/*Begining of Auto generated code by Atmel studio */
#include <Arduino.h>
#include <Colorduino.h>
int button_a_status;
int button_b_status;
int button_c_status;
int button_d_status;
ColorRGB COLOR_BLACK = {0, 0, 0};
ColorRGB COLOR_RED = {255, 0, 0};
ColorRGB COLOR_GREEN = {0, 255, 0};
ColorRGB COLOR_BLUE = {0, 0, 255};
ColorRGB COLOR_YELLOW = {255, 255, 0};
ColorRGB COLOR_CYAN = {0, 255, 255};
ColorRGB COLOR_MAGENTA = {255, 0, 255};
ColorRGB COLOR_WHITE = {255, 255, 255};
#define BUTTON_A_PIN 18 //grean SDA
#define BUTTON_D_PIN 1 //blue TXD
#define BUTTON_C_PIN 0 //blue RXD
#define BUTTON_B_PIN 19 //orange SCL
#define DEFAULT_LONGPRESS_LEN 25 // Min nr of loops for a long press
#define DELAY 20 // Delay per loop in ms
//////////////////////////////////////////////////////////////////////////////
enum { EV_NONE=0, EV_LONGPRESS = 1 };
//////////////////////////////////////////////////////////////////////////////
// Class definition
class ButtonHandler {
public:
// Constructor
ButtonHandler(int pin, int longpress_len=DEFAULT_LONGPRESS_LEN);
// Initialization done after construction, to permit static instances
void init();
// Handler, to be called in the loop()
int handle();
protected:
boolean was_pressed; // previous state
int pressed_counter; // press running duration
const int pin; // pin to which button is connected
const int longpress_len; // longpress duration
};
ButtonHandler::ButtonHandler(int p, int lp)
: pin(p), longpress_len(lp)
{
}
void ButtonHandler::init()
{
pinMode(pin, INPUT);
was_pressed = false;
pressed_counter = 0;
}
int ButtonHandler::handle()
{
int event;
int now_pressed = digitalRead(pin);
if (!now_pressed && was_pressed) {
// handle release event
if (pressed_counter > longpress_len)
event = EV_LONGPRESS;
}
else
event = EV_NONE;
// update press running duration
if (now_pressed)
++pressed_counter;
else
pressed_counter = 0;
// remember state, and we're done
was_pressed = now_pressed;
return event;
}
//////////////////////////////////////////////////////////////////////////////
// Instanciate button objects
ButtonHandler button_a(BUTTON_A_PIN, DEFAULT_LONGPRESS_LEN*2);
ButtonHandler button_b(BUTTON_B_PIN, DEFAULT_LONGPRESS_LEN*2);
ButtonHandler button_c(BUTTON_C_PIN, DEFAULT_LONGPRESS_LEN*2);
ButtonHandler button_d(BUTTON_D_PIN, DEFAULT_LONGPRESS_LEN*2);
//Beginning of Auto generated function prototypes by Atmel Studio
float dist(float a, float b, float c, float d);
void plasma_morph();
void ColorFill(unsigned char R, unsigned char G, unsigned char B);
unsigned char plasma[8][8];
long paletteShift;
float dist(float a, float b, float c, float d) {
return sqrt((c-a)*(c-a)+(d-b)*(d-b));
}
void plasma_morph() {
unsigned char x,y;
float value;
ColorRGB colorRGB;
ColorHSV colorHSV;
for(y = 0; y < 8; y++)
