.695312c-18.949218-8.089844-40.472656-21.523438-49.421875-40.183594-11.253906-23.472656-12.695312-68.363281 7.675781-75.699219 15.023438-5.40625 40.449219 14.632813 52.816407 49 8.414062 23.375-3.269531 51.851563-11.070313 66.882813zm0 0"/><path d="m160.164062 163.910156h7.644532c8.554687 0 15.492187-6.9375 15.492187-15.496094 0-8.558593-6.9375-15.496093-15.492187-15.496093h-7.644532c-8.558593 0-15.496093 6.9375-15.496093 15.496093 0 8.558594 6.9375 15.496094 15.496093 15.496094zm0 0"/><path d="m306.476562 163.910156h7.640626c8.558593 0 15.496093-6.9375 15.496093-15.496094 0-8.558593-6.9375-15.496093-15.496093-15.496093h-7.640626c-8.558593 0-15.496093 6.9375-15.496093 15.496093 0 8.558594 6.9375 15.496094 15.496093 15.496094zm0 0"/><path d="m299.222656 349.773438c-8.554687 0-15.492187 6.9375-15.492187 15.496093v10.613281c0 8.558594 6.9375 15.496094 15.492187 15.496094 8.558594 0 15.496094-6.9375 15.496094-15.496094v-10.613281c0-8.558593-6.9375-15.496093-15.496094-15.496093zm0 0"/><path d="m144.414062 300.671875c-8.558593 0-15.496093 6.9375-15.496093 15.496094v11c0 8.558593 6.9375 15.496093 15.496093 15.496093 8.558594 0 15.496094-6.9375 15.496094-15.496093v-11c0-8.558594-6.9375-15.496094-15.496094-15.496094zm0 0"/><path d="m339.300781 323.515625c-8.558593 0-15.496093 6.9375-15.496093 15.496094v11c0 8.558593 6.9375 15.496093 15.496093 15.496093 8.554688 0 15.492188-6.9375 15.492188-15.496093v-11c0-8.558594-6.933594-15.496094-15.492188-15.496094zm0 0"/><path d="m193.335938 180.429688 34.320312 26.574218c5.585938 4.324219 13.386719 4.324219 18.972656 0l34.316406-26.574218c3.789063-2.9375 6.007813-7.460938 6.007813-12.253907s-2.214844-9.316406-6.007813-12.25l-34.316406-26.578125c-5.585937-4.324218-13.386718-4.324218-18.972656 0l-34.320312 26.578125c-3.789063 2.933594-6.007813 7.457031-6.007813 12.25s2.21875 9.316407 6.007813 12.253907zm43.804687-19.230469 9.011719 6.976562-9.011719 6.980469-9.007813-6.980469zm0 0"/>
</g>
</svg>
<svg onclick="post('/chicken')" version="1.1" xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512"
style="background-color: #81F79F"
xml:space="preserve">
<style type="text/css">
.st0{fill:#4B4B4B;}
</style>
<g>
<path style="fill:#303C42;" d="M357.695,101.194C340.38,51.393,278.788,0,245.333,0c-12.854,0-32,8.521-32,32
c0,3.654,0.586,7.307,1.469,10.948C164.684,43.855,128,48.383,128,74.667c0,14.594,13.542,25.656,43.146,34.583
c-50.836,25.789-85.594,69.917-106.033,119.257l-1.322-6.6c-0.771-3.854-3.604-6.979-7.375-8.115
c-3.667-1.146-7.854-0.115-10.625,2.667l-10.667,10.667c-3.25,3.25-4.063,8.208-2,12.313l8.784,17.569l-27.284-10.913
c-3.271-1.302-7-0.906-9.938,1.073C1.75,249.156,0,252.458,0,256v21.333C0,283.229,4.771,288,10.667,288h21.346l-17.076,12.802
c-2.479,1.854-4.021,4.688-4.25,7.771c-0.208,3.083,0.917,6.115,3.104,8.302l10.667,10.667c2,2.01,4.729,3.125,7.542,3.125
c0.25,0,0.5-0.01,0.75-0.031c3.083-0.219,5.916-1.76,7.792-4.229l2.785-3.711c-0.404,6.26-0.66,12.488-0.66,18.638
