Map Your Particles!

Locate your Particle Photons, P1s and Electrons on a map without needing extra hardware. Use Ubidots or an offline map alternative.

BeginnerProtip5 hours6,149

Things used in this project

Hardware components

Particle Photon

Particle Electron

Software apps and online services

The Google Maps Geolocation API

particle-device-locator

Google Maps

Ubidots

Story

In this write-up I'll tell you everything I learned about the Particle integration with Google Maps.

Wait a minute, location without GPS?

Yes! We can now find the location of our Particles without needing extra hardware (eg: a GPS module). This is possible because the Google Maps Geolocation API is able to return a location and an accuracy radius from visible Wi-Fi access points or cells towers. Pretty cool, huh?

Limitations

There are some limitations to this technique.

For a Photon, there must be WIFI spots open around it. They must be already captured by Google in some of their ways (scanned by their cars or by some Android phones contributing their data and location). So if you live in a rural area you may not be able to map your Photon this way.

For an Electron you must have cell towers that were already scanned by Google in some way. Else, you are out of luck.

The four common types of geolocation

Some theory, from the Particle site:

GPS (GLOBAL POSITIONING SYSTEM): The Global Positioning System (GPS) is generally the most accurate and it can provide device location continuously. Under normal conditions, GPS can locate a device with an accuracy of ~4 meters.

CELLULAR TOWER LOCATION: Every cell tower has an identifier, and this can be looked up using the Google Geolocation API to find its location. This process is fast and provides a general location, usually within 4000 meters or a couple miles.

WI-FI LOCATION: The Google Maps integration also supports this method of geolocation. Particle Photon and P1 (Wi-Fi) devices can collect visible Wi-Fi access points, and send these to the geolocation API in exchange for its location. Often times, Wi-Fi geolocation is more precise than cellular geolocation, often with an accuracy radius of 50 meters or less.

IP ADDRESS LOCATION: Particle Wi-Fi devices report their last IP address to the cloud, which could be used for this geolocation method. This is most often the least accurate of the 4 methods described in this section. This technique is not used by the Particle-Google Maps integration.

Recap: this integration uses WI-FI and cellular tower location.

How to do this

Let's start setting things up.

STEP 1: get an API key. Go to this Google Maps Geolocation API link and hit on the GET A KEY button -> create a new project -> enter the name and hit CREATE AND ENABLE API.

1 / 2 • Get a key, create a new project and hit CREATE AND ENABLE API

To check your API keys, hit the Google Developer Credentials Console at any time.

If you get lost follow the Particle docs here.

Step 2: create the Particle-Google Maps integration on this link. You'll need the api key you got on step 1.

To ensure things are OK so far, hit the TEST button. You should get a Success popup at the bottom right.

Again, in case of trouble check the Particle docs.

Step 3: flash your particle with the code on this repo.

Now let's map it! There are many options to do this. In the following sections we'll explore a couple of them.

Map it on particle device locator

In this section we'll use the particle device locator.

Step a: Install the Google Cloud SDK.

Step b: once you installed the SDK, set it up by running in a console:

gcloud init

Step c: authenticate your SDK with the Google Cloud Platform:

gcloud beta auth application-default login

Step d: clone the repo:

git clone https://github.com/kwnevarez/particle-device-locator

Note: If the previous command fails, it may mean that you don't have git installed on your computer. Please use this link to install it. Once finished, run the command again.

Step e: install the dependencies:

cd particle-device-locator
npm install

Note: If the previous command fails, it may mean that you don't have npm or nodeJS installed on your computer. Please use this link and this link to install them. Once finished, run the command again.

Step f: configure it, by entering in config.json the api key you got in step 1:

cd particle-device-locator
vi config.json

Note: vi is a command line editor. If you don't have it around you can use notepad, nano, or anything you like to edit the config.json file (or my favorite: VS Code).

It should end up looking like this:

{
   "map_api_key": "AIzaSyDcuB2m-y7XxvFpIcNeeLP2MJCGLpm4lxs",
   "event_name": "deviceLocator"
}

HINT: use your api key, not mine (mine won't work - it's deactivated already...)

Step g: on the Google Developer Credentials Console, enable the google maps javascript API . It looks like this:

1 / 2 • You want to enable that JavaScript API

Step h: run it:

npm install

Step i: open it at http://localhost:8080. After logging in with your Particle credentials, you should be facing a map. Hitting All devices on the top right maps your particles with a red arrow like this:

1 / 2 • Los Roques, Venezuela, oh how I wish I were writing this article from those beaches...

