IOT TOMTA Lamp from IKEA

I changed ordinary boring desk lamp into Blynk controlled device :)

BeginnerFull instructions provided1 hour1,543

Things used in this project

Hardware components

SparkFun Blynk Board - ESP8266

WS2812B

USB-A to Micro-USB Cable

5V USB Charger

Software apps and online services

Blynk

Hand tools and fabrication machines

Soldering iron (generic)

Story

Basic idea here is to be able to control very cheap lamp that can be found in IKEA.

Before anything else scan QR Code with your Blynk App to get started with your dashboard already configured for this lamp.

Then first step is to disassemble typical light bulb mount found in TOMTA and separate cable from it. Second ideally you should solder leftovers of the cable to usb charger and glue it inside of the lamp, otherwise you can simply throw away the cable (assuming your micro usb cable is long enough).

We are gonna use those later...

Next step is to get small plastic round container I found this one in pharmacy and wrap around it your ws2812b led strip. Obviously amount of leds on the strip will determine brightness of your lamp. Wrap around the container your led strip and glue everything together with lightbulb mount.

I used something like this but you can use whatever will find inside our lamp.

Next step we need to solder wires going to our led strip. It's important to solder 5V pin on led strip to Vin pin on Blynk Board, otherwise you will burn 3.3v regulator that's on board. Also please don't solder VCC pin from WS2812B connector on Blynk Board to 5V as it will burn the whole board.

Din pin from led strip should be soldered to Dout pin on Blynk Board and GND to GND. Where you gonna put blynk board is up to you I've put it inside white ceramic base of the lamp along with 5v charger that powers up everything.

Lastly program your Blynk Board with my code, use QR code to scan my dashboard into Blynk. Change some things like Blynk auth key along with details for your WiFi network and you are ready to go.

Just static green light.

Main Code

 //#define BLYNK_PRINT Serial    // Comment this out to disable prints and save space
#include <ESP8266WiFi.h>
#include <BlynkSimpleEsp8266.h>
#include <Adafruit_NeoPixel.h>
#include <TimeLib.h>
#include <WidgetRTC.h>

// You should get Auth Token in the Blynk App.
// Go to the Project Settings (nut icon).
char auth[] = "**********************";

//Global variables
//
bool leds_enable;
bool blynk_connection;
bool change;
uint8_t red, green, blue, effect, led_speed;
float brightness = 1.0;
bool autoLED = false;
bool autoTime = false;
bool syncOnChange = false;

//WS2812B Config
//
#define PIXEL_PIN   4     // Digital IO pin connected to the NeoPixels. Pin 4 is on Blynk Board.
#define PIXEL_COUNT 18    // Pixels Count

//Config leds used to display connection status
//LED0 is red
//LED1 is green
//If you don want to use, comment out LED0, LED1 or both.
//
#define LED0 13 //RED
#define LED1 4  //GREEN

//For multiple config
//
#define LED_SET 1
int currentLedSet = 0; // if not using multiple LED sets please set to current LED_SET

Adafruit_NeoPixel strip = Adafruit_NeoPixel(PIXEL_COUNT, PIXEL_PIN, NEO_GRB + NEO_KHZ800);
WidgetLCD lcd(V0);
WidgetRTC rtc;

BLYNK_ATTACH_WIDGET(rtc, V7);

///Prototypes so some ArduinoIDEs wont cri
void leds_off();
void leds_on();
void colorWipe(uint32_t c, uint8_t wait);
void rainbow(uint8_t wait);
void rainbowCycle(uint8_t wait);
void theaterChase(uint32_t c, uint8_t wait);
void theaterChaseRainbow(uint8_t wait);
uint32_t Wheel(byte WheelPos);


void setup()
{
  led_speed = 0;
  red = 255;
  green = 255;
  blue = 255;
  leds_enable = true;
  #ifdef LED0
  pinMode(LED0, OUTPUT);
  digitalWrite(LED0, HIGH);
  #endif
  #ifdef LED1
  pinMode(LED1, OUTPUT);
  digitalWrite(LED1, HIGH);
  #endif
  Serial.begin(115200);
  Blynk.begin(auth, "SSID", "PASSWORD");
  strip.begin();
  strip.show(); // Initialize all pixels to 'off'
  Serial.print("Connecting");
  while (Blynk.connect() == false) {
    // Wait until connected
    Serial.print(".");
    delay(100);
  }
  Serial.println();
  Blynk.syncAll();
  rtc.begin();
  lcd.clear();
  lcd.print(0, 1, "Welcome!");
}

