Arduino Programmatic Timed Reminder Alerting Framework

// Copyright (c) Ron D Bentley (UK), see copyright notice
//
//  ****************************************************************************************************
//  USER CONFIGURABLE PARAMETERS ARE REFERENCED HERE (see User Guide):
//
#define diags_on                        true  // leave set to true whilst developing/testing

#define RTC_enabled                     true  // Real-time clock enabled if true, false, if not

int ETR_timer_number                   = 0;   // 0 for timer0, 2 for timer2

#define ETR_R_list_scan_freq            100   //time (msecs) between scans of the ETR list (see User Guide)
//
//  The timer_drift_adjustment variable allows the inaccuracy of timer0/2 to be
//  compensated for, but only as far as the drift per hour in seconds.
//  This is ONLY relevant for ETRs, see User Guide.
long signed int timer_drift_adjustment =  1;  // number of seconds (+/-) per hour to adjust elapsed times

#define max_RQ_free_chain_blocks          16  // size of the RQ free chain in blocks

#define max_R_list_entries                10  // number of reminder list entries
//
// END OF USER CONFIGURABLE DATA/PARAMETERS.
// *******************************************************************************************************
//
#define ETR_timer_freq         1000                            // 1 msec timer interrupt frequency
#define scans_per_sec   ETR_timer_freq / ETR_R_list_scan_freq  // number of R_list scans per second
#define scans_per_min            60 * scans_per_sec            // number of R_list scans per minute
#define scans_per_hr             60 * scans_per_min            // number of R_list scans per hour

//
//  The timer_drift_adjustment variable allows the inaccuracy of timer1 to be
//  compensated for, but only as far as the drift per hour.  See User Guide.
//

volatile long unsigned int Seconds_since_midnight;        // used by RTR scan process

//  ************************************
//  Reminder List variables/definitions:

volatile boolean reminders_suspended = true;  //  allows reminder list scans to be halted/started

#define success                    1
#define fail                      -1

#define inactive                   0          // if a reminder entry R_type is 0 it is inactive
#define final_alert                1
//Reminder types:
//   1-3 are elapsed remider types and
//   4-6 are real-time reminder times
#define ET_oneoff_type              1  // Elapsed time (ETR) R_type values
#define ET_recurring_type           2  //     ....
#define ET_repeat_duration_type     3  //     ....

#define RT_oneoff_type              4  // Real-time R_type (RTR) valiues
#define RT_recurring_type           5  //      ....
#define RT_repeat_duration_type     6  //      ....

#define ETR                         0  // ETR = Elapsed Time Reminder
#define RTR                         1  // RTR = Real Time Reminder

// definitions used by the create reminder routines
#define invalid_R_type            -1
#define invalid_R_subtype         -2
#define invalid_R_start_in        -3
#define invalid_start_in_mins     -4
#define invalid_start_in_secs     -5
#define invalid_start_in_subsecs  -6
#define invalid_duration_mins     -7
#define invalid_duration_secs     -8
#define invalid_duration_subsecs  -9
#define invalid_freq_mins         -10
#define invalid_freq_secs         -11
#define invalid_freq_subsecs      -12
#define invalid_freq              -13
#define invalid_RT_hrs            -14  // pertinent to real-time reminders only
#define invalid_RT_mins           -15  // ...
#define invalid_RT_secs           -16  // ...
#define reminder_list_full        -99
#define RTC_not_configured        -100

volatile struct Reminder_List {
  // Reminder List variables for managing reminder entries
  int R_type;     //  R_type = 0 if entry unused,
  int R_subtype;  //  end user definable
  union {
    long unsigned int R_remind_at;  // used for RTR processing
    long unsigned int R_start_in;   // used for ETR processing
  };
  long unsigned int R_freq;
  long unsigned int R_duration;
  long unsigned int R_count_down;
  //  End user variables held in a reminder entry
  int R_user1;
  int R_user2;
  int R_user3;
  int R_user4;
} R_list[max_R_list_entries];

//  ****************************************
//  Reminder Queue variables
#define free_chain_entry_size          6
#define end_of_chain_value            -1

//  When allocated to a triggered/elapsed reminder,a block from the free chain will be allocated
//  to the active RQ and be set up as follows:
//  word [0]          - forward chain pointer, or end of chain value
//  word [1]          - a compound integer that contains:
//                          bit 15      - set to 1 if this entry represents the last reminder alert for the
//                                        triggered/elapsed reminder or,
//                                        set to 0 otherwise
//                          bits 11-14  - not used
//                          bits 8-10   - the reminder type that was triggered/elasped
//                          bits 0-7    - the reminder subtype that was triggered/elapsed
//   words [2] to [5] - the end user parameters defined at reminder creation time

volatile int RQ[max_RQ_free_chain_blocks][free_chain_entry_size];

//  Pointers to manage the free blocks in the RQ
volatile int start_of_free_RQ_chain;
volatile int num_free_RQ_blocks;

//  Pointers to manage the allocated blocks in the RQ
volatile int start_of_RQ_chain =  -1;
volatile int end_of_RQ_chain =    -1;
volatile int num_RQ_reminders =    0;

//  general values to manage RQ processes
#define no_reminder_requests  -1
#define no_entry              -1

//  The following R_xxx variables are set up by scan_RQ so that they can be referenced from the main
//  end user code following a timed reminder alert being taken off the queue.
volatile int  R_status;      // used to indicate if the reminder alert is a final one or otherwise
volatile int  R_type;        // used to indicate what the reminder type was that triggered/elapsed
volatile int  R_subtype;     // used to indicate what the reminder subtype was that triggered/elapsed
volatile int  R_user1;       // end user parameters defined at reminder creation time
volatile int  R_user2;       // ditto
volatile int  R_user3;       // ditto
volatile int  R_user4;       // ditto

// Copyright (c) Ron D Bentley (UK), see copyright notice

// This segment comprises the timer setups and ISRs that underpin this framework.
// They are used to provide the timimg for both ETRs and RTRs.
//
// timer0 and timer2 are used as the source timer for processing ETRs, and
// timer1 is used as the source timer for processing RTRs.
//
// Note that the timer frequency for RTR processing is fixed (timer1).
// However, the frequency for processing ETRs is end user configurable (see User Guide).
//
// **************************************************************************************
// timer initialisation routines for timer0, timer1 and timer2:
//
// ETR timer:
// Set up timer0 interrupt for processimg ETRs for 1000 cycles per second,
// 1kHz interrupts, ie for 1 millisecond interrupts
void initialise_timer0() {
  //set timer0 interrupt at 1kHz
  noInterrupts();
  TCCR0A = 0;
  TCCR0B = 0;
  TCNT0  = 0;
  // set compare match register for 1khz increments
  OCR0A = 249;            // (16*10^6) / (1000*64) - 1 (must be <256)
  // turn on CTC mode
  TCCR0A |= (1 << WGM01);
  // Set CS01 and CS00 bits for 64 prescaler
  TCCR0B |= (1 << CS01) | (1 << CS00);
  // enable timer compare interrupt
  TIMSK0 |= (1 << OCIE0A);
  interrupts();
}

