Building and Deploying an IoT Project on Solutions.Carenuity.com

In this comprehensive guide, you will learn how to build an IoT project using the Arduino IDE, generate binary files, and share them with friends through Solution Builder http://solutions.carenuity.com. This platform simplifies the sharing with friends, who have no Arduino skills, allowing them to enjoy your project in a super simple way.

Step 1: Setting Up Your Project in the Arduino IDE

1.1 Install the Arduino IDE

• Download the IDE: Visit the Arduino Software page to download the latest version of the Arduino IDE for your operating system.
• Install Board Definitions: If you’re using a board like the ESP32, you’ll need to add the board definitions in the Arduino IDE. Go to File > Preferences and add the appropriate board manager URLs. For ESP32, you can add: https://dl.espressif.com/dl/package_esp32_index.json
• Install Libraries: You may need additional libraries depending on your project requirements. Go to Sketch > Include Library > Manage Libraries and search for your needed libraries.

1.2 Connect and Configure Your Board

• Select Your Board: Go to Tools > Board > Boards Manager and install your board (e.g., ESP32 or Arduino Uno).
• Select the Port: In Tools > Port, choose the correct COM port for your device.
• Check Board Configuration: Some boards, like the ESP32, have additional settings (e.g., Flash Frequency, Partition Scheme) under Tools. Configure these based on your device specifications.

1.3 Write or Import Your Code

• Create a New Sketch: Go to File > New to create a new sketch or File > Open to import an existing .ino file.
• Write or Edit Code: Enter your code in the editor. If importing, ensure that all referenced libraries are installed. You Can ask AI to do you a code based on the application that you intend to do.
• Verify the Code: Click on the Checkmark (Verify) button to compile the code and check for errors. Fix any issues as needed until the code for your application compiles successfully.

Step 2: Compiling and Accessing Binary Files

2.1 Compile the Sketch

• Select Board and Port Again: Double-check that the correct board and port are selected in the Tools menu. If you are using our Versatile C3-Mini_IoT board, you need to choose this board

• Verify and Compile: Click the Verify button to compile the sketch. The IDE will save compiled files in a temporary folder, including a .bin file for your project.

2.2 Locate Binary Files

• Enable Verbose Output: Go to File > Preferences and check Show verbose output during compilation. This displays the file paths during compilation.
• Find the Binary File Path: Once the compilation completes, scroll through the output to locate the path where the .bin file is saved. Copy this path for easy access.

Step 3: Preparing for Deployment on Solutions.Carenuity.com

3.1 Save and Test the Binary

• Organize Your Files: Move the merged-app.bin file to a dedicated folder for easy access.
• Test Locally (Optional): If possible, flash the merged binary onto your device using a tool like esptool or the Arduino IDE’s “Upload” function to verify that it works.

Step 4: Setting Up Your Account on Solutions.Carenuity.com

4.1 Create an Account

• Sign Up: Go to Solutions.Carenuity.com and create a new account.
• Complete Profile: Add a profile photo and link for at least one social media profile. This helps in networking and connecting with other developers on the platform.

4.2 Navigate to Applications

• Access My Applications: After logging in, go to Settings > My Applications. This section allows you to create, manage, and deploy applications.

Step 5: Adding a New Application and Uploading Your Binary

5.1 Create a New Application

• Click the “+” Button: Start the application creation process.
• Choose Solution Type: Select the solution template that best fits your project. Different templates offer pre-configured settings that can simplify deployment.
• Select ecosystem:Here’s a breakdown of the four ecosystems available on solutions.carenuity.com and how each one can support various project deployments:

1. Cloudfree Ecosystem

Overview: This ecosystem is designed for projects that prioritize local control, eliminating reliance on external cloud services.

2. HomeAssistant Ecosystem

Overview: A versatile ecosystem tailored for smart home enthusiasts and integrators, offering seamless integration with the HomeAssistant platform.

3. Matter Ecosystem

Overview: Focused on the emerging Matter protocol, this ecosystem is built for seamless interoperability and unified smart home standards.

4. InternetAppStory Ecosystem

Overview: This ecosystem is designed to streamline the development and deployment of connected apps, leveraging internet connectivity for remote control and monitoring.

• Choosetheapplicationtype: Select the application template from the available templates or enquire for a personalized application name.

5.2 Provide Project Information

• Select Board Type: Choose your device type (e.g., ESP32, ESP8266, Arduino Uno).
• Add GitHub Repository: If your project is hosted on GitHub, provide the repository link for easy reference and code access.

5.3 Upload the Merged Binary

• Locate Main Binary Section: In the application form, go to Main Binary and click Upload.
• Upload the merged-app.bin File: Navigate to where you saved the binary and upload it.

5.4 Finalize and Generate the Application

• Complete the Form: Confirm that you correctly assigned your application to the right development board, ecosystem, solution, and application.
• Click Create: Solutions.Carenuity.com will generate your application and prepare it for installation on compatible devices.

Step 6: Deploying and Reusing Your Application

6.1 Install on Compatible Devices

• Install the Application: With your application generated, simply click Install on compatible devices. solutions.carenuity.com will handle the deployment process, flashing the device with your binary and setting up the necessary configurations.

6.2 Scale and Manage Installations

• Reuse Across Projects: If you have similar projects, reuse the same application configuration to streamline the setup for new devices, making scaling simple and efficient without rewriting the codes and struggling with the endless recompilation and change of libraries.

Conclusion

By following these steps, you’ve learned how to develop, compile, merge, and deploy an IoT application using Solutions.Carenuity.com. This platform not only simplifies the deployment process but also makes it easy to manage and scale your applications. Whether you’re an IoT enthusiast or an experienced developer, Solutions.Carenuity.com provides a unified approach from code to fully deployed smart devices.

Attached is a video guide on the build and deployment.
