Thermocouple Interface using MAX31855 to Pi

Reading thermocouple data on Raspberry Pi using JAVA and Pi4J with the help of MAX31855 14 bit thermocouple to digital converter.

IntermediateShowcase (no instructions)1 hour2,214

Thermocouple Interface using MAX31855 to Pi

Things used in this project

Hardware components

Maxim Integrated MAX31855

Raspberry Pi 2 Model B

Story

The MAX31855

The MAX31855 performs cold-junction compensation and digitizes the signal from a K, J, N, T, S, R, or E-type thermocouple. The data is output in a signed 14-bit, SPI compatible, read-only format. This converter has a range from -270°C to +1800°C with a resolution of 0.25°C. It has an accuracy of ±2°C for temperatures ranging from -200°C to +700°C for K-type thermocouples.

MAX31855 Datasheet