C42.667,445.01,138.958,512,288,512c140.271,0,224-75.76,224-202.667C512,223.277,447.365,136.603,357.695,101.194z"/>
<path style="fill:#FFFFFF;" d="M437.333,298.667c0,5.104-0.938,10.094-2.833,14.906c-13.508-2.829-26.863-3.919-39.944-3.69
c0.01-0.193,0.111-0.354,0.111-0.549c0-5.892-4.776-10.667-10.667-10.667s-10.667,4.775-10.667,10.667
c0,0.025,0.014,0.047,0.014,0.072c-1.648-0.01-3.284,0.292-4.785,1.053c-2.452,1.225-9.966,5.078-19.63,10.701
c-18.766-1.832-38.262-1.053-58.099,3.081c-1.875-4.813-2.833-9.802-2.833-14.906c0-14.836,7.911-28.017,20.474-35.788
l60.901,24.361c1.271,0.51,2.604,0.76,3.958,0.76c1.146,0,2.271-0.177,3.375-0.552l55.388-18.465
C435.203,285.635,437.333,291.973,437.333,298.667z"/>
<path style="fill:#FDD835;" d="M304.021,383c10.292-13.688,34.896-33.24,69.458-51.115c12.875,6.5,50.771,28.01,67.563,63.49
c-2.938-1.021-11.146-3.542-12.167-3.667C387.333,380.917,331.646,381.708,304.021,383z"/>
<path style="opacity:0.2;fill:#FFFFFF;enable-background:new ;" d="M373.479,342.69c11.185,5.647,41.22,22.652,59.931,50.271
c2.763,0.828,5.986,1.842,7.632,2.414c-16.792-35.479-54.688-56.99-67.563-63.49c-34.563,17.875-59.167,37.427-69.458,51.115
c3.063-0.143,6.586-0.273,10.281-0.389C327.18,370.488,347.518,356.117,373.479,342.69z"/>
<path style="fill:#FDD835;" d="M409,409.104c-11.875,12.104-31.729,26.958-46.688,37.021c-24.479-14.51-46.583-30.885-57.146-41.854
C332.833,402.979,375.125,403.042,409,409.104z"/>
<path style="opacity:0.1;enable-background:new ;" d="M399.143,418.259c3.618-3.138,6.988-6.23,9.857-9.155
c-33.875-6.063-76.167-6.125-103.833-4.833c2.923,3.036,6.882,6.539,11.379,10.249C340.668,413.848,371.753,414.397,399.143,418.259
z"/>
<g>
<path style="fill:#E53935;" d="M288,490.667c-103.333,0-224-39.115-224-149.333c0-88.813,44.854-192.708,145.042-224.604
c5.021-1.594,9.042-6.51,8.229-11.708c-0.792-5.198-4.354-8.927-9.604-8.927c-54.167-10.521-58.313-21.406-58.333-21.427
c0-2.944,7.652-9.704,75.184-10.529c13.164,20.13,36.018,38.477,58.087,51.268c5.063,2.917,11.604,1.229,14.583-3.885
c2.958-5.094,1.208-11.615-3.875-14.573c-34.542-20-58.646-46.708-58.646-64.948c0-8.594,5.875-10.542,10.667-10.667
c23.667,0,81,46.698,93.625,90.844c0.961,3.379,3.641,5.411,6.695,6.56l-0.174,0.471c49.206,18.224,91.085,54.556,117.066,97.311
l-89.171,48.637l-90.854-50.479c-2.563-1.406-5.583-1.719-8.333-0.865c-2.792,0.854-5.083,2.813-6.396,5.417l-10.667,21.333
c-1.333,2.667-1.479,5.771-0.438,8.563c1.063,2.792,3.25,5,6.021,6.115l22.776,9.111c-11.842,11.757-18.818,27.697-18.818,44.983
c0,11.302,3.188,22.594,9.208,32.656c1.958,3.281,5.458,5.198,9.146,5.198c0.854,0,1.75-0.104,2.604-0.323
c9.887-2.491,19.688-3.98,29.352-4.74c-20.693,15.469-39.643,34.509-39.643,52.542c0,24.844,55.979,59.51,80.042,73.26
c1.646,0.938,3.458,1.406,5.292,1.406c2.021,0,4.021-0.573,5.771-1.698c5.208-3.354,46.75-30.49,63.813-52.844
c7.979,2.646,14.833,5.854,20.021,9.74c0.599,0.451,1.361,0.421,2.023,0.728C420.406,467.605,363.813,490.667,288,490.667z"/>
<path style="fill:#E53935;" d="M467.326,406.18c-8.482-33.905-32.499-58.611-53.674-74.434c7.949,0.928,15.99,2.421,24.057,4.452
