Simple Auto Fan

Basic instructions on building a simple auto fan.

BeginnerShowcase (no instructions)30 minutes36,547

Things used in this project

Hardware components

relay

fan

computer fan

9V battery (generic)

Arduino UNO

lm35

Story

There is one point to which I want to draw attention. When setting up the circuit I connect the common GND pins. Some fans cannot measure the extent of trying correctly. If you encounter such a thing, you can connect GND separately. When I hooked them up separately, it was solved.

I must say also that with the relay NO, it is necessary to pay attention to NC pins. NO means "normally open" and NC means "normally closed". So, if you connect the NO pin, it stops when it reaches 0. If you connect the NC pin, it stops when it reaches 0 1 runs.

First, let me mention that it produces a value between 0 and 1 volt with LM35 value as a margin of error; but the way you work with 5V, there are values that can be high.

That's why we need to inform the Arduino to produce values between 0 and 1.1 volts. Here you analogReference (INTERNAL) are doing with the command.

When we talk about self-assessing the degree 10mV from each LM35 that 1 ° C corresponds to, we were told to use the Arduino reference to 1,1V. In this way, it is going to have to look at each analog input value , like 1.0742 mV. i.e., 10 mV, since it corresponds to 1 ° C; 10 / 1.0742 gives us the value of approximately 9.31.

Code

Code

// LM35 and relay pins defined
int role=7;
int lm35=A0;

void setup() {

  Serial.begin(9600);    //Serial comminication started
  analogReference(INTERNAL);    //arduino 1,1V reference set
  pinMode(role,OUTPUT);       //Relay is defined as output

}

void loop() {
  int okunanDeger = analogRead(A0);          //Read analog value
  float derece = okunanDeger / 9.31;         //centigrade calculated
  Serial.println(derece);                    //centigrade print on screen
  delay(1000);                               // wait 1 sec

  if(derece >25)
    digitalWrite(role,HIGH);                 //relay power on
    else
    digitalWrite(role,LOW);                  //relay power off


}

Credits