// RTR timer:
// Set up timer1 interrupt for processing RTRs for 2 cycles per second,
// 2Hz interrupts, ie for 1/2 second interrupts
//
void initialise_timer1() {
  noInterrupts();
  TCCR1A = 0;
  TCCR1B = 0;
  TCNT1 = 0;
  // set Compare Match Register (CMR) for 1msec (2hz) increments
  OCR1A = 31249;                          // (16,000,000)/(256*2)) - 1
  // turn on CTC mode
  TCCR1B |= (1 << WGM12);                 // WGM12 = 3
  // Set CS11 bit for 256 prescaler
  //TCCR1B |= (1 << CS11) | (1 << CS10);  // CS11 = 1 and CS10 = 0
  TCCR1B |= (1 << CS12);                  // CS12 = 2
  // enable timer1 compare interrupt
  TIMSK1 |= (1 << OCIE1A);                // OCIE1A = 1
  interrupts();
}
//
// ETR timer:
// Alternative source timer for processimg ETRs for 1000 cycles per second,
// 1kHz interrupts, ie for 1 millisecond interrupts.
// This is provided if end user needs to use delay() function which makes
// use of timer0, hence a possible conflict.  End user encouraged not to
// use delay()!
void initialise_timer2() {
  noInterrupts();
  // Clear registers
  TCCR2A = 0;
  TCCR2B = 0;
  TCNT2 = 0;
  // 1000 Hz (16000000/((124+1)*128))
  OCR2A = 124;
  // CTC
  TCCR2A |= (1 << WGM21);
  // Prescaler 128
  TCCR2B |= (1 << CS22) | (1 << CS20);
  // Output Compare Match A Interrupt Enable
  TIMSK2 |= (1 << OCIE2A);
  interrupts();
}
//
//  ***************************************************************************
//  timer0, 1 and 2 ISRs:
//
//  timer0 is used as the timing source for ETR processing exclusively.
//  timer0 interrupt routine will be entered at ETR_timer_freq interrupt frequency
//  defined during the initialisation of timer0.
//  However, processing of the Remind List will only occur every R_List_scan_feq 'ticks'
//  of timer0.
//
ISR(TIMER0_COMPA_vect) {
  static int timer0_tick = 0;   // counts out the defined R_list scan frequency for ETRs.
  if (!reminders_suspended)
  { timer0_tick++;
    if (timer0_tick == ETR_R_list_scan_freq) {
      timer0_tick = 0;          // reset for next timer1 interrupt
      // scan ETR entries in reminder list
      scan_R_list(ETR);
    }
  }
}

//  Timer1 is used as the timing source for RTR processing exclusively.
//  Timer1 is initialised for 2 cycles per second (2hz) so is entered
//  every 1/2 second.
//  Note that this routne is only active if the RTC is enabled
//
ISR(TIMER1_COMPA_vect) {
  if (!reminders_suspended)
  {
    // scan RTR entries in reminder list
    interrupts(); // not normally the right thing, but this works and allows RTC lib to be accessed
    RTR_Processor();
  }
}

//  timer2 is an alternative timer interrupt routine to timer0.
//  It is offered to replace timer0 if end user wishes to use the delay() function!
//  It is used as the timing source for ETR processing exclusively.
//  timer2 interrupt routine will be entered at the ETR_timer_freq interrupt frequency
//  defined during the initialisation of timer2.
//  However, processing of the Remind List will only occur every R_List_scan_feq 'ticks'
//  of timer2.
//
ISR(TIMER2_COMPA_vect) {
  static int timer2_tick = 0;   // counts out the defined R_list scan frequency for ETRs.
  if (!reminders_suspended)
  { timer2_tick++;
    if (timer2_tick == ETR_R_list_scan_freq) {
      timer2_tick = 0;          // reset for next timer1 interrupt
      // scan ETR entries in reminder list
      scan_R_list(ETR);
    }
  }
}

// The framework supports one of two timers for processing ETRs, either timer0 or timer2.
// Both timers are initialised for 1khz (1000 cycles per second, or ETR_timer_freq).
// If end user wishes to use delay() function, choose to initialise timer2 NOT timer0.
//
void initialise_timers() {
  if (ETR_timer_number == 0) initialise_timer0();
  else initialise_timer2();
  if (RTC_enabled) {initialise_timer1();} // timer1 deals with the RTC
}

//
//  Routine sets the reminders_suspended flag to halt reminder list scans by ISR.
//
void suspend_reminders() {
  noInterrupts();
  reminders_suspended = true;
  interrupts();
}

//
//  Routine clears the reminders_suspended flag to resume reminder list scans by ISR.
//
void resume_reminders() {
  noInterrupts();
  reminders_suspended = false;
  interrupts();
}

// Copyright (c) Ron D Bentley (UK), see copyright notice
//
//  This tab contains the routines to establish and maintain reminder
//  queue management.
//
//  A free chain of blocks is set up that are then allocated to reminder alert requests
//  as they decome due.
//
//  'RQ' is used as the blocks of memory to be allocated/deallocated on request.
//  'RQ' comprises a number of free blocks each of 5 integers, the first word of each block
//  contains a forward pointer to next block or end of chain value(free/used).

//  When a free block is allocated to a reminder request, it is inserted at the beginning of the
//  reminder queue with the first word of the block being a forward pointer to next allocated
//  block and the remainder of block containing user values defined as part of the remider set up.
//
//  Note:
//      1.  The number of free blocks in the RQ free chain is defined by 'max_RQ_free_chain_blocks'.
//      2.  The implementation is as a queue, first in first out (FIFO).
//

