Tutorial for ILI9341 TFT LCD SD and Arduino MEGA (part 2)

//LCD
#include <ILI9341_kbv.h> // This library has been modified
ILI9341_kbv tft;
#define vali0 0

//COLORS
#define  BLACK   0x0000
#define BLUE    0x001F
#define RED     0xF800
#define GREEN   0x07E0
#define CYAN    0x07FF
#define MAGENTA 0xF81F
#define YELLOW  0xFFE0
#define WHITE   0xFFFF



//SD CARD
#include <SD.h>
#define TFT_SD 47  //SD_MOSI
Sd2Card card;
SdVolume volume;
SdFile root;


//Folder on the SD card to keep the pictures
String FOLDERROOT = ""; // I have no folder because all the pictures are on the root of the SD
uint8_t max_img = 40;
uint8_t image_counter = 0;
unsigned long auxtimer, colortimer;





void setup()
          {

            tft.begin();
            tft.setRotation(3);// Landscape
            tft.fillScreen(TFT_PINK);// set color iitial screen
            SD.begin(TFT_SD);
          }


// Makes an Array out of a BMP
void bmp (String filename){
                              int len = 30;
                            char pepito[len];
                            filename.toCharArray(pepito, len);
                            bmpDraw(pepito , 0, 0);}


void loop(){

  //Some text to see on the screen
      tft.setCursor(0, 0);
      tft.fillScreen(TFT_BLUE);
      tft.setTextColor(YELLOW);
      tft.setTextSize(2);
      tft.print("YELLOW");
      tft.setTextSize(4);
      tft.setTextColor(RED);
      tft.setTextSize(3);
      tft.print("RED");
      tft.setCursor(50, 50);
      tft.setTextColor(BLACK);
      tft.setTextSize(8);
      tft.print("TEST");
      bmp("roger.bmp");
      delay(3000);




}


uint16_t _read16(File f) {
  uint16_t result;
  ((uint8_t *)&result)[0] = f.read(); // LSB
  ((uint8_t *)&result)[1] = f.read(); // MSB
  return result;
}

uint32_t _read32(File f) {
  uint32_t result;
  ((uint8_t *)&result)[0] = f.read(); // LSB
  ((uint8_t *)&result)[1] = f.read();
  ((uint8_t *)&result)[2] = f.read();
  ((uint8_t *)&result)[3] = f.read(); // MSB
  return result;
}

#define BUFFPIXEL 20
void bmpDraw(char *fileName, int x, int y){

      File     bmpFile;
      int      bmpWidth, bmpHeight;   // W+H in pixels
      uint8_t  bmpDepth;              // Bit depth (currently must be 24)
      uint32_t bmpImageoffset;        // Start of image data in file
      uint32_t rowSize;               // Not always = bmpWidth; may have padding
      uint8_t  sdbuffer[3*BUFFPIXEL]; // pixel buffer (R+G+B per pixel)

      uint16_t lcdbuffer[BUFFPIXEL];  // pixel out buffer (16-bit per pixel)
      uint8_t  lcdidx = 0;
      boolean  first = true;

      uint8_t  buffidx = sizeof(sdbuffer); // Current position in sdbuffer
      boolean  goodBmp = false;       // Set to true on valid header parse
      boolean  flip    = true;        // BMP is stored bottom-to-top
      int      w, h, row, col;
      uint8_t  r, g, b;
      uint32_t pos = 0, startTime = millis();

      if((x >= tft.width()) || (y >= tft.height())) return;

      // Open requested file on SD card
      if ((bmpFile = SD.open(fileName)) == NULL) {
        Serial.println("File Found??" );
        Serial.println( fileName);
        return;
      }else{
         Serial.println("File Found" );
        }


      if(_read16(bmpFile) == 0x4D42) { // BMP signature

        (void)_read32(bmpFile); // Read & ignore creator bytes
        Serial.print("File size: ");Serial.println( _read32(bmpFile) );
        bmpImageoffset = _read32(bmpFile); // Start of image data
        Serial.print(" Header size: ");Serial.println( _read32(bmpFile) );

        // Read DIB header

        bmpWidth  = _read32(bmpFile);
        bmpHeight = _read32(bmpFile);
        if(_read16(bmpFile) == 1) { // # planes -- must be '1'
          bmpDepth = _read16(bmpFile); // bits per pixel

          if((bmpDepth == 24) && (_read32(bmpFile) == 0)) { // 0 = uncompressed

            goodBmp = true; // Supported BMP format -- proceed!

            // BMP rows are padded (if needed) to 4-byte boundary
            rowSize = (bmpWidth * 3 + 3) & ~3;

            // If bmpHeight is negative, image is in top-down order.
            // This is not canon but has been observed in the wild.
            if(bmpHeight < 0) {
              bmpHeight = -bmpHeight;
              flip      = false;
            }

            // Crop area to be loaded
            w = bmpWidth;
            h = bmpHeight;
            if((x+w-1) >= tft.width())  w = tft.width()  - x;
            if((y+h-1) >= tft.height()) h = tft.height() - y;

            // Set TFT address window to clipped image bounds
            tft.setAddrWindow(x, y, x+w-1, y+h-1);

            for (row=0; row<h; row++) { // For each scanline...
              // Seek to start of scan line.  It might seem labor-
              // intensive to be doing this on every line, but this
              // method covers a lot of gritty details like cropping
              // and scanline padding.  Also, the seek only takes
              // place if the file position actually needs to change
              // (avoids a lot of cluster math in SD library).
              if(flip) // Bitmap is stored bottom-to-top order (normal BMP)
                pos = bmpImageoffset + (bmpHeight - 1 - row) * rowSize;
              else     // Bitmap is stored top-to-bottom
                pos = bmpImageoffset + row * rowSize;
              if(bmpFile.position() != pos) { // Need seek?
                bmpFile.seek(pos);
                buffidx = sizeof(sdbuffer); // Force buffer reload
              }

              for (col=0; col<w; col++) { // For each column...
                // Time to read more pixel data?
                if (buffidx >= sizeof(sdbuffer)) { // Indeed
                  // Push LCD buffer to the display first

                    if(lcdidx > 0) {
                      tft.pushColors(lcdbuffer, lcdidx, first);
                      lcdidx = 0;
                      first  = false;
                    }

                  bmpFile.read(sdbuffer, sizeof(sdbuffer));
                  buffidx = 0; // Set index to beginning
                }

                // Convert pixel from BMP to TFT format
                b = sdbuffer[buffidx++];
                g = sdbuffer[buffidx++];
                r = sdbuffer[buffidx++];

                    lcdbuffer[lcdidx++] = tft.color565(r,g,b);
                } // end pixel
              } // end scanline

                if(lcdidx > 0) {
                  tft.pushColors(lcdbuffer, lcdidx, first);
                }
              Serial.print("Loaded in: ");Serial.println( millis() - startTime);
            } // end goodBmp
          }
        }

      bmpFile.close();
      if(!goodBmp) Serial.println("BMP format not recognized.");
    }
