SRES ( Smarter Retail & Emergency System)

Making all retail lines smarter and efficient

BeginnerWork in progress99

SRES ( Smarter Retail & Emergency System)

Things used in this project

Hardware components

M5Stack FIRE IoT Development Kit (PSRAM 2.0)

M5Stack Time-of-Flight (ToF) VL53L0X Laser Ranging Unit (MCP4725/)

M5Stack PIR Sensor Human Body Infrared PIR Motion Sensor (AS312)

SG90 Micro-servo motor

M5Stack ENV III Unit with Temperature Humidity Air Pressure Sensor (SHT30+QMP6988)

M5Stack Mini RFID Unit RC522 Module Sensor

M5Stack Pa.HUB

Software apps and online services

M5Stack M5 STACK

Story

Click on this to view our presentation!
Group presentation :

Prototype demo :

What came about this idea? The idea to design a sustainable technology solution for retail spaces came from my own experiences of frustration and inefficiency in shopping malls. Like many, I’ve wandered through overcrowded aisles, stood in endless lines for elevators, and wasted precious time searching for an available restroom. These moments may seem small, but they build up into a collective dissatisfaction, especially for individuals with special needs or mobility challenges. I realized that there had to be a better way to make these shared spaces more inclusive, efficient, and environmentally friendly.

This solution aims to tackle two significant challenges: congestion in retail spaces and the lack of accessible information about amenities. By leveraging a sensor-based system, we can provide real-time insights into the availability of services like lifts, toilets, or even seating areas. For example, PIR (Passive Infrared) and ToF (Time of Flight) sensors can detect movement and measure distances, giving live updates on congestion levels and occupancy statuses. These updates will empower shoppers to make informed decisions, reducing frustration and improving their overall experience.

Accessibility is another crucial focus. For those with disabilities, having real-time information about available toilets or less crowded pathways can make a world of difference. This solution will help them navigate malls with ease, ensuring a more inclusive environment. It’s not just about technology; it’s about giving everyone the dignity and convenience they deserve when accessing public spaces.

From an environmental perspective, this solution can reduce unnecessary energy consumption. Faulty lights left unnoticed, or air conditioning running at full blast in unoccupied areas, are common examples of waste in large retail spaces. By integrating all amenities into a central Wi-Fi network and monitoring them with sensors, building management can immediately address such issues. Automated alerts and actionable data can ensure resources are used only when and where needed.

Moreover, real-time congestion data can guide mall management in optimizing the use of energy-intensive facilities like escalators or elevators. For instance, elevators can operate at reduced frequencies during low-traffic periods or adjust based on demand. Similarly, lighting and cooling systems in less crowded areas can be dimmed or turned off automatically, contributing to a significant reduction in electricity consumption.

In essence, this project is about making retail spaces smarter and more sustainable. It’s a blend of technology and empathy—creating a system that not only enhances operational efficiency but also addresses the real, everyday struggles of shoppers and staff alike. By reducing frustration, enhancing accessibility, and minimizing environmental impact, this solution can set a new standard for how we design and manage retail spaces in the future. How it works. There are two systems, one for the public and the other is for the management side. Public use :Display screens used to inform shoppers of the occupancy of a certain area. Able to acquire assistance easily through a press of a button. Made to assist those in need, Handicap friendly. Management / Stores use : Able to know number of people visiting the store that day. Able to acquire assistance easily through a press of a button. Able to know whether a fire occurs through ENV display. Has control over Emergency doors. Only those with correct identification are able to access and use this system.

Schematics

Code

from m5stack import *
from m5ui import *
from uiflow import *
import unit
remoteInit()

setScreenColor(0x222222)
pir_0 = unit.get(unit.PIR, unit.PORTB)


sensor = None



label1 = M5TextBox(0, 175, "nil", lcd.FONT_DejaVu24, 0xFFFFFF, rotate=0)
label2 = M5TextBox(0, 133, "Handicap Toilet :", lcd.FONT_DejaVu24, 0xFFFFFF, rotate=0)
label0 = M5TextBox(0, 0, "Repairs will be arriving", lcd.FONT_DejaVu24, 0xffffff, rotate=0)
label3 = M5TextBox(0, 60, "Toilets :", lcd.FONT_DejaVu24, 0xFFFFFF, rotate=0)
label4 = M5TextBox(0, 94, "nil", lcd.FONT_DejaVu24, 0xFFFFFF, rotate=0)
label5 = M5TextBox(35, 220, "QR CODE", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label6 = M5TextBox(129, 220, "TOILETS", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label7 = M5TextBox(228, 220, "LIFTS", lcd.FONT_Default, 0xFFFFFF, rotate=0)