//  Set up the free RQ chain as defined by 'max_RQ_free__chain_blocks'
//  This is called just once per start/reset from te setup() process.
//
void  create_RQ_free_chain() {
  int  ptr, last_RQ_block;
  last_RQ_block = max_RQ_free_chain_blocks - 1;
  for (ptr = 0; ptr < max_RQ_free_chain_blocks; ptr++) {
    if (ptr == last_RQ_block) {
      RQ[ptr][0] = end_of_chain_value; // set end of chain
    }
    else                     {
      RQ[ptr][0] = ptr + 1; // set forward block pointer
    }
  }
  num_free_RQ_blocks = max_RQ_free_chain_blocks;
  start_of_free_RQ_chain = 0;
}
//
//  Allocates a block from the free chain, if one exists.
//  NOTE: assumes that interrupts are disabled by calling function(s).
//
int acquire_block_from_free_RQ() {
  int  block;
  if (num_free_RQ_blocks > 0) {
    //  There is at least 1 free block left.
    //  Take the next block off the free chain.
    num_free_RQ_blocks--;  //  reduce free blocks available.
    block = start_of_free_RQ_chain;
    start_of_free_RQ_chain = RQ[block][0];  //  take the first free block off the free chain.
    RQ[block][0] = end_of_chain_value;      //  set the forward pointer in this free block to out of range.
    return block;         //  return with the 'address' of the free block provided to calling routine.
  }
  return  fail;           //  no free blocks! Return error condition.
}

//
// Returns the given block back to the free chain.
// NOTE: assumes that reminders are disabled by calling function(s).
//
int relinquish_block_to_free_RQ(int block) {
  if (num_free_RQ_blocks < max_RQ_free_chain_blocks)  {
    //  there is space to add this block back to the free chain.
    num_free_RQ_blocks++;  //  increase number of free blocks on free chain by 1
    RQ[block][0] = start_of_free_RQ_chain;
    start_of_free_RQ_chain = block;
    return  success;      //  relinquish was successful.
  }
  return  fail;           //  free chain seems to be full of free blocks! No space to add another.
}

//
//  The function creates an entry in the interrupt queue for the given interrupt.
//
int insert_into_RQ(int R_status, int R_user1, int R_user2, int R_user3, int R_user4) {
  int  block;
  block = acquire_block_from_free_RQ();
  if (block == fail) {
    //  no free block available!
    return fail;
  }
  //  we have a free block, so chain it into the reminder queue
  //  placing it at the end of the current queue.
  if (num_RQ_reminders == 0) {
    // queue is empty, so set start pointer
    start_of_RQ_chain = block;
  }  else  {
    // at least on entry in RQ queue, so modify forward pointer of last block
    RQ[end_of_RQ_chain][0] = block;
  }
  //  now deal with rest of updates
  num_RQ_reminders++;
  end_of_RQ_chain = block;
  RQ[block][0] = end_of_chain_value;  // set new end of chain
  RQ[block][1] = R_status;
  RQ[block][2] = R_user1;
  RQ[block][3] = R_user2;
  RQ[block][4] = R_user3;
  RQ[block][5] = R_user4;
  return success;
}

//
//  See if there are any outstanding (unprocessed) reminder requests in the
//  reminder queue.  If so, take the first one on the queue and return it to the
//  free chain.  The answer to the function is either reminder found
//  or that no outstanding reminder requests exists.
//
//  Note that this function is not entered via any interrupt routine, so we do need to
//
int scan_RQ() {
  int RQ_block, interrupt;
  //noInterrupts();   //  ensure exclusive access of the RQ and its pointers
  if (num_RQ_reminders == 0)  {
    //  Clear down the end user reminder parameters, if no RQ entry to be processed.
    R_status  = 0;
    R_type    = 0;
    R_subtype = 0;
    R_user1   = 0;
    R_user2   = 0;
    R_user3   = 0;
    R_user4   = 0;
    //interrupts();
    return no_reminder_requests;
  }
  // take the first entry off the RQ as this is the next interrupt to be processed.
  noInterrupts();
  num_RQ_reminders--;
  RQ_block = start_of_RQ_chain;
  start_of_RQ_chain = RQ[RQ_block][0];    //  point to next interrupt to be processed, or end of chain
  if (num_RQ_reminders == 0)  {
    // last used block to be relinquished, so adjust end of chain pointer
    end_of_RQ_chain = end_of_chain_value;
  }
  //  set up the interrupt parameters for this interrupt,
  //  solely for end user reference if required
  R_status  = RQ[RQ_block][1];          // active/inactive, R_type and R_subtype
  R_type    = (R_status & 0x7ff) >> 8;  // the type of reminder
  R_subtype = R_status & 0xff;          // the reminder subtype value
  R_status  = bitRead(R_status, 15);    // indicates if last reminder alert recieved, or not
  R_user1   = RQ[RQ_block][2];
  R_user2   = RQ[RQ_block][3];
  R_user3   = RQ[RQ_block][4];
  R_user4   = RQ[RQ_block][5];
  relinquish_block_to_free_RQ(RQ_block);  //  put this block back on the free RQ chain
  interrupts();
  return success; // return with the internal value of the interrupt handler that was assigned to this pin
}
//
// Utility to print the reminder queue (RQ)
//
void print_RQ() {
  int ptr, count, i;
  if (diags_on) {
    noInterrupts();
    count = num_RQ_reminders;
    ptr = start_of_RQ_chain;
    Serial.println(F("_______________________________"));
    Serial.println(F("       REMINDER QUEUE"));
    Serial.print(F("          Num in RQ = "));
    Serial.println(count);
    Serial.print(F(" start of RQ chain = "));
    Serial.println(ptr);
    Serial.print(F("   end of RQ chain = "));
    Serial.println(end_of_RQ_chain);
    if (count > 0) {
      do {
        for (i = 0; i < free_chain_entry_size; i++) {
          Serial.print(F("RQ["));
          Serial.print(ptr);
          Serial.print(F("]"));
          Serial.print(i);
          Serial.print(F("] = "));
          Serial.println(RQ[ptr][i]);
        }
        Serial.print(F("\n"));
        ptr = RQ[ptr][0]; //  look at next entry/block
        count --;
      }
      while ((ptr != end_of_chain_value) && (count > 0));
    }
    Serial.println(F(""));
    Serial.println(F("_______________________________\n"));
    Serial.flush();
    interrupts();
  }
}
//
// Utility to print the free chain
//
void print_free_chain() {
  int ptr, count;
  if (diags_on) {
    noInterrupts();
    count = num_free_RQ_blocks;
    ptr = start_of_free_RQ_chain;
    Serial.println(F(""));
    Serial.println(F("_______________________________"));
    Serial.println(F("         FREE CHAIN"));
    Serial.print(F("  Num in free chain = "));
    Serial.println(count);
    Serial.print(F("start of free chain = "));
    Serial.println(ptr);
    if (count > 0) {
      do {
        Serial.print(F("RQ["));
        Serial.print(ptr);
        Serial.print(F("][0] = "));
        Serial.println(RQ[ptr][0]);
        ptr = RQ[ptr][0]; //  look at next entry/block
        count --;
      }
      while ((ptr != end_of_chain_value) && (count > 0));
    }
    Serial.println(F("_______________________________\n"));
    Serial.flush();
    interrupts();
  }
}

