Driver monitoring System using AMD Kria KR260 Robotics kit

Driver Monitoring System to detects & monitor the Driver drowsiness, distraction, yawning, fatigue etc.

IntermediateWork in progress8 hours374

Driver monitoring System using AMD Kria KR260 Robotics kit

Things used in this project

Hardware components

AMD Kria™ KR260 Robotics Starter Kit

Raspberry Pi Camera Module

Camera (generic)

Software apps and online services

Snappy Ubuntu Core

Story

The primary causes of road accidents are driver fatigue, drowsiness, alcohol, excessive speed, and distractions. To effectively combat these issues and enhance driver alertness, a novel solution is needed.

Continuous driving can be both tedious and exhausting, leading to drowsiness and a potential loss of focus. To address this concern, we propose the development of a drowsy driver detection system aimed at improving safety and preventing accidents caused by driver fatigue.

Now a days road safety is more critical than ever, the need for innovative solutions to prevent accidents is very important. As driving becomes increasingly automated, ensuring human drivers remain attentive and safe is crucial. Enter VigilantEyes, a cutting-edge driver monitoring system designed to tackle drowsiness, distraction, and fatigue. This project not only aims to enhance road safety but also paves the way for integrating advanced technology into everyday driving.

How The Solution Works:

For this, we will use Mediapipe’s Face Mesh solution in python and the Eye Aspect ratio formula. Our goal is to create a robust and easy-to-use application that detects and alerts users if their eyes are closed for a long time.

Formula for calculating Eye Aspect Ratio

First, we declare two threshold values and a counter.

EAR_thresh:A threshold value to check whether the current EAR value is within range.
D_TIME: A counter variable to track the amount of time passed with current EAR < EAR_THRESH.
WAIT_TIME: To determine whether the amount of time passed with EAR < EAR_THRESH exceeds the permissible limit.
When the application starts, we record the current time (in seconds) in a variable t1 and read the incoming frame.
Next, we preprocess and pass the frame through Mediapipe’s Face Mesh solution pipeline.
We retrieve the relevant (Pi) eye landmarks if any landmark detections are available. Otherwise, reset t1and D_TIME (D_TIME is also reset over here to make the algorithm consistent).
If detections are available, calculate the average EAR valuefor both eyes using the retrieved eye landmarks.
If the current EAR < EAR_THRESH, add the difference between the current time t2 and t1 to D_TIME. Then reset t1 for the next frame as t2.
If the D_TIME >= WAIT_TIME, we sound the alarm or move on to the next frame.

We have to calculate Eye Aspect Ratio for each eye. Calculating the final EAR value, the authors suggest averaging the two EAR values.

Importing libraries

Calculate Euclidean distance between two points.

Get landmarks (index) points for both eyes

For calculating Eye Aspect ratio.

Calculate average eye aspect ratio for two eyes.

Setup:

The setup consist of Kria KR260 Robotics Starter Kit and camera.

Working Solution Demo video:

If close the eyes or yawning or drowsiness for more than 2 seconds, the solution will play an alarm to the user.

The developed solution works with or without mask as well.

If I close eye for 2 sec. or more, it will play a alarm.

1 / 4

Code

Drowsiness Detection

from scipy.spatial import distance
# from imutils.video import VideoStream
# import imutils
from imutils.video import FPS
from pygame import mixer
import cv2
import mediapipe as mp
from scipy.spatial import distance
from pygame import mixer
import cv2
import mediapipe as mp
import time

mp_drawing = mp.solutions.drawing_utils
mp_drawing_styles = mp.solutions.drawing_styles
# mp_holistic = mp.solutions.holistic
# mp_pose = mp.solutions.pose
mp_facemesh = mp.solutions.face_mesh
denormalize_coordinates = mp_drawing._normalized_to_pixel_coordinates

mixer.init()
# give the directory to the music file
mixer.music.load("music.wav")


def distance(point_1, point_2):
    """Calculate l2-norm between two points"""
    dist = sum([(i - j) ** 2 for i, j in zip(point_1, point_2)]) ** 0.5
    return dist


def get_ear(landmarks, refer_idxs, frame_width, frame_height, frame):
    """
    Calculate Eye Aspect Ratio for one eye.

