Global awareness dashboard

The global warming is a global phenomenon. Day by day temperature of earth is increasing. There are many reasons for this

• Deforestation
• Burning fuel gas etc

I got to know about hackster contest and I thought to apply and try. Unfortunately because of the pandemic there was lot of struggle to do this project like because of sudden lock downs lost access to place where my windows pc and hardware lab set up.

Setting up system

quickfeather team have shared qorc sdk in git hub to help developers. I also used that

you can find the same repo here

inside the repo you can find TinyFPGA-Programmer-Application which is our tool to flash code into quick feather board.

quickfeather board have same pinout as adafruit feather. connect the usb to TTL connector. for blinking led and changing colors we can use qf_helloworldsw inside qf apps in sdk

for integrating sensors we have to look into qf_ssi_ai_app

qorc_ssi_adc.begin();
qorc_ssi_adc.setSampleRate(sensor_ssss_config.rate_hz);
int16_t *p_adc_data = (int16_t *)p_dest;
int16_t channel_A2 = qorc_ssi_adc.getSingleEnded(0);

after collecting enough data sets in DCL we can train our model using analytical studio

for integrating knowledge pack we can follow this video

after integration we can flash the new binary to quickfeather

connection

quickfeather rx- photon tx

quickfeather tx- photon rx

gnd-gnd

quickfeather sda - ads1015 sda

quickfather scl -ads1015 scl

using particle photon connected with quick feather we can send data to adafruit dashboard

we can create different blocks in adafruit dashboard

#define ADAFRUIT_IO_DEBUG 1
#include "Adafruit_IO_Particle.h"

FeedData::FeedData() {
    // Feed data is invalid without a value so write all zeros.
    memset(_value, 0, sizeof(_value));
}

FeedData::FeedData(const FeedData& copy) {
    // Copy the value from the provided FeedData object.
    memset(_value, 0, sizeof(_value));
    strncpy(_value, copy._value, sizeof(_value)-1);
}

FeedData::FeedData(const char* value) {
    // Copy the provided string value as the feed data value.
    memset(_value, 0, sizeof(_value));
    strncpy(_value, value, FEEDDATA_LENGTH-1);
}

FeedData::FeedData(Stream& stream, uint16_t length, uint32_t timeoutMS) {
    // Load the data value from the provided stream.  Will read a value up to
    // length characters in size.  If the data can't be read for some reason,
    // like the timeout exceeding, then the FeedData will be left in an invalid
    // state.
    memset(_value, 0, sizeof(_value));
    if (length > FEEDDATA_LENGTH-1) {
        // Not enough space to store the value.
        DEBUG_PRINTLN(F("Not enough space to store feed data!"));
        return;
    }
    stream.setTimeout(timeoutMS);
    if (stream.readBytes(_value, length) != length) {
        // Didn't find enough data, set the value as invalid.
        DEBUG_PRINTLN(F("Failed to find expected data!"));
        memset(_value, 0, sizeof(_value));
    }
}

bool FeedData::intValue(int* value) {
    // Attempt to convert the value to an integer.  Returns true if it succeeds,
    // and false if it fails for some reason.
    char* endptr;
    *value = (int)strtol(_value, &endptr, 10);
    return (*_value != 0 && *endptr == 0);
}

bool FeedData::uintValue(unsigned int* value) {
    // Attempt to convert the value to an unsigned integer.  Returns true if it
    // succeeds, and false if it fails for some reason.
    char* endptr;
    #ifdef ESP8266
        // For some reason strtoul is not defined on the ESP8266 platform right now.
        // Just use a strtol function and hope for the best.
        *value = (unsigned int)strtol(_value, &endptr, 10);
    #else
        *value = (unsigned int)strtoul(_value, &endptr, 10);
    #endif
    return (*_value != 0 && *endptr == 0);
}

bool FeedData::longValue(long* value) {
    // Attempt to convert the value to a long.  Returns true if it
    // succeeds, and false if it fails for some reason.
    char* endptr;
    *value = strtol(_value, &endptr, 10);
    return (*_value != 0 && *endptr == 0);
}

