TinyML Forest Ranger: Illegal Logging Detection and Alert 🪵

Introduction: The Problem of Illegal Wood Logging 🪵

Illegal wood logging is a serious global issue threatening our forests, biodiversity, and climate stability. It involves the unauthorized cutting and trade of timber, often in protected areas or without following legal procedures. This activity not only leads to rapid deforestation but also destroys wildlife habitats, contributes to carbon emissions, and undermines local communities who depend on forests for their livelihood. Monitoring vast forest areas is challenging with limited human resources, making it difficult to catch illegal activities in time. Innovative, tech-driven solutions are essential to tackle this hidden yet destructive problem.

🛠️ Solution: How will it work?

TinyML Forest Ranger is a TinyML-powered environmental monitoring system designed to detect illegal logging and unauthorized vehicle movement in forest buffer zones. Using TinyML models deployed on ultra-low-power edge devices, combined with LoRa communication over the Helium Network, this solution enables real-time sound analysis of chainsaws and vehicles, triggering instant alerts to protect vulnerable forest areas. It's an innovative, scalable, and sustainable approach to forest conservation.

🧪 Architecture: TinyML-based illegal logging detection system.

This image is a flowchart that illustrates the working process of a TinyML-based illegal logging detection system, specifically focusing on vehicle sound detection in forest buffer zones using XIAO nRF52840 Sense, LoRa Radio, and the Helium Network.

🔍 Step-by-step Explanation:

• StartThe system initializes
• Capture SoundThe microphone on the XIAO nRF52840 Sense board begins listening to the environment.
• Analyse the SoundThe captured sound is analyzed using a TinyML program deployed on the XIAO nRF52840 Sense board.If the sound is background noise, the system goes into Idle mode and loops back to sound capturing And If it detects a "Vehicle" sound (indicating possible unauthorized access), it proceeds to the next step
• Connect to LoRa NetworkIf it hasn't already, the device connects to the LoRa network and performs OTAA (Over-The-Air Activation).
• Send Data to Helium ConsoleData is transmitted over LoRa WAN to the Helium Console.
• Route Data to Dashboard/DatabaseHTTPS sends the data to a dashboard or database for monitoring and analysis
• Send Alert to Forest RangerBased on the data, an SMS or Email alert is sent to the concerned Forest Ranger.
• Loop BackThe system loops back to continue capturing and analyzing sound.

🧰 Hardware Required

• Seeeduino XIAO nRF52840 Sense x 1
• Grove - Wio-E5 x 1
• Seeeduino XIAO Expansion Board x 1 (recommended for easy interface between XIAO and Grove module)

💾 Software Tools/Service Required

• 1x Arduino IDE
• 1x Helium IoT Console .
• 1 x Computer
• 1 x USB Type-C cable

🛠️ Setup XIAO nRF52840 Sense on Arduino IDE

Seeed Studio XIAO nRF52840 Sense is equipped with a powerful Nordic nRF52840 MCU which integrates Bluetooth 5.0 connectivity.

It has two extra onboard sensors. One of them is a Pulse Density Modulation (PDM) Digital Microphone. The other one is a 6-axis Inertial Measurement Unit (IMU),

Step 1: Connect the Seeed Studio XIAO nRF52840 (Sense) to your computer via a USB Type-C cable.

👨‍💻 Software setup

Step 1. Download and Install the latest version of Arduino IDE according to your operating system

Step 2. Add Seeed Studio XIAO nRF52840 (Sense) board package to your Arduino IDENavigate to File > Preferences, and fill "Additional Boards Manager URLs" with the url below:

https://files.seeedstudio.com/arduino/package_seeeduino_boards_index.json

Navigate to Tools > Board > Boards Manager..., type the keyword "seeed nrf52" in the search box, select the latest version of the board you want, and install it. You can install both.

• Step 4. Select your board and port

After installing the board package, navigate to Tools > Board and choose the board you want, continue to select "Seeed XIAO BLE Sense nRF52840" from "Seeed nRF mbed-enabled Boards". Now we have finished setting up the Seeed Studio XIAO nRF52840 (Sense) for Arduino IDE.

