# Team: Michelle Zheng, Maya Borowicz, Faith Mulugeta, Yurie Han
# Class: COMP/ELEC 424
# Final Project
# Fall 2023
#
#
# Code drawn from:
# https://www.hackster.io/colonel-hackers/autonomous-rc-car-elec-424-final-project-732fd1
# https://www.hackster.io/paul-walker/autonomous-rc-car-eebfb4?f=1
# https://www.hackster.io/really-bad-idea/autonomous-path-following-car-6c4992
# Import Packages
import cv2
import numpy as np
import matplotlib.pyplot as plt
import math
import sys
import time
import os
import board
import busio
import adafruit_mcp4728
import RPi.GPIO as GPIO
# Setup DAC
i2c = busio.I2C(board.SCL, board.SDA)
mcp4728 = adafruit_mcp4728.MCP4728(i2c, 0x64)
# Manage car behaviour
speed_encode = True
# Encoder
encoder_path = "/sys/module/gpiod_driver_encoder/parameters/encoder_val"
encoder_target_rotation = 4046040
encoder_rotation_variance = 1500000
encoder_max_rotation = encoder_target_rotation + encoder_rotation_variance
# Camera
frame_width = 160
frame_height = 120
cam_idx = 0
# PD variables
kp = 0.09
kd = kp * 0.5
# Speed Values
zero_speed = int(65535 / 2) # car is stopped
base_speed = int(65535 / 1.87) # car moves forward slowly
speed_variance = 100
zero_turn = int(65535 / 2) # neutral steering
# Max number of loop
max_ticks = 4000
class NotSudo(Exception):
pass
def set_speed(speed):
# Set the speed of the car
mcp4728.channel_b.value = speed
def set_turn(turn):
# Turn wheels
mcp4728.channel_a.value = turn
def reset_car():
# set speed to zero and steering to neutral
set_speed(zero_speed)
set_turn(zero_turn)
print("Car: stopped & straightened")
def start_car():
# Set speed to base speed and steering to neutral
print("Car ready")
set_turn(zero_turn)
set_speed(base_speed)
def manage_speed():
# Adjust the speed based on the speed encoder
# read the file with encoder data
f = open(encoder_path, "r")
enc = int(f.readline())
f.close()
ret = enc
# If within bounds (wait for car to start / stop)
ret = base_speed
if enc <= encoder_max_rotation:
# speed encode based on percentage
enc_pct_rotation = (enc - (encoder_target_rotation - encoder_rotation_variance)) / (2 * encoder_rotation_variance)
ret = int(((speed_variance * 2) * abs(enc_pct_rotation - 1)) + (base_speed - speed_variance))
# If speed from encoder is too fast, use base speed
if ret > base_speed:
ret = base_speed
return ret
def wait(wait_time):
# Wait for a period of time
start_time = time.perf_counter() # start
end_time = start_time + wait_time # end
# loop until finished
while (time.perf_counter() < end_time):
pass
return
def detect_edges(frame):
# Detetct the blue lines
# filter for blue lane lines
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV)
# This color values were adjusted from Paul Walker Team code
lower_blue = np.array([90, 50, 50], dtype="uint8")
upper_blue = np.array([130, 255, 255], dtype="uint8")
# make mask
mask = cv2.inRange(hsv, lower_blue, upper_blue)
# Get edges
edges = cv2.Canny(mask, 50, 100)
return edges
def region_of_interest(edges):
# Find region to look at
height, width = edges.shape
mask = np.zeros_like(edges)
# only focus lower half of the screen
polygon = np.array([[
(0, height),
(0, height / 2),
(width, height / 2),
(width, height),
]], np.int32)
cv2.fillPoly(mask, polygon, 255)
# Get region to look at
cropped_edges = cv2.bitwise_and(edges, mask)
return cropped_edges
def detect_line_segments(cropped_edges):
# Find line segments
# set constants
rho = 1
theta = np.pi / 180
min_threshold = 10
#get lines
line_segments = cv2.HoughLinesP(cropped_edges, rho, theta, min_threshold,
np.array([]), minLineLength=5, maxLineGap=150)
return line_segments
def average_slope_intercept(frame, line_segments):
# finding slope of the line
lane_lines = []
if line_segments is None:
print("No line segments detected")
return lane_lines
# set boundries
height, width, _ = frame.shape
left_fit = []
right_fit = []
boundary = 1 / 3
left_region_boundary = width * (1 - boundary)
right_region_boundary = width * boundary