c0.854,0.219,1.729,0.323,2.604,0.323c3.687,0,7.188-1.917,9.146-5.198c6.021-10.063,9.208-21.354,9.208-32.656
c0-9.035-2.111-17.771-5.822-25.934l30.53-10.177c4.678,15.462,7.292,31.193,7.292,46.777
C490.667,347.147,482.564,379.548,467.326,406.18z"/>
</g>
<g>
<path style="opacity:0.2;fill:#FFFFFF;enable-background:new ;" d="M277.324,274.319c2.38-3.564,5.087-6.918,8.16-9.969
l-8.152-3.262l7.49,3.262C281.999,267.401,279.51,270.755,277.324,274.319z"/>
<path style="opacity:0.2;fill:#FFFFFF;enable-background:new ;" d="M278.355,213.404c-0.342-0.039-0.678,0.1-1.022,0.1
C277.677,213.504,278.013,213.371,278.355,213.404z"/>
<path style="opacity:0.2;fill:#FFFFFF;enable-background:new ;" d="M282.176,115.406c1.355,0.85,2.819,1.199,4.29,1.297
c-1.324-0.184-2.639-0.592-3.862-1.297c-1.759-1.02-3.508-2.284-5.271-3.372C278.953,113.122,280.56,114.387,282.176,115.406z"/>
<path style="opacity:0.2;fill:#FFFFFF;enable-background:new ;" d="M284.396,347.188c0.135,0,0.276-0.049,0.413-0.056
c-2.921-0.061-5.504-1.533-7.477-3.72C279.19,345.655,281.637,347.188,284.396,347.188z"/>
<path style="opacity:0.2;fill:#FFFFFF;enable-background:new ;" d="M316.977,342.125c-1.238,0.098-2.497,0.319-3.741,0.441
c-18.806,15.391-35.902,34.234-35.902,52.1C277.333,376.634,296.284,357.594,316.977,342.125z"/>
</g>
<circle style="fill:#303C42;" cx="330.667" cy="309.333" r="10.667"/>
<linearGradient id="SVGID_1_" gradientUnits="userSpaceOnUse" x1="-30.6741" y1="628.1334" x2="-27.221" y2="624.6793" gradientTransform="matrix(21.3333 0 0 -21.3333 996.3334 13791.667)">
<stop offset="0" style="stop-color:#000000;stop-opacity:0.1"/>
<stop offset="1" style="stop-color:#000000;stop-opacity:0"/>
</linearGradient>
<path style="fill:url(#SVGID_1_);" d="M432.25,414.792c-17.063,22.354-58.604,49.49-63.813,52.844
c-1.75,1.125-3.75,1.698-5.771,1.698c-1.833,0-3.646-0.469-5.292-1.406c-13.406-7.66-36.706-21.818-54.725-37.148l52.531,52.53
c42.634-9.826,76.186-29.4,99.113-58.049c-0.663-0.307-1.424-0.277-2.023-0.728C447.083,420.646,440.229,417.438,432.25,414.792z"/>
<path style="opacity:0.1;enable-background:new ;" d="M65.789,363.035C80.656,456.681,191.785,490.667,288,490.667
c75.813,0,132.406-23.061,166.294-65.408c-0.663-0.307-1.424-0.277-2.023-0.728c-5.188-3.885-12.042-7.094-20.021-9.74
c-17.063,22.354-58.604,49.49-63.813,52.844c-1.75,1.125-3.75,1.698-5.771,1.698c-1.833,0-3.646-0.469-5.292-1.406
c-15.294-8.74-43.443-25.931-61.954-43.677c-12.536,1.503-25.595,2.417-39.421,2.417C169.967,426.667,103.275,403.19,65.789,363.035
z"/>
<path style="opacity:0.1;enable-background:new ;" d="M458.667,298.667c0,11.302-3.188,22.594-9.208,32.656
c-1.958,3.281-5.459,5.198-9.146,5.198c-0.576,0-1.143-0.118-1.714-0.212c-2.01,3.898-4.262,7.598-6.565,11.259
c15.217,14.948,29.232,34.389,35.292,58.612c15.238-26.632,23.341-59.033,23.341-96.846c0-15.585-2.613-31.315-7.292-46.777
l-26.206,8.736c-0.368,3.469-0.807,6.889-1.326,10.253C457.495,287.102,458.667,292.781,458.667,298.667z"/>