Navigate to Tools > Port and select the serial port name of the connected Seeed Studio XIAO nRF52840 (Sense). This is likely to be COM3 or higher (COM1 and COM2 are usually reserved for hardware serial ports). The serial port of the connected Seeed Studio XIAO nRF52840 (Sense) usually contains parentheses that are written Seeed Studio XIAO nRF52840 for Seeed Studio XIAO nRF52840 or Seeed Studio XIAO nRF52840 Sense for Seeed Studio XIAO nRF52840 Sense

• Step 5. Navigate to File > Examples > 01.Basics > Blink to open Blink example

• Step 6. Click the Upload button to upload the Blink example code to the board

Once uploaded, you will see the built-in red LED blinking with a 1-second delay between each blink. This means the connection is successful and now you can explore more projects with the Seeed Studio XIAO nRF52840 (Sense)!

☁️ Setup Helium LoRa WAN Console.

⚠️ Make sure you are inside the helium network coverage. You can find the network coverage at explorer.helium.com

⚠️ Please ensure the consistent of the frequency band among the end nodes, gateway, and Helium configuration you are using by following this instruction. The frequency plan this demo applied is for IN865.

The Helium IOT Network uses the LoRaWAN protocol to provide internet connectivity to "Internet of Things" devices and is the original sub-network in the Helium ecosystem. Developers and companies worldwide rely on the Helium IOT Network for connectivity.

📡 Helium IoT Console Preparation

• Step 1. Visit Helium Console website and sign up for a new account

• Step 2. After logging in, click "Devices" to manage devices.

• Step 3. Then click on "Add New Device"

• Step 4. Here, 1) Add device a new, 2) Copy the Dev EUI, 3) Copy the App EUI, 4) Copy the App Key, 5) Finally Click Save.

• Step 5. Now you can see the device under the "Devices" section.

Now, the helium console setup is done. we can move to the Software part and upload data to the helium console over the helium LoRa network.

🔧 Hardware Preparation.

Place the XIAO nRF52840 BLE Sense to the Seeeduino XIAO Expansion board and then Connect the Grove - Wio E5 to the XIAO Expansion board UART Port.

🧠 TinyML Model Preparation.

I developed the tinyML model using the Edge impulse tool, and you can find the dataset and project details here, you can also clone the project and do the modifications as per your need.

We have around 1h and 6m dataset

And used the MFEa as a processing block to extract the features and Keras as neural network classification.

We got a good training result since the sound is easily distinguishable as per the extracted features we have from the dataset.

You can make your own model or clone my Edge impulse project to implement this project.

For now, download the Edge Impulse tinyML library from here and add it the Arduino. Follow this guide to learn how to add ZIP libraries.

After adding the library, copy the code below and past in to your arduino sketch and replace the helium LoRa WAN Credentials.

/* Edge Impulse ingestion SDK
 * Copyright (c) 2022 EdgeImpulse Inc.
 *
 * Licensed under the Apache License, Version 2.0 (the "License");
 * you may not use this file except in compliance with the License.
 * You may obtain a copy of the License at
 * http://www.apache.org/licenses/LICENSE-2.0
 *
 * Unless required by applicable law or agreed to in writing, software
 * distributed under the License is distributed on an "AS IS" BASIS,
 * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
 * See the License for the specific language governing permissions and
 * limitations under the License.
 *
 * Modified by Salman Faris
 *
 */

// If your target is limited in memory remove this macro to save 10K RAM
#define EIDSP_QUANTIZE_FILTERBANK 0

/*
 ** NOTE: If you run into TFLite arena allocation issue.
 **
 ** This may be due to may dynamic memory fragmentation.
 ** Try defining "-DEI_CLASSIFIER_ALLOCATION_STATIC" in boards.local.txt (create
 ** if it doesn't exist) and copy this file to
 ** `<ARDUINO_CORE_INSTALL_PATH>/arduino/hardware/<mbed_core>/<core_version>/`.
 **
 ** See
 ** (https://support.arduino.cc/hc/en-us/articles/360012076960-Where-are-the-installed-cores-located-)
 ** to find where Arduino installs cores on your machine.
 **
 ** If the problem persists then there's not enough memory for this model and application.
 */