# go through line segments and get line of best fit
for line_segment in line_segments:
for x1, y1, x2, y2 in line_segment:
if x1 == x2:
continue
fit = np.polyfit((x1, x2), (y1, y2), 1)
slope = (y2 - y1) / (x2 - x1)
intercept = y1 - (slope * x1)
if slope < 0:
if x1 < left_region_boundary and x2 < left_region_boundary:
left_fit.append((slope, intercept))
else:
if x1 > right_region_boundary and x2 > right_region_boundary:
right_fit.append((slope, intercept))
# take average line of best fit
left_fit_average = np.average(left_fit, axis=0)
if len(left_fit) > 0:
lane_lines.append(make_points(frame, left_fit_average))
right_fit_average = np.average(right_fit, axis=0)
if len(right_fit) > 0:
lane_lines.append(make_points(frame, right_fit_average))
return lane_lines
def make_points(frame, line):
# For getting visual of lines
height, width, _ = frame.shape
slope, intercept = line
y1 = height # bottom of the frame
y2 = int(y1 / 2) # make points from middle of the frame down
if slope == 0:
slope = 0.1
x1 = int((y1 - intercept) / slope)
x2 = int((y2 - intercept) / slope)
return [[x1, y1, x2, y2]]
def display_lines(frame, lines, line_color=(0, 255, 0), line_width=6):
# Get visual of lines
line_image = np.zeros_like(frame)
if lines is not None:
for line in lines:
for x1, y1, x2, y2 in line:
cv2.line(line_image, (x1, y1), (x2, y2), line_color, line_width)
line_image = cv2.addWeighted(frame, 0.8, line_image, 1, 1)
return line_image
def display_heading_line(frame, steering_angle, line_color=(0, 0, 255), line_width=5):
# Show a hedaing line
heading_image = np.zeros_like(frame)
height, width, _ = frame.shape
steering_angle_radian = steering_angle / 180.0 * math.pi
x1 = int(width / 2)
y1 = height
x2 = int(x1 - height / 2 / math.tan(steering_angle_radian))
y2 = int(height / 2)
cv2.line(heading_image, (x1, y1), (x2, y2), line_color, line_width)
heading_image = cv2.addWeighted(frame, 0.8, heading_image, 1, 1)
return heading_image
def get_steering_angle(frame, lane_lines):
# Get the angle to steer towards
height, width, _ = frame.shape
if len(lane_lines) == 2:
_, _, left_x2, _ = lane_lines[0][0]
_, _, right_x2, _ = lane_lines[1][0]
mid = int(width / 2)
x_offset = (left_x2 + right_x2) / 2 - mid
y_offset = int(height / 2)
elif len(lane_lines) == 1:
x1, _, x2, _ = lane_lines[0][0]
x_offset = x2 - x1
y_offset = int(height / 2)
elif len(lane_lines) == 0:
x_offset = 0
y_offset = int(height / 2)
angle_to_mid_radian = math.atan(x_offset / y_offset)
angle_to_mid_deg = int(angle_to_mid_radian * 180.0 / math.pi)
steering_angle = angle_to_mid_deg + 90
return steering_angle
def plot_pd(p_vals, d_vals, error, show_img=False):
# Plot the proportional, derivative and error
fig, ax1 = plt.subplots()
t_ax = np.arange(len(p_vals))
ax1.plot(t_ax, p_vals, '-', label="P values")
ax1.plot(t_ax, d_vals, '-', label="D values")
ax2 = ax1.twinx()
ax2.plot(t_ax, error, '--r', label="Error")
ax1.set_xlabel("Frames")
ax1.set_ylabel("PD Value")
ax2.set_ylim(-90, 90)
ax2.set_ylabel("Error Value")
plt.title("PD Values over time")
fig.legend()
fig.tight_layout()
plt.savefig("pd_plot.png")
if show_img:
plt.show()
plt.clf()
def plot_pwm(speed_pwms, turn_pwms, error, show_img=False):
# Plot teh speed steering and the error
fig, ax1 = plt.subplots()
t_ax = np.arange(len(speed_pwms))
ax1.plot(t_ax, speed_pwms, '-', label="Speed Voltage")
ax1.plot(t_ax, turn_pwms, '-', label="Steering Voltage")
ax2 = ax1.twinx()
ax2.plot(t_ax, error, '--r', label="Error")
ax1.set_xlabel("Frames")
ax1.set_ylabel("Voltage")
ax2.set_ylabel("Error Value")
plt.title("Voltage over time")
fig.legend()
plt.savefig("voltage_plot.png")
if show_img:
plt.show()
plt.clf()
# adapted from hackster, changed to adhere to red HSV color segments
def isRedFloorVisible(image):
"""
Detects whether or not the majority of a color on the screen is a particular color
:param image:
:param boundaries: [[color boundaries], [success boundaries]]
:return: boolean if image satisfies provided boundaries, and an image used for debugging
"""
