Compressing EfficientNetB0 and Quantizing

I believe I've managed to compress EfficientNetB0 down from 4.5 million parameters and an input size of 224x224 to around 190 thousand with only a drop in accuracy of around 12%. My tests of my kept segregated test data show 82% post quantization with relu6.

This article was originally posted on my website: https://www.cranberrygrape.com/machine%20learning/tinyml/bird-detection-tinyml/ but I've condensed the content down to post it as a guide here on compressing EfficientNetB0 to reach a wider audience.

I didn't use Edge Impulse to build it but rather imported my custom model there: https://studio.edgeimpulse.com/public/370799/live so while I included it here in the list of applications it's only helping to bundle up the tflite model.

Note: there may be fundamental flaws with my approach. To date I have yet to receive any feedback that my approach is valid here and I've shared it pretty heavily on discord, reddit, twitter, etc. It makes me worried that there must be some significant issue I'm not seeing offhand. I'm passing it along so others can experiment if there's interest with these techniques.

This output includes the state of each my notebooks as I progressed in the compression process. https://github.com/Timo614/machine-learning/tree/main/birds/notebooks

I'll go a bit into the changes I made, what I discovered, and where I am now with it. Note: there has been little interest in this work though to date so I'm not sure if there's some fundamental flaw with my model folks are politely not telling me. It does make me a bit anxious to put this project to my name as if it has some fundamental flaw it reflects badly on me (it seems a bit too good to be true in terms of the end size at 4.24% of the original model with a complete different set of activations). Keep in mind I am a novice by any measure though so perhaps some if not all of this may be useless if there is some fundamental issue I am unable to see with my approach / results.

For more documentation (outside of the gist mentioned here, I included some details on my site): https://www.cranberrygrape.com/machine%20learning/tinyml/bird-detection-tinyml/ I have the same above table there as well with links to the associated notebooks and models (easier than trying to parse via the github file names).

Dataset and Prep

• Dataset: BIRDS 525 SPECIES- IMAGE CLASSIFICATION
• Data Preparation Notebook: birds_data_prep.ipynb

The data preparation notebook above loads up the training folder of the above dataset, creates train, validation, test splits, and then further defines a bird feeder birds subset and copies just these birds to another set of folders to be used while training the 411 reduced output set. I did this as I knew I'd likely want to drop down to the smaller subset but I wanted to ensure there was no chance of ever leaking between train, test, and split.

EfficientNetB0 Compression Strategies

While attempting to compress the model I identified three areas I could compress further to shrink the model size.

• Conv2D Compression
• Dense Layer Compression
• Input Size Compression

There are likely various approaches to these forms of compression outside of the ones I've used here. I also experienced various degrees of effectiveness to the compression approaches in these areas as I refined my techniques so one could argue there may be even more effective approaches than my own for these.

Before we go into the various types I'd like to discuss the effects each of these has on the model size, their purpose, and their benefits.

Conv2D Compression: For EfficientNet the Conv2D layers, squeeze excite blocks, etc. are the bulk of the model. While a slow process compressing these sections allows for significant dropping of model size. In addition the last Conv2D filters size sets the size of the input to the first Dense layer which can have a massive impact on end model size.

That is if the final Conv2D has a filters size of 240 and the first Dense layer after a GlobalAveragePooling2D is 120 then the total number of parameters for the layer is equal to: 240 (input) * 120 (weights) + 120 (bias) One can reason by dropping down to a smaller final Conv2D size the subsequent Dense layer parameter count will be significantly lower even ignoring all the other removed layer weights. It's worth noting vanilla EfficientNetB0 has a last Conv2D layer with 1280 filters while the reduced models used in this article drop down to 480 filters.

Dense Layer Compression: Dense layers are far easier to compress than Conv2D layers. Given the earlier mention of parameter counts being influenced by inputs and outputs of layers it's worth noting that there are times when it is beneficial to add additional dense layers to actually reduce a model's size.

This may seem counterintuitive at first but reason this:

You have a Conv2D output filters size of 1280.

You have a fixed output layer with 524 outputs.

Assuming you only use one output layer directly attached to GlobalAveragePooling2D layer you'd end up with:

1280 * 524 + 524 = 671244

Yeah, that's **671, 244** parameters for the one dense layer (that's contains more parameters than 3 times the total number of parameters used in the final models used here to represent one layer).

