PC Chassis Fans

Intro

This project is about driving 2x120mm brush less Fans using Arduino Nano, 12 bit PWM module PCA9685, LCD HD44780+I2C module, 2 Rotary Encoders, Temperature Sensor NTC MF 52-103 and optocouplers.

The Fans (Front and Rear Chassis) from Delta FFB1212EH (4000 RPM max)

It is 4 pin PWM controlled Fans.

• Pin1 - GND

• Pin2 - VCC (12V+)

• Pin3 - FG (RPM signal)

• Pin4 - PWM

To driving Fan I used 12 bit resolution PWM module PCA9685. Connected it over I2C port to Nano. To read the RPM of Fans I isolated the inputs with PC817 Optocouplers. The FG signal provides 2 pulses every 1 period.

Encoders using only manually increase and decrease the speeds of Fan (0-4000). The Encoders switch I used to select of increasing/decreasing amount of speed. It`s 1, 10 and 100. To save calculated Integer value from Encoders, I used 2 byte of EEPROM memory for each. In code you can find how to use it

Besides it I used SPDT switch to select Manual or Temperature controlling. Connected NTC MF 52-103 type temperature sensor to A0 of Nano using Voltage divider method. Connected 10k potentiometer to A1 and mapped it between 20 - 40 degrees Celsius. So calculating automatically and mapping selected Temperature Set value and Temperature Sensor to driving the Fans.

Used https://www.desmos.com/calculator to make a graphic function

LCD Display HD44780 displaying what`s going on

Here is the schematic of connection:

And finally the sketch:

