Published July 24, 2019 © GPL3+

M5Stack Faces Joystick Simon Game

The classic '70s and '80s Simon game revived on the M5Stack and created fully in UIflow.

BeginnerWork in progress1 hour1,124

Things used in this project

Hardware components

M5Stack M5 Faces Pocket Computer with Keyboard/PyGamer/Calculator

Story

M5Stack Faces kits are now programmable in Uiflow. Let's see how to program a basic Simon memory game. Check out the following video for a step by step instruction of how to create this project.

M5stack Faces Simon Game Code

from m5stack import *
from m5ui import *
from uiflow import *
from emoji import Emoji
import face

setScreenColor(0x222222)



emoji0 = Emoji(7, 7, 15, 9)
faces_joystick = face.get(face.JOYSTICK)
label1 = M5TextBox(85, 104, "Text", lcd.FONT_DejaVu24,0xFFFFFF, rotate=0)
title1 = M5Title(title="Title", x=3 , fgcolor=0xFFFFFF, bgcolor=0x0000FF)

import random

directions = None
playing = None
sequence = None
input2 = None
i = None



directions = ['left', 'up', 'down', 'right']
playing = False
sequence = []
input2 = []
while True:
  emoji0.show_normal(3)
  title1.show()
  while playing == False:
    title1.setTitle('Get Ready')
    wait(1)
    sequence.append(directions[int(random.randint(0, 3) - 1)])
    wait_ms(100)
    for i in sequence:
      if i == 'left':
        emoji0.show_map([[0,0,0,1,0,0,0],[0,0,1,0,0,0,0],[0,1,0,0,0,0,0],[1,1,1,1,1,1,1],[0,1,0,0,0,0,0],[0,0,1,0,0,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
      elif i == 'up':
        emoji0.show_map([[0,0,0,1,0,0,0],[0,0,1,1,1,0,0],[0,1,0,1,0,1,0],[1,0,0,1,0,0,1],[0,0,0,1,0,0,0],[0,0,0,1,0,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
      elif i == 'down':
        emoji0.show_map([[0,0,0,1,0,0,0],[0,0,0,1,0,0,0],[0,0,0,1,0,0,0],[1,0,0,1,0,0,1],[0,1,0,1,0,1,0],[0,0,1,1,1,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
      else:
        emoji0.show_map([[0,0,0,1,0,0,0],[0,0,0,0,1,0,0],[0,0,0,0,0,1,0],[1,1,1,1,1,1,1],[0,0,0,0,0,1,0],[0,0,0,0,1,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
      wait_ms(500)
      emoji0.show_map([[0,0,0,0,0,0,0],[0,0,0,0,0,0,0],[0,0,0,0,0,0,0],[0,0,0,0,0,0,0],[0,0,0,0,0,0,0],[0,0,0,0,0,0,0],[0,0,0,0,0,0,0]], 0xFF0000)
      wait_ms(100)
      playing = True
  while playing == True:
    if (faces_joystick.X) < 300:
      wait_ms(200)
      input2.append('left')
      emoji0.show_map([[0,0,0,1,0,0,0],[0,0,1,0,0,0,0],[0,1,0,0,0,0,0],[1,1,1,1,1,1,1],[0,1,0,0,0,0,0],[0,0,1,0,0,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
    elif (faces_joystick.X) > 750:
      wait_ms(200)
      input2.append('right')
      emoji0.show_map([[0,0,0,1,0,0,0],[0,0,0,0,1,0,0],[0,0,0,0,0,1,0],[1,1,1,1,1,1,1],[0,0,0,0,0,1,0],[0,0,0,0,1,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
    elif (faces_joystick.Y) > 670:
      wait_ms(200)
      input2.append('up')
      emoji0.show_map([[0,0,0,1,0,0,0],[0,0,1,1,1,0,0],[0,1,0,1,0,1,0],[1,0,0,1,0,0,1],[0,0,0,1,0,0,0],[0,0,0,1,0,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
    elif (faces_joystick.Y) < 370:
      wait_ms(200)
      input2.append('down')
      emoji0.show_map([[0,0,0,1,0,0,0],[0,0,0,1,0,0,0],[0,0,0,1,0,0,0],[1,0,0,1,0,0,1],[0,1,0,1,0,1,0],[0,0,1,1,1,0,0],[0,0,0,1,0,0,0]], 0xFF0000)
    elif input2 == sequence:
      speaker.sing(523, 1)
      title1.setTitle('You Win')
      wait_ms(500)
      input2 = []
      playing = False
    elif input2 != sequence and len(input2) >= len(sequence):
      lcd.clear()
      speaker.sing(220, 1)
      label1.setText('Game Over')
      wait(1)
      input2 = []
      sequence = []
      playing = False
  wait_ms(2)
