Intruder alert!

Receive notifications via the Azure cloud if an intruder is detected, and additional information such as whether the detector has been moved

IntermediateFull instructions provided4 hours56
Intruder alert!

Things used in this project

Hardware components

Azure Sphere MT3620 Starter Kit
Avnet Azure Sphere MT3620 Starter Kit
×1
Mikroelektronika motion sensor
×1
Adafruit PowerBoost 1000C
Adafruit PowerBoost 1000C
×1
Rechargeable Battery, 3.7 V
Rechargeable Battery, 3.7 V
×1
Raspberry Pi 3 power supply
×1
Project box IP55 with clear lid
×1

Software apps and online services

Microsoft Visual Studio 2019

Story

Read more

Schematics

Mikroelektronika Click Motion

Click sensor

MT3620 board withg Click sensor installed

Click sensor

MT3620 and Click Motion powered by LiPo

Click Motion

Triggering motion sensor

Motion sensor

Azure cloud notification

Azure

IoT Central

IoT Central

Device moved Rule

If device is moved, send an email

Code

main.c from AvnetStartKitReferenceDesign

C/C++
Replacement main.c to support Mikroelektronika Motion sensor
/* Copyright (c) Microsoft Corporation. All rights reserved.
   Licensed under the MIT License. */

   /************************************************************************************************
   Name: AvnetStarterKitReferenceDesign
   Sphere OS: 19.02
   This file contains the 'main' function. Program execution begins and ends there

   Authors:
   Peter Fenn (Avnet Engineering & Technology)
   Brian Willess (Avnet Engineering & Technology)

   Purpose:
   Using the Avnet Azure Sphere Starter Kit demonstrate the following features

   1. Read X,Y,Z accelerometer data from the onboard LSM6DSO device using the I2C Interface
   2. Read X,YZ Angular rate data from the onboard LSM6DSO device using the I2C Interface
   3. Read the barometric pressure from the onboard LPS22HH device using the I2C Interface
   4. Read the temperature from the onboard LPS22HH device using the I2C Interface
   5. Read the state of the A and B buttons
   6. Read BSSID address, Wi-Fi AP SSID, Wi-Fi Frequency
   *************************************************************************************************
      Connected application features: When connected to Azure IoT Hub or IoT Central
   *************************************************************************************************
   7. Send X,Y,Z accelerometer data to Azure
   8. Send barometric pressure data to Azure
   9. Send button state data to Azure
   10. Send BSSID address, Wi-Fi AP SSID, Wi-Fi Frequency data to Azure
   11. Send the application version string to Azure
   12. Control user RGB LEDs from the cloud using device twin properties
   13. Control optional Relay Click relays from the cloud using device twin properties
   14. Send Application version up as a device twin property
   15. Stop application using "haltApplication" Direct Method call from the cloud
   16. Modify sensor polling time using "setSensorPollTinme" Direct Method from the cloud
   TODO
   1. Add support for a OLED display
   2. Add support for on-board light sensor

   *************************************************************************************************/

#include <errno.h>
#include <signal.h>
#include <stdbool.h>
#include <stdlib.h>
#include <string.h>
#include <time.h>
#include <unistd.h>
#include <stdio.h>
#include <math.h>

// applibs_versions.h defines the API struct versions to use for applibs APIs.
#include "applibs_versions.h"
#include "epoll_timerfd_utilities.h"
#include "i2c.h"
#include "mt3620_avnet_dev.h"
#include "deviceTwin.h"
#include "azure_iot_utilities.h"
#include "connection_strings.h"
#include "build_options.h"

#include <applibs/log.h>
#include <applibs/i2c.h>
#include <applibs/gpio.h>
#include <applibs/wificonfig.h>
#include <azureiot/iothub_device_client_ll.h>

// Provide local access to variables in other files
extern twin_t twinArray[];
extern int twinArraySize;
extern IOTHUB_DEVICE_CLIENT_LL_HANDLE iothubClientHandle;
extern int accelTimerFd;

// Support functions.
static void TerminationHandler(int signalNumber);
static int InitPeripheralsAndHandlers(void);
static void ClosePeripheralsAndHandlers(void);

