Blaze Buster

#include <Servo.h>
#include "IR_remote.h"
#include "Keymap.h"

IRremote ir(3);

Servo water_servo;
int starting_Angle;
int Avoidance_distance;
int manual_Or_Automatic;
byte ir_Status;
unsigned long previousMillis = 0UL;
unsigned long interval = 1000UL;
int currentMillis = 0;

//Flame sensor pin is D7, Pump pin is D8, Rotating platform (Servo) is D12.
//NOTE: if manual_Or_Automatic value is 0, then it is on Automatic mode. Else its manual.
//Used with Ultrasonic Avoidance Car made by LAFVIN
// Fadel Taha {Copyright 2023}

float checkdistance() {
  digitalWrite(12, LOW);
  delayMicroseconds(2);
  digitalWrite(12, HIGH);
  delayMicroseconds(10);
  digitalWrite(12, LOW);
  float distance = pulseIn(13, HIGH) / 58.00;
  delay(10);
  return distance;
}

void Stop() {
  digitalWrite(2,LOW);
  analogWrite(5,0);
  digitalWrite(4,HIGH);
  analogWrite(6,0);
}

void Move_Backward(int speed) {
  digitalWrite(2,LOW);
  analogWrite(5,speed);
  digitalWrite(4,HIGH);
  analogWrite(6,speed);
}

void Rotate_Left(int speed) {
  digitalWrite(2,LOW);
  analogWrite(5,speed);
  digitalWrite(4,LOW);
  analogWrite(6,speed);
}

void Rotate_Right(int speed) {
  digitalWrite(2,HIGH);
  analogWrite(5,speed);
  digitalWrite(4,HIGH);
  analogWrite(6,speed);
}

void Move_Forward(int speed) {
  digitalWrite(2,HIGH);
  analogWrite(5,speed);
  digitalWrite(4,LOW);
  analogWrite(6,speed);
}
void setup() {
  Serial.begin(9600);
  IRremote ir(3);

  pinMode(8, OUTPUT);
  pinMode(7, INPUT);
  pinMode(12, OUTPUT);
  pinMode(13, INPUT);
  pinMode(2, OUTPUT);
  pinMode(5, OUTPUT);
  pinMode(4, OUTPUT);
  pinMode(6, OUTPUT);
  //water_servo.attach(12);
  water_servo.attach(11);
  digitalWrite(8, LOW);
  manual_Or_Automatic = 0;
  ir_Status = "";
}

/*void IR_control_Function() {
  ir_Status = ir.getIrKey(ir.getCode(),1);
  if (ir_Status == IR_KEYCODE_UP && manual_Or_Automatic == 1){
    Move_Forward(100);
    Serial.println("Moving forward...");
    delay(300);
    Stop();
  } else if (ir_Status == IR_KEYCODE_DOWN && manual_Or_Automatic == 1){
    Move_Backward(100);
    Serial.println("Moving backward...");
    delay(300);
    Stop();
  } else if (ir_Status == IR_KEYCODE_LEFT && manual_Or_Automatic == 1){
    Rotate_Left(70);
    Serial.println("Moving right...");
    delay(300);
    Stop();
  } else if (ir_Status == IR_KEYCODE_RIGHT && manual_Or_Automatic == 1){
    Rotate_Right(70);
    Serial.println("Moving left...");
    delay(300);
    Stop();
  }
}*/

/*void IR_recieve()
{
  if (ir_Status == IR_KEYCODE_1)
  {
    Serial.println("AUTOMATIC MODE ON");
    manual_Or_Automatic = 1;
  } else if (ir_Status == IR_KEYCODE_0)
  {
    Serial.println("MANUAL MODE ON");
    manual_Or_Automatic = 0;
  }
}*/

void is_Fire_Detected()
{
  if (digitalRead(7) == 0)
  {                          //IF FIRE IS DETECTED
    Stop();
    Serial.println("|||FLAME DETECTED|| Car Stopped. Servo about to start.");
    water_servo.write(starting_Angle);
    digitalWrite(8, HIGH);
    for (int i=0; i < 60; i++)
    {
      water_servo.write(i);
      Serial.println("ServoLoop "+i);
      delay(10);
    }
   digitalWrite(8, LOW);
  }
}

void ultrasonic_Function()
{
  int awareness_Distance = 25;
  while (true)
  {
    Avoidance_distance = checkdistance();
    if (Avoidance_distance <= awareness_Distance)
    {
      if (Avoidance_distance <= 15)
      {
        Stop();
        delay(100);
        Move_Backward(50);
        delay(1000);
      } else
      {
        Stop();
        delay(100);
        Rotate_Left(100);
        delay(600);
      }
    }
    else
    {
    Move_Forward(70);
    delay(1000);
    break;
    }
  }
}

void loop() {
  digitalWrite(8, LOW);
  int starting_Angle = 0;
  int Avoidance_distance = 0;
  Avoidance_distance = checkdistance();
  water_servo.write(starting_Angle);
  Serial.println("Moving forward.");
  //Move_Forward(75);
  //delay(1000);
  ultrasonic_Function();
  Stop();
  delay(1000);
  if (digitalRead(7) == 0)
  {                          //IF FIRE IS DETECTED
    while (digitalRead(7) == 0)
    {
      water_servo.write(starting_Angle);
      Serial.println("|||FLAME DETECTED|| Car Stopped. Servo about to start.");
      digitalWrite(8, HIGH);                       //PUMP WILL START WORKING
      for (int i=0; i < 60; i++)
      {
        water_servo.write(i);
        Serial.println("ServoLoop "+i);
        delay(10);
      }
      digitalWrite(8, LOW);
      }
    }
  digitalWrite(8, LOW);
  Rotate_Left(75);
  delay(2100);
  Stop();
  /*else
  {
    digitalWrite(8, LOW);
    Rotate_Left(50);
    delay(1200);
    Stop();
  }*/
}
