Heart of The Hustle: Cardio Counts in Pull-Up

Lets make PE teachers' and students' life by making an all in one ID scanner, pull-up counter, and a heart rate measuring device!

IntermediateProtip11 hours127

Heart of The Hustle: Cardio Counts in Pull-Up

Things used in this project

Hardware components

M5Stack Mini RFID Unit RC522 Module Sensor

M5Stack FIRE IoT Development Kit (PSRAM 2.0)

ProtoCentral Electronics ProtoCentral Pulse Oximeter & Heart Rate Sensor based on MAX30100

M5Stack Time-of-Flight (ToF) VL53L0X Laser Ranging Unit (MCP4725/)

M5Stack Mini Angle Unit Potentiometer Inside

Software apps and online services

UI Flow

Story

My team and I, students from Nanyang Polytechnic Singapore, were assigned the task of identifying a problem and implementing a solution using the M5Stack kit set. Our lecturer presented the problem statement: "How can we design a sustainable technology solution in retail, urban farming, smart factory, or healthy lifestyle?" We opted to address the healthy lifestyle aspect, utilizing the M5Stack, Angle sensor, RFID unit, ToF unit, and a Heart Pulse Rate sensor.

Our project is intended for secondary schools, aiming to assist both teachers and students. Specifically, we focused on the NAPFA pull-up test, which is conducted for secondary 2 and 4 students. Further details about our project will be provided in the next paragraph.

Figure 1. A secondary student doing pull ups

We, as a team, discussed how we can address a healthy lifestyle. We decided to create a healthy lifestyle device that can scan a student’s card to identify them, count the number of pull-ups the student can do, and measure their pulse rate simultaneously.

Figure 2. RFID sensor

Firstly, we utilized the RFID sensor (Figure 2), which enables us to identify the individual performing pull-ups by reading the admin card data and matching it to the data in the system. If there is no admin card on the RFID sensor, the entire circuit will not function.

Figure 3. Heart rate sensor

Secondly, we incorporated the heart rate sensor (Figure 3). After the user places the admin card on the RFID sensor, they must place their finger on the heart rate sensor, and the heart rate will be displayed on the M5 stack.

Figure 4. Angle sensor

Thirdly, we employed the angle sensor (Figure 4) as a switch to turn the circuit on and off. When the angle sensor is turned to 1024, the circuit will be activated, and when it is turned to 0, it will be turned off.

figure 5. TOF sensor

Finally, we used the TOF sensor (Figure 5) to measure the number of pull-ups the user has done. When the user ascends 10 cm, the sensor will increment by 1, indicating that 1 pull-up has been completed. This process continues until the user is unable to perform more pull-ups or the time limit is reached.

Figure 6. This is the output before doing the pull ups

Once the user has completed the pull-ups, they need to press the buttons on the M5 stack to indicate how many pull-ups they have done. Button A represents less than 2 pull-ups, Button B is more than or equal to 3 pull-ups but less than or equal to 5 pull-ups, and Button C is more than or equal to 6 pull-ups. When the user presses the button, the LED will change from pink to blue and then to grey, signifying that the data has been sent to Google Sheets, which will update a graph displaying statistics for all individuals who performed pull-ups. If the LED turns red, it indicates an error, and the program must be restarted.

Figure 7. Project Postal

Figure 8. Flowchart

In conclusion, our team has successfully developed a comprehensive and innovative solution to tackle the challenge of promoting a healthy lifestyle, with a specific focus on the NAPFA pull-up test for secondary school students. Our healthy lifestyle device, tailored for the NAPFA pull-up test, not only meets academic requirements but also serves as a testament to the potential of technology to positively impact education and foster healthier living habits among the youth.

You may access my team's presentation as well as how the coding was done here!

