Hardware components | ||||||
 |
| × | 1 | |||
Software apps and online services | ||||||
 |
| |||||
 |
| |||||
Want to cook but not sure what? Tell Alexa what's on hand and get a list of recipes! You can find the skill here. Let's get started...
AWS LambdaTo generate our recipe lists we'll use Recipe Puppy's public API.
- Go to the AWS Portal
Click Lambda under the Compute group
- Create a Lambda function using the Blank Function template
- For the trigger click on the dotted box on the left and choose Alexa Skills Kit
- On the next screen, name the function Kitchen Sink, pick Node.js 4.3 for the runtime, paste in the code from the index.js file in GitHub (or copy it from below)
Name and code your function
- Pick lambda_basic_execution for the Execution Policy then continue onward. If there isn't a basic execution role set up yet choose Create new role from template(s) for Role. Set the Role Name to "lambda_basic_execution" and select Basic Lambda Permissions from the Policy Templates. This permission set defines what amazon services the function will have access to.
1 / 2 • Select an existing role
'use strict';
var http = require('http');
var maxPage = 100;
function buildSpeechletResponse(title, output, repromptText, shouldEndSession) {
return {
outputSpeech: {
type: 'PlainText',
text: output,
},
card: {
type: 'Simple',
title: `${title}`,
content: `${output}`,
},
reprompt: {
outputSpeech: {
type: 'PlainText',
text: repromptText,
},
},
shouldEndSession,
};
}
function buildResponse(sessionAttributes, speechletResponse) {
return {
version: '1.0',
sessionAttributes,
response: speechletResponse,
};
}
function startCooking(session, callback) {
getJson(
session,
function(results) {
const cardTitle = "Let's Cook";
const shouldEndSession = false;
var speechOutput = "";
var repromptText = "";
if (!results) {
speechOutput = "I was unable to find any recipes containing "
+ session.attributes.ingredients.join(" ")
+ " Try removing an ingredient.";
repromptText = "Try saying, remove " + session.attributes.ingredients[0];
} else if (results.length <= session.attributes.currentIndex) {
speechOutput = "I was unable to find any more recipes containing "
+ session.attributes.ingredients.join(" ")
+ " Try removing an ingredient.";
repromptText = "Try saying, remove " + session.attributes.ingredients[0];
} else {
var title = results[session.attributes.currentIndex].title.replace(/\n/g, '');
session.attributes.lastResult = results;
speechOutput = "Does " + title + " sound good?";
repromptText = 'Or maybe you want to add an ingredient?';
}
const sessionAttributes = session.attributes;
callback(sessionAttributes,
buildSpeechletResponse(cardTitle, speechOutput, repromptText, shouldEndSession));
}
);
}
function startHelp(callback) {
const sessionAttributes = {};
const cardTitle = "Let's Cook";
const speechOutput = "Are you looking around the kitchen wondering what you can make? "
+ "Ask me what can I make with cucumbers and beets. Toss in some chicken. "
+ "Nevermind the beets. And I'll make recipe suggestions.";
const repromptText = "I'm getting hungry just thinking about it.";
const shouldEndSession = false;
callback(sessionAttributes,
buildSpeechletResponse(cardTitle, speechOutput, repromptText, shouldEndSession));
}
function sendRecipe(session, callback) {
if (!session.attributes ||
!session.attributes.lastResult ||
!session.attributes.lastResult.length ||
session.attributes.lastResult.length <= session.attributes.currentIndex
) {
return startHelp(callback);
}
var currentRecipe = session.attributes.lastResult[session.attributes.currentIndex];
const sessionAttributes = session.attributes;
const speechOutput = "Open the Alexa app for a link to the recipe.";
const repromptText = "";
const shouldEndSession = true;
var speechletResponse = buildSpeechletResponse(currentRecipe.title, speechOutput, repromptText, shouldEndSession);
speechletResponse.card = {
type: "Standard",
title: currentRecipe.title,
text: currentRecipe.href
};
callback(sessionAttributes, speechletResponse);
}
function nextRecipe(session, callback) {
const cardTitle = "Let's Cook";
const shouldEndSession = false;
const sessionAttributes = session.attributes;
var speechOutput, repromptText;
if (!session.attributes ||
!session.attributes.lastResult ||
!session.attributes.lastResult.length
) {
return startHelp(callback);
} else if (session.attributes.lastResult.length <= session.attributes.currentIndex) {
speechOutput = "I was unable to find any more recipes containing "
+ session.attributes.ingredients.join(" ")
+ " Try removing an ingredient.";
repromptText = "Try saying, remove " + session.attributes.ingredients[0];
