Play Home Alone song with a piezo buzzer and Arduino

Main article: Play Home Alone song with a piezo buzzer and Arduino

Home Alone has since been considered one of the best Christmas films and Somewhere in My Memory has been nominated as best original song. We wanted to recreate the melody of the film's theme song with a piezo buzzer and share with you. Buzzer is used to generate sound, beep or even melody of a song. It can be found in alarm devices, computers, timers and confirmation of user input such as a mouse click or keystroke.

A piezo buzzer is not like a regular speaker that you might think of. It uses a material that actually changes shape when you apply electricity to it which in turn creates noise. The faster you bend the material, the higher the pitch of the noise that is produced.

Wiring schema

The connection is pretty easy, it only has control signal and GND. Pin D9 will be used to control the tone.

Pitches library

The code used to generate the melody uses an extra library with predefined pitches. It's a set of constants that represent notes. It can be downloaded from our official repository.

To import a library, open the Arduino IDE, go to Sketch > Include Library > Add.ZIP Library and select the library file downloaded from our GitHub repository.

Then you can simply use include statement:

#include "pitches.h"

It will include the library with predefined pitch constants so the melody generation becomes easier.

Arduino code

Built-in Arduino functions will be used to generate the melody. Tone() generates a square wave of the specified frequency (and 50% duty cycle) on a pin. A duration can be specified, otherwise the wave continues until a call to noTone(). If you are trying to make tones for the human ear, then values between 2000 and 5000 are where our ears are most tuned.

The main program will iterate over notes and and use assigned duration for the note. The code has self explanatory comments to better understand what is being done.

#include "pitches.h"

#define BUZZER_PIN 9

int melody[] = {
  NOTE_E4, NOTE_C5, NOTE_B4, NOTE_B4,
  NOTE_C5, NOTE_B4, NOTE_F4, NOTE_G4,
  NOTE_G4, NOTE_E4, NOTE_G4, NOTE_E4,
  NOTE_C5, NOTE_G4,
  NOTE_D4, NOTE_A4, NOTE_G4, NOTE_C4, NOTE_F4,
  NOTE_E4, NOTE_D4,
  NOTE_G4, NOTE_E4, NOTE_G4, NOTE_E4,
  NOTE_C5, NOTE_G4,
  NOTE_A4, NOTE_C5, NOTE_F4, NOTE_E4, NOTE_G4, NOTE_C4,
  NOTE_E4, NOTE_D4,
  REST, NOTE_E4,NOTE_C4, NOTE_F4, NOTE_D4,
  REST, NOTE_FS4, NOTE_D4, NOTE_A4, NOTE_G4,
  REST, NOTE_GS5, NOTE_E4, NOTE_B4, NOTE_A4,
  NOTE_F4, NOTE_C5, NOTE_A4, NOTE_B4,
  NOTE_G4, NOTE_E4, NOTE_G4, NOTE_E4,
  NOTE_C5, NOTE_G4,
  NOTE_D4, NOTE_A4, NOTE_G4, NOTE_C4, NOTE_F4,
  NOTE_E4, NOTE_D4,
  NOTE_G4, NOTE_E4, NOTE_G4, NOTE_E4,
  NOTE_C5, NOTE_G4,
  REST, NOTE_A4, NOTE_B4, NOTE_C5, NOTE_G4, NOTE_E4,
  REST, NOTE_A4, NOTE_B4, NOTE_C5, NOTE_G4, NOTE_E4,
  REST, NOTE_A4, NOTE_B4, NOTE_C5, NOTE_G4, NOTE_E4,
  NOTE_C4, NOTE_C5, NOTE_B4,
  NOTE_D5, NOTE_E4, NOTE_G4, NOTE_E4,
  NOTE_C5, NOTE_G4,
  NOTE_C5
};

int durations[] = {
  4, 8, 8, 2,
  8, 8, 4, 4,
  4, 4, 4, 4,
  2, 2,
  4, 4, 4, 8, 8,
  2, 2,
  4, 4, 4, 4,
  2, 2,
  8, 8, 4, 8, 8, 4,
  2, 2,
  4, 8, 8, 4, 4,
  4, 8, 8, 4, 4,
  4, 8, 8, 4, 4,
  4, 8, 8, 2,
  4, 4, 4, 4,
  2, 2,
  4, 4, 4, 8, 8,
  2, 2,
  4, 4, 4, 4,
  2, 2,
  4, 16, 16, 8, 4, 4,
  4, 16, 16, 8, 4, 4,
  4, 16, 16, 8, 4, 4,
  4, 2, 4,
  4, 4, 4, 4,
  2, 2,
  1
};

void setup()
{
  pinMode(BUZZER_PIN, OUTPUT);
}

void loop()
{
  int size = sizeof(durations) / sizeof(int);

  for (int note = 0; note < size; note++) {
    //to calculate the note duration, take one second divided by the note type.
    //e.g. quarter note = 1000 / 4, eighth note = 1000/8, etc.
    int duration = 1000 / durations[note];
    tone(BUZZER_PIN, melody[note], duration);

    //to distinguish the notes, set a minimum time between them.
    //the note's duration + 30% seems to work well:
    int pauseBetweenNotes = duration * 1.30;
    delay(pauseBetweenNotes);

    //stop the tone playing:
    noTone(BUZZER_PIN);
  }
}

Note: tone() function uses one of the built in timers on the Arduino’s micro-contoller and works independently of the delay() function.

Only one tone can be generated at a time. If a tone is already playing on a different pin, the call to tone() will have no effect. If the tone is playing on the same pin, the call will set its frequency. Use of the tone() function will interfere with PWM output on pins 3 and 11 (on boards other than the Mega). Also, it is not possible to generate tones lower than 31Hz.

Merry Christmas and Happy New Year!