/* Ron D Bentley (UK) (c) 2020
   This tab contains additional routines (and more) to support real-time reminders
   these being in addition to the base framework which privides elapsed time reminder (ETR)
   functionality.
*/
//****************************************************************************************
//                                    Date Functions
//****************************************************************************************
// Define the start date (origin) for elapsed days calculations.
// There is a constraint on the origin date:
//    1. it MUST be of the form 01/01/LEAP_YEAR(or pseudo Leap year, eg divisible by 100)
//    2. Also, if this is changed then change day_of_week_offset too.
//
int origin_day   = 1;
int origin_month = 1;
int origin_year  = 2020;

int today_day_number;   // used to keep a note of the day_number for today in midnight process
int today_day_of_week;  // used to keep a note of the day_of_week for today in midnight process

#define day_of_week_offset  2 // offset value for referencing days_of_week array as
// 1/1/2020 is a Wednesday, so offset provides
// correcting adjustment for day_of_week function,
// as day_number(1,1,2020) gives 1
#define valid_date     1
#define invalid_day   -1
#define invalid_month -2
#define invalid_year  -3

#define Jan            1
#define Feb            2
#define Mar            3
#define Apr            4
#define May            5
#define Jun            6
#define Jul            7
#define Aug            8
#define Sep            9
#define Oct           10
#define Nov           11
#define Dec           12

#define Sunday         0
#define Monday         1
#define Tuesday        2
#define Wednesday      3
#define Thursday       4
#define Friday         5
#define Saturday       6

char days_of_week[7][12] =
{
  "Sunday", "Monday", "Tuesday", "Wednesday", "Thursday", "Friday", "Saturday"
};
byte days_in_month[13] =
{
  0,  // entry 0 not used
  31, 28, 31, 30, 31, 30, 31, 31, 30, 31, 30, 31        //  Jan, Feb, March, etc
};
int accumulated_days_in_month[13] =
{
  0, // entry 0 not used
  0, 31, 59, 90, 120, 151, 181, 212, 243, 273, 304, 334 // Jan, Feb, March, etc
};
//
// Checks the given day,month,year being a valid date
//
int check_date(int day, int month, int year) {
  int Days_in_month;
  if (year < origin_year) {
    return invalid_year;
  }
  if (month < Jan || month > Dec) {
    return invalid_month;
  }
  Days_in_month = days_in_month[month];
  if (month == Feb && leap_year(year)) {
    Days_in_month++; // adjust for leap year
  }
  if (day < 1 || day > Days_in_month) {
    return invalid_day;
  }
  return valid_date;
}
//
// leap_year will return whether the given year is a leap year
// and takes into account the leap year rule:
//    if divisible by   4 then it IS a leap year, UNLESS
//    divisible by 100 then it is NOT a leap year, UNLESS
//    divisible by 400 the it IS a leap year.
//
int leap_year(int year) {
  if (year % 400 == 0) {
    return true;
  }
  if (year % 100 == 0) {
    return false;
  }
  if (year % 4   == 0) {
    return true;
  }
  return false;
}
//
// day_number will return the number of inclusive elapsed days from the
// origin date of the given parameter date, taking ino account leap years.
//
int day_number(int day, int month, int year) {
  int num_leaps, yr;
  // start by counting the number of leap years from the origin year
  // to the given year.
  num_leaps = 0;
  for (yr = origin_year; yr <= year; yr = yr + 4) {
    if (leap_year(yr)) num_leaps++;
  }
  // final adjustment if given year being a leap
  // year and given month is Jan or Feb.
  if (month < Mar && leap_year(year)) {
    num_leaps--;
  }
  // now calculate elapsed days...
  return (year - origin_year) * 365
         + accumulated_days_in_month[month]
         + day
         + num_leaps;
}
//
// Given a day_number, function will determine the date as day, month, year.
//
void date_from_day_number(int day_number, int &day, int &month, int &year) {
  int days_in_year, Days_in_month;
  // determine what year the day_number falls in, count up from origin_year
  // in full years as days.
  year = origin_year;
  if (leap_year(year)) {
    days_in_year = 366;
  } else {
    days_in_year = 365;
  }
  do {
    if (day_number > days_in_year) {
      // move year on
      day_number = day_number - days_in_year;
      year++;
      if (leap_year(year)) {
        days_in_year = 366;
      } else {
        days_in_year = 365;
      }
    }
  }
  while (day_number > days_in_year);
  // now step through days_in_month to determine month.  What is
  // left as the remainder is the day of the month, and we are done.
  month = 1;
  Days_in_month = days_in_month[1];
  while (month <= Dec && day_number > Days_in_month) {
    if (month == Feb && leap_year(year)) {
      Days_in_month = 29;
    } else {
      Days_in_month = days_in_month[month];
    }
    day_number = day_number - Days_in_month;
    month++;
    if (month <= Dec) { // this set up for next while cycle test condition
      Days_in_month = days_in_month[month];
      if (month == Feb && leap_year(year)) {
        Days_in_month++;
      }
    }
  }
  day = day_number; // what is left in day_number is now that day of the month
}
//
// returns the index for the day of the week in the days_of_week array
//
int day_of_week(int day, int month, int year) {
  return (day_number(day, month, year)
          + day_of_week_offset) % 7; // map to 0 (Sunday), 1 (Monday), ... , 6 (Saturday)
}

//******************************************************************************************
//                  date & time funcions required for other ETR/RTR code
//                                  DO NOT REMOVE
//******************************************************************************************
//  RTC libraries and declarations
#include <RTClib.h>

RTC_DS1307 rtc;

void display_now_date_time() {
  if (RTC_enabled) {
    DateTime now = rtc.now();
    Serial.print(now.day());
    Serial.print(F("/"));
    Serial.print(now.month());
    Serial.print(F("/"));
    Serial.print(now.year());
    Serial.print(F(", "));
    Serial.print(days_of_week[now.dayOfTheWeek()]);
    Serial.print(F(", "));
    Serial.print(now.hour());
    Serial.print(F(":"));
    Serial.print(now.minute());
    Serial.print(F(":"));
    Serial.println(now.second());
    Serial.flush();
  }
}

//
// Function returns the number of seconds since midnight.
long unsigned int seconds_since_midnight() {
  long unsigned int secs, mins, hrs;
  if (RTC_enabled) {
    if (rtc.isrunning()) {
      DateTime now = rtc.now();
      hrs  = now.hour();
      mins = now.minute();
      secs = now.second();
      return hrs * 3600 + mins * 60 + secs;
    }  else  {
      Serial.println(F("!secs_since_midnight - RTC is not operating, terminating!"));
      Serial.flush();
      exit(0);
    }
  } else return 0; // RTC not configured
}