<linearGradient id="SVGID_2_" gradientUnits="userSpaceOnUse" x1="-44.8289" y1="638.6147" x2="-23.1622" y2="628.5118" gradientTransform="matrix(21.3333 0 0 -21.3333 996.3334 13791.667)">
<stop offset="0" style="stop-color:#FFFFFF;stop-opacity:0.2"/>
<stop offset="1" style="stop-color:#FFFFFF;stop-opacity:0"/>
</linearGradient>
<path style="fill:url(#SVGID_2_);" d="M357.695,101.194C340.38,51.393,278.788,0,245.333,0c-12.854,0-32,8.521-32,32
c0,3.654,0.586,7.307,1.469,10.948C164.684,43.855,128,48.383,128,74.667c0,14.594,13.542,25.656,43.146,34.583
c-50.836,25.789-85.594,69.917-106.033,119.257l-1.322-6.6c-0.771-3.854-3.604-6.979-7.375-8.115
c-3.667-1.146-7.854-0.115-10.625,2.667l-10.667,10.667c-3.25,3.25-4.063,8.208-2,12.313l8.784,17.569l-27.284-10.913
c-3.271-1.302-7-0.906-9.938,1.073C1.75,249.156,0,252.458,0,256v21.333C0,283.229,4.771,288,10.667,288h21.346l-17.076,12.802
c-2.479,1.854-4.021,4.688-4.25,7.771c-0.208,3.083,0.917,6.115,3.104,8.302l10.667,10.667c2,2.01,4.729,3.125,7.542,3.125
c0.25,0,0.5-0.01,0.75-0.031c3.083-0.219,5.916-1.76,7.792-4.229l2.785-3.711c-0.404,6.26-0.66,12.488-0.66,18.638
C42.667,445.01,138.958,512,288,512c140.271,0,224-75.76,224-202.667C512,223.277,447.365,136.603,357.695,101.194z"/>
<g>
</g>
</g>
</svg>
<svg onclick="post('/take_picture')" version="1.1" xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" style="background-color: #e0efff" xml:space="preserve">
<style type="text/css">
.st0{fill:#4B4B4B;}
</style>
<g>
<path class="st0" d="M235.194,131.024c4.298-0.115,8.845-0.192,13.72-0.192c54.374-0.01,144.447,8.509,252.193,51.19
c-12.337-40.941-34.595-77.545-64.084-107.034c-23.46-23.451-51.402-42.335-82.448-55.296
C303.931,57.372,264.923,95.968,235.194,131.024z"/>
<path class="st0" d="M175.627,150.831c30.423-42.374,75.219-93.65,138.832-144.052C295.671,2.403,276.134,0,255.991,0
C197.512,0.01,143.745,19.605,100.66,52.574c7.298,62.672,21.23,115.736,36.72,158.966
C146.254,195.146,158.696,174.398,175.627,150.831z"/>
<path class="st0" d="M124.726,273.029c-21.47-47.528-43.469-111.949-55.315-192.195C26.374,126.668,0.009,188.156,0,256
c0,11.115,0.788,22.047,2.154,32.788c57.911,24.998,110.871,39.527,156.062,47.738
C148.436,320.632,136.687,299.489,124.726,273.029z"/>
<path class="st0" d="M276.807,380.967c-4.298,0.115-8.856,0.192-13.73,0.192c-54.374,0.019-144.456-8.51-252.183-51.181
c12.336,40.922,34.595,77.536,64.084,107.034c23.461,23.442,51.402,42.326,82.449,55.296
C208.069,454.628,247.078,416.013,276.807,380.967z"/>
<path class="st0" d="M336.372,361.169c-30.421,42.374-75.218,93.65-138.832,144.053c18.788,4.384,38.326,6.778,58.451,6.778
c58.498-0.009,112.245-19.605,155.35-52.574c-7.317-62.671-21.239-115.717-36.72-158.966
C365.746,316.854,353.304,337.604,336.372,361.169z"/>
<path class="st0" d="M509.847,223.213c-57.912-24.99-110.872-39.537-156.062-47.748c9.769,15.893,21.528,37.047,33.488,63.507
c21.471,47.527,43.47,111.948,55.316,192.205C485.626,385.332,511.99,323.844,512,256C512,244.886,511.211,233.943,509.847,223.213
z"/>
</g>
</svg>
</div>
</body>
</html>