#include <Adafruit_PWMServoDriver.h>
#include <Wire.h>
#include <LiquidCrystal_I2C.h>
#include <EEPROM.h>
//#include "writeAnything.h"
/*
-VCC-5V
 |
NTC - Vout
 |
 R(fixed)
 |
GND
----Scaling Formula----
Reference Point        ADC Reading
  ===========          ==========
     x1(min)             a1(min)
     x2(max)             a2(max)
X - x1          A - a1
---------  =  -----------
x2 - x1          a2 - a1
==>  X = (x2 - x1)*(A - a1)/(a2 - a1) + x1
temp = ((110 - 0)*(average_sensor - 498))/191;
*/
Adafruit_PWMServoDriver pwm = Adafruit_PWMServoDriver();
#define ledPin 13
LiquidCrystal_I2C lcd(0x3C,16,2);  //sometimes the adress is not 0x3f. Change to 0x27 if it dosn't work.//0x3C is that A0 and A1 are shorted
short ThermistorPin = 0;// Analog input pin for thermistor voltage
short Temp_Pot = 1; //Temperature Potentiometer PIN
boolean f_encoder_a;
boolean f_encoder_b;
boolean r_encoder_a;
boolean r_encoder_b;
boolean f_encoder_sw;
boolean r_encoder_sw;
uint8_t f_pwmnum= 0;
uint8_t r_pwmnum= 1;
boolean switch_temp;
int Vo;// Integer value of voltage reading
float R = 9870.0;// Fixed resistance in the voltage divider
float logRt,Rt,T;
float c1 = 2.108508173e-03, c2 = 0.7979204727e-04, c3 = 6.535076315e-07;//Water Sersor R=10kOhm-25 degree Celcius.   B=3435
int pot_raw;
float pot_map;
boolean f_encoder_a_prev;
boolean r_encoder_a_prev;
boolean f_encoder_sw_prev;
boolean r_encoder_sw_prev;
boolean f_fan_raw;
boolean r_fan_raw;
boolean trig_a;
boolean trig_b;
unsigned int f_counter;
unsigned int r_counter;
unsigned int f_counter_temp;
unsigned int r_counter_temp;
unsigned int amount[3];
unsigned short f_rpm_amount;
unsigned short r_rpm_amount;
unsigned short f_encoder_sw_counter;
unsigned short r_encoder_sw_counter;
unsigned short f_counter_th;
unsigned short f_counter_hu;
unsigned short f_counter_te;
unsigned short f_counter_de;
unsigned short f_counter_12;
unsigned short f_counter_34;
int f_c;
int r_c;
//RPMreading//
int f_frequency;
int r_frequency;
int f_freq_counter;
int r_freq_counter;
unsigned long currentMicros;
unsigned long previousMicros = 0;
const long interval = 1000000;
void setup() {
 pwm.begin();
 pwm.setPWMFreq(1600);  // This is the maximum PWM frequency
   Wire.setClock(300000); //I2C clock frequency 300kHz
 Serial.begin(9600);
   f_counter = EEPROM_int_read(0);
   r_counter = EEPROM_int_read2(10);
 lcd.init(); // Initializing LCD
 lcd.begin(16, 2);
 lcd.backlight(); //lcd backlight o
 pinMode(2, INPUT);
 pinMode(3, INPUT);
 pinMode(4, INPUT);
 pinMode(5, INPUT);
 pinMode(6, INPUT);
 pinMode(7, INPUT); //Front Fan RPM input
 pinMode(8, INPUT); //Rear Fan RPM input
 pinMode(11, INPUT); //Front Encoder Switch
 pinMode(12, INPUT); //Rear Encoder Switch
 amount[0] = 1;
 amount[1] = 10;
 amount[2] = 100;
}
void loop() {
 temp_reading();
 rpm_reading();
 switch_temp = digitalRead(2);
 f_encoder_a = digitalRead(3);
 f_encoder_b = digitalRead(4);
 r_encoder_a = digitalRead(5);
 r_encoder_b = digitalRead(6);
 f_encoder_sw = digitalRead(11);
 r_encoder_sw = digitalRead(12);
 encoder_switch();
 encoder_reading();
 pwm_out();
 /*
 Serial.print(f_counter);
 Serial.print(" ");
 Serial.print(f_frequency_out);
 Serial.println();
 */
}
void temp_reading()
{
 Vo = analogRead(ThermistorPin);
 Rt = R*( (1023.0 / (float)Vo) - 1.0 );
 logRt = log(Rt);
 T = ( 1.0 / (c1 + c2*logRt + c3*logRt*logRt*logRt ) ) - 273.15;
 pot_raw = analogRead(Temp_Pot);
 pot_map = ((40.0 - 20.0)*(float(pot_raw) - 0.0))/(1023.0 - 0.0)+20.0;
 if(f_counter_temp<4096)
 {
  f_counter_temp = sqrt((T-pot_map))*550+500;
  r_counter_temp = sqrt((T-pot_map))*550+250;//Rear RPM less than Front
 }
} //end temp_reading
/***************************************************************************************/
void rpm_reading()
{
     //FRONT FAN RPM//
 f_fan_raw = digitalRead(7);
 if(f_fan_raw==false&&trig_a==false)
 {
   f_freq_counter++;
   trig_a = true;
 }
 if(f_fan_raw==true&&trig_a==true)
 {
   trig_a = false;
 }
    //REAR FAN RPM//
  r_fan_raw = digitalRead(8);
    if(r_fan_raw==false&&trig_b==false)
 {
   r_freq_counter++;
   trig_b = true;
 }
 if(r_fan_raw==true&&trig_b==true)
 {
   trig_b = false;
 }
 currentMicros = micros();
 if(currentMicros<previousMicros){previousMicros = currentMicros;}
 if(currentMicros-previousMicros>=interval)
{
 f_frequency = f_freq_counter * 60;
 f_frequency=f_frequency/2;