// Copyright (c) Ron D Bentley (UK), see copyright notice
//
//  Scan the reminder list to process active reminder entries (ETR and RTR types).
//
void scan_R_list(int E_or_R) {
  int R_entry, R_type, R_status;
  //  scan each possible reminder list entry and process if active according to reminder type
  for (R_entry = 0; R_entry < max_R_list_entries; R_entry++) {
    if (R_list[R_entry].R_type != inactive) {
      // this reminder entry is active
      R_type = R_list[R_entry].R_type;
      R_status = 0;    //  assume the timed remider is not the final one, for now
      // process ETR or RTR entries depending on value of the parameter
      if (E_or_R == ETR && R_type >= ET_oneoff_type && R_type <= ET_repeat_duration_type) {
        // process ETR reminder entry
        if (R_list[R_entry].R_count_down > 0) {
          R_list[R_entry].R_count_down--; // decrement countdown timer
        }
        if (R_list[R_entry].R_count_down == 0) {
          //  count down time elapsed so time to raise the reminder via the
          //  RQ for end user asynchronous processing
          //R_status = 0;    //  assume the timed remider is not the final one, for now
          switch (R_type) {
            case ET_oneoff_type:
              // 'oneoff' reminder type so remove this reminder as it has elapsed
              R_list[R_entry].R_type = inactive;
              R_status = final_alert;
              break;
            case ET_recurring_type:
              //  'recurring' reminder type so reset counter for next wait cycle
              R_list[R_entry].R_count_down = R_list[R_entry].R_freq;
              break;
            case ET_repeat_duration_type:
              if (R_list[R_entry].R_duration == 0)
              { //  no further reminders are due of this reminder type
                //  ('remind_duration') time has now elapsed so remove this reminder
                R_list[R_entry].R_type = inactive;
                R_status = final_alert;
              } else {
                //  'repeat_duration' type, so reset counter for next cycle
                if (R_list[R_entry].R_duration < R_list[R_entry].R_freq) {
                  // less time left than defined by R_freq, so take lesser value
                  R_list[R_entry].R_count_down = R_list[R_entry].R_duration;
                  R_list[R_entry].R_duration = 0;
                } else {
                  //  reduce end time by R_freq
                  if (R_list[R_entry].R_freq == 0) {
                    R_list[R_entry].R_count_down = R_list[R_entry].R_duration;
                    R_list[R_entry].R_duration = 0;
                  } else {
                    R_list[R_entry].R_duration   = R_list[R_entry].R_duration - R_list[R_entry].R_freq;
                    R_list[R_entry].R_count_down = R_list[R_entry].R_freq;
                  }
                }
              }
              break;
          }
          // assemble R_status to be a compound value to store whether this is a final alert
          // for this reminder or not, together with the reminder type and subtype.
          // These calues will be unpicked at set to global variables once the reminder
          // has triggered and scan_RQ takes it off the RQ. This saves a little on space.
          R_status = (R_status << 15) + (R_type << 8) + R_list[R_entry].R_subtype;
          if (insert_into_RQ(R_status,
                             R_list[R_entry].R_user1,
                             R_list[R_entry].R_user2,
                             R_list[R_entry].R_user3,
                             R_list[R_entry].R_user4) == fail) {
            if (diags_on) {
              Serial.println(F("\n!!scan_list ETR insert failure!!"));
              Serial.flush();
            }
          }
        }
      }
      else if (E_or_R == RTR && R_type >= RT_oneoff_type && R_type <= RT_repeat_duration_type) {
        // process RTR reminder entry
        if (R_list[R_entry].R_remind_at == Seconds_since_midnight) {
          switch (R_type) {
            case RT_oneoff_type:
              R_list[R_entry].R_type = inactive; // reminder has now expired so clear it
              R_status = final_alert;
              break;
            case RT_recurring_type:
              // perform modulo 24 hours arithmetic on next reminder time (86400 = 24 hrs in seconds)
              R_list[R_entry].R_remind_at = (R_list[R_entry].R_remind_at + R_list[R_entry].R_freq) % 86400;
              break;
            case RT_repeat_duration_type:

              if (R_list[R_entry].R_duration == 0) {
                //  no further reminders are due of this reminder type
                //  ('remind_duration') time has now elapsed so remove this reminder
                R_list[R_entry].R_type = inactive;
                R_status = final_alert;
              } else {
                //  'repeat_duration' type, so reset counter for next cycle
                if (R_list[R_entry].R_duration < R_list[R_entry].R_freq) {
                  // less time left than defined by R_freq, so take lesser value
                  R_list[R_entry].R_remind_at = (R_list[R_entry].R_remind_at + R_list[R_entry].R_duration) % 86400;
                  R_list[R_entry].R_duration = 0;
                } else {
                  //  reduce end time by R_freq
                  if (R_list[R_entry].R_freq == 0) {
                    R_list[R_entry].R_remind_at = (R_list[R_entry].R_remind_at + R_list[R_entry].R_duration) % 86400;
                    R_list[R_entry].R_duration  = 0;
                  } else {
                    R_list[R_entry].R_duration  = R_list[R_entry].R_duration - R_list[R_entry].R_freq;
                    R_list[R_entry].R_remind_at = (R_list[R_entry].R_remind_at + R_list[R_entry].R_freq) % 86400;
                  }
                }
              }
              break;
          }
          R_status = (R_status << 15) + (R_type << 8) + R_list[R_entry].R_subtype;
          if (insert_into_RQ(R_status,
                             R_list[R_entry].R_user1,
                             R_list[R_entry].R_user2,
                             R_list[R_entry].R_user3,
                             R_list[R_entry].R_user4) == fail) {
            if (diags_on) {
              Serial.println(F("\n!!scan_list RTR insert failure!!"));
              Serial.flush();
            }
          }
        }
      }
    }
  }
}

//
//  This routine drives the Real-Time scan process and is initiated via timer0 interrupts
//
int RTR_Processor() {
  static  int last_seconds = 60; // a start value that now_seconds cant achieve
  static int now_second = 0;
  if (rtc.isrunning()) {
    DateTime now = rtc.now();
    now_second = now.second();   // get RTC second now
    if (now_second != last_seconds) {
      // must have moved on by at least 1 second so scan RT reminder list entries
      last_seconds = now_second; // ready for next pass
      Seconds_since_midnight = seconds_since_midnight(); // used in scan_R_list for RTR checking
      scan_R_list(RTR);
      return 1;                  // return that remind list was scanned this pass
    }
  } else  {
    Serial.println(F("!RTR_Processor - RTC not operating, terminating!"));
    Serial.flush();
    exit(0);
  }
  return 0;                      // return that remind list not scanned this pass
}