// File descriptors - initialized to invalid value
int epollFd = -1;
static int buttonPollTimerFd = -1;
static int buttonAGpioFd = -1;
static int buttonBGpioFd = -1;
static int motionGpioFd = -1;

int userLedRedFd = -1;
int userLedGreenFd = -1;
int userLedBlueFd = -1;
int appLedFd = -1;
int wifiLedFd = -1;
int clickSocket1Relay1Fd = -1;
int clickSocket1Relay2Fd = -1;

// Button state variables, initilize them to button not-pressed (High) [added motion sensor]
static GPIO_Value_Type buttonAState = GPIO_Value_High;
static GPIO_Value_Type buttonBState = GPIO_Value_High;
static GPIO_Value_Type motionState = GPIO_Value_High;

#if (defined(IOT_CENTRAL_APPLICATION) || defined(IOT_HUB_APPLICATION))
	bool versionStringSent = false;
#endif

// Define the Json string format for the accelerator button press data
static const char cstrButtonTelemetryJson[] = "{\"%s\":\"%d\"}";

// Termination state
volatile sig_atomic_t terminationRequired = false;

/// <summary>
///     Signal handler for termination requests. This handler must be async-signal-safe.
/// </summary>
static void TerminationHandler(int signalNumber)
{
    // Don't use Log_Debug here, as it is not guaranteed to be async-signal-safe.
    terminationRequired = true;
}

/// <summary>
///     Allocates and formats a string message on the heap.
/// </summary>
/// <param name="messageFormat">The format of the message</param>
/// <param name="maxLength">The maximum length of the formatted message string</param>
/// <returns>The pointer to the heap allocated memory.</returns>
static void *SetupHeapMessage(const char *messageFormat, size_t maxLength, ...)
{
	va_list args;
	va_start(args, maxLength);
	char *message =
		malloc(maxLength + 1); // Ensure there is space for the null terminator put by vsnprintf.
	if (message != NULL) {
		vsnprintf(message, maxLength, messageFormat, args);
	}
	va_end(args);
	return message;
}

/// <summary>
///     Direct Method callback function, called when a Direct Method call is received from the Azure
///     IoT Hub.
/// </summary>
/// <param name="methodName">The name of the method being called.</param>
/// <param name="payload">The payload of the method.</param>
/// <param name="responsePayload">The response payload content. This must be a heap-allocated
/// string, 'free' will be called on this buffer by the Azure IoT Hub SDK.</param>
/// <param name="responsePayloadSize">The size of the response payload content.</param>
/// <returns>200 HTTP status code if the method name is reconginized and the payload is correctly parsed;
/// 400 HTTP status code if the payload is invalid;</returns>
/// 404 HTTP status code if the method name is unknown.</returns>
static int DirectMethodCall (const char *methodName, const char *payload, size_t payloadSize, char **responsePayload, size_t *responsePayloadSize)
{
	Log_Debug("\nDirect Method called %s\n", methodName);

	int result = 404; // HTTP status code.

	if (payloadSize < 32) {

		// Declare a char buffer on the stack where we'll operate on a copy of the payload.
		char directMethodCallContent[payloadSize + 1];

		// Prepare the payload for the response. This is a heap allocated null terminated string.
		// The Azure IoT Hub SDK is responsible of freeing it.
		*responsePayload = NULL;  // Reponse payload content.
		*responsePayloadSize = 0; // Response payload content size.


		// Look for the haltApplication method name.  This direct method does not require any payload, other than
		// a valid Json argument such as {}.

		if (strcmp(methodName, "haltApplication") == 0) {

			// Log that the direct method was called and set the result to reflect success!
			Log_Debug("haltApplication() Direct Method called\n");
			result = 200;

			// Construct the response message.  This response will be displayed in the cloud when calling the direct method
			static const char resetOkResponse[] =
				"{ \"success\" : true, \"message\" : \"Halting Application\" }";
			size_t responseMaxLength = sizeof(resetOkResponse);
			*responsePayload = SetupHeapMessage(resetOkResponse, responseMaxLength);
			if (*responsePayload == NULL) {
				Log_Debug("ERROR: Could not allocate buffer for direct method response payload.\n");
				abort();
			}
			*responsePayloadSize = strlen(*responsePayload);