def buttonA_wasPressed():
  global sensor
  setScreenColor(0x000000)
  lcd.qrcode('https://flow.m5stack.com/remote?id=undefined', 60, 25, 200)
  pass
btnA.wasPressed(buttonA_wasPressed)

def buttonC_wasPressed():
  global sensor
  setScreenColor(0x000000)
  label0.hide()
  label4.show()
  label3.hide()
  label2.hide()
  label1.show()
  label1.setText('Long press to check availability')
  label4.setText('Lift availability')
  pass
btnC.wasPressed(buttonC_wasPressed)

def buttonB_wasPressed():
  global sensor
  setScreenColor(0x000000)
  label0.hide()
  label1.show()
  label2.hide()
  label3.hide()
  label4.show()
  label1.setText('Long press to check availability')
  label4.setText('Toilet availability')
  pass
btnB.wasPressed(buttonB_wasPressed)

def buttonC_pressFor():
  global sensor
  setScreenColor(0x000000)
  sensor = pir_0.state
  if sensor == 1:
    label2.setText('Lobby B Lift :')
    label3.setText('Lobby A Lift :')
    label1.setText('Occupied')
    label4.setText('Occupied')
  else:
    label2.setText('Lobby B Lift :')
    label3.setText('Lobby A Lift :')
    label1.setText('Unoccupied')
    label4.setText('Unoccupied')
  pass
btnC.pressFor(0.8, buttonC_pressFor)

def buttonB_pressFor():
  global sensor
  setScreenColor(0x000000)
  sensor = pir_0.state
  if sensor == 1:
    label2.setText('Toilets :')
    label3.setText('Handicap Toilet :')
    label1.setText('Occupied')
    label4.setText('Occupied')
  else:
    label2.setText('Toilets :')
    label3.setText('Handicap Toilet :')
    label1.setText('Unoccupied')
    label4.setText('Unoccupied')
  pass
btnB.pressFor(0.8, buttonB_pressFor)


def button_1_callback():
  global sensor, pir_0
  label1.hide()
  setScreenColor(0xffff66)
  rgb.setColorAll(0xffff66)
  speaker.sing(831, 1/4)
  rgb.setColorAll(0x000000)
  label0.show()
  label0.setColor(0x000000)

def button_2_callback():
  global sensor, pir_0
  label1.hide()
  setScreenColor(0x3366ff)
  rgb.setColorAll(0x000000)

label0.hide()
label1.hide()
label2.hide()
label3.hide()
label4.hide()

from m5stack import *
from m5ui import *
from uiflow import *
import time
import unit
remoteInit()

setScreenColor(0x222222)
env_1 = unit.get(unit.ENV, unit.PAHUB0)
rfid_1 = unit.get(unit.RFID, unit.PAHUB1)
tof_2 = unit.get(unit.TOF, unit.PAHUB5)
servo_2 = unit.get(unit.SERVO, unit.PORTB)
pahub_0 = unit.get(unit.PAHUB, unit.PORTA, 0x70)


switch_value = None
DistData = None
counter = None
TempV = None
HumidV = None
PresV = None
average = None



label1 = M5TextBox(0, 0, "Number Of Customers :", lcd.FONT_DejaVu24, 0xFFFFFF, rotate=0)
label2 = M5TextBox(250, 200, "label2", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label9 = M5TextBox(0, 0, "WARNING : EMERGENCY", lcd.FONT_DejaVu72, 0xFFFFFF, rotate=0)
label3 = M5TextBox(0, 150, "No. of people entering and leaving", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label0 = M5TextBox(257, 144, "0", lcd.FONT_DejaVu40, 0xFFFFFF, rotate=0)
label4 = M5TextBox(0, 44, "label4", lcd.FONT_DejaVu40, 0xFFFFFF, rotate=0)
label5 = M5TextBox(147, 65, "Customers", lcd.FONT_DejaVu18, 0xFFFFFF, rotate=0)
TEMPERATURE = M5TextBox(0, 124, "TEMPERATURE", lcd.FONT_Default, 0xFFFFFF, rotate=0)
HUMIDITY = M5TextBox(0, 166, "HUMIDITY", lcd.FONT_Default, 0xFFFFFF, rotate=0)
PRESSURE = M5TextBox(0, 208, "PRESSURE", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label6 = M5TextBox(182, 124, "label6", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label7 = M5TextBox(182, 170, "label7", lcd.FONT_Default, 0xFFFFFF, rotate=0)
label8 = M5TextBox(182, 208, "label8", lcd.FONT_Default, 0xFFFFFF, rotate=0)