Let's shrink it by adding a 32 units Dense layer in there:

1280 * 32 + 32 = 40992
32 * 524 + 524 = 17292
40992 + 17292 = 58284

So by adding a single layer we just decreased the size of the model significantly. Keep in mind that adding the 32 units Dense layer there reduces the complexity of the model in turn and it may cause the model to fail to reach high accuracy if there isn't enough definition to represent the problem space. One could use the selective freezing technique mentioned in this article, add a new dense layer in front of the output, and train just the output and that new layer. If you decide to do this I suggest using comments in your notebook to markdown what level of accuracy you obtained while testing various dense layer unit sizes.

That is perhaps try adding a Dense layer of 64 and note your accuracy after it stabilizes. Has your accuracy stayed constant? Drop it further and retrain. Has it dropped significantly? Try 128 and see the result, etc. This process is a bit time consuming although the model training is limited to two layers in this case.

Input Size Compression: Input size compression has a direct effect on the RAM used by the model. The amount of RAM used significantly increases as the size increases as well given we're using 3 channels (RGB). By retraining the model for the new input size we're able to quickly reduce the model to fit on various devices (with some accuracy loss as we decrease the input).

Conv2D Compression

The first, and by far the most annoying to use, compression type I found was the Conv2D compression.

The short behind it is the nature of EfficientNetB0 appears to allow for large chunks of the underlying model to be removed and then to retrain most of the lost accuracy compressing it into the rest of the model. I'm not sure why that is but from my testing it seems to work.

As you can see from the example there's the initial loss of accuracy from the missing segment of model followed by the dense layers retraining to return the accuracy levels back into an acceptable range.

Before removing the segment:

423/423 [==============================] - 120s 274ms/step - loss: 0.0339 - accuracy: 0.9911 - val_loss: 0.5087 - val_accuracy: 0.9065

After removing the segment with one epoch of retrain:

423/423 [==============================] - 117s 271ms/step - loss: 0.7256 - accuracy: 0.8411 - val_loss: 0.5867 - val_accuracy: 0.8693

This approach works rather well initially but does experience diminishing returns. I took it further with two additional improvements to this approach which allowed me to reach the 200k parameter level. The first improvement was to use selective locking to unlock only segments of the model at a time. Think of it this way: I have an equation `a * b * c * d = 10000`

Now assume at the current moment my values are `10 * 10 * 10 * 10 = 10000`

Now assume I go ahead and remove d (representing a squeeze excite block) so my values are `10 * 10 * 10 = 10000`

I could unlock all 3 variables (in my mediocre analogy) which, given enough time, should once again converge. Or I could unlock just c effectively removing some of the randomness from the learning process as it only needs to focus on a smaller problem space left behind by the missing layers structure.

So in this way the model is able to compress the logic from the existing layers into the other layers. Either you can retrain the dense layers from a given shortened base that remains untouched or attempt to compress the removed base layers into the remaining base layers. With the static dense layers (where possible given shifting outputs from the base model) there's enough of the structure to allow the remaining unlocked squeeze excite blocks to absorb that data. If you unlock them all at once it loses the lock on the model structure and you'll need to revert back to an earlier checkpoint and restart (reminds me of the bad Hollywood movies where the hacker has to lock onto a signal and then keep a hold on it). It's a balancing act of unlocking the right layers, letting it learn as much as it can, and then unlocking even more layers, and so on.

The second improvement involved further reducing the amount of loss caused by the removal of the layers. It's a prep step that ends up significantly preventing model loss (the short of it is it biases the model toward reducing the importance of those layers). At this time I'm not going into too much detail about the second improvement but may in future articles.

Along the process I tried some other approaches with some mixed results (some just felt like a waste of time even though they appeared to work). In the future if there's interest I can go into the things I tried that didn't work.

Dense Layer Compression

Dense layer shrinking is another form of compression used for my bird model. There were three forms of it used. I'll discuss two in detail but holding off on discussing the last until I test it more.

Selective freezing

Selective freezing is the simplest form of dense layer shrinking. The idea is that you're replacing a complex layer with a less complex one and then retraining up the replacement layer in its place.

Take this sort of setup: `Base layer output -> Dense layers -> Output dense layer`

Assume we have the following structure:

If I want to shrink the Dense 200 layer to let's say Dense 100 the following will occur to the shape of the data:

With this the two associated Dense layers had their structure invalidated. The other layers, however, can retain their existing state. You can freeze the base model, the Dense 100 (in this example), and the dense output and retrain just the two associated dense layers.

Here's a simple example of this in practice. As you can see the model (using the 96x96 pre shrink model as a base) quickly relearns from the missing data.