//
//  create_ET_reminder() - routine creates a new Elapsed Time (ET) reminder in R_list if
//  there is space and parameters are valid!
//
//  Paramerters in scope, by R_type:
//  one_off, R_type = 1
//  R_start_in: Yes
//  R_freq:     n/a, ignored if set
//  R_duration: n/a, ignored if set
//
//  recurring, R_type = 2
//  R_start_in: Yes
//  R_freq:     Yes
//  R_duration: n/a, ignored if set
//
//  for a duration, R_type = 3
//  R_start_in: Yes
//  R_freq:     Yes
//  R_duration: Yes
//
//  Note that:
//  1.  the parameters for start, frequency and for (duration) all follow same format:
//      hrs, mins, secs, subsecs
//  2.  the subsecs value is the number of cycles per second the remind list is scanned.
//      It is 0..'scans_per_sec'-1.  'scans_per_sec' is 'timer1_freq' / 'ETR_R_list_scan_freq'.
//
int create_ET_reminder(int R_type, int R_subtype,
                       long signed int R_start_in_hrs,   long signed int R_start_in_mins,
                       long signed int R_start_in_secs,  long signed int R_start_in_subsecs,
                       long signed int R_freq_hrs,       long signed int R_freq_mins,
                       long signed int R_freq_secs,      long signed int R_freq_subsecs,
                       long signed int R_duration_hrs,   long signed int R_duration_mins,
                       long signed int R_duration_secs,  long signed int R_duration_subsecs,
                       int R_user1, int R_user2, int R_user3, int R_user4) {
  int R_entry, R_list_status;
  long signed int R_start_in, R_freq, R_duration;
  //  start by validating the parameters
  if (R_type < ET_oneoff_type || R_type > ET_repeat_duration_type) {
    return invalid_R_type;
  }
  if (R_subtype < 0 || R_subtype > 255) {
    return invalid_R_subtype;
  }
  // R_start_in is required for all R_types, so validate
  if (R_start_in_mins < 0 || R_start_in_mins > 59) {
    return invalid_start_in_mins;
  }
  if (R_start_in_secs < 0 || R_start_in_secs > 59) {
    return invalid_start_in_secs;
  }
  if (R_start_in_subsecs < 0 || R_start_in_subsecs >= scans_per_sec) {
    return invalid_start_in_subsecs;
  }
  //  validate R_freq
  if (R_type != ET_oneoff_type) {
    //  R_frequency is required for recurring_type or repeat_duration_type, so validate
    //  and set up the interval count
    if (R_freq_mins < 0 || R_freq_mins > 59) {
      return invalid_freq_mins;
    }
    if (R_freq_secs < 0 || R_freq_secs > 59) {
      return invalid_freq_secs;
    }
    if (R_freq_subsecs < 0 || R_freq_subsecs >= scans_per_sec) {
      return invalid_freq_subsecs;
    }
    R_freq_secs = R_freq_secs + timer_drift_adjustment * R_freq_hrs; // add the number of secs per hour adjustment

