Juan Says: A Juanderful Memory Game

//#define RED 19 // pin 19 is always PWM capable according to LaunchPad standard
//#define GREEN 18 // may need to change this for your LaunchPad
//#define BLUE 11 // may need to change this for your LaunchPad
//I changed this to RGB LEDs on board, can change back

#define RED RED_LED
#define GREEN GREEN_LED
#define BLUE BLUE_LED



byte seven_segment_digits[10][7] = { { 0,0,0,0,0,0,1 }, // display '0'
                                     { 1,0,0,1,1,1,1 }, // display '1'
                                     { 0,0,1,0,0,1,0 }, // display '2'
                                     { 0,0,0,0,1,1,0 }, // display '3'
                                     { 1,0,0,1,1,0,0 }, // display '4'
                                     { 0,1,0,0,1,0,0 }, // display '5'
                                     { 0,1,0,0,0,0,0 }, // display '6'
                                     { 0,0,0,1,1,1,1 }, // display '7'
                                     { 0,0,0,0,0,0,0 }, // display '8'
                                     { 0,0,0,1,1,0,0 }  // display '9'
                                   };

byte seven_segment_celebrate[6][7] = {  { 0,1,1,1,1,1,1 },
                                        { 1,0,1,1,1,1,1 },
                                        { 1,1,0,1,1,1,1 },
                                        { 1,1,1,0,1,1,1 },
                                        { 1,1,1,1,0,1,1 },
                                        { 1,1,1,1,1,0,1 },
                                   };

#define timePrsd 250
#define timeBtwnSeq 500
#define splashTime 200


int btn_pin[]={11,12,13}; // change for launchpad
int led_pin[]={17,18,19}; // change for launchpad
int swch_pin = 9;
int led[]={LOW,LOW,LOW};          //current value
int bState = 0;
int swch = HIGH;            // current value
int swch_new = HIGH;         // value just read
int swch_changed = LOW;     // turns HIGH for one cycle after each keypress
int swch_last= HIGH;   // the previous reading from the input pin
long swch_lastDebounceTime = 0;  // the last time the output pin was toggled
long swch_debounceDelay = 50;    // the debounce time; increase if the output flickers
int btn[]={LOW,LOW,LOW};            // current value
int btn_new[]={LOW,LOW,LOW};         // value just read
int btn_changed[]={HIGH,HIGH,HIGH};     // turns HIGH for one cycle after each keypress
int btn_last[]={LOW,LOW,LOW};   // the previous reading from the input pin
long btn_lastDebounceTime[]={0,0,0};  // the last time the output pin was toggled
long btn_debounceDelay = 50;    // the debounce time; increase if the output flickers
int currentNum = 2; // current highest index of the sequence
int roundNum = 0;
int sequence[15]; // maximum length of memory sequence

int timeBtwnLED = 500; // this will get smaller as the rounds progress

void debounceButtons() // debuonces buttons
{
  for (int i=0; i<3; ++i)
  {
   btn_changed[i]=LOW;
   btn_new[i]=digitalRead(btn_pin[i]);
   if (btn_new[i] != btn_last[i])
   {
     btn_lastDebounceTime[i] = millis();
   }
   if ((millis() - btn_lastDebounceTime[i]) > btn_debounceDelay)
   {
     if (btn_new[i] != btn[i])
     {
       btn_changed[i]=HIGH;
       btn[i] = btn_new[i];
     }
   }
   btn_last[i]=btn_new[i];
  }
}

void debounceSwitch() // debuonces switch
{
   swch_changed=HIGH;
   swch_new=digitalRead(swch_pin);
   if (swch_new != swch_last)
   {
     swch_lastDebounceTime = millis();
   }
   if ((millis() - swch_lastDebounceTime) > swch_debounceDelay)
   {
     if (swch_new != swch)
     {
       swch_changed = LOW;
       swch = swch_new;
     }
   }
   swch_last = swch_new;
}


void makeSequence() // generates a random sequence
{
  for (int i = 0; i <= currentNum; ++i)
  {
    sequence[i] = random(3);
  }
}

void showSequence() //shows the sequence
{
 for (int i=0; i<=currentNum; ++i)
 {
   delay(timeBtwnLED);
   digitalWrite(led_pin[sequence[i]], HIGH);
   delay(timeBtwnLED - 250); //maybe?
   digitalWrite(led_pin[sequence[i]], LOW);
 }
}

void nextRound() //prepares everything for next round
{
  currentNum++;
  timeBtwnLED -= 10;
  roundNum++;
  int pin = 2;
  for (int segCount = 0; segCount < 7; ++segCount) {
    digitalWrite(pin, seven_segment_digits[roundNum][segCount]);
    ++pin;
  }
}


boolean checkSequence(int correctAnswer) // checks if answer is right or wrong
{
  int answerIs=LOW;
  int receivedAnswer=LOW;

  while ( receivedAnswer == LOW )
  {
    debounceButtons();
    for (int i=0; i<3; ++i)
    {
      if ((btn_changed[i]==HIGH) and (btn[i] == LOW))
      {
        if (i == correctAnswer)
        {
          answerIs=HIGH;
        }
        receivedAnswer=HIGH;
        do
        {
          digitalWrite (led_pin[i], HIGH);
        }
        while (digitalRead(btn_pin[i]) != HIGH);

        digitalWrite (led_pin[i], LOW);
      }
    }
  }

  return answerIs;

