Tiny Radio Telescope

A tiny homemade radio telescope I built which can take pictures IN RADIO.

IntermediateFull instructions providedOver 416 days2,410

Things used in this project

Hardware components

Small and lightweight satellite dish

LNB

Sockets and Accessories / Socket Strips (mine is a dual LNB, and allowed me to receive signals ranging from 10,7GHz to 12,75GHz)

DRV-8825 drivers for the stepper motors

Some custom 3D printed parts.

Satellite finder

Lazy Susan

This is the turntable. I bought a cheap one from Ikea

Some F-connector coaxial cable

Raspberry Pi

I used a Pi 2 Model B, with a WiFi dongle

NEMA 17 stepper motors

I used two of these, one for each axis.

Arduino Nano

Power supplies for everything

For RPi, stepper motors, the LNB and the satellite finder

Story

1 / 6

Description

The aim of this project was to build a radio telescope using a small satellite dish, which can scan its surroundings and create an image representing the intensity of the radio in different areas of the sky. I was inspired to create this project after watching a video by "The Thought Emporium" (there's a link at the bottom of the details page), where he shows how he built a radio telescope at home. My radio telescope is different to this one, and I used my own design and wrote my own code to control the dish and receive radio data, but the idea is more or less the same. I finished this project a few months ago, and decided to post it here to see what people think, and to help anyone who wants to build their own radio telescope.

I consider this project more of an experiment, to see what can be done with a tiny radio telescope. Even though the results aren't great, I learned A LOT while working on this project.

Details

What it can do:

This radio telescope takes pictures in radio (on frequencies between 10.7Ghz and 12.75GHz). Theoretically, this radio telescope should be able to take pictures of the sky, in radio. If the dish is aimed properly, the results should create an image of TV satellites orbiting the earth (those in geostationary orbit - they are always in the same position in the sky since they orbit the earth at the same speed at which it rotates). However, due to limitations caused by the small size of the dish, I won't be able to do any real radio astronomy with this (with a bigger dish, we can listen to lower frequencies (due to their longer wavelength) and a larger dish would also provide increased aperture which means more gain and smaller beamwidth (so higher resolution images too) . For example, by using a 1m dish, I would be able to listen to the hydrogen line. This is a spectral line (around 1420MHz) caused by the change in energy state of hydrogen atoms. Considering hydrogen is the most abundant element in the universe, and there are huge clouds of hydrogen everywhere in our galaxy, if I applied the same imaging technique (read How it works, below), I would be able to see the centre of the Milky Way (or at least receive a faint signal at 1420MHz). Now this is pretty cool, but very difficult to achieve.

How it works:

The idea is to have a motorised satellite dish, which can be controlled by a Raspberry Pi. The code on the Pi points the dish in a certain direction, and measures the intensity of the radio signal being received. This intensity and the position of the dish are then stored in a database. This is done many times as the radio telescope moves around and scans its surroundings. Each value for the intensity of the signal (with its associated dish position) are converted to pixels in the final image: the intensity of the signal being the brightness of the pixel, and the position of the dish being the location of the pixel on the final image. The output is a low resolution image, which represents the intensity of signals being received from different areas in the telescope's surroundings. Here is a video of my first scan:

Moving the dish:

I used 3D printed parts I designed to build each axis to move the dish. What I built is essentially and alt-azimuth mount for the satellite dish.

For the altitude axis, (up and down) I attached a stepper motor to a threaded rod using a flexible coupling. On the threaded rod I placed a nut, which, as the threaded rod rotates, moves forwards and backwards. Part A (below) is a 3D printed piece which then translates the horizontal motion of the nut into a vertical motion, to move the dish up and down, by pulling it and pushing it. I found that this method worked really well since it allowed for a decent amount of torque, and for precise, small movements. However, I was only able to point the dish between 0° and 50°(altitude), but with a few modifications i'm sure i could fix this.

For the azimuth axis, (left and right) I ran a ball chain around a 3D printed adapter for the stepper motor, and around the base for the Lazy Susan. As the stepper motor rotates, the top plate of the Lazy Susan will also rotate, moving the dish, which is mounted on top of it. I had a few problems with this design, since the stepper motor had a little trouble rotating because of the weight of all the parts mounted on the turntable, but I managed to make it work in the end.

Receiving the signal on the Raspberry Pi:

For the Raspberry Pi to be able to measure the power of the signal...