Code

Python Code

from m5stack import *
from m5ui import *
from uiflow import *
import wifiCfg
import time
import urequests
import unit

setScreenColor(0x222222)
tof_1 = unit.get(unit.TOF, unit.PORTA)
rfid_1 = unit.get(unit.RFID, unit.PORTA)
heart_1 = unit.get(unit.HEART, unit.PORTA)
angle_2 = unit.get(unit.ANGLE, unit.PORTB)


number = None
distance = None
detected = None
count = None
Heartrate = None

wifiCfg.doConnect("Ur mom's eyebrows", 'addpasswordhere')

label0 = M5TextBox(0, 8, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label6 = M5TextBox(0, 78, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label7 = M5TextBox(0, 36, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label8 = M5TextBox(0, 162, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label1 = M5TextBox(0, 137, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label9 = M5TextBox(144, 112, "Distance", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label2 = M5TextBox(144, 36, "No. of pull ups", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label3 = M5TextBox(278, 36, "0", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label10 = M5TextBox(255, 111, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label4 = M5TextBox(144, 78, "Heart rate", lcd.FONT_Default, 0xf4f4f4, rotate=0)
circle0 = M5Circle(267, 162, 15, 0xFFFFFF, 0xFFFFFF)
label5 = M5TextBox(259, 78, "Text", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label11 = M5TextBox(46, 214, "=<2", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label12 = M5TextBox(123, 214, ">=3,=<5", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label13 = M5TextBox(233, 214, ">=6", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label14 = M5TextBox(46, 187, "Press A,B,C for No. of pull up", lcd.FONT_Default, 0xFFFFFF, rotate=0)

from numbers import Number



def buttonC_wasPressed():
  global number, distance, detected, count, Heartrate
  circle0.setBgColor(0xff99ff)
  wait_ms(500)
  try:
    req = urequests.request(method='GET', url='https://maker.ifttt.com/trigger/ESP32_GoogleSheets/with/key/bJIH8SMHtQtPQwMsUHGC40?value1=>=6')
    circle0.setBgColor(0x3366ff)
    wait_ms(500)
    circle0.setBgColor(0x999999)
  except:
    circle0.setBgColor(0xff0000)
  pass
btnC.wasPressed(buttonC_wasPressed)

def buttonA_wasPressed():
  global number, distance, detected, count, Heartrate
  circle0.setBgColor(0xff99ff)
  wait_ms(500)
  try:
    req = urequests.request(method='GET', url='https://maker.ifttt.com/trigger/ESP32_GoogleSheets/with/key/bJIH8SMHtQtPQwMsUHGC40?value1=<=2')
    circle0.setBgColor(0x3366ff)
    wait_ms(500)
    circle0.setBgColor(0x999999)
  except:
    circle0.setBgColor(0xff0000)
  pass
btnA.wasPressed(buttonA_wasPressed)

def buttonB_wasPressed():
  global number, distance, detected, count, Heartrate
  circle0.setBgColor(0xff99ff)
  wait_ms(500)
  try:
    req = urequests.request(method='GET', url='https://maker.ifttt.com/trigger/ESP32_GoogleSheets/with/key/bJIH8SMHtQtPQwMsUHGC40?value1=>=3,=<5')
    circle0.setBgColor(0x3366ff)
    wait_ms(500)
    circle0.setBgColor(0x999999)
  except:
    circle0.setBgColor(0xff0000)
  pass
btnB.wasPressed(buttonB_wasPressed)


if wifiCfg.wlan_sta.isconnected():
  circle0.setBgColor(0x33ff33)
detected = False
number = 0
while True:
  if (rfid_1.readUid()) == 'a491691945':
    label6.setText(str(rfid_1.readUid()))
    label7.setText('Jovan')
    label8.setText(str(angle_2.read()))
    Heartrate = heart_1.getHeartRate()
    label5.setText(str(Heartrate))
    if (angle_2.read()) == 1024:
      label1.setText('On')
      distance = (tof_1.distance) / 10
      label10.setText(str(distance))
      if distance <= 7:
        detected = True
      if distance > 10 and detected == True:
        detected = False
        number = (number if isinstance(number, Number) else 0) + 1
        label3.setText(str(number))
    else:
      label1.setText('Off')
  else:
    if rfid_1.isCardOn():
      label6.setText(str(rfid_1.readUid()))


label7.setText('New user')
      label8.setText(str(angle_2.read()))
      Heartrate = heart_1.getHeartRate()
      label5.setText(str(Heartrate))
      if (angle_2.read()) == 1024:
        label1.setText('On')
        distance = (tof_1.distance) / 10
        label10.setText(str(distance))
        if distance <= 7:
          detected = True
        if distance > 10 and detected == True:
          detected = False
          number = (number if isinstance(number, Number) else 0) + 1
          label3.setText(str(number))
      else:
        label1.setText('Off')
    else:
      label0.setText('Please tap a card')
  wait_ms(2)