			// Set the terminitation flag to true.  When in Visual Studio this will simply halt the application.
			// If this application was running with the device in field-prep mode, the application would halt
			// and the OS services would resetart the application.
			terminationRequired = true;
			return result;
		}

		// Check to see if the setSensorPollTime direct method was called
		else if (strcmp(methodName, "setSensorPollTime") == 0) {

			// Log that the direct method was called and set the result to reflect success!
			Log_Debug("setSensorPollTime() Direct Method called\n");
			result = 200;

			// The payload should contain a JSON object such as: {"pollTime": 20}
			if (directMethodCallContent == NULL) {
				Log_Debug("ERROR: Could not allocate buffer for direct method request payload.\n");
				abort();
			}

			// Copy the payload into our local buffer then null terminate it.
			memcpy(directMethodCallContent, payload, payloadSize);
			directMethodCallContent[payloadSize] = 0; // Null terminated string.

			JSON_Value *payloadJson = json_parse_string(directMethodCallContent);

			// Verify we have a valid JSON string from the payload
			if (payloadJson == NULL) {
				goto payloadError;
			}

			// Verify that the payloadJson contains a valid JSON object
			JSON_Object *pollTimeJson = json_value_get_object(payloadJson);
			if (pollTimeJson == NULL) {
				goto payloadError;
			}

			// Pull the Key: value pair from the JSON object, we're looking for {"pollTime": <integer>}
			// Verify that the new timer is < 0
			int newPollTime = (int)json_object_get_number(pollTimeJson, "pollTime");
			if (newPollTime < 1) {
				goto payloadError;
			}
			else {

				Log_Debug("New PollTime %d\n", newPollTime);

				// Construct the response message.  This will be displayed in the cloud when calling the direct method
				static const char newPollTimeResponse[] =
					"{ \"success\" : true, \"message\" : \"New Sensor Poll Time %d seconds\" }";
				size_t responseMaxLength = sizeof(newPollTimeResponse) + strlen(payload);
				*responsePayload = SetupHeapMessage(newPollTimeResponse, responseMaxLength, newPollTime);
				if (*responsePayload == NULL) {
					Log_Debug("ERROR: Could not allocate buffer for direct method response payload.\n");
					abort();
				}
				*responsePayloadSize = strlen(*responsePayload);

				// Define a new timespec variable for the timer and change the timer period
				struct timespec newAccelReadPeriod = { .tv_sec = newPollTime,.tv_nsec = 0 };
				SetTimerFdToPeriod(accelTimerFd, &newAccelReadPeriod);
				return result;
			}
		}
		else {
			result = 404;
			Log_Debug("INFO: Direct Method called \"%s\" not found.\n", methodName);

			static const char noMethodFound[] = "\"method not found '%s'\"";
			size_t responseMaxLength = sizeof(noMethodFound) + strlen(methodName);
			*responsePayload = SetupHeapMessage(noMethodFound, responseMaxLength, methodName);
			if (*responsePayload == NULL) {
				Log_Debug("ERROR: Could not allocate buffer for direct method response payload.\n");
				abort();
			}
			*responsePayloadSize = strlen(*responsePayload);
			return result;
		}

	}
		else {
		Log_Debug("Payload size > 32 bytes, aborting Direct Method execution\n");
		goto payloadError;
	}

	// If there was a payload error, construct the
	// response message and send it back to the IoT Hub for the user to see
payloadError:


	result = 400; // Bad request.
	Log_Debug("INFO: Unrecognised direct method payload format.\n");

	static const char noPayloadResponse[] =
		"{ \"success\" : false, \"message\" : \"request does not contain an identifiable "
		"payload\" }";

	size_t responseMaxLength = sizeof(noPayloadResponse) + strlen(payload);
	responseMaxLength = sizeof(noPayloadResponse);
	*responsePayload = SetupHeapMessage(noPayloadResponse, responseMaxLength);
	if (*responsePayload == NULL) {
		Log_Debug("ERROR: Could not allocate buffer for direct method response payload.\n");
		abort();
	}
	*responsePayloadSize = strlen(*responsePayload);

	return result;

