SeeSomethingSendSomething

/*
 * SeeSomethingSendSomething is an Spresence sketch for recording photos and audio at the
 * flip of a switch! When powered on, the sketch captures 10 images and 10 seconds of audio,
 * and stores them on a microSD card which can later be used to upload the images and audio
 * to a centralized Cloud (or other) location. The hardware is compact enough to fit in an
 * enclosure about the same size as an Altoids tin or pack of cigarettes, so its operation need
 * not be conspicuous.
 */

#include <SDHCI.h>
#include <stdio.h>  /* for sprintf */
#include <Audio.h>
#include <Camera.h>

#define RECORD_FILE_NAME "Sound.mp3"

#define BAUDRATE                (115200)
#define TOTAL_PICTURE_COUNT     (10)

SDClass  theSD;
AudioClass *theAudio;

File myAudioFile;

bool ErrEnd = false;

/**
 * @brief Audio attention callback
 *
 * When audio internal error occurc, this function will be called back.
 */

static void audio_attention_cb(const ErrorAttentionParam *atprm)
{
  puts("Attention!");

  if (atprm->error_code >= AS_ATTENTION_CODE_WARNING)
    {
      ErrEnd = true;
   }
}

/**
 * @brief Setup recording of mp3 stream to file
 *
 * Select input device as microphone <br>
 * Initialize filetype to stereo mp3 with 48 Kb/s sampling rate <br>
 * Open RECORD_FILE_NAME file in write mode
 */

/* Recording time[second] */

static const int32_t recording_time = 10;

/* Recording bit rate
 * Set in bps.
 * Note: 96kbps fixed
 */
static const int32_t recording_bitrate = 96000;

/* Bytes per second */
static const int32_t recording_byte_per_second = (recording_bitrate / 8);

/* Total recording size */
static const int32_t recording_size = recording_byte_per_second * recording_time;

int take_picture_count = 0;

/**
 * Print error message
 */

void recordAudio() {
  /* Initialize SD */
  while (!theSD.begin())
    {
      /* wait until SD card is mounted. */
      Serial.println("Insert SD card.");
    }
  theAudio = AudioClass::getInstance();
  theAudio->begin(audio_attention_cb);
  puts("initialization Audio Library");

  /* Select input device as microphone */
  theAudio->setRecorderMode(AS_SETRECDR_STS_INPUTDEVICE_MIC);
  /*
   * Initialize filetype to stereo mp3 with 48 Kb/s sampling rate
   * Search for MP3 codec in "/mnt/sd0/BIN" directory
   */
  theAudio->initRecorder(AS_CODECTYPE_MP3, "/mnt/sd0/BIN", AS_SAMPLINGRATE_48000, AS_CHANNEL_STEREO);
  puts("Init Recorder!");

  /* Open file for data write on SD card */

  if (theSD.exists(RECORD_FILE_NAME))
    {
      printf("Remove existing file [%s].\n", RECORD_FILE_NAME);
      theSD.remove(RECORD_FILE_NAME);
    }

  myAudioFile = theSD.open(RECORD_FILE_NAME, FILE_WRITE);
  /* Verify file open */
  if (!myAudioFile)
    {
      printf("File open error\n");
      exit(1);
    }

  printf("Open! [%s]\n", RECORD_FILE_NAME);

  theAudio->startRecorder();
  puts("Recording Start!");
}

void printError(enum CamErr err)
{
  Serial.print("Error: ");
  switch (err)
    {
      case CAM_ERR_NO_DEVICE:
        Serial.println("No Device");
        break;
      case CAM_ERR_ILLEGAL_DEVERR:
        Serial.println("Illegal device error");
        break;
      case CAM_ERR_ALREADY_INITIALIZED:
        Serial.println("Already initialized");
        break;
      case CAM_ERR_NOT_INITIALIZED:
        Serial.println("Not initialized");
        break;
      case CAM_ERR_NOT_STILL_INITIALIZED:
        Serial.println("Still picture not initialized");
        break;
      case CAM_ERR_CANT_CREATE_THREAD:
        Serial.println("Failed to create thread");
        break;
      case CAM_ERR_INVALID_PARAM:
        Serial.println("Invalid parameter");
        break;
      case CAM_ERR_NO_MEMORY:
        Serial.println("No memory");
        break;
      case CAM_ERR_USR_INUSED:
        Serial.println("Buffer already in use");
        break;
      case CAM_ERR_NOT_PERMITTED:
        Serial.println("Operation not permitted");
        break;
      default:
        break;
    }
}