 r_frequency = r_freq_counter * 60;
 r_frequency=r_frequency/2;
   Serial.print(f_counter);
 Serial.print(" ");
 Serial.print(f_frequency);
 Serial.println();
 lcd.clear();
 lcd.setCursor(0, 0);
 lcd.print(f_counter);
 lcd.setCursor(0, 1);
 lcd.print(f_frequency);
 lcd.setCursor(5, 0);
 lcd.print(r_counter);
 lcd.setCursor(5, 1);
 lcd.print(r_frequency);
 lcd.setCursor(10, 0);
 lcd.print(T);
 lcd.setCursor(15, 0);
 lcd.print("C");
 lcd.setCursor(10, 1);
 lcd.print("S:");
 lcd.setCursor(12, 1);
 lcd.print(pot_map);
 f_freq_counter = 0;
 r_freq_counter = 0;
 previousMicros = currentMicros;
}
}//end rpm_reading
void encoder_switch()
{
                  //FRONT//
 if(f_encoder_sw==false){f_encoder_sw_prev = f_encoder_sw;}
 if(f_encoder_sw==true&&f_encoder_sw_prev==false)
 {
   f_encoder_sw_counter++;
   if(f_encoder_sw_counter>2){f_encoder_sw_counter = 0;}
   f_encoder_sw_prev = f_encoder_sw;
 }
 switch (f_encoder_sw_counter)
 {
   case 0:
         f_rpm_amount = amount[0];
   break;
   case 1:
         f_rpm_amount = amount[1];
   break;
   case 2:
        f_rpm_amount = amount[2];
   break;
 }
                    //REAR//
 if(r_encoder_sw==false){r_encoder_sw_prev = r_encoder_sw;}
 if(r_encoder_sw==true&&r_encoder_sw_prev==false)
 {
   r_encoder_sw_counter++;
   if(r_encoder_sw_counter>2){r_encoder_sw_counter = 0;}
   r_encoder_sw_prev = r_encoder_sw;
 }
 switch (r_encoder_sw_counter)
 {
   case 0:
         r_rpm_amount = amount[0];
   break;
   case 1:
         r_rpm_amount = amount[1];
   break;
   case 2:
        r_rpm_amount = amount[2];
   break;
 }
}//end encoder_switch
/***************************************************************************/
// reading FRONT Fan conrolling value to EEPROM using 2bytes
int EEPROM_int_read(int addr) {
 byte raw[2];
 for(byte i = 0; i < 2; i++) raw[i] = EEPROM.read(addr+i);
 int &f_c = (int&)raw;
 return f_c;
}
// writing FRONT Fan conrolling value to EEPROM using 2bytes
void EEPROM_int_write(int addr, int f_c) {
 if (EEPROM_int_read(addr)!= f_c){//если сохраняемое отличается
   byte raw[2];
   (int&)raw = f_c;
   for(byte i = 0; i < 2; i++) EEPROM.write(addr+i, raw[i]);
 }
}
// reading REAR Fan conrolling value to EEPROM using 2bytes
int EEPROM_int_read2(int addr) {
 byte raw[2];
 for(byte i = 0; i < 2; i++) raw[i] = EEPROM.read(addr+i);
 int &num = (int&)raw;
 return num;
}
// writing REAR Fan conrolling value to EEPROM using 2bytes
void EEPROM_int_write2(int addr, int num) {
 if (EEPROM_int_read2(addr)!= num){//если сохраняемое отличается
   byte raw[2];
   (int&)raw = num;
   for(byte i = 0; i < 2; i++) EEPROM.write(addr+i, raw[i]);
 }
}
void encoder_reading()
{
           //FRONT//
if(f_encoder_a != f_encoder_a_prev) //Increasing
{
     if(f_encoder_b != f_encoder_a)
     {
       if(f_encoder_a_prev==true)
        {
         if((f_counter+f_rpm_amount)<4096)
          {
           f_counter = f_counter + f_rpm_amount;
           EEPROM_int_write(0, f_counter);
          }
        }
       f_encoder_a_prev = f_encoder_a;
     }
     else                        //Decreasing
     {
       if(f_encoder_a_prev==true)
         {
          if(f_counter>200)
          {
           f_counter = f_counter - f_rpm_amount;
           EEPROM_int_write(0, f_counter);
          }
         }
       f_encoder_a_prev = f_encoder_a;
     }
 }
            //REAR//
 if(r_encoder_a != r_encoder_a_prev) //Increasing
{
     if(r_encoder_b != r_encoder_a)
     {
       if(r_encoder_a_prev==true)
        {
         if((r_counter+r_rpm_amount)<4096)
          {
           r_counter = r_counter + r_rpm_amount;
           EEPROM_int_write2(10, r_counter);
          }
        }
       r_encoder_a_prev = r_encoder_a;
     }
     else                           //Decreasing
     {
       if(r_encoder_a_prev==true)
         {
          if(r_counter>200)
          {
           r_counter = r_counter - r_rpm_amount;
           EEPROM_int_write2(10, r_counter);
          }
         }
       r_encoder_a_prev = r_encoder_a;
     }
 }
}//end encoder_reading
void pwm_out()
{
     if(switch_temp==true)
     {
      pwm.setPWM(f_pwmnum, 0, f_counter % 4096 );
      pwm.setPWM(r_pwmnum, 0, r_counter % 4096 );
     }else
     {
      pwm.setPWM(f_pwmnum, 0, f_counter_temp % 4096 );
      pwm.setPWM(r_pwmnum, 0, r_counter_temp % 4096 );
     }
}