}


void endGame() // shows the end of the game
{
  for (int x = 0; x <= currentNum; ++x)
  {
    sequence[x] = 0;
  }
  for(int i = 0; i < 3; i++ )
  {
      digitalWrite(led_pin[0], HIGH);
      digitalWrite(led_pin[1], HIGH);
      digitalWrite(led_pin[2], HIGH);
      digitalWrite(led_pin[3], HIGH);
      delay (500);
      digitalWrite(led_pin[0], LOW);
      digitalWrite(led_pin[1], LOW);
      digitalWrite(led_pin[2], LOW);
      digitalWrite(led_pin[3], LOW);
      delay (500);
  }
  currentNum = 2;
  roundNum = 0;
  timeBtwnLED = 500;
  int pin = 2;
  for (int segCount = 0; segCount < 7; ++segCount)
  {
    digitalWrite(pin, seven_segment_digits[roundNum][segCount]);
    ++pin;
  }
  delay (500);
}

void victoryLights() //modified Fade from Energia Examples
{
    int brightness = 0;    // how bright the LED is
    int fadeAmount = 20;    // how many points to fade the LED by, variable to change speed
    int color = 0;        //color of current LED
    int numLoops = 0;
    int colors[3]= {RED, GREEN, BLUE};

    while(numLoops < 5)//# of times to shine victory light sequence
    {
    analogWrite(colors[color], brightness);

    // change the brightness for next time through the loop:
    brightness = brightness + fadeAmount;

    // reverse the direction of the fading at the ends of the fade:
    if (brightness == 0 || brightness >= 255)
    {
      fadeAmount = -fadeAmount ;
    }

    if (brightness == 0)
    {
      analogWrite(colors[color], brightness);
      color++;
      if (color == 3)
      {
        color = 0;
        numLoops++;
      }
    }

    // wait for 30 milliseconds to see the dimming effect
    delay(30);
  }
}

void victoryDisplay() //Celebrate!
{
  for(int cycles = 0; cycles < 10; ++cycles)
  {
    for(int count = 0; count< 5; ++count)
    {
      int pin = 2;
      for (int segCount = 0; segCount < 7; ++segCount) {
        digitalWrite(pin, seven_segment_celebrate[count][segCount]);
        ++pin;
      }
      delay(30);
    }
  }
}

void game() //this is the whole game. it is basically a loop with instructions
{
  int answer = HIGH;
  int pin = 2;
  ++roundNum;
  for (int segCount = 0; segCount < 7; ++segCount) {
     digitalWrite(pin, seven_segment_digits[roundNum][segCount]);
     ++pin;
  }
  do
  {
    //generates and displays the sequence
    makeSequence();
    showSequence();

    for (int i = 0; i <= currentNum; ++i )
    {
     //checks the user input
     answer = checkSequence(sequence[i]);
     if (answer == LOW) //wrong answer
     {
      //RGB LED lights up red
      digitalWrite(RED_LED, HIGH);
      delay(3000);
      digitalWrite(RED_LED, LOW);
      delay(1000);
      break;
     }
    }
    if (answer == HIGH) //right answer
    {
      //RGB LED lights up green
      digitalWrite(GREEN_LED, HIGH);
      delay(3000);
      digitalWrite(GREEN_LED, LOW);
      delay(500);
      //calls the update round function
      nextRound();
    }
    if (roundNum >= 9) //Game end
    {
      victoryLights();
      victoryDisplay();
      break;
    }
  }
  while (answer == HIGH);

}


void splashScreen() //This waits for the user to start tha game
{
  int check = 0;
  //stays in the loop until the check = 1, given by checkSwitch()
  do
  {
    check = checkSwitch();
    long timeStart = millis();
    do
    {
      digitalWrite(led_pin[0],HIGH);
      check = checkSwitch();
      if (check == 1)
      break;
    }
    while (millis() <= timeStart + splashTime);
    check = checkSwitch();
    timeStart = millis();
    do
    {
      digitalWrite(led_pin[0],LOW);
      check = checkSwitch();
      if (check == 1)
        break;
      digitalWrite(led_pin[1],HIGH);
    }
    while (millis() <= timeStart + splashTime);
    check = checkSwitch();
    timeStart = millis();
    do
    {
      digitalWrite(led_pin[1],LOW);
      check = checkSwitch();
      if (check == 1)
        break;
      digitalWrite(led_pin[2],HIGH);
    }
    while (millis() <= timeStart + splashTime);
    check = checkSwitch();
    timeStart = millis();
    do
    {
      digitalWrite(led_pin[2],LOW);
      check = checkSwitch();
      if (check == 1)
        break;
      digitalWrite(led_pin[1],HIGH);
    }
    while (millis() <= timeStart + splashTime);
    check = checkSwitch();
    digitalWrite(led_pin[1],LOW);
    check = checkSwitch();
    if (check == 1)
      break;
  }
  while(check == 0);
  delay(1000);

}


int checkSwitch() //checks the state of switch and returns 1 or 0
{
  debounceSwitch();
  if ((digitalRead(swch_pin) == LOW))
  {
    return 1;
  }
  else
    return 0;
}


void setup()
{
  randomSeed(analogRead(0));

  pinMode(GREEN, OUTPUT);
  pinMode(BLUE, OUTPUT);
  pinMode(RED, OUTPUT);

  //pins for the 7 segment display
  pinMode(2, OUTPUT); // set segment A as output
  pinMode(3, OUTPUT); // set segment B as output
  pinMode(4, OUTPUT); // set segment C as output
  pinMode(5, OUTPUT); // set segment D as output
  pinMode(6, OUTPUT); // set segment E as output
  pinMode(7, OUTPUT); // set segment F as output
  pinMode(8, OUTPUT); // set segment G as output

  pinMode(9, INPUT); // set tilt switch as input

  for (int i=0; i<3; ++i)
  {
    pinMode(btn_pin[i],INPUT_PULLUP); // set each button as pull up input
    pinMode(led_pin[i],OUTPUT); // set each LED as output
  }
}

void loop()
{
  splashScreen();
  game();
  endGame();
}
