Door Alarm with Display

#include <LiquidCrystal.h>
#include <pitches.h>

// Set up the display pins.
const int rs = 8, en = 9, d4 = 10, d5 = 11, d6 = 12, d7 = 13;
LiquidCrystal lcd(rs, en, d4, d5, d6, d7);

/*** Setup our door alarm variables. ***/
// The pins connected to thr ultrasonic sensor.
int echoPin = 4;
int trigPin = 5;

// The pin connected to our push button.
int buttonPin = 2;

// The pin the speaker is attached to.
int speakerPin = 7;

// A distance reading has to change more or less than the recorded distance and the tolerance.
float distToDoor_Tolerance = 10;

// The distance to our door in cm -1 means it has not yet been set.
float distToDoor = -1;

// The notes in our melody and their duration in fractions of a second. Exampls: quarter note = 4, eigth note = 8, etc.
const int melody[][2] =
{
  // These notes can be changed based on user preference.
  {NOTE_D7, 4},
  {NOTE_A6, 4},
  {NOTE_B0, 4}
};
/***************************************/

void play_alarm()
{
  // Figure out the number of notes in our melody.
  int numberOfNotes = sizeof(melody) / sizeof(melody[0]);

  // Iterate over the notes of the melody.
  for(int i = 0; i < numberOfNotes; i++)
  {
    // Grab our note and note duration.
    int thisNoteTone = melody[i][0];
    int thisNoteDuration = melody[i][1];

    // To calculate the note duration in milliseconds.
    int noteDurationMS = 1000 / thisNoteDuration;

    // Play the note.
    tone(speakerPin, thisNoteTone, noteDurationMS);

    // Distinguish the notes, set a minimum time between them. The notes duration plus 30% seems to work well.
    delay(noteDurationMS * 1.3);
  }
}

float get_distance_cm()
{
  float distance_cm;
  int pulseLenMS;

  // Bit-bang a small square wave on the trig pin to start the wave finder.
  digitalWrite(trigPin, LOW);
  delayMicroseconds(20);
  digitalWrite(trigPin, HIGH);
  delayMicroseconds(100);
  digitalWrite(trigPin, LOW);

  // Measure the pulse length from the echo pin.
  pulseLenMS = pulseIn(echoPin, HIGH);

  // Calculate the distnce using the speed of sound.
  distance_cm = pulseLenMS / 29.387 / 2;

  return distance_cm;
}

void setup() {
  // Put your setup code here, to run once:
  // Set the pin mode on your ultrasonic echo and trig pins.
  pinMode(echoPin, INPUT);
  pinMode(trigPin, OUTPUT);

  lcd.clear();

  // Set the pin mode for our button to input with pull up.
  pinMode(buttonPin, INPUT_PULLUP);

  lcd.begin(16,2);
}

void loop() {
  // Put your main code here, to run repeatedly:
  int button;
  float distance;


  // Read the ultrasonic sensor.
  distance = get_distance_cm();

  // if the distance is greater or less than our preset alarm distance, and we have set a distance, sound the alarm.
  if(distance > distToDoor + distToDoor_Tolerance || distance < distToDoor - distToDoor_Tolerance)
  {
    if(distToDoor != -1){
      play_alarm();
      // Print to the LCD screen.
      lcd.clear();
      lcd.print("Door is open!");
      delay(100);
    }
    else{
      // Print to the LCD screen.
      lcd.clear();
      lcd.print("Door is closed.");
      delay(100);
    }
  }
  else
  {
    // Print to the LCD screen.
    lcd.clear();
    lcd.print("Door is closed.");
    delay(100);
  }

  // Read our button state.
  button = digitalRead(buttonPin);

  // if the button is pressed, set the distance to the last distance read.
  if(button == LOW)
  {
    distToDoor = distance;
  }
}