/**
 * Callback from Camera library when video frame is captured.
 */

void CamCB(CamImage img)
{

  /* Check the img instance is available or not. */

  if (img.isAvailable())
    {

      /* If you want RGB565 data, convert image data format to RGB565 */

      img.convertPixFormat(CAM_IMAGE_PIX_FMT_RGB565);

      /* You can use image data directly by using getImgSize() and getImgBuff().
       * for displaying image to a display, etc. */

      Serial.print("Image data size = ");
      Serial.print(img.getImgSize(), DEC);
      Serial.print(" , ");

      Serial.print("buff addr = ");
      Serial.print((unsigned long)img.getImgBuff(), HEX);
      Serial.println("");
    }
  else
    {
      Serial.println("Failed to get video stream image");
    }
}

/**
 * @brief Initialize camera
 */
void setup()
{
  CamErr err;

  /* Open serial communications and wait for port to open */

  Serial.begin(BAUDRATE);
  while (!Serial)
    {
      ; /* wait for serial port to connect. Needed for native USB port only */
    }

  /* Initialize SD */
  while (!theSD.begin())
    {
      /* wait until SD card is mounted. */
      Serial.println("Insert SD card.");
    }

  /* begin() without parameters means that
   * number of buffers = 1, 30FPS, QVGA, YUV 4:2:2 format */

  Serial.println("Prepare camera");
  err = theCamera.begin();
  if (err != CAM_ERR_SUCCESS)
    {
      printError(err);
    }

  /* Start video stream.
   * If received video stream data from camera device,
   *  camera library call CamCB.
   */

  Serial.println("Start streaming");
  err = theCamera.startStreaming(true, CamCB);
  if (err != CAM_ERR_SUCCESS)
    {
      printError(err);
    }

  /* Auto white balance configuration */

  Serial.println("Set Auto white balance parameter");
  err = theCamera.setAutoWhiteBalanceMode(CAM_WHITE_BALANCE_DAYLIGHT);
  if (err != CAM_ERR_SUCCESS)
    {
      printError(err);
    }

  /* Set parameters about still picture.
   * In the following case, QUADVGA and JPEG.
   */

  Serial.println("Set still picture format");
  err = theCamera.setStillPictureImageFormat(
     CAM_IMGSIZE_QUADVGA_H,
     CAM_IMGSIZE_QUADVGA_V,
     CAM_IMAGE_PIX_FMT_JPG);
  if (err != CAM_ERR_SUCCESS)
    {
      printError(err);
    }
}

/**
 * @brief Take picture with format JPEG per second
 */

void loop()
{
  sleep(1); /* wait for one second to take still picture. */

  /* You can change the format of still picture at here also, if you want. */

  /* theCamera.setStillPictureImageFormat(
   *   CAM_IMGSIZE_HD_H,
   *   CAM_IMGSIZE_HD_V,
   *   CAM_IMAGE_PIX_FMT_JPG);
   */

  /* This sample code can take pictures in every one second from starting. */

  if (take_picture_count < TOTAL_PICTURE_COUNT)
    {

      /* Take still picture.
      * Unlike video stream(startStreaming) , this API wait to receive image data
      *  from camera device.
      */

      Serial.println("call takePicture()");
      CamImage img = theCamera.takePicture();

      /* Check availability of the img instance. */
      /* If any errors occur, the img is not available. */

      if (img.isAvailable())
        {
          /* Create file name */

          char filename[16] = {0};
          sprintf(filename, "PICT%03d.JPG", take_picture_count);

          Serial.print("Save taken picture as ");
          Serial.print(filename);
          Serial.println("");

          /* Remove the old file with the same file name as new created file,
           * and create new file.
           */

          theSD.remove(filename);
          File myAudioFile = theSD.open(filename, FILE_WRITE);
          myAudioFile.write(img.getImgBuff(), img.getImgSize());
          myAudioFile.close();
        }
      else
        {
          /* The size of a picture may exceed the allocated memory size.
           * Then, allocate the larger memory size and/or decrease the size of a picture.
           * [How to allocate the larger memory]
           * - Decrease jpgbufsize_divisor specified by setStillPictureImageFormat()
           * - Increase the Memory size from Arduino IDE tools Menu
           * [How to decrease the size of a picture]
           * - Decrease the JPEG quality by setJPEGQuality()
           */