# Convert to HSV color space
hsv_img = cv2.cvtColor(image, cv2.COLOR_BGR2HSV)
cv2.imwrite("redfloor.jpg", hsv_img)
# parse out the color boundaries and the success boundaries
# percentage was adjusted
percentage = 25
# lower and upper range for the lower part of red
lower_red1 = np.array([0, 40, 60], dtype="uint8")
upper_red1 = np.array([10, 255, 255], dtype="uint8")
# lower and upper range for the upper part of red
lower_red2 = np.array([170, 40, 60], dtype="uint8")
upper_red2 = np.array([180, 255, 255], dtype="uint8")
# create two masks to capture both ranges of red
mask1 = cv2.inRange(hsv_img, lower_red1, upper_red1)
mask2 = cv2.inRange(hsv_img, lower_red2, upper_red2)
# combining the masks
mask = cv2.bitwise_or(mask1, mask2)
# applying the mask
output = cv2.bitwise_and(hsv_img, hsv_img, mask=mask)
# save the output image
cv2.imwrite("redfloormask.jpg", output)
# calculating what percentage of image falls between color boundaries
percentage_detected = np.count_nonzero(mask) * 100 / np.size(mask)
# if the percentage percentage_detected is betweeen the success boundaries, we return true,
# otherwise false for result
result = percentage < percentage_detected
if result:
print(percentage_detected)
return result, output
def main():
#setup variables
lastTime = 0
lastError = 0
SecondStopTick = 0
# arrays for making the final graphs
p_vals = [] # proportional
d_vals = [] # Derivative
err_vals = [] # error
speed_vals = [] # speed values
steer_vals = [] # steering values
# set up video
video = cv2.VideoCapture(cam_idx)
video.set(cv2.CAP_PROP_FRAME_WIDTH, frame_width)
video.set(cv2.CAP_PROP_FRAME_HEIGHT, frame_height)
#Starts car
start_car()
curr_speed = base_speed
counter = 0
passedFirstStopSign = False
while counter < max_ticks:
set_speed(zero_speed)
# manage video
ret, original_frame = video.read()
frame = cv2.resize(original_frame, (160, 120))
# process the frame to determine the desired steering angle
edges = detect_edges(frame)
cv2.imshow("edges", edges)
roi = region_of_interest(edges)
line_segments = detect_line_segments(roi)
lane_lines = average_slope_intercept(frame, line_segments)
lane_lines_image = display_lines(frame, lane_lines)
steering_angle = get_steering_angle(frame, lane_lines)
heading_image = display_heading_line(lane_lines_image,steering_angle)
# calculate changes for PD
now = time.time()
dt = now - lastTime
deviation = steering_angle - 90
# PD Code
error = -deviation
base_turn = 7.5
proportional = kp * error
derivative = kd * (error - lastError) / dt
# Get Speed voltage
speed_voltage = curr_speed*(3.3/65535)
# take values for graphs
p_vals.append(proportional)
d_vals.append(derivative)
err_vals.append(error)
speed_vals.append(speed_voltage)
# determine actual turn to do
turn_amt = base_turn + proportional + derivative
# makes trun based on turn_amt
# Inspiration for sigmoid from Team Colonel Hackers
turn_amt = int(1/(1 + np.exp(0.32*(turn_amt -9.4)))*65535)
steer_voltage = turn_amt* (3.3/65535)
steer_vals.append(steer_voltage)
set_turn(turn_amt)
# Stops if sees the red box
if counter % 20: # looks every 20 ticks
if not passedFirstStopSign:
isStopSign, floorSight = isRedFloorVisible(frame)
# Sees red box
if isStopSign:
wait(3)
passedFirstStopSign = True
SecondStopTick = counter
# for last box
elif passedFirstStopSign and counter > SecondStopTick+100:
isStopSign, _ = isRedFloorVisible(frame)
if isStopSign:
set_speed(zero_speed)
break # Stop forever
# speed encoding
if speed_encode:
if counter % 3 == 0: # Check every 3 ticks
# adjust speed
temp_speed = manage_speed()
if temp_speed != curr_speed:
set_speed(temp_speed)
curr_speed = temp_speed
set_speed(curr_speed)
wait(0.023) # Run at speed for a short amount of time
key = cv2.waitKey(1)
if key == 27:
break
counter += 1
# Reset car and close everything
reset_car()
video.release()
cv2.destroyAllWindows()
# save plots
plot_pd(p_vals, d_vals, err_vals)
plot_pwm(speed_vals, steer_vals, err_vals)
if __name__ == "__main__":
main()
Comments
Please log in or sign up to comment.
