Monitoring of cleaning supplies

/*
 AWS iot con ESP32
 By:nccencho for www.smelpro.com
 Versin: V2.0
 contenido privado
 */
#include <M5Core2.h>                         // Library for the M5 core2
#include <FastLED.h>                         // Library to use LEDs
#include "SPIFFS.h"                          // Library to load credential files
#include <WiFiClientSecure.h>                // Free for secure connection the M5 core2 and AWS IoT
#include <Wire.h>                            // Wire protocol free.
#include <PubSubClient.h>                    // Free for mqtt, publish and subscribe.

const char * ssid = "Smel3d";                 // SSId credentials
const char * password = "20142016";           // Pass credentials
const char * mqtt_server = "a2s70tnvueqbje-ats.iot.us-east-1.amazonaws.com"; // Replace your account endpoint
const int mqtt_port = 8883;                   // Port for MQTT

String Read_rootca;
String Read_cert;
String Read_privatekey;

//********************************
#define BUFFER_LEN  256
long lastMsg = 0;
long lastMsg2 = 0;
char msg[BUFFER_LEN];
int value = 0;
byte mac[6];
char mac_Id[18];
int i=0;
int capacity=100;
int agua=0;
int papel=100;
//********************************
String messageData;
String macIdStr,agel,sen_papel,sen_agua;
char data_digital[2]="";

//**************************************
WiFiClientSecure espClient;
PubSubClient client(espClient);

//*************************************
#define NUM_LEDS 10
#define DATA_PIN 25
// Define the array of leds
CRGB leds[NUM_LEDS];
//*************************************
int const pin_agel = 36;
int const pin_agua = 13;
int const pin_papel = 14;
int const led = 21;

//*************************************

// Variable de timer usando millis()
unsigned long lastTime = 0;
unsigned long timerDelay = 1500;



void setup_wifi() {
  delay(10);
  Serial.println();
  Serial.print("Conectando.. ");
  Serial.println(ssid);

  WiFi.begin(ssid, password);

  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
  }

  randomSeed(micros());

  Serial.println("");
  Serial.println("WiFi conectado");
  Serial.println("Direccion IP: ");
  Serial.println(WiFi.localIP());
}

void callback(String topic, byte* message, unsigned int length){
  Serial.print("Mensaje que llega del topic: ");
  Serial.print(topic);
  Serial.print(". Message: ");
  //String messageData;

  for(int i =0; i<length; i++){
    Serial.print((char)message[i]);
    messageData +=(char)message[i];
  }
  Serial.println();


// Enciende led
   if(messageData == "true")
      {digitalWrite(led,HIGH);}
   if(messageData == "false")
      {digitalWrite(led,LOW);}

   Serial.println("Recibe: " + messageData );

}

void reconnect() {

  // Loop para reconeccin
  while (!client.connected()) {
    Serial.print("Attempting MQTT connection...");

    // Creando un ID como ramdon
    String clientId = "ESP32-";
    clientId += String(random(0xffff), HEX);

    // Intentando conectarse
    if (client.connect(clientId.c_str())) {
      Serial.println("conectada");

    // Conectado, publicando un payload...
      client.publish("ei_out", "hello world");

    // ... y suscribiendo
      client.subscribe("ei_in");
    } else {
      Serial.print("failed, rc=");
      Serial.print(client.state());
      Serial.println(" Esperando 5 segundos");

      // Tiempo muerto de 5 segundos
      delay(5000);
    }
  }
}

void setup() {

  FastLED.addLeds<SK6812, DATA_PIN, RGB>(leds, NUM_LEDS);  // GRB ordering is typical
  Serial.begin(115200);
  Serial.setDebugOutput(true);
  pinMode(pin_agel, INPUT);
  pinMode(pin_agua, INPUT);
  pinMode(pin_papel, INPUT);
  setup_wifi();
  delay(1000);

  //****************
  if (!SPIFFS.begin(true)) {
    Serial.println("Se ha producido un error al montar SPIFFS");
    return;
  }
  //**********************
  //Root CA leer archivo.
  File file2 = SPIFFS.open("/AmazonRootCA1.pem", "r");
  if (!file2) {
    Serial.println("No se pudo abrir el archivo para leerlo");
    return;
  }
  Serial.println("Root CA File Content:");
  while (file2.available()) {
    Read_rootca = file2.readString();
    Serial.println(Read_rootca);
  }
  //*****************************
  // Cert leer archivo
  File file4 = SPIFFS.open("/6c57eabebe-certificate.pem.crt", "r");
  if (!file4) {
    Serial.println("No se pudo abrir el archivo para leerlo");
    return;
  }
  Serial.println("Cert File Content:");
  while (file4.available()) {
    Read_cert = file4.readString();
    Serial.println(Read_cert);
  }
  //***************************************
  //Privatekey leer archivo
  File file6 = SPIFFS.open("/6c57eabebe-private.pem.key", "r");
  if (!file6) {
    Serial.println("No se pudo abrir el archivo para leerlo");
    return;
  }
  Serial.println("privateKey contenido:");
  while (file6.available()) {
    Read_privatekey = file6.readString();
    Serial.println(Read_privatekey);
  }
  //=====================================================