          Serial.println("Failed to take picture");
        }
    }
  else if (take_picture_count == TOTAL_PICTURE_COUNT)
    {
      Serial.println("Picture capture completed.");
      theCamera.end();

      /* Images have been taken, so record 10 seconds of audio.
       *
       */
      bool ErrEnd = false;

/**
 * @brief Audio attention callback
 *
 * When audio internal error occurs, this function will be called back.
 */


//set up for recording
/**
 * @brief Setup recording of mp3 stream to file
 *
 * Select input device as microphone <br>
 * Initialize filetype to stereo mp3 with 48 Kb/s sampling rate <br>
 * Open RECORD_FILE_NAME file in write mode
 */

/* Recording time[second] */

static const int32_t recording_time = 10;

/* Recording bit rate
 * Set in bps.
 * Note: 96kbps fixed
 */

static const int32_t recording_bitrate = 96000;

/* Bytes per second */

static const int32_t recording_byte_per_second = (recording_bitrate / 8);

/* Total recording size */

static const int32_t recording_size = recording_byte_per_second * recording_time;
{
  /* Initialize SD */
  while (!theSD.begin())
    {
      /* wait until SD card is mounted. */
      Serial.println("Insert SD card.");
    }

  theAudio = AudioClass::getInstance();

  theAudio->begin(audio_attention_cb);

  puts("initialization Audio Library");

  /* Select input device as microphone */
  theAudio->setRecorderMode(AS_SETRECDR_STS_INPUTDEVICE_MIC);

  /*
   * Initialize filetype to stereo mp3 with 48 Kb/s sampling rate
   * Search for MP3 codec in "/mnt/sd0/BIN" directory
   */
  theAudio->initRecorder(AS_CODECTYPE_MP3, "/mnt/sd0/BIN", AS_SAMPLINGRATE_48000, AS_CHANNEL_STEREO);
  puts("Init Recorder!");

  /* Open file for data write on SD card */

  if (theSD.exists(RECORD_FILE_NAME))
    {
      printf("Remove existing file [%s].\n", RECORD_FILE_NAME);
      theSD.remove(RECORD_FILE_NAME);
    }

  myAudioFile = theSD.open(RECORD_FILE_NAME, FILE_WRITE);
  /* Verify file open */
  if (!myAudioFile)
    {
      printf("File open error\n");
      exit(1);
    }

  printf("Open! [%s]\n", RECORD_FILE_NAME);

  theAudio->startRecorder();
  puts("Recording Start!");
}

/**
 * @brief Record given frame number
 */

  err_t err;
  /* recording end condition */
  if (theAudio->getRecordingSize() > recording_size)
    {
      theAudio->stopRecorder();
      sleep(1);
      err = theAudio->readFrames(myAudioFile);

      goto exitRecording;
    }

  /* Read frames to record in file */
  err = theAudio->readFrames(myAudioFile);

  if (err != AUDIOLIB_ECODE_OK)
    {
      printf("File End! =%d\n",err);
      theAudio->stopRecorder();
      goto exitRecording;
    }

  if (ErrEnd)
    {
      printf("Error End\n");
      theAudio->stopRecorder();
      goto exitRecording;
    }

  /* This sleep is adjusted by the time to write the audio stream file.
   * Please adjust in according with the processing contents
   * being processed at the same time by Application.
   *
   * The usleep() function suspends execution of the calling thread for usec
   * microseconds. But the timer resolution depends on the OS system tick time
   * which is 10 milliseconds (10,000 microseconds) by default. Therefore,
   * it will sleep for a longer time than the time requested here.
   */

//  usleep(10000);

  return;

exitRecording:

  theAudio->closeOutputFile(myAudioFile);
  myAudioFile.close();

  theAudio->setReadyMode();
  theAudio->end();

  puts("End Recording");
  exit(1);
}
      Serial.println("Audio capture completed.");
      while(1);  //Endless loop to preserve what has been captured and
                 //prevent over-writing with new data.

  take_picture_count++;
}