return callback(sessionAttributes,
buildSpeechletResponse(cardTitle, speechOutput, repromptText, shouldEndSession));
}
var nextRecipe = session.attributes.lastResult[session.attributes.currentIndex];
var title = nextRecipe.title.replace(/\n/g, '');
speechOutput = "Does " + title + " sound good?";
repromptText = 'Or maybe you want to add an ingredient?';
callback(sessionAttributes,
buildSpeechletResponse(cardTitle, speechOutput, repromptText, shouldEndSession));
}
function handleSessionEndRequest(callback) {
const cardTitle = "Let's Cook";
const speechOutput = 'Bone app petite';
const shouldEndSession = true;
callback({}, buildSpeechletResponse(cardTitle, speechOutput, null, shouldEndSession));
}
function onSessionStarted(sessionStartedRequest, session) {
console.log(`onSessionStarted requestId=${sessionStartedRequest.requestId}, sessionId=${session.sessionId}`);
}
function onLaunch(launchRequest, session, callback) {
console.log(`onLaunch requestId=${launchRequest.requestId}, sessionId=${session.sessionId}`);
if (!session.attributes) {
session.attributes = {};
}
if (!session.attributes.ingredients) {
session.attributes.ingredients = [];
}
if (!session.attributes.currentIndex) {
session.attributes.currentIndex = 0;
}
startCooking(session, callback);
}
function onIntent(intentRequest, session, callback) {
console.log(`onIntent requestId=${intentRequest.requestId}, sessionId=${session.sessionId}`);
const intent = intentRequest.intent;
const intentName = intentRequest.intent.name;
if (!session.attributes) {
session.attributes = {};
}
if (!session.attributes.ingredients) {
session.attributes.ingredients = [];
}
if (!session.attributes.currentIndex) {
session.attributes.currentIndex = 0;
}
var newIngredientsList = [];
if (intentName === 'NewIngredientIntent') {
session.attributes.currentIndex = 0;
if (intent.slots.ingredients && intent.slots.ingredients.value) {
session.attributes.ingredients = intent.slots.ingredients.value.split(" ");
} else {
session.attributes.ingredients = [];
}
startCooking(session, callback);
} else if (intentName === 'AddIngredientIntent') {
session.attributes.currentIndex = 0;
var ingredientsToAdd = intent.slots.ingredients;
if (ingredientsToAdd.value) {
var ingredientsToAddArray = ingredientsToAdd.value.split(" ");
newIngredientsList = session.attributes.ingredients.concat(ingredientsToAddArray);
newIngredientsList = newIngredientsList.filter(
function(value, index, self) {
return self.indexOf(value) === index;
}
);
session.attributes.ingredients = newIngredientsList;
}
startCooking(session, callback);
} else if (intentName === 'RemoveIngredientIntent') {
session.attributes.currentIndex = 0;
var ingredientsToRemove = intent.slots.ingredients;
if (ingredientsToRemove.value) {
var i;
var ingredientsToRemoveArray = ingredientsToRemove.value.split(" ");
for (i = 0; i < session.attributes.ingredients.length; i++) {
if (ingredientsToRemoveArray.indexOf(session.attributes.ingredients[i]) === -1) {
newIngredientsList.push(session.attributes.ingredients[i]);
}
}
session.attributes.ingredients = newIngredientsList;
}
startCooking(session, callback);
} else if (intentName === 'AMAZON.YesIntent') {
// send recipe to card
sendRecipe(session, callback);
} else if (intentName === 'AMAZON.NoIntent') {
session.attributes.currentIndex++;
// get read next suggestion
nextRecipe(session, callback);
} else if (intentName === 'AMAZON.HelpIntent') {
startHelp(callback);
} else if (intentName === 'AMAZON.StopIntent' || intentName === 'AMAZON.CancelIntent'|| intentName === 'AMAZON.NoIntent') {
handleSessionEndRequest(callback);
} else {
throw new Error('Invalid intent');
}
}
function onSessionEnded(sessionEndedRequest, session) {
console.log(`onSessionEnded requestId=${sessionEndedRequest.requestId}, sessionId=${session.sessionId}`);
// Add cleanup logic here
}
function getJson(session, eventCallback) {
var url = "http://www.recipepuppy.com/api/?i=";
if (session.attributes.ingredients.length === 0) {
var page = Math.random() * (maxPage - 1) + 1;
url += "&p=" + page;
}
else {
url += session.attributes.ingredients.join(',');
}
http.get(url, function(res) {
var body = '';
if (res.statusCode !== 200) {
eventCallback(false);
return;
}
res.on('data', function (chunk) {
body += chunk;
});
res.on('end', function () {
var result = JSON.parse(body);
eventCallback(result.results);
});
}).on('error', function (e) {
console.log("Got error: ", e);
});
}
// --------------- Main handler -----------------------
// Route the incoming request based on type (LaunchRequest, IntentRequest,
// etc.) The JSON body of the request is provided in the event parameter.