}

/// <summary>
///     Handle button timer event: if the button is pressed, report the event to the IoT Hub.
/// </summary>
static void ButtonTimerEventHandler(EventData *eventData)
{

	bool sendTelemetryButtonA = false;
	bool sendTelemetryButtonB = false;
	bool sendTelemetryMotion = false;

	if (ConsumeTimerFdEvent(buttonPollTimerFd) != 0) {
		terminationRequired = true;
		return;
	}

	// Check for button A press
	GPIO_Value_Type newButtonAState;
	int result = GPIO_GetValue(buttonAGpioFd, &newButtonAState);
	if (result != 0) {
		Log_Debug("ERROR: Could not read button GPIO: %s (%d).\n", strerror(errno), errno);
		terminationRequired = true;
		return;
	}

	// If the A button has just been pressed, send a telemetry message
	// The button has GPIO_Value_Low when pressed and GPIO_Value_High when released
	if (newButtonAState != buttonAState) {
		if (newButtonAState == GPIO_Value_Low) {
			Log_Debug("Button A pressed!\n");
			sendTelemetryButtonA = true;
		}
		else {
			Log_Debug("Button A released!\n");
		}

		// Update the static variable to use next time we enter this routine
		buttonAState = newButtonAState;
	}

	// Check for button B press
	GPIO_Value_Type newButtonBState;
	result = GPIO_GetValue(buttonBGpioFd, &newButtonBState);
	if (result != 0) {
		Log_Debug("ERROR: Could not read button GPIO: %s (%d).\n", strerror(errno), errno);
		terminationRequired = true;
		return;
	}

	// If the B button has just been pressed/released, send a telemetry message
	// The button has GPIO_Value_Low when pressed and GPIO_Value_High when released
	if (newButtonBState != buttonBState) {
		if (newButtonBState == GPIO_Value_Low) {
			// Send Telemetry here
			Log_Debug("Button B pressed!\n");
			sendTelemetryButtonB = true;
		}
		else {
			Log_Debug("Button B released!\n");

		}

		// Update the static variable to use next time we enter this routine
		buttonBState = newButtonBState;
	}

	// Check for motion
	GPIO_Value_Type newMotionState;
	result = GPIO_GetValue(motionGpioFd, &newMotionState);
	if (result != 0) {
		Log_Debug("ERROR: Could not read motion GPIO: %s (%d).\n", strerror(errno), errno);
		terminationRequired = true;
		return;
	}

	// If motion, send a telemetry message
	// Has GPIO_Value_Low when motion and GPIO_Value_High when no motion
	if (newMotionState != motionState) {
		if (newMotionState == GPIO_Value_Low) {
			// Send Telemetry here
			Log_Debug("Motion detected!\n");
			sendTelemetryMotion = true;
		}
		else {
			Log_Debug("No motion!\n");

		}

		// Update the static variable to use next time we enter this routine
		motionState = newMotionState;
	}

	// If either button was pressed or motion detected, then enter the code to send the telemetry message
	if (sendTelemetryButtonA || sendTelemetryButtonB || sendTelemetryMotion) {

		char *pjsonBuffer = (char *)malloc(JSON_BUFFER_SIZE);
		if (pjsonBuffer == NULL) {
			Log_Debug("ERROR: not enough memory to send telemetry");
		}

		if (sendTelemetryButtonA) {
			// construct the telemetry message  for Button A
			snprintf(pjsonBuffer, JSON_BUFFER_SIZE, cstrButtonTelemetryJson, "buttonA", newButtonAState);
			Log_Debug("\n[Info] Sending telemetry %s\n", pjsonBuffer);
			AzureIoT_SendMessage(pjsonBuffer);
		}

		if (sendTelemetryButtonB) {
			// construct the telemetry message for Button B
			snprintf(pjsonBuffer, JSON_BUFFER_SIZE, cstrButtonTelemetryJson, "buttonB", newButtonBState);
			Log_Debug("\n[Info] Sending telemetry %s\n", pjsonBuffer);
			AzureIoT_SendMessage(pjsonBuffer);
		}

		if (sendTelemetryMotion) {
			// construct the telemetry message for motion
			snprintf(pjsonBuffer, JSON_BUFFER_SIZE, cstrButtonTelemetryJson, "motion", newMotionState);
			Log_Debug("\n[Info] Sending telemetry %s\n", pjsonBuffer);
			AzureIoT_SendMessage(pjsonBuffer);
		}

		free(pjsonBuffer);
	}

}

// event handler data structures. Only the event handler field needs to be populated.
static EventData buttonEventData = { .eventHandler = &ButtonTimerEventHandler };

