"Mini-Vintage" Internet Radio

Vintage-style, minimal sized enclosure for a Raspberry-Pi + Arduino Internet Radio.

AdvancedFull instructions provided52,098

Things used in this project

Hardware components

Raspberry Pi 1 Model B+
Raspberry Pi 1 Model B+
×1
Arduino UNO
Arduino UNO
×1
LCD Keypad Shield for Arduino
×1
Miniature Wi-Fi Module
×1
DC Power Adapter (female)
×1
Power Supply (2A - 5V)
×1
Rotary Potentiometer w/ Switch
×1
Rotary Encoder (360°)
×1
Hook-up wire
×1
Pan Head Phillips Machine Screw (M2.5 x 8mm)
×4
Hex Nut (M2.5)
×4
Flat Head Phillips Screw (#2 x 3/8")
×4
Thread-Forming Screw for Plastic (2-28 x 3/8")
×4

Software apps and online services

Fusion
Autodesk Fusion

Hand tools and fabrication machines

3D Printer (generic)
3D Printer (generic)
Soldering iron (generic)
Soldering iron (generic)

Story

Read more

Custom parts and enclosures

Fusion 360 f3d file

Online 3D design