BLYNK_WRITE(V1) {
  if (currentLedSet == LED_SET) {
    leds_enable = param.asInt();
    change = true;
    if (leds_enable) {
      Blynk.virtualWrite(8, 0);
      autoLED = false;
    }
  }
}

BLYNK_WRITE(V2) {
  if (currentLedSet == LED_SET) {
    brightness = (float)param.asInt()/100;
  }
}

BLYNK_WRITE(V3) {
  if (currentLedSet == LED_SET) {
    green = param.asInt();
    change = true;
  }
}

BLYNK_WRITE(V4) {
  if (currentLedSet == LED_SET) {
    red = param.asInt();
    change = true;
  }
}

BLYNK_WRITE(V5) {
  if (currentLedSet == LED_SET) {
    blue = param.asInt();
    change = true;
  }
}

BLYNK_WRITE(V6) {
  if (currentLedSet == LED_SET) {
    led_speed = param.asInt();
  }
}

BLYNK_WRITE(V8) {
  if (currentLedSet == LED_SET) {
    autoLED = param.asInt();
    if (autoLED) {
      Blynk.virtualWrite(1, 0);
      leds_enable = false;
    }
  }
}

BLYNK_WRITE(V9) {
  if (currentLedSet == LED_SET) {
    effect = param.asInt();
    change = true;
    lcd.clear();
    switch (effect) {
      case 0:
        lcd.print(0, 0, "LEDS OFF");
        break;
      case 1:
        lcd.print(0, 0, "LEDS ON");
        break;
      case 2:
        lcd.print(0, 0, "Color Wipe");
        break;
      case 3:
        lcd.print(0, 0, "Theater Chase");
        break;
      case 4:
        lcd.print(0, 0, "Theater Chase");
        lcd.print(0, 1, "Rainbow");
        break;
      case 5:
        lcd.print(0, 0, "Rainbow");
        break;
      case 6:
        lcd.print(0, 0, "Rainbow Cycle");
        break;
    }
  }
}

BLYNK_READ(V10) {
  if (currentLedSet == LED_SET) {
    String timeString = String(hour()) + ":" + String(minute()) + ":" +  String(second());
    Blynk.virtualWrite(10, timeString);
  }
}


BLYNK_WRITE(V11) {
  autoTime = param.asInt();
  (autoTime) ? Blynk.virtualWrite(12, 255) : Blynk.virtualWrite(12, 0);
}

BLYNK_WRITE(V13) {
  if (currentLedSet != LED_SET) syncOnChange = true;
  currentLedSet = param.asInt();
}

void loop()
{
  if (syncOnChange) {
    Blynk.syncAll();
    syncOnChange = false;
  }
  change = false;
  if (Blynk.connected()) {
    #ifdef LED1
    digitalWrite(LED1, HIGH);
    #endif
    #ifdef LED0
    digitalWrite(LED0, LOW);
    #endif
  }
  else {
    #ifdef LED0
    digitalWrite(LED0, HIGH);
    #endif
    #ifdef LED1
    digitalWrite(LED1, LOW);
    #endif
  }
  Blynk.run();
  if (leds_enable) {
    switch (effect) {
      case 0:
        leds_off();
        break;
      case 1:
        leds_on();
        break;
      case 2:
        colorWipe(strip.Color(brightness*(float)red, brightness*(float)green, brightness*(float)blue), led_speed);
        break;
      case 3:
        theaterChase(strip.Color(brightness*(float)red, brightness*(float)green, brightness*(float)blue), led_speed);
        break;
      case 4:
        theaterChaseRainbow(led_speed);
        break;
      case 5:
        rainbow(led_speed);
        break;
      case 6:
        rainbowCycle(led_speed);
        break;
    }
  }
  else {
    leds_off();
  }
  if (autoLED) {
    if (autoTime) {
      leds_enable = true;
    } else {
      leds_enable = false;
    }
  }
}