 /*
** Developed by Salman Faris
** Date: 20/09/2023
 */



/* Includes ---------------------------------------------------------------- */
#include <PDM.h>
#include <Illegal_Logging_Detection_-_Vehicle_sound_-_XIAO-nRF52_inferencing.h>
#include <Arduino.h>
#include <U8x8lib.h>

U8X8_SSD1306_128X64_NONAME_HW_I2C u8x8(/*reset=*/U8X8_PIN_NONE);

/** Audio buffers, pointers and selectors */
typedef struct {
  int16_t *buffer;
  uint8_t buf_ready;
  uint32_t buf_count;
  uint32_t n_samples;
} inference_t;

static inference_t inference;
static signed short sampleBuffer[2048];
static bool debug_nn = false;  // Set this to true to see e.g. features generated from the raw signal

//LoRa Buffer
static char recv_buf[512];
static bool is_exist = false;
static bool is_join = false;
static int led = 0;

//Inference Data
int pred_index = 0;    // Initialize pred_index
float pred_value = 0;  // Initialize pred_value

static int at_send_check_response(char *p_ack, int timeout_ms, char *p_cmd, ...) {
  int ch;
  int num = 0;
  int index = 0;
  int startMillis = 0;
  va_list args;
  char cmd_buffer[256];  // Adjust the buffer size as needed
  memset(recv_buf, 0, sizeof(recv_buf));
  va_start(args, p_cmd);
  vsprintf(cmd_buffer, p_cmd, args);  // Format the command string
  Serial1.print(cmd_buffer);
  Serial.print(cmd_buffer);
  va_end(args);
  delay(200);
  startMillis = millis();

  if (p_ack == NULL) {
    return 0;
  }

  do {
    while (Serial1.available() > 0) {
      ch = Serial1.read();
      recv_buf[index++] = ch;
      Serial.print((char)ch);
      delay(2);
    }

    if (strstr(recv_buf, p_ack) != NULL) {
      return 1;
    }

  } while (millis() - startMillis < timeout_ms);
  return 0;
}

static void recv_prase(char *p_msg) {
  if (p_msg == NULL) {
    return;
  }
  char *p_start = NULL;
  int data = 0;
  int rssi = 0;
  int snr = 0;

  p_start = strstr(p_msg, "RX");
  if (p_start && (1 == sscanf(p_start, "RX: \"%d\"\r\n", &data))) {
    Serial.println(data);
    u8x8.setCursor(2, 4);
    u8x8.print("led :");
    led = !!data;
    u8x8.print(led);
    if (led) {
      digitalWrite(LED_BUILTIN, LOW);
    } else {
      digitalWrite(LED_BUILTIN, HIGH);
    }
  }

  p_start = strstr(p_msg, "RSSI");
  if (p_start && (1 == sscanf(p_start, "RSSI %d,", &rssi))) {
    u8x8.setCursor(0, 6);
    u8x8.print("                ");
    u8x8.setCursor(2, 6);
    u8x8.print("rssi:");
    u8x8.print(rssi);
  }
  p_start = strstr(p_msg, "SNR");
  if (p_start && (1 == sscanf(p_start, "SNR %d", &snr))) {
    u8x8.setCursor(0, 7);
    u8x8.print("                ");
    u8x8.setCursor(2, 7);
    u8x8.print("snr :");
    u8x8.print(snr);
  }
}


/**
 * @brief      Arduino setup function
 */
void setup() {
  // put your setup code here, to run once:
  Serial.begin(115200);
  Serial1.begin(9600);
  // comment out the below line to cancel the wait for USB connection (needed for native USB)
  while (!Serial)
    ;
  Serial.println("Edge Impulse Inferencing Demo");

