ROS LiDAR Robot - Mark1

My first foray into exploring ROS - Robot Operating System. Learning it by creating a Robot project, parts mainly from my son's STEM toys.

AdvancedWork in progress12 hours1,338
ROS LiDAR Robot - Mark1

Things used in this project

Hardware components

Raspberry Pi 3 Model B
Raspberry Pi 3 Model B
×1
Makeblock mBot Ranger Robot Chassis
This will be the ROS Navigation base for the Robot. Utilizing the following components; (A.) Me Auriga ( Arduino Mega 2560) MCU. (B.) Me 180 Encoder Motors (C.) TB6612FNG Motor Driver for the ROS serial low-level interface.
×1
Slamtec RP LiDAR A1
×1
Promate 30000mAh Battery Bank
×1
Lego Mechanic Assorted Pieces
×1

Software apps and online services

Ubuntu Bionic 18.04
ROS Melodic
ROS Master
ROS Noetic
RVIZ , Path Planning, and Visualisation

Story

Read more

Schematics

Me Auriga PinOut Diagram

Reference to the Pin Outs of the Onboard Mega2560 MCU, TB6612 Motor Driver, and Me 180 Encoder Motors.

Software Structure

Software Structure

Code

mbot_ranger_cmd_vel.ino

Arduino
This file is the cmd_vel code for the mBot Ranger. Using the Makeblock Me Auriga Board which is actually an integrated MCU (Arduino Mega2560 and an on-board TB6612 Motor Driver) for the Two Me-180 Encoder Motors.
/**
 * @file         mbot_ranger_cmd_vel.ino
 * @author       Erwin Rabano Pasia
 * @version      V1.0
 * @date         2022/02/01
 * @description  This file is the cmd_vel code for the mBot Ranger.
 * Using the Makeblock Me Auriga Board which is actually an integrated MCU (Arduino Mega2560 and an on-board TB6612 Motor Driver)
 * for the Two Me-180 Encoder Motors.
 */


#include <ros.h>
#include <geometry_msgs/Twist.h>

// Maximum PWM = 255
int maxPwm=225;
int halfPwm=225;
int stopPwm=0;
int turnPwm=255;

//Encoder Motor Left
const int pwmMotor1 = 11;
const int inMotor1_1 = 49;
const int inMotor1_2 = 48;

//Encoder Motor Right
const int pwmMotor2 = 10;
const int inMotor2_1 = 47;
const int inMotor2_2 = 46;


ros::NodeHandle  nh;

void MoveBack() {
    digitalWrite(inMotor1_1, HIGH);
    digitalWrite(inMotor1_2, LOW);
    analogWrite(pwmMotor1,maxPwm);
    digitalWrite(inMotor2_1, LOW);
    digitalWrite(inMotor2_2, HIGH);
    analogWrite(pwmMotor2,maxPwm);
    Serial.println("Move Backward at Full speed"); //For debugging
}

void MoveStop() {
    digitalWrite(inMotor1_1, LOW);
    digitalWrite(inMotor1_2, LOW);
    analogWrite(pwmMotor1,stopPwm);
    digitalWrite(inMotor2_1, LOW);
    digitalWrite(inMotor2_2, LOW);
    analogWrite(pwmMotor2,stopPwm);
    Serial.println("At Full-Stop Mode"); //For debugging
}
void MoveRight() {
    digitalWrite(inMotor1_1, LOW);
    digitalWrite(inMotor1_2, HIGH);
    analogWrite(pwmMotor1,turnPwm);//Set speed via PWM
    digitalWrite(inMotor2_1, LOW);
    digitalWrite(inMotor2_2, HIGH);
    analogWrite(pwmMotor2,turnPwm);//Set speed via PWM
    Serial.println("Turning the Robot Right"); //For debugging
}
void MoveLeft() {
    digitalWrite(inMotor1_1, HIGH);
    digitalWrite(inMotor1_2, LOW);
    analogWrite(pwmMotor1,turnPwm);//Set speed via PWM
    digitalWrite(inMotor2_1, HIGH);
    digitalWrite(inMotor2_2, LOW);
    analogWrite(pwmMotor2,turnPwm);//Set speed via PWM
    Serial.println("Turning the Robot Left"); //For debugging
}
void MoveFwd() {
    digitalWrite(inMotor1_1, LOW);
    digitalWrite(inMotor1_2, HIGH);
    analogWrite(pwmMotor1,maxPwm);
    digitalWrite(inMotor2_1, HIGH);
    digitalWrite(inMotor2_2, LOW);
    analogWrite(pwmMotor2,maxPwm);
    Serial.println("Move Forward at Full speed"); //For debugging
}

void cmd_vel_cb(const geometry_msgs::Twist & msg) {
  // Read the message.
  // We only care about the linear x, and the rotational z.
  const float x = msg.linear.x;
  const float z_rotation = msg.angular.z;

  // Decide on the encoder motor state we need, according to command.
  if (x > 0 && z_rotation == 0) {
    MoveFwd();
  }
  else if (x == 0 && z_rotation == 1) {
    MoveRight();
  }
else if (x == 0 && z_rotation < 0) {
    MoveLeft();
  }
else if (x < 0 && z_rotation == 0) {
    MoveBack();
  }
else{
    MoveStop();
  }
}
ros::Subscriber<geometry_msgs::Twist> sub("cmd_vel", cmd_vel_cb);
void setup() {
  // pinMode(right_back, OUTPUT);
  // pinMode(left_back, OUTPUT);
  // pinMode(right_front, OUTPUT);
  // pinMode(left_front, OUTPUT);

  pinMode(pwmMotor1, OUTPUT);
  pinMode(pwmMotor2, OUTPUT);

  nh.initNode();
  nh.subscribe(sub);
}

void loop() {
  nh.spinOnce();
  delay(1);
}