////////////////////////////////////////////////////////////////
////////////////////////////////////////////////////////////////
////////////////////////////////////////////////////////////////

void leds_off() {
  for (int i=0; i<strip.numPixels(); i++) {
    strip.setPixelColor(i, strip.Color(0, 0, 0));
  }
  strip.show();
  delay(20);
}

void leds_on() {
  for (int i=0; i<strip.numPixels(); i++) {
    strip.setPixelColor(i, strip.Color(brightness*(float)red, brightness*(float)green, brightness*(float)blue));
  }
  strip.show();
  delay(20);
}

/////////////////////////////////////////////////////////////////////////
//
//Any functions from now on are from Adafruit library with little mods.
//
/////////////////////////////////////////////////////////////////////////

// Fill the dots one after the other with a color
void colorWipe(uint32_t c, uint8_t wait) {
  delay(wait);
  leds_off();
  for(uint16_t i=0; i<strip.numPixels(); i++) {
    strip.setPixelColor(i, c);
    strip.show();
    delay(wait);
    Blynk.run();
    if (change) {return;}
  }
  delay(wait);
  leds_off();
  delay(wait);
  for(int i=strip.numPixels(); i>=0; i--) {
    strip.setPixelColor(i, c);
    strip.show();
    delay(wait);
    Blynk.run();
    if (change) {return;}
  }
  return;
}

void rainbow(uint8_t wait) {
  uint16_t i, j;

  for(j=0; j<256; j++) {
    for(i=0; i<strip.numPixels(); i++) {
      strip.setPixelColor(i, Wheel((i+j) & 255));
    }
    strip.show();
    delay(wait);
    Blynk.run();
    if (change) {return;}
  }
}

// Slightly different, this makes the rainbow equally distributed throughout
void rainbowCycle(uint8_t wait) {
  uint16_t i, j;

  for(j=0; j<256*5; j++) { // 5 cycles of all colors on wheel
    for(i=0; i< strip.numPixels(); i++) {
      strip.setPixelColor(i, Wheel(((i * 256 / strip.numPixels()) + j) & 255));
    }
    strip.show();
    delay(wait);
    Blynk.run();
    if (change) {return;}
  }
}

//Theatre-style crawling lights.
void theaterChase(uint32_t c, uint8_t wait) {
  for (int j=0; j<10; j++) {  //do 10 cycles of chasing
    for (int q=0; q < 3; q++) {
      for (int i=0; i < strip.numPixels(); i=i+3) {
        strip.setPixelColor(i+q, c);    //turn every third pixel on
      }
      strip.show();

      delay(wait);
      Blynk.run();
      if (change) {return;}
      for (int i=0; i < strip.numPixels(); i=i+3) {
        strip.setPixelColor(i+q, 0);        //turn every third pixel off
      }
    }
  }
}

//Theatre-style crawling lights with rainbow effect
void theaterChaseRainbow(uint8_t wait) {
  for (int j=0; j < 256; j++) {     // cycle all 256 colors in the wheel
    for (int q=0; q < 3; q++) {
      for (int i=0; i < strip.numPixels(); i=i+3) {
        strip.setPixelColor(i+q, Wheel( (i+j) % 255));    //turn every third pixel on
      }
      strip.show();

      delay(wait);
      Blynk.run();
      if (change) {return;}
      for (int i=0; i < strip.numPixels(); i=i+3) {
        strip.setPixelColor(i+q, 0);        //turn every third pixel off
      }
    }
  }
}

// Input a value 0 to 255 to get a color value.
// The colours are a transition r - g - b - back to r.
uint32_t Wheel(byte WheelPos) {
  WheelPos = 255 - WheelPos;
  if(WheelPos < 85) {
    return strip.Color(255 - WheelPos * 3, 0, WheelPos * 3);
  }
  if(WheelPos < 170) {
    WheelPos -= 85;
    return strip.Color(0, WheelPos * 3, 255 - WheelPos * 3);
  }
  WheelPos -= 170;
  return strip.Color(WheelPos * 3, 255 - WheelPos * 3, 0);
}