    Args:
        landmarks: (list) Detected landmarks list
        refer_idxs: (list) Index positions of the chosen landmarks
                            in order P1, P2, P3, P4, P5, P6
        frame_width: (int) Width of captured frame
        frame_height: (int) Height of captured frame

    Returns:
        ear: (float) Eye aspect ratio
    """
    try:
        # Compute the euclidean distance between the horizontal
        coords_points = []
        for i in refer_idxs:
            lm = landmarks[i]
            coord = denormalize_coordinates(lm.x, lm.y,
                                             frame_width, frame_height)

            coords_points.append(coord)

        # Eye landmark (x, y)-coordinates
        # python index start from 0 so we have to substract 1 from each index
        P2_P6 = distance(coords_points[1], coords_points[5])
        P3_P5 = distance(coords_points[2], coords_points[4])
        P1_P4 = distance(coords_points[0], coords_points[3])

        # Compute the eye aspect ratio
        ear = (P2_P6 + P3_P5) / (2.0 * P1_P4)

        for cord_point in coords_points:

            if ear < 0.22:
                cv2.circle(frame, cord_point, 2, (0,0,255), -1)
            else:
                cv2.circle(frame, cord_point, 2, (0,255,0), -1)


    except:
        ear = 0.0
        coords_points = None

    return ear, coords_points


def get_mar(landmarks, refer_idxs, frame_width, frame_height, frame):

    """Calculate Mouth Aspect Ratio
    Args:
        landmarks: (list) Detected landmarks list
        refer_idxs: (list) Index positions of the chosen landmarks
                            in order Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8
        frame_width: (int) Width of captured frame
        frame_height: (int) Height of captured frame

    Returns:
        mar: (float) Mouth aspect ratio  """

    try:
        # Compute the euclidean distance between the horizontal
        coords_points = []
        for i in refer_idxs:
            lm = landmarks[i]
            coord = denormalize_coordinates(lm.x, lm.y,
                                             frame_width, frame_height)

            coords_points.append(coord)

        # Eye landmark (x, y)-coordinates
        # python index start from 0 so we have to substract 1 from each index
        Q2_Q8 = distance(coords_points[1], coords_points[7])
        Q3_Q7 = distance(coords_points[2], coords_points[6])
        Q4_Q6 = distance(coords_points[3], coords_points[5])
        Q1_Q5 = distance(coords_points[0], coords_points[4])
        # Compute the mouth aspect ratio
        mar = (Q2_Q8 + Q3_Q7 + Q4_Q6) / (3.0 * Q1_Q5)

        for cord_point in coords_points:

            if mar > 0.4:
                cv2.circle(frame, cord_point, 2, (0,0,255), -1)
            else:
                cv2.circle(frame, cord_point, 2, (0,255,0), -1)


    except:
        mar = 0.0
        coords_points = None

    return mar, coords_points


def calculate_avg_ear(landmarks, left_eye_idxs, right_eye_idxs, image_w, image_h, frame):
    """Calculate Eye aspect ratio"""
    left_ear, left_lm_coordinates = get_ear(
                                      landmarks,
                                      left_eye_idxs,
                                      image_w,
                                      image_h,
                                      frame
                                    )

    right_ear, right_lm_coordinates = get_ear(
                                      landmarks,
                                      right_eye_idxs,
                                      image_w,
                                      image_h,
                                      frame
                                    )
    Avg_EAR = (left_ear + right_ear) / 2.0

    return Avg_EAR, (left_lm_coordinates, right_lm_coordinates)


# def eye_aspect_ratio(eye):
# 	A = distance.euclidean(eye[1], eye[5])
# 	B = distance.euclidean(eye[2], eye[4])
# 	C = distance.euclidean(eye[0], eye[3])
# 	ear = (A + B) / (2.0 * C)
# 	return ear

