DIY Tablet PC

This is my attempt at recreating the Surface Pro from Microsoft.

IntermediateFull instructions provided2 days3,716
DIY Tablet PC

Things used in this project

Hardware components

LattePanda 2GB/32GB (Unactivated)
LattePanda 2GB/32GB (Unactivated)
×1
7" screen
×1
PAM8403 2 Channel Audio Amplifier 3Wx2 with Volume Control
×1
Speaker: 3W, 4 ohms
Speaker: 3W, 4 ohms
I used a smaller speaker so it fits inside the case
×1
flat hdmi cable
Used to connect the screen to the lattepanda
×1
Powerbank charger circuit
This is the one I used to charge 4 18650 cells in parraler but you can use other li ion cahrgers
×1
Li-Ion Battery 1000mAh
Li-Ion Battery 1000mAh
I used 18650 cells but you can use any type of battery in combination with a charger that can supply 2 amps
×1

Software apps and online services

Windows 10
Microsoft Windows 10
You might need to activate windows,depending on the board you buy.

Hand tools and fabrication machines

3D Printer (generic)
3D Printer (generic)
Soldering iron (generic)
Soldering iron (generic)
Solder Wire, Lead Free
Solder Wire, Lead Free
Hot glue gun (generic)
Hot glue gun (generic)
Super Glue

Story

Read more

Custom parts and enclosures

Screen part

This is where you glue the screen in and over it you will have the electronics part. The enclosure is made by 3 parts: screen,electronics and lid all stacked on top of each other like a sandwich.

Electronics

You will glue this part on top of the screen after you put the scree in place and start fitting all the electnrocis inside!(supports generated because CuraEngine would not generate supports :/_

The lid

After you glued everything inside, test it out and glue the back piece and you should be done!

Schematics

Schematics

The tablet is made by parts and at the end everything is connected to each pother one by one
