Shield Your Fruits with XIAO: A DIY Fruit Protector Tutorial

# include <Arduino.h>
# include <U8x8lib.h>
# include "DHT.h"

# define DHTPIN D5 // what pin we're connected to

// Uncomment whatever type you're using!
# define DHTTYPE DHT10 // DHT 11
// #define DHTTYPE DHT22   // DHT 22  (AM2302)
// #define DHTTYPE DHT21   // DHT 21 (AM2301)

DHT dht(DHTPIN, DHTTYPE);

U8X8_SSD1306_128X64_NONAME_HW_I2C u8x8(/*reset=*/U8X8_PIN_NONE);
// U8X8_SSD1306_128X64_NONAME_SW_I2C u8x8(/*clock=*/ SCL, /*data=*/ SDA, /*reset=*/ U8X8_PIN_NONE);   // OLEDs without Reset of the Display

static char recv_buf[512];
static bool is_exist = false;
static bool is_join = false;
static int led = 0;

static int at_send_check_response(char *p_ack, int timeout_ms, char*p_cmd, ...)
{
    int ch;
    int num = 0;
    int index = 0;
    int startMillis = 0;
    va_list args;
    memset(recv_buf, 0, sizeof(recv_buf));
    va_start(args, p_cmd);
    Serial1.printf(p_cmd, args);
    Serial.printf(p_cmd, args);
    va_end(args);
    delay(200);
    startMillis = millis();

    if (p_ack == NULL)
    {
        return 0;
    }

    do
    {
        while (Serial1.available() > 0)
        {
            ch = Serial1.read();
            recv_buf[index++] = ch;
            Serial.print((char)ch);
            delay(2);
        }

        if (strstr(recv_buf, p_ack) != NULL)
        {
            return 1;
        }

    } while (millis() - startMillis < timeout_ms);
    return 0;
}

static void recv_prase(char *p_msg)
{
    if (p_msg == NULL)
    {
        return;
    }
char*p_start = NULL;
    int data = 0;
    int rssi = 0;
    int snr = 0;

    p_start = strstr(p_msg, "RX");
    if (p_start && (1 == sscanf(p_start, "RX: \"%d\"\r\n", &data)))
    {
        Serial.println(data);
        u8x8.setCursor(2, 4);
        u8x8.print("led :");
        led = !!data;
        u8x8.print(led);
        if (led)
        {
            digitalWrite(LED_BUILTIN, LOW);
        }
        else
        {
            digitalWrite(LED_BUILTIN, HIGH);
        }
    }

    p_start = strstr(p_msg, "RSSI");
    if (p_start && (1 == sscanf(p_start, "RSSI %d,", &rssi)))
    {
        u8x8.setCursor(0, 6);
        u8x8.print("                ");
        u8x8.setCursor(2, 6);
        u8x8.print("rssi:");
        u8x8.print(rssi);
    }
    p_start = strstr(p_msg, "SNR");
    if (p_start && (1 == sscanf(p_start, "SNR %d", &snr)))
    {
        u8x8.setCursor(0, 7);
        u8x8.print("                ");
        u8x8.setCursor(2, 7);
        u8x8.print("snr :");
        u8x8.print(snr);
    }
}

void setup(void)
{
    u8x8.begin();
    u8x8.setFlipMode(1);
    u8x8.setFont(u8x8_font_chroma48medium8_r);

    Serial.begin(115200);
    pinMode(LED_BUILTIN, OUTPUT);
    digitalWrite(LED_BUILTIN, HIGH);

    Serial1.begin(9600, SERIAL_8N1,44,43);
    Serial.print("E5 LORAWAN TEST\r\n");
    u8x8.setCursor(0, 0);
    // +ID: DevAddr, 42:00:1E:FA
    // +ID: DevEui, 2C:F7:F1:C0:42:80:01:65
    // +ID: AppEui, 80:00:00:00:00:00:00:09
    if (at_send_check_response("+AT: OK", 100, "AT\r\n"))
    {
        is_exist = true;
        at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
        at_send_check_response("+MODE: LWOTAA", 1000, "AT+MODE=LWOTAA\r\n");
        at_send_check_response("+DR: EU868", 1000, "AT+DR=EU868\r\n");
        at_send_check_response("+CH: NUM", 1000, "AT+CH=NUM,0-2\r\n");
        at_send_check_response("+KEY: APPKEY", 1000, "AT+KEY=APPKEY,\"AAE529D7C9DF2441E799EC77FDBF86BA\"\r\n");
        at_send_check_response("+CLASS: C", 1000, "AT+CLASS=A\r\n");
        at_send_check_response("+PORT: 8", 1000, "AT+PORT=8\r\n");
        delay(200);
        u8x8.setCursor(5, 0);
        u8x8.print("LoRaWAN");
        is_join = true;
    }
    else
    {
        is_exist = false;
        Serial.print("No E5 module found.\r\n");
        u8x8.setCursor(0, 1);
        u8x8.print("unfound E5 !");
    }

    dht.begin();

    u8x8.setCursor(0, 2);
    u8x8.setCursor(2, 2);
    u8x8.print("temp:");

    u8x8.setCursor(2, 3);
    u8x8.print("humi:");

    u8x8.setCursor(2, 4);
    u8x8.print("led :");
    u8x8.print(led);
}

void loop(void)
{

    float temp = 0;
    float humi = 0;

    temp = dht.readTemperature();
    humi = dht.readHumidity();

    Serial.print("Humidity: ");
    Serial.print(humi);
    Serial.print(" %\t");
    Serial.print("Temperature: ");
    Serial.print(temp);
    Serial.println(" *C");

    u8x8.setCursor(0, 2);
    u8x8.print("      ");
    u8x8.setCursor(2, 2);
    u8x8.print("temp:");
    u8x8.print(temp);
    u8x8.setCursor(2, 3);
    u8x8.print("humi:");
    u8x8.print(humi);

    if (is_exist)
    {
        int ret = 0;
        if (is_join)
        {

            ret = at_send_check_response("+JOIN: Network joined", 12000, "AT+JOIN\r\n");
            if (ret)
            {
                is_join = false;
            }
            else
            {
                at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
                Serial.print("JOIN failed!\r\n\r\n");
                delay(5000);
            }
        }
        else
        {
            char cmd[128];
            sprintf(cmd, "AT+CMSGHEX=\"%04X%04X\"\r\n", (int)temp, (int)humi);
            ret = at_send_check_response("Done", 5000, cmd);
            if (ret)
            {
                recv_prase(recv_buf);
            }
            else
            {
                Serial.print("Send failed!\r\n\r\n");
            }
            delay(5000);
        }
    }
    else
    {
        delay(1000);
    }
}