# The chosen 12 points:   P1,  P2,  P3,  P4,  P5,  P6
chosen_left_eye_idxs  = [362, 385, 387, 263, 373, 380]
chosen_right_eye_idxs = [33,  160, 158, 133, 153, 144]

all_chosen_idxs = chosen_left_eye_idxs + chosen_right_eye_idxs

# The chosen 8 points
#   on mouth: Q1, Q2, Q3, Q4,  Q5,  Q6,  Q7, Q8
mouth_idxs = [61, 41, 13, 271, 291, 402, 14, 178]

thresh = 0.22
frame_check = 48
# detect = dlib.get_frontal_face_detector()
# predict = dlib.shape_predictor("shape_predictor_68_face_landmarks.dat")

# (lStart, lEnd) = face_utils.FACIAL_LANDMARKS_68_IDXS["left_eye"]
# (rStart, rEnd) = face_utils.FACIAL_LANDMARKS_68_IDXS["right_eye"]
# (rStart, rEnd) = face_utils.FACIAL_LANDMARKS_68_IDXS["right_eye"]
cap=cv2.VideoCapture("Can You Watch This Without Yawning_.mp4")
# cap=cv2.VideoCapture(0)
flag=0

# start the FPS counter
fps = FPS().start()

# Rest of the code...

# Initialize timer variables
start_time = None
end_time = None
alert_interval = 2  # Time in seconds for the alert to be active

# Rest of the code...

with mp_facemesh.FaceMesh(refine_landmarks=True) as face_mesh:
    while True:
        ret, frame=cap.read()
        time.sleep(0.05)
        # frame = imutils.resize(frame, width=450)
        frame = cv2.cvtColor(cv2.flip(frame, 1), cv2.COLOR_BGR2RGB)
        imgH, imgW, _ = frame.shape
        # Running inference using static_image_mode
        results = face_mesh.process(frame).multi_face_landmarks
        frame = cv2.cvtColor(frame, cv2.COLOR_RGB2BGR)

        # If detections are available.
        if results:
            for face_id, face_landmarks in enumerate(results):
                landmarks = face_landmarks.landmark
                EAR, _ = calculate_avg_ear(
                    landmarks,
                    chosen_left_eye_idxs,
                    chosen_right_eye_idxs,
                    imgW,
                    imgH,
                    frame
                )

                MAR, mar_position = get_mar(
                    landmarks,
                    mouth_idxs,
                    imgW,
                    imgH,
                    frame
                )

                cv2.putText(frame,"EAR:" + str(round(EAR,2)), (5, 40),
                            cv2.FONT_HERSHEY_COMPLEX, 1, (0,255,0),2)

                cv2.putText(frame, "MAR:" + str(round(MAR,2)), (imgW-200, 40),
                            cv2.FONT_HERSHEY_COMPLEX, 1, (0,255,0), 2)


            if (EAR < thresh) or (MAR > 0.4):
                if start_time is None:
                    start_time = time.time()  # Start the timer

                if end_time is not None and (time.time() - end_time) >= alert_interval:
                    start_time = time.time()  # Start the timer again after the alert interval

                if (time.time() - start_time) >= alert_interval:
                    cv2.putText(frame, "****************ALERT!****************", (10, 30),
                                cv2.FONT_HERSHEY_SIMPLEX, 0.7, (0, 0, 255), 2)
                    cv2.putText(frame, "****************ALERT!****************", (10, 325),
                                cv2.FONT_HERSHEY_SIMPLEX, 0.7, (0, 0, 255), 2)
                    mixer.music.play()
                    end_time = time.time()  # Save the end time of the alert
            else:
                start_time = None  # Reset the timer
                end_time = None  # Reset the end time of the alert

        cv2.imshow("Frame", frame)
        key = cv2.waitKey(1) & 0xFF
        if key == ord("q"):
            break

        # update the FPS counter
        fps.update()

    # stop the timer and display FPS information
    fps.stop()
    print("[INFO] elasped time: {:.2f}".format(fps.elapsed()))
    print("[INFO] approx. FPS: {:.2f}".format(fps.fps()))

    cv2.destroyAllWindows()
    cap.release()