Before adjustment model structure:

x = Dense(200, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_1", activation='relu')(x)
x = Dense(256, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_2", activation='relu')(x)
outputs = Dense(524, kernel_regularizer = ACosR(weight = 0.005), trainable = False, activation=tf.keras.activations.softmax, name="dense_output")(x)

Before adjusting:

423/423 [==============================] - 834s 1s/step - loss: 0.0312 - accuracy: 0.9923 - val_loss: 0.5031 - val_accuracy: 0.9069

After adjustment model structure:

x = Dense(100, trainable = True, kernel_regularizer = ACosR(weight = 0.005), name="dense_1", activation='relu')(x)
x = Dense(256, trainable = True, kernel_regularizer = ACosR(weight = 0.005), name="dense_2", activation='relu')(x)
outputs = Dense(524, kernel_regularizer = ACosR(weight = 0.005), trainable = False, activation=tf.keras.activations.softmax, name="dense_output")(x)

After adjusting:

Epoch 1/6
423/423 [==============================] - 423s 996ms/step - loss: 0.9748 - accuracy: 0.8296 - val_loss: 0.5965 - val_accuracy: 0.8667
Epoch 2/6
423/423 [==============================] - 112s 264ms/step - loss: 0.1267 - accuracy: 0.9698 - val_loss: 0.5768 - val_accuracy: 0.8761
Epoch 3/6
423/423 [==============================] - 112s 265ms/step - loss: 0.0961 - accuracy: 0.9748 - val_loss: 0.5939 - val_accuracy: 0.8789
Epoch 4/6
423/423 [==============================] - 111s 263ms/step - loss: 0.0825 - accuracy: 0.9778 - val_loss: 0.5836 - val_accuracy: 0.8816
Epoch 5/6
423/423 [==============================] - 113s 266ms/step - loss: 0.0734 - accuracy: 0.9799 - val_loss: 0.6034 - val_accuracy: 0.8832
Epoch 6/6
423/423 [==============================] - 627s 1s/step - loss: 0.0694 - accuracy: 0.9801 - val_loss: 0.6190 - val_accuracy: 0.8853

In this same way you can prune outputs (a form of selective freezing).

Output pruning

Output pruning is the process by which less useful outputs can be pruned from a model. This technique also likely would work in the opposite direction adding additional outputs (assuming the new output is similar enough to existing).

To output prune you simply lock the entire model except the output layer. You then retrain just that layer selectively freezing all of the others. Once it finishes training unlock the remainder of the dense layers to further refine it.

This can be shown the following example when I dropped the outputs toward the end to include bird feeder only birds and the accuracy jumped on the test data.

Model showing 524 outputs prior to pruning:

x = Dense(200, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_1", activation='relu')(x)
x = Dense(256, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_2", activation='relu')(x)
outputs = Dense(524, kernel_regularizer = ACosR(weight = 0.005), trainable = False, activation=tf.keras.activations.softmax, name="dense_output")(x)
423/423 [==============================] - 123s 280ms/step - loss: 0.0326 - accuracy: 0.9918 - val_loss: 0.5031 - val_accuracy: 0.9068

Pruning process example with associated notebook:

x = Dense(200, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_1", activation='relu')(x)
x = Dense(256, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_2", activation='relu')(x)
outputs = Dense(411, kernel_regularizer = ACosR(weight = 0.005), trainable = True, activation=tf.keras.activations.softmax, name="dense_output")(x)
Epoch 1/2
333/333 [==============================] - 97s 283ms/step - loss: 1.0641 - accuracy: 0.8503 - val_loss: 0.5228 - val_accuracy: 0.8954
Epoch 2/2
333/333 [==============================] - 91s 274ms/step - loss: 0.1373 - accuracy: 0.9855 - val_loss: 0.4504 - val_accuracy: 0.9036

Dense layer decimation

Dense layer decimation is name of the technique I came up with for shrinking the dense layers more effectively with little loss of accuracy. I need to test it further before I document it but it worked fairly well for removing the dense layers on my bird model.

You can see it here between my initial model with several dense layers in place of various sizes and my ending model. This process was actually fairly quick and one of the more enjoyable elements of the shrink process as it gave huge savings for little effort relative to the Conv2D "compression." Given the model is composed mostly of Conv2D layers this approach, while effective, is limited in terms of how much model size it can reduce.