from numbers import Number



def buttonA_wasPressed():
  global switch_value, DistData, counter, TempV, HumidV, PresV, average
  label0.hide()
  label1.hide()
  label2.hide()
  label3.hide()
  label5.hide()
  setScreenColor(0x000000)
  lcd.qrcode('https://flow.m5stack.com/remote?id=undefined', 72, 32, 176)
  pass
btnA.wasPressed(buttonA_wasPressed)

def buttonC_wasPressed():
  global switch_value, DistData, counter, TempV, HumidV, PresV, average
  setScreenColor(0x000000)
  TEMPERATURE.show()
  HUMIDITY.show()
  PRESSURE.show()
  label0.hide()
  label1.hide()
  label2.hide()
  label3.hide()
  label4.hide()
  label5.hide()
  label9.hide()
  TempV = env_1.temperature
  HumidV = env_1.humidity
  PresV = env_1.pressure
  label6.setText(str(TempV))
  label7.setText(str(HumidV))
  label8.setText(str(PresV))
  if TempV >= 55:
    setScreenColor(0xff0000)
    rgb.setColorAll(0xff0000)
    label4.setColor(0x000000)
    label4.show()
    label4.setText('WARNING : FIRE HAZARD DETECTED')
  pass
btnC.wasPressed(buttonC_wasPressed)

def buttonB_wasPressed():
  global switch_value, DistData, counter, TempV, HumidV, PresV, average
  setScreenColor(0x000000)
  label1.show()
  label3.show()
  label5.show()
  label4.setText('-')
  label2.setText(str(DistData))
  while True:
    DistData = (tof_2.distance) / 10
    wait_ms(50)
    if DistData <= 30:
      counter = (counter if isinstance(counter, Number) else 0) + 1
      label0.setText(str(counter))
      wait_ms(50)
      average = counter / 2
      label4.setText(str(average))
    wait_ms(2)
  pass
btnB.wasPressed(buttonB_wasPressed)



def button_1_callback():
  global switch_value, DistData, counter, TempV, HumidV, PresV, average, env_1, rfid_1, tof_2, servo_2, pahub_0
  setScreenColor(0xffff66)
  rgb.setColorAll(0xffff66)
  speaker.sing(220, 1/4)

def switch_1_callback(switch_value):
  global DistData, counter, TempV, HumidV, PresV, average, env_1, rfid_1, tof_2, servo_2, pahub_0
  if switch_value == 1:
    servo_2.write_angle(90)
    for count in range(1):
      rgb.setColorAll(0xff6666)
      setScreenColor(0xff0000)
      label9.show()
      speaker.sing(784, 1)
      speaker.setVolume(0.1)
      wait_ms(10)
      rgb.setColorAll(0x000000)
      speaker.sing(392, 1)
      speaker.setVolume(0.1)
      wait_ms(10)
      rgb.setColorAll(0xff6666)
  elif switch_value == 0:
    servo_2.write_angle(0)
    label9.hide()
    setScreenColor(0x000000)
    rgb.setColorAll(0x000000)

def gauge_1_callback():
  global switch_value, DistData, counter, TempV, HumidV, PresV, average, env_1, rfid_1, tof_2, servo_2, pahub_0
  return env_1.temperature
label0.hide()
label1.hide()
label2.hide()
label3.hide()
label4.hide()
label5.hide()
TEMPERATURE.hide()
HUMIDITY.hide()
PRESSURE.hide()
label6.hide()
label7.hide()
label8.hide()
label9.hide()
label4.setText('Scan Your Card')
while True:
  if rfid_1.isCardOn():
    rgb.setColorAll(0xff0000)
    wait(1)
    if (rfid_1.readUid()) == 'e0c8284f4f':
      speaker.tone(800, 200)
      label4.setText('Welcome!')
      rgb.setColorAll(0x33ff33)
      wait(1)
  else:
    label4.setText('Scan Your Card')
  wait_ms(2)