exports.handler = (event, context, callback) => {
try {
console.log(`event.session.application.applicationId=${event.session.application.applicationId}`);
if (event.session.application.applicationId !== 'INSERT-SKILL-ID-HERE') {
callback('Invalid Application ID');
}
if (event.session.new) {
onSessionStarted({ requestId: event.request.requestId }, event.session);
}
if (event.request.type === 'LaunchRequest') {
onLaunch(event.request,
event.session,
(sessionAttributes, speechletResponse) => {
callback(null, buildResponse(sessionAttributes, speechletResponse));
});
} else if (event.request.type === 'IntentRequest') {
onIntent(event.request,
event.session,
(sessionAttributes, speechletResponse) => {
callback(null, buildResponse(sessionAttributes, speechletResponse));
});
} else if (event.request.type === 'SessionEndedRequest') {
onSessionEnded(event.request, event.session);
callback();
}
} catch (err) {
callback(err);
}
};
- Once the function is created, find the ARN in the upper right, it should look like arn:aws:lambda:us-east-1:{UniqueID}:function:KitchenSink. Save it for later.
- Keep the tab open, we'll need the Skill Id in a bit.
Now that we have the backend set up to handle requests, we'll need to configure the frontend.
- Go to the Amazon developer portal
- Click the Alexa tab
- Choose the Alexa Skills Kit
- Click Add a New Skill
- For Skill Information set the name to Kitchen Sink and give "kitchen sink" for the invocation name
- Under the Interaction Model set the Intent Schema to
{
"intents": [
{
"intent": "NewIngredientIntent",
"slots": [
{
"name": "ingredients",
"type": "INGREDIENTS"
}
]
},
{
"intent": "AddIngredientIntent",
"slots": [
{
"name": "ingredients",
"type": "INGREDIENTS"
}
]
},
{
"intent": "RemoveIngredientIntent",
"slots": [
{
"name": "ingredients",
"type": "INGREDIENTS"
}
]
},
{
"intent": "AMAZON.YesIntent"
},
{
"intent": "AMAZON.NoIntent"
},
{
"intent": "AMAZON.StopIntent"
},
{
"intent": "AMAZON.CancelIntent"
},
{
"intent": "AMAZON.HelpIntent"
}
]
}
and create a Custom Slot Type named INGREDIENTS with the following values
avocado
edamame
cucumber
eggs
curry
olives
hoison
scallions
steak
portobello
mushroom
beans
cheese
pasta
basil
mussels
pesto
fish
salmon
halibut
cod
bread
pistachios
milk
chocolate
cocoa
chocolate chips
whipped cream
cream
sugar
powdered sugar
brown sugar
butter
margarine
cilantro
pineapple
bacon
ginger
sausage
shrimp
garlic
paprika
rice
barley
oats
flour
peas
squash
pumpkin
blueberries
strawberries
apple
orange
banana
kiwi
watermelon
lemon
lime
chicken
pork
beef
peanuts
almonds
pecans
nutmeg
turmeric
rosemary
sage
parsley
salt
pepper
peppers
bell pepper
ham
celery
tomato
potato
corn
carrots
sprouts
vinegar
onion
artichoke
saffron
and for sample utterances put
NewIngredientIntent give me recipes for {ingredients}
NewIngredientIntent i need recipes for {ingredients}
NewIngredientIntent what can I make with {ingredients}
NewIngredientIntent what can I cook with {ingredients}
NewIngredientIntent what can I make from {ingredients}
AddIngredientIntent {ingredients}
AddIngredientIntent add {ingredients}
AddIngredientIntent with {ingredients}
AddIngredientIntent add {ingredients}
AddIngredientIntent toss in {ingredients}
AddIngredientIntent some {ingredients}
AddIngredientIntent {ingredients} as well
AddIngredientIntent {ingredients} too
RemoveIngredientIntent remove {ingredients}
RemoveIngredientIntent scratch {ingredients}
RemoveIngredientIntent nevermind the {ingredients}
RemoveIngredientIntent never mind the {ingredients}
RemoveIngredientIntent forget the {ingredients}
RemoveIngredientIntent minus the {ingredients}
RemoveIngredientIntent without the {ingredients}
- In the Configuration tab select AWS Lambda ARN and choose North America, then paste in the ARN from your lambda function.
- Now we can go back to the Lambda function and bind it to this skill. Towards the top of the page, in small font, you should see an ID like amzn1.echo-sdk-ams.app.{UniqueID} Copy it. Back in the lamba function go to line 241 in the code and replace the placeholder id with the skill id
- For the Publishing Information tab select Food & Drink for the Category and Cooking & Recipes for the Sub Category. After some basic testing instructions and skill descriptions put "Alexa, ask kitchen sink what can I make with avocado.", "Toss in tomato." and "Never mind the avocado." for the Example Phrases. Upload the icons from the GitHub repo or copy them from this page (I also highly recommend vectr for online vector graphics) and then it's on to Privacy.
- For Privacy and Compliance say No to everything and check the box for Export Compliance.
- Finally, you can hit that sweet, sweet Submit for Certification button. With any luck it will be listed on the store for all to enjoy.
Congratulations! Now you're Alexa enabled device has a little more Betty Crocker in her!
Comments