    R_freq =  R_freq_hrs   * scans_per_hr  +
              R_freq_mins  * scans_per_min +
              R_freq_secs  * scans_per_sec +
              R_freq_subsecs;
    if (R_type == ET_recurring_type && R_freq == 0) {
      return invalid_freq;
    }
  } else {
    R_freq = 0;
  }
  //  validate R_duration time if R_type is repeat_duration_type
  if (R_type == ET_repeat_duration_type) {
    if (R_duration_mins < 0 || R_duration_mins > 59) {
      return invalid_duration_mins;
    }
    if (R_duration_secs < 0 || R_duration_secs > 59) {
      return invalid_duration_secs;
    }
    if ( R_duration_subsecs < 0 || R_duration_subsecs >= scans_per_sec) {
      return invalid_duration_subsecs;
    }
    R_duration_secs = R_duration_secs + timer_drift_adjustment * R_duration_hrs; // add the number of secs per hour adjustment
    R_duration =  R_duration_hrs * scans_per_hr    +
                  R_duration_mins * scans_per_min  +
                  R_duration_secs * scans_per_sec  +
                  R_duration_subsecs;
    if (R_freq > R_duration) {
      return invalid_freq;
    }
  } else {
    R_duration = 0;
  }
  R_start_in_secs = R_start_in_secs + timer_drift_adjustment * R_start_in_hrs; // add the number of secs per hour adjustment
  R_start_in = R_start_in_hrs * scans_per_hr    +
               R_start_in_mins * scans_per_min  +
               R_start_in_secs * scans_per_sec  +
               R_start_in_subsecs;
  //  now look for an empty slot...
  R_entry = 0; //  start with first reminder entry and scan until empty entry found, or not
  do {
    // R_list_status=R_list[R_entry].R_type;
    if ( R_list[R_entry].R_type == inactive) {
      //  this entry is not used, so set up it...
      R_list[R_entry].R_subtype     = R_subtype;
      R_list[R_entry].R_start_in    = R_start_in;     //  used for all R_types
      R_list[R_entry].R_freq        = R_freq;         //  only used if R_type is recurring_type or repeat_duration_type
      R_list[R_entry].R_duration    = R_duration;     //  only used if R_type is repeat_duration_type
      R_list[R_entry].R_count_down  = R_start_in;
      //  End user variables held in a reminder entry
      R_list[R_entry].R_user1 = R_user1;
      R_list[R_entry].R_user2 = R_user2;
      R_list[R_entry].R_user3 = R_user3;
      R_list[R_entry].R_user4 = R_user4;
      //  set this reminder as active
      noInterrupts();
      R_list[R_entry].R_type = R_type;  //  note, setting this last variable will trigger the timer scan
      interrupts();
      return  R_entry;  //  return with the entry number of the reminder
    }
    R_entry++;  // look at next entry
  }
  while ( R_entry < max_R_list_entries);
  return reminder_list_full;
}
//
//  create_RT_reminder() - routine creates a new Real-Time (RT)reminder in R_list if
//  there is space and parameters are valid!
//
//  Paramerters in scope, by R_type:
//  one_off, R_type = 4
//  R_remind_at:  Yes
//  R_freq:       n/a, ignored if set
//  R_duration:   n/a, ignored if set
//
//  recurring, R_type = 5
//  R_remind_at:  Yes
//  R_freq:       Yes
//  R_duration:   n/a, ignored if set
//
//  for a duration, R_type = 6
//  R_remind_at:  Yes
//  R_freq:       Yes
//  R_duration:   Yes
//
//  Note that:
//  1.  the parameters for remind_at, frequency and for (duration) all follow same format:
//      hrs, mins, secs (no subsecs)
//
int create_RT_reminder(int R_type, int R_subtype,
                       long signed int R_remind_at_hrs,  long signed int R_remind_at_mins,
                       long signed int R_remind_at_secs,
                       long signed int R_freq_hrs,       long signed int R_freq_mins,
                       long signed int R_freq_secs,
                       long signed int R_duration_hrs,   long signed int R_duration_mins,
                       long signed int R_duration_secs,
                       int R_user1, int R_user2, int R_user3, int R_user4) {
  int R_entry;
  long signed int R_remind_at, R_freq, R_duration;
  if (RTC_enabled) {
    //  start by validating the parameters
    if (R_type < RT_oneoff_type || R_type > RT_repeat_duration_type) {
      return invalid_R_type;
    }
    if (R_subtype < 0 || R_subtype > 255) {
      return invalid_R_subtype;
    }
    if (R_remind_at_hrs  < 0 || R_remind_at_hrs  > 23) {
      return invalid_RT_hrs;
    }
    if (R_remind_at_mins < 0 || R_remind_at_mins > 59) {
      return invalid_RT_mins;
    }
    if (R_remind_at_secs < 0 || R_remind_at_secs > 59) {
      return invalid_RT_secs;
    }
    //  validate R_freq
    if (R_type != RT_oneoff_type) {
      //  R_frequency is required for recurring_type or repeat_duration_type, so validate
      //  and set up the interval count
      if (R_freq_mins < 0 || R_freq_mins > 59) {
        return invalid_freq_mins;
      }
      if (R_freq_secs < 0 || R_freq_secs > 59) {
        return invalid_freq_secs;
      }
      R_freq =  R_freq_hrs * 3600 +
                R_freq_mins * 60 +
                R_freq_secs;
      if (R_type == RT_recurring_type && R_freq == 0) {
        return invalid_freq;
      }
    } else {
      R_freq = 0;
    }
    //  validate R_duration time if R_type is repeat_duration_type
    if (R_type == RT_repeat_duration_type) {
      if (R_duration_mins < 0 || R_duration_mins > 59) {
        return invalid_duration_mins;
      }
      if (R_duration_secs < 0 || R_duration_secs > 59) {
        return invalid_duration_secs;
      }
      R_duration =  R_duration_hrs * 3600 +
                    R_duration_mins * 60 +
                    R_duration_secs;
      if (R_freq > R_duration) {
        return invalid_freq;
      }
    } else {
      R_duration = 0;
    }
    // now calculate the numer of seconds since last midnight of this real-time
    R_remind_at = R_remind_at_hrs   * 3600  +
                  R_remind_at_mins  * 60    +
                  R_remind_at_secs ;
    //  now look for an empty slot...
    R_entry = 0; //  start with first reminder entry and scan until empty entry found, or not
    do {
      if ( R_list[R_entry].R_type == inactive) {
        //  this entry is not used, so set up it...
        R_list[R_entry].R_subtype     = R_subtype;
        R_list[R_entry].R_remind_at   = R_remind_at;    // real-time of reminder in secs from last midnight
        R_list[R_entry].R_freq        = R_freq;         // only used if R_type is recurring_type or repeat_duration_type
        R_list[R_entry].R_duration    = R_duration;     // only used if R_type is repeat_duration_type
        R_list[R_entry].R_count_down  = 0;              // not used for RTRs
        //  End user variables held in a reminder entry
        R_list[R_entry].R_user1 = R_user1;
        R_list[R_entry].R_user2 = R_user2;
        R_list[R_entry].R_user3 = R_user3;
        R_list[R_entry].R_user4 = R_user4;
        //  set this reminder as active
        noInterrupts();
        R_list[R_entry].R_type = R_type;  //  note, setting this last value/field will trigger the scan process
        interrupts();
        return  R_entry;  //  return with the entry number of the reminder
      }
      R_entry++;  // look at next entry
    }
    while ( R_entry < max_R_list_entries);
    return reminder_list_full;
  }
  return RTC_not_configured;
}

//
//  Routine deletes a reminder entry of the specified parameters
//  That is, for the given R_id and R_id_subtype values
//  if 'lockout' true then interrupts are first disabled and then reenabled
//  otherwise.
//  if called from within a routine where interrupts are disabled, eg and
//  interrupt routine then 'lockout' should be set to false as interrupts
//  will already be disabled.
//
int delete_reminder(int R_type, int R_subtype) {
  int R_entry;
  noInterrupts();
  for (R_entry = 0; R_entry < max_R_list_entries; R_entry++) {
    if ( R_list[R_entry].R_type != inactive) {
      if (R_type == R_list[R_entry].R_type && R_subtype == R_list[R_entry].R_subtype) {
        //  match on this entry, so remove it, ie make inactive
        R_list[R_entry].R_type = inactive;
        interrupts();
        return success;
      }
    }
  }
  interrupts();
  return fail;
}

//
//  Print given Reminder details
//
void print_reminder(int R_entry) {
  int R_type;
  long unsigned int R_remind_at, hrs, mins, secs;
  noInterrupts();
  if (R_list[R_entry].R_type != inactive) {
    Serial.println(F("============ Reminder Parameters ================"));
    Serial.print(F("Reminder entry no: ")); Serial.println(R_entry);
    R_type = R_list[R_entry].R_type;
    Serial.print(F("R_type: ")); Serial.print(R_type);
    Serial.print(F("  R_subtype:  ")); Serial.println(R_list[R_entry].R_subtype);
    if (R_type >= ET_oneoff_type && R_type <= ET_repeat_duration_type) {
      Serial.print(F("R_start_in: ")); Serial.print(R_list[R_entry].R_start_in);
      Serial.print(F(" "));
    } else {
      R_remind_at = R_list[R_entry].R_remind_at;
      hrs = R_remind_at / 3600;
      secs = R_remind_at % 3600;
      mins = secs / 60;
      secs = secs % 60;
      Serial.print(F("R_remind_at: "));
      Serial.print(hrs); Serial.print(F(":"));
      Serial.print(mins); Serial.print(F(":"));
      Serial.print(secs); Serial.print(F(" ("));
      Serial.print(R_remind_at);
      Serial.println(F(")" ));
    }
    Serial.print(F("R_freq: ")); Serial.print(R_list[R_entry].R_freq);
    Serial.print(F(" R_duration: ")); Serial.println(R_list[R_entry].R_duration);
    Serial.print(F("R_count_down: ")); Serial.println(R_list[R_entry].R_count_down);
    Serial.println(F("============== User Parameters =================="));
    Serial.print(F("R_user1: ")); Serial.println(R_list[R_entry].R_user1);
    Serial.print(F("R_user2: ")); Serial.println(R_list[R_entry].R_user2);
    Serial.print(F("R_user3: ")); Serial.println(R_list[R_entry].R_user3);
    Serial.print(F("R_user4: ")); Serial.println(R_list[R_entry].R_user4);
  } else {
    Serial.print(F("\n\n** Reminder "));
    Serial.print(R_entry);
    Serial.println(F(" is inactive **"));
  }
  Serial.flush();
  interrupts();
}