for(x = 0; x < 8; x++) {
{
value = sin(dist(x + paletteShift, y, 128.0, 128.0) / 8.0)
+ sin(dist(x, y, 64.0, 64.0) / 8.0)
+ sin(dist(x, y + paletteShift / 7, 192.0, 64) / 7.0)
+ sin(dist(x, y, 192.0, 100.0) / 8.0);
colorHSV.h=(unsigned char)((value) * 128)&0xff;
colorHSV.s=255;
colorHSV.v=255;
Colorduino.HSVtoRGB(&colorRGB, &colorHSV);
Colorduino.SetPixel(x, y, colorRGB.r, colorRGB.g, colorRGB.b);
}
}
paletteShift++;
Colorduino.FlipPage(); // swap screen buffers to show it
}
/********************************************************
Name: ColorFill
Function: Fill the frame with a color
Parameter:R: the value of RED. Range:RED 0~255
G: the value of GREEN. Range:RED 0~255
B: the value of BLUE. Range:RED 0~255
********************************************************/
void ColorFill(unsigned char R,unsigned char G,unsigned char B) {
ColorRGB *p = Colorduino.GetPixel(0,0);
for (unsigned char y=0;y<8;y++) {
for(unsigned char x=0;x<8;x++) {
p->r = R;
p->g = G;
p->b = B;
p++;
}
}
Colorduino.FlipPage();
}
unsigned long time_previous;
unsigned long time_previous_for_button;
//End of Auto generated function prototypes by Atmel Studio
/*End of auto generated code by Atmel studio */
//Beginning of Auto generated function prototypes by Atmel Studio
void gameOver();
void restartGame();
void updateBall();
void buzz();
void update();
void draw();
void updateScore();
//End of Auto generated function prototypes by Atmel Studio
unsigned long lastRefreshTime = 0;
int refreshInterval = 1;
unsigned long lastMoveTime = 0;
int moveInterval;
int rowPins[8] = {0,1,2,3,4,5,6,7};
int colPins[3] = {8,9,10};
int speakerPin = 11;
unsigned long now = 0;
unsigned long overTime = 100000000;
int currentColumn = 0;
int ballX;
int ballY;
int player1Score, player2Score;
int player1Position, player2Position;
boolean ballMovingUp = true;
boolean ballMovingLeft = true;
boolean isGameOn = true;
/*int shape[8][8] = {
{0,0,0,0,0,0,0,0},
{0,0,0,0,0,0,0,0},
{0,0,0,0,0,0,0,0},
{0,0,0,0,0,0,0,0},
{0,0,0,0,0,0,0,0},
{0,0,0,0,0,0,0,0},
{0,0,0,0,0,0,0,0},
{0,0,0,0,0,0,0,0}
};*/
ColorRGB shape[8][8] = {
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
{COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK, COLOR_BLACK},
};
void setup(){
// init buttons pins;
button_a.init();
button_b.init();
button_c.init();
button_d.init();
Colorduino.Init(); // initialize the board
time_previous = millis();
// compensate for relative intensity differences in R/G/B brightness
// array of 6-bit base values for RGB (0~63)
// whiteBalVal[0]=red
// whiteBalVal[1]=green
// whiteBalVal[2]=blue
unsigned char whiteBalVal[3] = {36,63,63}; // for LEDSEE 6x6cm round matrix
Colorduino.SetWhiteBal(whiteBalVal);
// start with morphing plasma, but allow going to color cycling if desired.