bool FeedData::ulongValue(unsigned long* value) {
    // Attempt to convert the value to an unsigned long.  Returns true if it
    // succeeds, and false if it fails for some reason.
    char* endptr;
    #ifdef ESP8266
        // For some reason strtoul is not defined on the ESP8266 platform right now.
        // Just use a strtol function and hope for the best.
        *value = (unsigned long)strtol(_value, &endptr, 10);
    #else
        *value = strtoul(_value, &endptr, 10);
    #endif
    return (*_value != 0 && *endptr == 0);
}

bool FeedData::floatValue(float* value) {
    // Attempt to convert the value to a float.  Returns true if it succeeds,
    // and false if it fails for some reason.
    char* endptr;
    *value = (float)strtod(_value, &endptr);
    return (*_value != 0 && *endptr == 0);
}

bool FeedData::doubleValue(double* value) {
    // Attempt to convert the value to a double.  Returns true if it succeeds,
    // and false if it fails for some reason.
    char* endptr;
    *value = strtod(_value, &endptr);
    return (*_value != 0 && *endptr == 0);
}

// Buffer to store values converted from numbers to strings before sending to IO.
static char _converted[FEEDDATA_LENGTH];

bool Adafruit_IO_Feed::send(int value) {
    // Convert int to string, then send the value (being careful not to quote it).
    memset(_converted, 0, sizeof(_converted));
    itoa(value, _converted, 10);
    return _adapter->send(_name, _converted, _key, false);
}

bool Adafruit_IO_Feed::send(unsigned int value) {
    // Convert uint to string, then send the value (being careful not to quote it).
    memset(_converted, 0, sizeof(_converted));
    utoa(value, _converted, 10);
    return _adapter->send(_name, _converted, _key, false);
}

bool Adafruit_IO_Feed::send(long value) {
    // Convert long to string, then send the value (being careful not to quote it).
    memset(_converted, 0, sizeof(_converted));
    ltoa(value, _converted, 10);
    return _adapter->send(_name, _converted, _key, false);
}

bool Adafruit_IO_Feed::send(unsigned long value) {
    // Convert ulong to string, then send the value (being careful not to quote it).
    memset(_converted, 0, sizeof(_converted));
    ultoa(value, _converted, 10);
    return _adapter->send(_name, _converted, _key, false);
}

bool Adafruit_IO_Feed::send(float value, int precision) {
    // Convert float to string using scientific notation, then send the value
    // (being careful not to quote it).
    memset(_converted, 0, sizeof(_converted));
    #if defined(ARDUINO_ARCH_AVR)
        // Use avrlibc dtostre function on AVR platforms.
        dtostre(value, _converted, 10, 0);
    #elif defined(ESP8266)
        // ESP8266 Arduino only implements dtostrf and not dtostre.  Use dtostrf
        // but accept a hint as to how many decimals of precision are desired.
        dtostrf(value, 0, precision, _converted);
    #else
        // Otherwise fall back to snprintf on other platforms.
        snprintf(_converted, sizeof(_converted)-1, "%f", value);
    #endif
    return _adapter->send(_name, _converted, _key, false);
}

bool Adafruit_IO_Feed::send(double value, int precision) {
    // Convert double to string using scientific notation, then send the value
    // (being careful not to quote it).
    memset(_converted, 0, sizeof(_converted));
    #if defined(ARDUINO_ARCH_AVR)
        // Use avrlibc dtostre function on AVR platforms.
        dtostre(value, _converted, 10, 0);
    #elif defined(ESP8266)
        // ESP8266 Arduino only implements dtostrf and not dtostre.  Use dtostrf
        // but accept a hint as to how many decimals of precision are desired.
        dtostrf(value, 0, precision, _converted);
    #else
        // Otherwise fall back to snprintf on other platforms.
        snprintf(_converted, sizeof(_converted)-1, "%f", value);
    #endif
    return _adapter->send(_name, _converted, _key, false);
}
