The COLLATZ Conjecture

An easy to explore and yet unproven mathematical sequence

BeginnerProtip471
The COLLATZ Conjecture

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
Any Arduino microcontroller will do
×1

Software apps and online services

Arduino IDE
Arduino IDE

Story

Read more

Schematics

Collatz Conject Hardware Setup

Simple Configuration for Producing Collatz Sequences

Code

Collatz Conjecture

C/C++
A short C++ program to produce Collatz sequences for any given positive integer.
//
// Ron Bentley, Stafford UK
// November 2021
//
// This example and code is in the public domain and may be used without
// restriction and without warranty.
//
// Collatz Conjecture
// ^^^^^^^^^^^^^^^^^^
//
// A sketch to produce the Collatz sequence for a given positive integer.
// The Collatz sequence for any positive integer, N, is determined as follows:
//
//   if N is odd set  N = 3*N + 1 (which will then be even)
//   if N is even set N = N/2     (which will be either be an odd or an even number)
//   repeat the above until N converges to 1, ie N = 1.
//
// For any given positive integer the Collatz squence will always converge to 1, although
// this remains unproven.  The Collatz conjecture is also know as the 3N+1 conjecture.
//

uint32_t collatz_num;  // the positive integer for which the Collatz sequence will be determined

//
// The function implements/executes the Collatz 'rules' to determine the Collatz
// sequence for the given positive integer.
// The function prints each number in the Collatz sequence to the currently
// selected output stream - the serial monitor ot the serial polotter.
//
void collatz(uint32_t collatz_num) {
  uint16_t convergence_steps; // records the number of steps performed before the Collatz sequence reaches 1
  convergence_steps = 0;      // count of the number of steps to convergence
  Serial.print("\nCollatz sequence for ");
  Serial.print(collatz_num);
  Serial.println("...");
  // apply the Collatz rules
  while (collatz_num > 1) {
    convergence_steps++;
    Serial.println(collatz_num);
    if (collatz_num & 1 == 1) {// test bottom bit
      // odd number
      collatz_num = collatz_num * 3 + 1;
    } else
    {
      // even number
      collatz_num = collatz_num >> 1; // divide by 2
    }
  }
  // done, we have reached convergence (1)
  convergence_steps++;
  Serial.println(collatz_num); // final value in the Collatz sequence, which will be 1
  Serial.print("Collatz convergence steps = ");
  Serial.println(convergence_steps);
  Serial.flush();
}

uint32_t read_collatz_num() {
  int32_t collatz_num = 0;
  while (!Serial.available()); // wait for input
  while (collatz_num <= 0) {
    collatz_num = Serial.parseInt(); // read next +ve integer in the current input stream
  }
  // input is a positive integer, now flush out any following chars
  delay(50); // this shouldnt be necessary but it is!
  while (Serial.available() > 0) {
    // still more chars in the input stream so read and discard
    Serial.read();
  }
  return collatz_num; // return the integer read
}

void setup() {
  Serial.begin(9600);
  Serial.println("Collatz Conjecture Examples");
  Serial.println("^^^^^^^^^^^^^^^^^^^^^^^^^^^");
  Serial.println("Enter any positive integer and press return/send");
}

void loop() {
  // keep reading user supplied values and determine their Collatz sequences
  do {
    collatz_num = read_collatz_num(); // read user input
    collatz(collatz_num);
  } while (true);
}