  // summary of inferencing settings (from model_metadata.h)
  ei_printf("Inferencing settings:\n");
  ei_printf("\tInterval: %.2f ms.\n", (float)EI_CLASSIFIER_INTERVAL_MS);
  ei_printf("\tFrame size: %d\n", EI_CLASSIFIER_DSP_INPUT_FRAME_SIZE);
  ei_printf("\tSample length: %d ms.\n", EI_CLASSIFIER_RAW_SAMPLE_COUNT / 16);
  ei_printf("\tNo. of classes: %d\n", sizeof(ei_classifier_inferencing_categories) / sizeof(ei_classifier_inferencing_categories[0]));

  if (microphone_inference_start(EI_CLASSIFIER_RAW_SAMPLE_COUNT) == false) {
    ei_printf("ERR: Could not allocate audio buffer (size %d), this could be due to the window length of your model\r\n", EI_CLASSIFIER_RAW_SAMPLE_COUNT);
    return;
  }


  u8x8.begin();
  u8x8.setFlipMode(1);
  u8x8.setFont(u8x8_font_chroma48medium8_r);

  Serial.begin(115200);
  pinMode(LED_BUILTIN, OUTPUT);
  digitalWrite(LED_BUILTIN, HIGH);

  Serial1.begin(9600);
  Serial.print("E5 LORAWAN TEST\r\n");
  u8x8.setCursor(0, 0);

  if (at_send_check_response("+AT: OK", 100, "AT\r\n")) {
    is_exist = true;
    at_send_check_response("+ID: DevEui", 1000, "AT+ID=DevEui,\"XXXXXXXXXX"\r\n");
    at_send_check_response("+ID: AppEui", 1000, "AT+ID=AppEui,\"XXXXXXXXXXX\"\r\n");
    at_send_check_response("+KEY: APPKEY", 1000, "AT+KEY=APPKEY,\"XXXXXXXXXXXX\"\r\n");
    at_send_check_response("+ID: DevAddr", 1000, "AT+ID=DevAddr\r\n");
    at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
    at_send_check_response("+MODE: LWOTAA", 1000, "AT+MODE=LWOTAA\r\n");
    at_send_check_response("+DR: IN865", 1000, "AT+DR=IN865\r\n");
    at_send_check_response("+CH: NUM", 1000, "AT+CH=NUM,0-2\r\n");
    at_send_check_response("+CLASS: A", 1000, "AT+CLASS=A\r\n");
    at_send_check_response("+PORT: 8", 1000, "AT+PORT=8\r\n");
    delay(200);
    u8x8.setCursor(5, 0);
    u8x8.print("LoRaWAN");
    is_join = true;
  } else {
    is_exist = false;
    Serial.print("No E5 module found.\r\n");
    u8x8.setCursor(0, 1);
    u8x8.print("unfound E5 !");
  }

  //dht.begin();
}

/**
 * @brief      Arduino main function. Runs the inferencing loop.
 */
void loop() {
  ei_printf("Starting inferencing in 2 seconds...\n");

  delay(2000);

  ei_printf("Recording...\n");

  bool m = microphone_inference_record();
  if (!m) {
    ei_printf("ERR: Failed to record audio...\n");
    return;
  }

  ei_printf("Recording done\n");

  signal_t signal;
  signal.total_length = EI_CLASSIFIER_RAW_SAMPLE_COUNT;
  signal.get_data = &microphone_audio_signal_get_data;
  ei_impulse_result_t result = { 0 };

  EI_IMPULSE_ERROR r = run_classifier(&signal, &result, debug_nn);
  if (r != EI_IMPULSE_OK) {
    ei_printf("ERR: Failed to run classifier (%d)\n", r);
    return;
  }


  int pred_index = 0;    // Initialize pred_index
  float pred_value = 0;  // Initialize pred_value

  // print the predictions
  ei_printf("Predictions ");
  ei_printf("(DSP: %d ms., Classification: %d ms., Anomaly: %d ms.)",
            result.timing.dsp, result.timing.classification, result.timing.anomaly);
  ei_printf(": \n");

  for (size_t ix = 0; ix < EI_CLASSIFIER_LABEL_COUNT; ix++) {
    ei_printf("    %s: %.5f\n", result.classification[ix].label, result.classification[ix].value);
    ei_printf("\n");
    if (result.classification[ix].value > pred_value) {
      pred_index = ix;
      pred_value = result.classification[ix].value;
    }
  }