Initial model layer structure:

x = Dense(480, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_s_1", activation='relu')(x)
x = Dense(480, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_0", activation='relu')(x)
x = Dense(200, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_1", activation='relu')(x)
x = Dense(256, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_2", activation='relu')(x)
outputs = Dense(524, kernel_regularizer = ACosR(weight = 0.005), trainable = False, activation=tf.keras.activations.softmax, name="dense_output")(x)

Single epoch run (pretrained):

423/423 [==============================] - 1886s 4s/step - loss: 0.4815 - accuracy: 0.8781 - val_loss: 0.7078 - val_accuracy: 0.8251

Test accuracy:

132/132 [==============================] - 55s 420ms/step - loss: 0.8167 - accuracy: 0.8014
Test Loss: 0.81666
Test Accuracy: 80.14%

**Post dense layer decimation**:

x = Dense(180, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_s_1", activation='relu')(x)
x = Dense(50, trainable = False, kernel_regularizer = ACosR(weight = 0.005), name="dense_2", activation='relu')(x)
outputs = Dense(524, kernel_regularizer = ACosR(weight = 0.005), trainable = False, activation=tf.keras.activations.softmax, name="dense_output")(x)

Single epoch run (pretrained):

423/423 [==============================] - 113s 264ms/step - loss: 0.3088 - accuracy: 0.9201 - val_loss: 0.6311 - val_accuracy: 0.8458

Test accuracy:

132/132 [==============================] - 10s 79ms/step - loss: 0.7537 - accuracy: 0.8203
Test Loss: 0.75374
Test Accuracy: 82.03%

Input size compression

I'm currently exploring whether there's interest in a service where I could provide shrinking as a SAAS. I also need to further see if this technique applies to other base models (it would apply to any EfficientNet based ones). As such I'm holding off on documenting this process entirely but may do so in the future.

After I managed to shrink my model initially I realized I had one significant problem. Despite my model taking up very little room on my microcontroller it was far too resource intensive for use. As such I set to figuring out a way to reduce the image size from the existing model as I did not want to restart the entire shrinking process.

After some experimentation I discovered a technique to do this. There is some loss of accuracy as you decrease the size of the input image which can't be avoided. For example purposes I've included variations of my model at 96x96, 88x88, and 80x80. As you can see the drop from 96x96 to 88x88 was more significant than the drop from 88x88 to 80x80. Image shrinking is a fairly quick process even on my home hardware and required a lot less time. You can also shrink the input size at any time in the training process.

Post dense layer decimation input size compression:

**96x96**:

104/104 [==============================] - 9s 82ms/step - loss: 0.7380 - accuracy: 0.8505
Test Loss: 0.73796
Test Accuracy: 85.05%

**88x88**:

104/104 [==============================] - 8s 81ms/step - loss: 0.8327 - accuracy: 0.8404
Test Loss: 0.83271
Test Accuracy: 84.04%

**80x80**:

104/104 [==============================] - 8s 76ms/step - loss: 0.8743 - accuracy: 0.8267
Test Loss: 0.87433
Test Accuracy: 82.67%

You can see it's possible to go the opposite direction as well (I went up to 96x96 after having shrunk down to 80x80).

**80x80 (relu6)**:

104/104 [==============================] - 9s 90ms/step - loss: 0.8034 - accuracy: 0.8144
Test Loss: 0.80342
Test Accuracy: 81.44%

**96x96 (relu6)**:

416/416 [==============================] - 17s 41ms/step - loss: 0.6836 - accuracy: 0.8350
Test Loss: 0.68357
Test Accuracy: 83.50%

Quantization

From my limited experience searching most articles I found about quantization were not discussing int8 quantization. There are specific challenges that arise from int8 quantization as it requires a representative dataset to be crafted and certain activations can cause issues.

EfficientNetB0 model is not a good choice for int8 quantization as the swish activation causes wild swings in the potential outputs which don't map well.

For more information why it's an issue [see Tensorflow's article on EfficientNetLite](https://blog.tensorflow.org/2020/03/higher-accuracy-on-vision-models-with-efficientnet-lite.html).

This first problem can be addressed by converting the model's swish activations to relu6 with selective freezing. To do this the following technique can be applied:

1. Freeze the entire model

2. Unfreeze only one squeeze excite block at a time

3. Modify that segment of the base model to use relu6 where it was using swish

4. Retrain just that segment, freeze it when done, rinse repeat until the entire model is converted

This can be seen via this example in my repo shown from my own conversion. Just keep in mind I later realized relu was insufficient for int8 quantization and had to convert the whole thing over to relu6 so save yourself the trouble and just go directly to relu6.

Next steps?

I'm hoping to put my model on some TinyML hardware to further test it once a waterproof enclosure comes in.