  char* pRead_rootca;
  pRead_rootca = (char *)malloc(sizeof(char) * (Read_rootca.length() + 1));
  strcpy(pRead_rootca, Read_rootca.c_str());

  char* pRead_cert;
  pRead_cert = (char *)malloc(sizeof(char) * (Read_cert.length() + 1));
  strcpy(pRead_cert, Read_cert.c_str());

  char* pRead_privatekey;
  pRead_privatekey = (char *)malloc(sizeof(char) * (Read_privatekey.length() + 1));
  strcpy(pRead_privatekey, Read_privatekey.c_str());

  Serial.println("================================================================================================");
  Serial.println("Certificados que pasan adjuntan al espClient");
  Serial.println();
  Serial.println("Root CA:");
  Serial.write(pRead_rootca);
  Serial.println("================================================================================================");
  Serial.println();
  Serial.println("Cert:");
  Serial.write(pRead_cert);
  Serial.println("================================================================================================");
  Serial.println();
  Serial.println("privateKey:");
  Serial.write(pRead_privatekey);
  Serial.println("================================================================================================");

  espClient.setCACert(pRead_rootca);
  espClient.setCertificate(pRead_cert);
  espClient.setPrivateKey(pRead_privatekey);

  client.setServer(mqtt_server, mqtt_port);
  client.setCallback(callback);

  //******************************************
  WiFi.macAddress(mac);
  snprintf(mac_Id, sizeof(mac_Id), "%02x:%02x:%02x:%02x:%02x:%02x",
           mac[0], mac[1], mac[2], mac[3], mac[4], mac[5]);
  Serial.println(mac_Id);
  //****************************************
  delay(2000);
  //M5.begin();
  M5.lcd.setTextSize(3);             //Set the text size to 2.
  M5.Lcd.setCursor(50, 20);          //Set the cursor at (50,20).
  M5.Lcd.print("Monitoring of ");    // Print text on the screen (string)
  M5.Lcd.setCursor(10, 50);          //Set the cursor at (10,50).
  M5.Lcd.print("cleaning supplies"); // Print text on the screen (string)
}
void loop() {

  messageData = "";
  if (!client.connected()) {
    reconnect();
  }

  client.loop();

 //============ Monitoreo de Alcohol ==============
    if(digitalRead(pin_agel)==LOW){
      leds[1] = CRGB::Blue;
      leds[3] = CRGB::Blue;
      leds[6] = CRGB::Blue;
      leds[9] = CRGB::Blue;
      FastLED.show();

      long now = millis();
      if (now - lastMsg > 1000) {
        --capacity;
        lastMsg = now;}
      }

    else{
      leds[1] = CRGB::Black;
      leds[3] = CRGB::Black;
      leds[6] = CRGB::Black;
      leds[9] = CRGB::Black;
      FastLED.show();
    }

 //========= Monitoreo de Agua ======================
       agua=digitalRead(pin_agua);

 //======== Monitoreo de Papel ======================
    if(digitalRead(pin_papel)== LOW){
      //while(digitalRead(pin_papel)== LOW){}
      long now2 = millis();
      if (now2 - lastMsg2 > 1000) {
        --papel;
        lastMsg2 = now2;}
      }



 // ******************************* Enviando los valores de sensores a AWS IoT Core *******************************

      if ((millis() - lastTime) > timerDelay) {
        lastTime = millis();

        macIdStr = String(mac_Id);
        agel = String(capacity);
        sen_agua = String(agua);
        sen_papel = String(papel);
        snprintf (msg, BUFFER_LEN, "{\"mac_Id\" : \"%s\", \"Alcohol\" : %s, \"Agua\" : %s,\"Papel\" : %s}", macIdStr.c_str(),agel.c_str(), sen_agua.c_str(), sen_papel.c_str());
        Serial.print("Publicando mensaje: ");
        Serial.println(msg);
        Serial.println("Alcohol: "+ agel+"%" +" Agua: "+sen_agua+" Papel: "+sen_papel);
        client.publish("sensor", msg);
      }

}