/// <summary>
///     Set up SIGTERM termination handler, initialize peripherals, and set up event handlers.
/// </summary>
/// <returns>0 on success, or -1 on failure</returns>
static int InitPeripheralsAndHandlers(void)
{
    struct sigaction action;
    memset(&action, 0, sizeof(struct sigaction));
    action.sa_handler = TerminationHandler;
    sigaction(SIGTERM, &action, NULL);

    epollFd = CreateEpollFd();
    if (epollFd < 0) {
        return -1;
    }

	if (initI2c() == -1) {
		return -1;
	}

	// Traverse the twin Array and for each GPIO item in the list open the file descriptor
	for (int i = 0; i < twinArraySize; i++) {

		// Verify that this entry is a GPIO entry
		if (twinArray[i].twinGPIO != NO_GPIO_ASSOCIATED_WITH_TWIN) {

			*twinArray[i].twinFd = -1;

			// For each item in the data structure, initialize the file descriptor and open the GPIO for output.  Initilize each GPIO to its specific inactive state.
			*twinArray[i].twinFd = (int)GPIO_OpenAsOutput(twinArray[i].twinGPIO, GPIO_OutputMode_PushPull, twinArray[i].active_high ? GPIO_Value_Low : GPIO_Value_High);

			if (*twinArray[i].twinFd < 0) {
				Log_Debug("ERROR: Could not open LED %d: %s (%d).\n", twinArray[i].twinGPIO, strerror(errno), errno);
				return -1;
			}
		}
	}

	// Open button A GPIO as input
	Log_Debug("Opening Starter Kit Button A as input.\n");
	buttonAGpioFd = GPIO_OpenAsInput(MT3620_RDB_BUTTON_A);
	if (buttonAGpioFd < 0) {
		Log_Debug("ERROR: Could not open button A GPIO: %s (%d).\n", strerror(errno), errno);
		return -1;
	}
	// Open button B GPIO as input
	Log_Debug("Opening Starter Kit Button B as input.\n");
	buttonBGpioFd = GPIO_OpenAsInput(MT3620_RDB_BUTTON_B);
	if (buttonBGpioFd < 0) {
		Log_Debug("ERROR: Could not open button B GPIO: %s (%d).\n", strerror(errno), errno);
		return -1;
	}

	// Open motion GPIO as input
	Log_Debug("Opening motion sensor as input.\n");
	motionGpioFd = GPIO_OpenAsInput(MIKRO_INT);
	if (motionGpioFd < 0) {
		Log_Debug("ERROR: Could not open motion sensor GPIO: %s (%d).\n", strerror(errno), errno);
		return -1;
	}

	// Set up a timer to poll the buttons
	struct timespec buttonPressCheckPeriod = { 0, 1000000 };
	buttonPollTimerFd =
		CreateTimerFdAndAddToEpoll(epollFd, &buttonPressCheckPeriod, &buttonEventData, EPOLLIN);
	if (buttonPollTimerFd < 0) {
		return -1;
	}

	// Tell the system about the callback function that gets called when we receive a device twin update message from Azure
	AzureIoT_SetDeviceTwinUpdateCallback(&deviceTwinChangedHandler);

	// Tell the system about the callback function to call when we receive a Direct Method message from Azure
	AzureIoT_SetDirectMethodCallback(&DirectMethodCall);

    return 0;
}

/// <summary>
///     Close peripherals and handlers.
/// </summary>
static void ClosePeripheralsAndHandlers(void)
{
    Log_Debug("Closing file descriptors.\n");

	closeI2c();
    CloseFdAndPrintError(epollFd, "Epoll");
	CloseFdAndPrintError(buttonPollTimerFd, "buttonPoll");
	CloseFdAndPrintError(buttonAGpioFd, "buttonA");
	CloseFdAndPrintError(buttonBGpioFd, "buttonB");