// Copyright (c) Ron D Bentley (UK), see copyright notice
//
// This framework is provided with two standing reminders that provide:
//  1.  a heart beat visual monitor which shows that the code is operating.
//      This is configured for pin 13 (on board LED), but do change if necessary.
//  2.  a midnight processor to allow daily processing/housekeeping to be
//      carried out as necessary ech midnight.a
//
int hb_intensity                = 255; // start by setting to max output level
#define heart_beat_pin    LED_BUILTIN  // digital pin for visible heart beat
#define heart_beat                254  // ETR reminder sub_type for heart beat
#define midnight                  255  // RTR reminder sub_type for midnight processing

//  %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
//  H00_Setup [DECLARE] - insert any additional declaration requirements here.
//  %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%




//
void setup()
{
  int result;
  if (diags_on) {
    Serial.begin(115200);
    if (RTC_enabled) {
      !rtc.begin();
      if (!rtc.isrunning())
      {
        Serial.println(F("!setup() - RTC is not operating, terminating!"));
        Serial.flush();
        exit(0);
      }
    }
  }
  if (RTC_enabled) {
    //  Set up 'today_day_number' to provide ready access to this value at any point
    //  in the program without the need for it to be recalculated.
    //  This will get incremented each midnight to stay in step with the current date.
    DateTime now = rtc.now();
    today_day_number = day_number(now.day(), now.month(), now.year());
    today_day_of_week = (today_day_number + day_of_week_offset) % 7; // map to 0 (Sunday), 1 (Monday),.., 6 (Saturday)
  }
  // **********************************************************************************
  // set up the two standing reminders:
  //  1.  the heart beat visual monitor as an ETR, to show processes are operating, and
  //  2.  the midnight RTR each midnight to deal with any daily processing/housekeeping
  // The alerts for each of the above remnders are dealt with in the main segment.
  // **********************************************************************************
  int freq_secs, freq_subsecs;
  pinMode(heart_beat_pin, OUTPUT);
  // set the ETR reminder for the heart beat to be 1/2 second if possible, if not,
  // set to 1 second.
  freq_subsecs = scans_per_sec / 2;                           // take as 1/2 scan rate per second, if possible
  if (freq_subsecs == 0) freq_secs = 1; else freq_secs = 0;
  result = create_ET_reminder(ET_recurring_type, heart_beat,
                              0, 0, 0, 0,                     // start immediately
                              0, 0, freq_secs, freq_subsecs,  // 1/2 or 1 second frequency
                              0, 0, 0, 0,                     // not used
                              0, 0, 0, 0);                    // not used
  if (result < 0 && diags_on) {
    Serial.print(F("setup() - error creating ETR for heart_beat, error value = "));
    Serial.println(result);
    Serial.flush();
  }
  if (RTC_enabled) {
    //  set up RTR for each midnight, so that any daily processing can be performed
    result = create_RT_reminder(RT_recurring_type, midnight,
                                0, 0, 0,      // start at midnight (00:00:00)
                                24, 0, 0,      // repeat each midnight (24 hrs)
                                0, 0, 0,      // not used
                                0, 0, 0, 0);  // not used
    if (result < 0 && diags_on) {
      Serial.print(F("setup() error creating RTR for midnight, error value = "));
      Serial.println(result);
      Serial.flush();
    }
  }
  //  %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
  //  H00_Setup [INITIALISE] - insert any additional initialisation
  //  requirements here, but before the timers and remind queues are initialised
  //  %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%




  //  ******************************************************************
  //  create free chain and initialise timers (0 or 2 and 1)
  //  ******************************************************************
  create_RQ_free_chain();   //  create free chain of reminder queue blocks
  suspend_reminders();      //  ensure timers do not action the reminder list yet
  initialise_timers();
  resume_reminders();       //  allow timer scans of the reminder list
}

// Copyright (c) Ron D Bentley (UK), see copyright notice
//
//  main segment for end user code
//  insert end user code where indicated:
//  1.  if timed reminder alert processing is needed then within the 'do{if (scan_RQ){...}'
//      control block, otherwise.  Use swich case on R_subtype to process alerts.
//  2.  for non-reminder requirements, place code within the 'do{if (scan_RQ)..else {..}'
//      control block

void loop() {
  do {
    if (scan_RQ() != no_reminder_requests) {
      //  *******************************************************************************
      //  the following global data variables are available at this point relating to the
      //  reminder triggered/alerted:
      //  1.  R_type          - reminder type, ETRs: 1, 2, or 3, / RTRs: 4, 5, or 6
      //  2.  R_subtype       - reminder subtype (0 <= R_subtype <= 255)
      //  3.  R_status        - set to 1 if this is the FINAL reminder alert, 0 otherwise.
      //                        Only relevant for oneoff and repeat_duration reminder types.
      //  4.  R_user1-R_user4 - user data values set up when the reminder was created
      //
      //  The above variable are those defined when the timed reminder was created.
      //  These can be 'crafted' to control flow and decision processes.
      //
      //  Insert end user code here to process timed reminder alerts by R_subtype.
      //  *******************************************************************************
      switch (R_subtype) {
        case heart_beat:
          //  ******** provides a visual indication that the program is running
          analogWrite(heart_beat_pin, hb_intensity);
          // toggle heart beat output level for next pass
          hb_intensity = 255 - hb_intensity;  // produces 0 and 255 on alternate passes
          break;
        case midnight:
          // ********* midnight processing. Insert any code relevant for daily housekeeping
          //           Note, this is only entered if the RTC is configured.
          today_day_number++;                              // day_number for today, a new day
          today_day_of_week = (today_day_of_week + 1) % 7; // next day of week value
          break;
        // %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
        // M00_Main_Segment [ALERT PROCESSING], timer alert processing -
        // Insert ETR/RTR alert switch case code handling here:
        // %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%







        // default switch value 'catcher'
        default:
          Serial.print(F("!Spurious switch value="));
          Serial.println(R_subtype);
          Serial.flush();
          display_now_date_time();
          break;
      }
    } else {
      //  %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
      //  M00_Main_Segment [GENERAL PROCESSING].
      //  Reminder queue is currently empty, so do other things.
      //  Insert end user code here for processing non-reminder alerts
      //  %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%






    }
  } while (true);
}
