#!/usr/bin/env python3
# Copyright 2019 Amazon.com, Inc. or its affiliates. All Rights Reserved.
#
# You may not use this file except in compliance with the terms and conditions
# set forth in the accompanying LICENSE.TXT file.
#
# THESE MATERIALS ARE PROVIDED ON AN "AS IS" BASIS. AMAZON SPECIFICALLY DISCLAIMS, WITH
# RESPECT TO THESE MATERIALS, ALL WARRANTIES, EXPRESS, IMPLIED, OR STATUTORY, INCLUDING
# THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT.
import os
import sys
import time
import logging
import json
import random
import threading
from enum import Enum
from agt import AlexaGadget
from ev3dev2.led import Leds
from ev3dev2.sound import Sound
from ev3dev2.motor import OUTPUT_A, OUTPUT_B, OUTPUT_C, MoveTank, SpeedPercent, MediumMotor
from ev3dev2.sensor.lego import InfraredSensor
# Set the logging level to INFO to see messages from AlexaGadget
logging.basicConfig(level=logging.INFO, stream=sys.stdout, format='%(message)s')
logging.getLogger().addHandler(logging.StreamHandler(sys.stderr))
logger = logging.getLogger(__name__)
class Direction(Enum):
"""
The list of directional commands and their variations.
These variations correspond to the skill slot values.
"""
FORWARD = ['forward', 'forwards', 'go forward']
BACKWARD = ['back', 'backward', 'backwards', 'go backward']
LEFT = ['left', 'go left']
RIGHT = ['right', 'go right']
STOP = ['stop', 'brake', 'halt']
class Command(Enum):
"""
The list of preset commands and their invocation variation.
These variations correspond to the skill slot values.
"""
MOVE_CIRCLE = ['circle', 'move around']
MOVE_SQUARE = ['square']
SENTRY = ['guard', 'guard mode', 'sentry', 'sentry mode']
PATROL = ['patrol', 'patrol mode']
ROTATE = ['rotate','turn','move','swipe']
# FIRE_ONE = ['cannon', '1 shot', 'one shot']
# FIRE_ALL = ['all shots', 'all shot']
class EventName(Enum):
"""
The list of custom event name sent from this gadget
"""
SENTRY = "Sentry"
PROXIMITY = "Proximity"
SPEECH = "Speech"
class MindstormsGadget(AlexaGadget):
"""
A Mindstorms gadget that can perform bi-directional interaction with an Alexa skill.
"""
def __init__(self):
"""
Performs Alexa Gadget initialization routines and ev3dev resource allocation.
"""
super().__init__()
# Robot state
self.sentry_mode = False
self.patrol_mode = False
# Connect two large motors on output ports B and C
self.drive = MoveTank(OUTPUT_B, OUTPUT_C)
self.hand = MediumMotor(OUTPUT_A)
self.sound = Sound()
self.leds = Leds()
self.ir = InfraredSensor()
# Start threads
threading.Thread(target=self._patrol_thread, daemon=True).start()
threading.Thread(target=self._proximity_thread, daemon=True).start()
def on_connected(self, device_addr):
"""
Gadget connected to the paired Echo device.
:param device_addr: the address of the device we connected to
"""
self.leds.set_color("LEFT", "GREEN")
self.leds.set_color("RIGHT", "GREEN")
logger.info("{} connected to Echo device".format(self.friendly_name))
def on_disconnected(self, device_addr):
"""
Gadget disconnected from the paired Echo device.
:param device_addr: the address of the device we disconnected from
"""
self.leds.set_color("LEFT", "BLACK")
self.leds.set_color("RIGHT", "BLACK")
logger.info("{} disconnected from Echo device".format(self.friendly_name))
def on_custom_mindstorms_gadget_control(self, directive):
"""
Handles the Custom.Mindstorms.Gadget control directive.
:param directive: the custom directive with the matching namespace and name
"""
try:
payload = json.loads(directive.payload.decode("utf-8"))
print("Control payload: {}".format(payload), file=sys.stderr)
control_type = payload["type"]
if control_type == "move":
# Expected params: [direction, duration, speed]
self._move(payload["direction"], int(payload["duration"]), int(payload["speed"]))
if control_type == "command":
# Expected params: [command]
self._activate(payload["command"])
except KeyError:
print("Missing expected parameters: {}".format(directive), file=sys.stderr)
def _move(self, direction, duration: int, speed: int, is_blocking=False):
"""
Handles move commands from the directive.
Right and left movement can under or over turn depending on the surface type.