  // Display inference result and Send message to Helium Console.
  if ((pred_index == 1 && (pred_value > 0.8))) {
    ei_printf("Vehicle Sound is Detected ");
    ei_printf("\n");
    int SOS = 10;
    int DeviceID = 1;
    if (is_exist) {
      int ret = 0;
      if (is_join) {

        ret = at_send_check_response("+JOIN: Network joined", 12000, "AT+JOIN\r\n");
        if (ret) {
          is_join = false;
        } else {
          at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
          Serial.print("JOIN failed!\r\n\r\n");
          delay(5000);
        }
      } else {
        char cmd[128];
        sprintf(cmd, "AT+CMSGHEX=\"%04X%04X\"\r\n", (int)DeviceID, (int)SOS);
        ret = at_send_check_response("Done", 5000, cmd);

        u8x8.setCursor(0, 2);
        u8x8.print("      ");
        u8x8.setCursor(2, 2);
        u8x8.print("Vehicle Detected");
        u8x8.setCursor(2, 3);
        u8x8.print("Sending SOS");
        if (ret) {
          recv_prase(recv_buf);
        } else {
          Serial.print("Send failed!\r\n\r\n");
        }
        delay(5000);
      }
    } else {
      delay(1000);
    }

  }
  else {
        u8x8.setCursor(0, 2);
        u8x8.print("      ");
        u8x8.setCursor(2, 2);
        u8x8.print("Normal Condition");
        u8x8.setCursor(2, 3);
        u8x8.print("idle");
  }

#if EI_CLASSIFIER_HAS_ANOMALY == 1
  ei_printf("    anomaly score: %.3f\n", result.anomaly);
#endif
}

/**
 * @brief      PDM buffer full callback
 *             Get data and call audio thread callback
 */
static void pdm_data_ready_inference_callback(void) {
  int bytesAvailable = PDM.available();

  // read into the sample buffer
  int bytesRead = PDM.read((char *)&sampleBuffer[0], bytesAvailable);

  if (inference.buf_ready == 0) {
    for (int i = 0; i < bytesRead >> 1; i++) {
      inference.buffer[inference.buf_count++] = sampleBuffer[i];

      if (inference.buf_count >= inference.n_samples) {
        inference.buf_count = 0;
        inference.buf_ready = 1;
        break;
      }
    }
  }
}

/**
 * @brief      Init inferencing struct and setup/start PDM
 *
 * @param[in]  n_samples  The n samples
 *
 * @return     { description_of_the_return_value }
 */
static bool microphone_inference_start(uint32_t n_samples) {
  inference.buffer = (int16_t *)malloc(n_samples * sizeof(int16_t));

  if (inference.buffer == NULL) {
    return false;
  }

  inference.buf_count = 0;
  inference.n_samples = n_samples;
  inference.buf_ready = 0;

  // configure the data receive callback
  PDM.onReceive(&pdm_data_ready_inference_callback);

  PDM.setBufferSize(4096);

  // initialize PDM with:
  // - one channel (mono mode)
  // - a 16 kHz sample rate
  if (!PDM.begin(1, EI_CLASSIFIER_FREQUENCY)) {
    ei_printf("Failed to start PDM!");
    microphone_inference_end();

    return false;
  }

  // set the gain, defaults to 20
  PDM.setGain(127);

  return true;
}

/**
 * @brief      Wait on new data
 *
 * @return     True when finished
 */
static bool microphone_inference_record(void) {
  inference.buf_ready = 0;
  inference.buf_count = 0;

  while (inference.buf_ready == 0) {
    delay(10);
  }

  return true;
}

/**
 * Get raw audio signal data
 */
static int microphone_audio_signal_get_data(size_t offset, size_t length, float *out_ptr) {
  numpy::int16_to_float(&inference.buffer[offset], out_ptr, length);

  return 0;
}

/**h
 * @brief      Stop PDM and release buffers
 */
static void microphone_inference_end(void) {
  PDM.end();
  free(inference.buffer);
}