	// Traverse the twin Array and for each GPIO item in the list the close the file descriptor
	for (int i = 0; i < twinArraySize; i++) {

		// Verify that this entry has an open file descriptor
		if (twinArray[i].twinGPIO != NO_GPIO_ASSOCIATED_WITH_TWIN) {

			CloseFdAndPrintError(*twinArray[i].twinFd, twinArray[i].twinKey);
		}
	}
}

/// <summary>
///     Main entry point for this application.
/// </summary>
int main(int argc, char *argv[])
{
	// Variable to help us send the version string up only once
	bool networkConfigSent = false;
	char ssid[128];
	uint32_t frequency;
	char bssid[20];

	// Clear the ssid array
	memset(ssid, 0, 128);

	Log_Debug("Version String: %s\n", argv[1]);
	Log_Debug("Avnet Starter Kit Simple Reference Application starting.\n");
    if (InitPeripheralsAndHandlers() != 0) {
        terminationRequired = true;
    }

    // Use epoll to wait for events and trigger handlers, until an error or SIGTERM happens
    while (!terminationRequired) {
        if (WaitForEventAndCallHandler(epollFd) != 0) {
            terminationRequired = true;
        }

#if (defined(IOT_CENTRAL_APPLICATION) || defined(IOT_HUB_APPLICATION))
		// Setup the IoT Hub client.
		// Notes:
		// - it is safe to call this function even if the client has already been set up, as in
		//   this case it would have no effect;
		// - a failure to setup the client is a fatal error.
		if (!AzureIoT_SetupClient()) {
			Log_Debug("ERROR: Failed to set up IoT Hub client\n");
			break;
		}
#endif

		WifiConfig_ConnectedNetwork network;
		int result = WifiConfig_GetCurrentNetwork(&network);
		if (result < 0) {
			// Log_Debug("INFO: Not currently connected to a WiFi network.\n");
		}
		else {

			frequency = network.frequencyMHz;
			snprintf(bssid, JSON_BUFFER_SIZE, "%02x:%02x:%02x:%02x:%02x:%02x",
				network.bssid[0], network.bssid[1], network.bssid[2],
				network.bssid[3], network.bssid[4], network.bssid[5]);

			if ((strncmp(ssid, (char*)&network.ssid, network.ssidLength)!=0) || !networkConfigSent) {

				memset(ssid, 0, 128);
				strncpy(ssid, network.ssid, network.ssidLength);
				Log_Debug("SSID: %s\n", ssid);
				Log_Debug("Frequency: %dMHz\n", frequency);
				Log_Debug("bssid: %s\n", bssid);
				networkConfigSent = true;

#if (defined(IOT_CENTRAL_APPLICATION) || defined(IOT_HUB_APPLICATION))
				// Note that we send up this data to Azure if it changes, but the IoT Central Properties elements only
				// show the data that was currenet when the device first connected to Azure.
				checkAndUpdateDeviceTwin("ssid", &ssid, TYPE_STRING, false);
				checkAndUpdateDeviceTwin("freq", &frequency, TYPE_INT, false);
				checkAndUpdateDeviceTwin("bssid", &bssid, TYPE_STRING, false);
#endif
			}
		}
#if (defined(IOT_CENTRAL_APPLICATION) || defined(IOT_HUB_APPLICATION))
		if (iothubClientHandle != NULL && !versionStringSent) {

			checkAndUpdateDeviceTwin("versionString", argv[1], TYPE_STRING, false);
			versionStringSent = true;
		}

		// AzureIoT_DoPeriodicTasks() needs to be called frequently in order to keep active
		// the flow of data with the Azure IoT Hub
		AzureIoT_DoPeriodicTasks();
#endif
    }

    ClosePeripheralsAndHandlers();
    Log_Debug("Application exiting.\n");
    return 0;
}

Credits

Steve Smythe

Steve Smythe

3 projects • 0 followers

Comments
