Top PCB Inspection Testing Techniques

PCB Inspection/Testing techniques are an important part of PCB manufacturing before production. These evaluative tests are essential in determining the quality of your final product. Even after following proper design and manufacturing processes, there is always a risk of defects, bugs, human errors at the prototype stages. Identifying and addressing these issues before the final product is critical in ensuring the performance, functionality, and reliability of the products. A great number of popular Electronic contract manufacturers (ECMs) offer a wide range of QA tests in order to ensure the quality of your PCB boards. So, in today’s article, we are going to go over the top PCB Inspection/Testing Techniques Used in PCB Fab Houses.

Top PCB Inspection/Testing Techniques Used In PCB Manufacturing

1) In-Circuit Testing

In-Circuit testing is a fully automated test, which detects defects in an assembly of PCBs through ‘Schematic verification’. ICT works in two parts, namely the Power-off & Power-on test. ICT identifies a large number of defects in the assembly; which includes, but is not limit to Component markings, Presence/absence of passive components, etc.

2) Time Domain Reflectometry Test (TDR Test)

Time Domain Reflectometry (TDR); in literal sense, allows the design engineer to determine the characteristic impedance of the PCB board or card in a test. TDR test also helps in determining whether if the differential traces present on the PCB board are a complete match for good signal integrity or not

3) Automated Optical Inspection (AOI) Test

AOI tests use a single 2D or two 3D camera’s visual input to monitor PCBs for defects. This method is only useful on PCBs where the points to test are optically visible. It is performed to check solder quality and verify pad and trace connections. AOI is also very useful for the early detection of assembly issues.