Map it on Ubidots

In this section we'll use Ubidots.

Step a: flash the attached code (maps.ino) in your Particle or add a publish like this in your locationCallback() function:

 Particle.publish("ubidotsLatLong", "{\"ubi-dsl-vl\":\"" + Particle.deviceID() + "/" + name + "\", \"ubi-token\":\"" + ubidotsToken + "\", \"ubi-value\":\"" + value + "\" , \"google-lat\":\"" + lat + "\" , \"google-lng\":\"" + lon + "\"}", 60, PRIVATE);

Step b: setup a webhook hitting the Ubidots HTTPS API. Go to the particle integrations and hit NEW INTEGRATION. This is the webhook information:

Event name: ubidotsLatLong
url: https://things.ubidots.com/api/v1.6/devices/{{ubi-dsl-vl}}/values/?token={{ubi-token}}
Request type: POST
Device: Any
Advanced settings:
Send custom data: JSON

And then enter:

   {
      "value": "{{ubi-value}}",
      "context": {
        "lat": " {{google-lat}}",
        "lng": "{{google-lng}}"
      }
    }

include default data: no
enforce ssl: yes

This is what the webhook is doing for us:

The webhook is sending lat/long coordinates to Ubidots

Step c: Get an account on Ubidots. You can start using it for free.

Step d: Create a dashboard by hitting the Dashboard tab on top and then hitting the yellow + to add a dashboard.

Step e: Add a new map widget (note the button on the top right corner):

Adding a map widget

Step f: select the geo variable on the device that is sending this data and hit on Add variable then Finish

Select the variable with lat/long coordinates info

Step g: Enjoy looking at the location of your Particle:

It's right there!

References

These links helped me get started on Ubidots:

Conclusion

Particle, Google Maps and Ubidots made it really easy to put our projects on a map, without needing to add a GPS to our hardware. Impressive!

Need help?

If you require professional help with your projects, don't hesitate to write me a line about your needs at gusgonnet@gmail.com. Thank you!

maps.ino

#include <google-maps-device-locator.h>

// NOTE: localData.h should contain the ubidots token in this form:
// This value comes from ubidots -> menu -> API keys -> Authentication token
// #define UBIDOTS_TOKEN "skljfhsakldjdfh29841283840922324"
// Alternatively, do not create localData.h, remove line 8 below
// and define UBIDOTS_TOKEN in the current file
#include "localData.h"

/*******************************************************************************
 ubidots variables

 webhook definition:
  Event name: ubidotsLatLong
  url: https://things.ubidots.com/api/v1.6/devices/{{ubi-dsl-vl}}/values/?token={{ubi-token}}
  Request type: POST
  Device: Any
  Advanced settings:
  Send custom data: JSON
  and then enter:

    {
      "value": "{{ubi-value}}",
      "context": {
        "lat": " {{google-lat}}",
        "lng": "{{google-lng}}"
      }
    }

  include default data: no
  enforce ssl: yes
*******************************************************************************/
// This value comes from ubidots
const String ubidotsToken = UBIDOTS_TOKEN;


GoogleMapsDeviceLocator locator;

#define APP_NAME "googleMaps"
String VERSION = "Version 0.01";
/*******************************************************************************
 * changes in version 0.01:
       * Initial version
*******************************************************************************/


SYSTEM_MODE(AUTOMATIC);

void setup()
{
  Particle.publish(APP_NAME, VERSION, PRIVATE);

  // Scan for visible networks and publish to the cloud every 30 seconds
  // Pass the returned location to be handled by the locationCallback() method
  locator.withSubscribe(locationCallback).withLocatePeriodic(60);
}

void loop() {
  locator.loop();
}

void locationCallback(float lat, float lon, float accuracy) {
  // Handle the returned location data for the device. This method is passed three arguments:
  // - Latitude
  // - Longitude
  // - Accuracy of estimated location (in meters)

  String name = "geo";
  String value = "1"; //dummy value

  Particle.publish("ubidotsLatLong", "{\"ubi-dsl-vl\":\"" + Particle.deviceID() + "/" + name + "\", \"ubi-token\":\"" + ubidotsToken + "\", \"ubi-value\":\"" + value + "\" , \"google-lat\":\"" + lat + "\" , \"google-lng\":\"" + lon + "\"}", 60, PRIVATE);
}

Credits

gusgonnet

37 projects • 306 followers

With a decade of Software Engineering experience in IoT, I focus on creating Particle IoT solutions coupled with mobile and web applications

Thanks to Winston Ford.