paletteShift=128000;
unsigned char bcolor;
//generate the plasma once
for(unsigned char y = 0; y < 8; y++)
for(unsigned char x = 0; x < 8; x++) {
//the plasma buffer is a sum of sines
bcolor = (unsigned char)
(128.0 + (128.0 * sin(x*8.0 / 16.0)) +
128.0 + (128.0 * sin(y*8.0 / 16.0))) / 2;
plasma[x][y] = bcolor;
}
// to adjust white balance you can uncomment this line
// and comment out the plasma_morph() in loop()
// and then experiment with whiteBalVal above
// ColorFill(255,255,255);
for(int i=0;i<50;i++)
plasma_morph();
ColorFill(0,0,0);
//Serial.begin(9600);
player1Score = 0;
player2Score = 0;
restartGame();
}
void loop(){
button_a_status = button_a.handle();
button_b_status = button_b.handle();
button_c_status = button_c.handle();
button_d_status = button_d.handle();
//Player 1 button left
if((button_b_status==1) ){
if(player2Position>4)
player2Position = 5;
else
player2Position++;
//update player positions
}
//Player 1 button right
if((button_a_status==1)){
if(player2Position<1)
player2Position = 0;
else
player2Position--;
}
//Player 2 button left
if((button_c_status==1)){
if(player1Position>4)
player1Position = 5;
else
player1Position++;
}
//Player 2 button right
if( (button_d_status==1)){
if(player1Position<1)
player1Position = 0;
else
player1Position--;
}
now = millis();
if(isGameOn){
update();
}else{
updateScore();
}
draw();
}
void gameOver(){
isGameOn = false;
overTime = now;
player1Score %= 7;
player2Score %= 7;
ColorFill(0,0,0);
int note[] = {700, 600, 500, 400, 300, 200};
delay(200);
}
void restartGame(){
moveInterval = 700;
ballX = now % 8;
if(ballX == 0)
ballX =1;
if((now % 2)==0)
{
ballY = 6;
ballMovingUp = true;
}
else
{
ballY = 1;
ballMovingUp = false;
}
ballMovingLeft = true;
isGameOn = true;
}
void updateBall(){
if(ballMovingLeft)
ballX--;
else
ballX++;
if(ballX == 0)
ballMovingLeft = false;
else if (ballX == 7)
ballMovingLeft = true;
if(ballMovingUp)
ballY--;
else
ballY++;
if(ballY == 1 && ballX >= player2Position && ballX < player2Position + 3){
ballMovingUp = false;
moveInterval -= 20;
}
else if(ballY == 6 && ballX >= player1Position && ballX < player1Position + 3){
ballMovingUp = true;
moveInterval -= 20;
}
if(ballY == 0 && ballX >= player2Position && ballX < player2Position + 3){
ballMovingUp = false;
moveInterval -= 20;
}
else if(ballY == 7 && ballX >= player1Position && ballX < player1Position + 3){
ballMovingUp = true;
moveInterval -= 20;
} else if(ballY == 0){
player1Score++;
gameOver();
}else if (ballY == 7){
player2Score++;
gameOver();
}
}
void update(){
//clear table;
if(now - lastMoveTime > moveInterval){
for(int i = 0; i < 8; i++){
for(int j = 0; j < 8; j++){
shape[i][j] = COLOR_BLACK;
}
}
for(int i = 0; i < 8; i++){
if(i >= player1Position && i < player1Position + 3){
shape[7][i] = COLOR_RED;
}else{
shape[7][i] = COLOR_BLACK;
}
if(i >= player2Position && i < player2Position + 3){
shape[0][i] = COLOR_RED;
}else{
shape[0][i] = COLOR_BLACK;
}
}
//update the ball
updateBall();
//draw the ball
shape[ballY][ballX] = COLOR_GREEN;
lastMoveTime = now;
}
}
void displayColorRGBData(ColorRGB data[8][8])
{
for(int w = 0; w < 8; w++){
for(int h = 0; h < 8; h++){
Colorduino.SetPixel(h, w, data[w][h].r, data[w][h].g, data[w][h].b);
}
}
Colorduino.FlipPage();
}
void draw(){
if(now - lastRefreshTime >= refreshInterval){
displayColorRGBData(shape);
lastRefreshTime = now;
}
}
void updateScore(){
for(int i = 0; i < 8; i++){
for(int j = 0; j < 8; j++){
shape[i][j] = COLOR_BLACK;
}
}
for(int i = 0; i < player2Score; i++){
for(int j = 0; j < i + 1; j++){
shape[j][6 - i] = COLOR_BLUE;
}
}
for(int i = 0; i < player1Score; i++){
for(int j = 0; j < i + 1; j++){
shape[7 - j][i + 1] = COLOR_GREEN;
}
}
if(now - overTime > 3000)
restartGame();
}