:param direction: the move direction
:param duration: the duration in seconds
:param speed: the speed percentage as an integer
:param is_blocking: if set, motor run until duration expired before accepting another command
"""
print("Move command: ({}, {}, {}, {})".format(direction, speed, duration, is_blocking), file=sys.stderr)
if direction in Direction.FORWARD.value:
self.drive.on_for_seconds(SpeedPercent(speed), SpeedPercent(speed), duration, block=is_blocking)
if direction in Direction.BACKWARD.value:
self.drive.on_for_seconds(SpeedPercent(-speed), SpeedPercent(-speed), duration, block=is_blocking)
if direction in (Direction.RIGHT.value + Direction.LEFT.value):
self._turn(direction, speed)
self.drive.on_for_seconds(SpeedPercent(speed), SpeedPercent(speed), duration, block=is_blocking)
if direction in Direction.STOP.value:
self.drive.off()
self.patrol_mode = False
def _activate(self, command, speed=50):
"""
Handles preset commands.
:param command: the preset command
:param speed: the speed if applicable
"""
print("Activate command: ({}, {})".format(command, speed), file=sys.stderr)
if command in Command.MOVE_CIRCLE.value:
self.drive.on_for_seconds(SpeedPercent(int(speed)), SpeedPercent(5), 12)
if command in Command.MOVE_SQUARE.value:
for i in range(4):
self._move("right", 2, speed, is_blocking=True)
if command in Command.PATROL.value:
# Set patrol mode to resume patrol thread processing
self.patrol_mode = True
if command in Command.SENTRY.value:
self.sentry_mode = True
self._send_event(EventName.SPEECH, {'speechOut': "Sentry mode activated"})
# Perform Shuffle posture
self.drive.on_for_seconds(SpeedPercent(80), SpeedPercent(-80), 0.2)
time.sleep(0.3)
self.drive.on_for_seconds(SpeedPercent(-40), SpeedPercent(40), 0.2)
self.leds.set_color("LEFT", "YELLOW", 1)
self.leds.set_color("RIGHT", "YELLOW", 1)
if command in Command.ROTATE.value:
print("Hand", file=sys.stderr)
self.hand.on_for_rotations(SpeedPercent(100), 3)
self._send_event(EventName.SENTRY, {'hand': 1})
self.sentry_mode = False
print("Rotate Hand", file=sys.stderr)
self.leds.set_color("LEFT", "GREEN", 1)
self.leds.set_color("RIGHT", "GREEN", 1)
def _turn(self, direction, speed):
"""
Turns based on the specified direction and speed.
Calibrated for hard smooth surface.
:param direction: the turn direction
:param speed: the turn speed
"""
if direction in Direction.LEFT.value:
self.drive.on_for_seconds(SpeedPercent(0), SpeedPercent(speed), 2)
if direction in Direction.RIGHT.value:
self.drive.on_for_seconds(SpeedPercent(speed), SpeedPercent(0), 2)
def _send_event(self, name: EventName, payload):
"""
Sends a custom event to trigger a sentry action.
:param name: the name of the custom event
:param payload: the sentry JSON payload
"""
self.send_custom_event('Custom.Mindstorms.Gadget', name.value, payload)
def _proximity_thread(self):
"""
Monitors the distance between the robot and an obstacle when sentry mode is activated.
If the minimum distance is breached, send a custom event to trigger action on
the Alexa skill.
"""
count = 0
while True:
# while self.sentry_mode:
distance = self.ir.proximity
print("Proximity: {}".format(distance), file=sys.stderr)
count = count + 1 if distance < 10 else 0
if count > 3:
print("Proximity breached. Sending event to skill", file=sys.stderr)
self.leds.set_color("LEFT", "RED", 1)
self.leds.set_color("RIGHT", "RED", 1)
self.drive.on_for_seconds(SpeedPercent(50), SpeedPercent(0), 2)
self._send_event(EventName.PROXIMITY, {'distance': distance})
self.sentry_mode = False
time.sleep(0.2)
# time.sleep(1)
def _patrol_thread(self):
"""
Performs random movement when patrol mode is activated.
"""
while True:
while self.patrol_mode:
print("Patrol mode activated randomly picks a path", file=sys.stderr)
direction = random.choice(list(Direction))
duration = random.randint(1, 5)
speed = random.randint(1, 4) * 25
while direction == Direction.STOP:
direction = random.choice(list(Direction))
# direction: all except stop, duration: 1-5s, speed: 25, 50, 75, 100
self._move(direction.value[0], duration, speed)
time.sleep(duration)
time.sleep(1)
if __name__ == '__main__':
gadget = MindstormsGadget()
# Set LCD font and turn off blinking LEDs
os.system('setfont Lat7-Terminus12x6')
gadget.leds.set_color("LEFT", "BLACK")
gadget.leds.set_color("RIGHT", "BLACK")
# Startup sequence
gadget.sound.play_song((('C4', 'e'), ('D4', 'e'), ('E5', 'q')))
gadget.leds.set_color("LEFT", "GREEN")
gadget.leds.set_color("RIGHT", "GREEN")
# Gadget main entry point
gadget.main()
# Shutdown sequence
gadget.sound.play_song((('E5', 'e'), ('C4', 'e')))
gadget.leds.set_color("LEFT", "BLACK")
gadget.leds.set_color("RIGHT", "BLACK")