#if !defined(EI_CLASSIFIER_SENSOR) || EI_CLASSIFIER_SENSOR != EI_CLASSIFIER_SENSOR_MICROPHONE
#error "Invalid model for current sensor."
#endif

Reaplace the DevEUI, AppEUI and APPKEY with your credentails obtained from the Helium console. Also make sure to replace the IN865 as per your region FREQ plan.

at_send_check_response("+ID: DevEui", 1000, "AT+ID=DevEui,\"xxxxxxxxxxx\"\r\n");
at_send_check_response("+ID: AppEui", 1000, "AT+ID=AppEui,\"xxxxxxxxxxx\"\r\n");
at_send_check_response("+KEY: APPKEY", 1000, "AT+KEY=APPKEY,\"xxxxxxxxxxxxxxx\"\r\n");
at_send_check_response("+ID: DevAddr", 1000, "AT+ID=DevAddr\r\n");
at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
at_send_check_response("+MODE: LWOTAA", 1000, "AT+MODE=LWOTAA\r\n");
at_send_check_response("+DR: IN865", 1000, "AT+DR=IN865\r\n");
at_send_check_response("+CH: NUM", 1000, "AT+CH=NUM,0-2\r\n");
at_send_check_response("+CLASS: A", 1000, "AT+CLASS=A\r\n");
at_send_check_response("+PORT: 8", 1000, "AT+PORT=8\r\n");

In the below section, you can see the XIAO will check if there any Vehicle sound detected and if it's detected, it will establish an LoRa WAN Connection to the helium console and send data 1 as Vehicle Sound is Detected symbol.

// Display inference result and Send message to Helium Console.
  if ((pred_index == 1 && (pred_value > 0.8))) {
    ei_printf("Vehicle Sound is Detected ");
    ei_printf("\n");
    int SOS = 10;
    int DeviceID = 1;
    if (is_exist) {
      int ret = 0;
      if (is_join) {

        ret = at_send_check_response("+JOIN: Network joined", 12000, "AT+JOIN\r\n");
        if (ret) {
          is_join = false;
        } else {
          at_send_check_response("+ID: AppEui", 1000, "AT+ID\r\n");
          Serial.print("JOIN failed!\r\n\r\n");
          delay(5000);
        }
      } else {
        char cmd[128];
        sprintf(cmd, "AT+CMSGHEX=\"%04X%04X\"\r\n", (int)DeviceID, (int)SOS);
        ret = at_send_check_response("Done", 5000, cmd);

        u8x8.setCursor(0, 2);
        u8x8.print("      ");
        u8x8.setCursor(2, 2);
        u8x8.print("Vehicle Detected");
        u8x8.setCursor(2, 3);
        u8x8.print("Sending SOS");
        if (ret) {
          recv_prase(recv_buf);
        } else {
          Serial.print("Send failed!\r\n\r\n");
        }
        delay(5000);
      }
    } else {
      delay(1000);
    }

  }
  else {
        u8x8.setCursor(0, 2);
        u8x8.print("      ");
        u8x8.setCursor(2, 2);
        u8x8.print("Normal Condition");
        u8x8.setCursor(2, 3);
        u8x8.print("idle");
  }

✨ Demo

Note: Make sure you are inside the helium network coverage. You can find the network coverage at explorer.helium.com

After uploading the code, The XIAO nRF52840 Sense will capture sound and check if there is any engine sound using tinyML, so try to play engine sound to trigger the action. Once it's detect the engine sound (1), XIAO will establish the Helium LoRa network connection and send command "1" as Vehicle Sound is Detected symbol (2).

You can see the data over the helium console and it's debug window.

📋 ToDo ​

So far, we have made integration with tinyML and LoRa. And we have a few to-dos that you can work on as exercise to improve the project.

• Integrate the helium console with the dashboard and visualise the data
• Create an Email/SMS/Phone Alert with a custom dashboard to inform the forest ranger.

⚠️Update ToD:

Helium console LNS is appreciated, so weweneed to upgrade with compatible LNS or move to TTN.

Originally published on : SeeedStudio Grove E5 https://wiki.seeedstudio.com/Grove_Wio_E5_Helium_tinyML_Demo/
