Control Home Appliance From Internet Using Arduino and WiFi

Control home appliances from anywhere in world using Internet. Make your home smart with Arduino and ESP8266 WiFi Module.

AdvancedProtip12 hours86,901
Control Home Appliance From Internet Using Arduino and WiFi

Things used in this project

Hardware components

Arduino UNO
Arduino UNO
×1
ESP8266 ESP-01
Espressif ESP8266 ESP-01
×1
Relay (generic)
×1
Breadboard (generic)
Breadboard (generic)
×1
Two AC Bulbs(Red,Yellow)
×1
Jumper wires (generic)
Jumper wires (generic)
×1

Software apps and online services

Arduino IDE
Arduino IDE
REST API

Story

Read more

Schematics

Circuit Design

Circuit Design

Code

Source Code

C/C++
Source Code
#include "SoftwareSerial.h"

String ssid ="WIFI_NAME";
String password="WIFI_PASSWORD";

SoftwareSerial esp(3, 2);// RX, TX

String server = "www.iotboys.com"; //Your Host
String uri = "/YOUR_API"; // Your URI

int RED_BULB=5;
int YELLOW_BULB=6;

void setup() {

  pinMode(RED_BULB, OUTPUT);
  pinMode(YELLOW_BULB, OUTPUT);

  digitalWrite(RED_BULB, HIGH);
  digitalWrite(YELLOW_BULB, HIGH);

  esp.begin(9600);

  Serial.begin(9600);

  connectWifi();

  httpget();

  delay(1000);

}
void connectWifi() {

String cmd = "AT+CWJAP=\"" +ssid+"\",\"" + password + "\"";

esp.println(cmd);

delay(4000);

if(esp.find("OK")) {

Serial.println("Connected!");

}
else {

Serial.println("Cannot connect to wifi ! Connecting again..."); }
connectWifi();

}
/////////////////////////////GET METHOD///////////////////////////////
void httpget() {
esp.println("AT+CIPSTART=\"TCP\",\"" + server + "\",80");//start a TCP connection.

if( esp.find("OK")) {

Serial.println("TCP connection ready");

} delay(1000);

String getRequest =
"GET " + uri + " HTTP/1.0\r\n" +
"Host: " + server + "\r\n" +
"Accept: *" + "/" + "*\r\n" +
"Content-Type: application/json\r\n" +
"\r\n";

String sendCmd = "AT+CIPSEND=";

esp.print(sendCmd);

esp.println(getRequest.length() );

delay(500);

if(esp.find(">")) {
  Serial.println("Sending..");
  esp.print(getRequest);

if( esp.find("SEND OK")) {

Serial.println("Packet sent");

while (esp.available()) {

String response = esp.readString();

int RED_BULB_ON = response.indexOf("RED_BULB>TRUE")>0?1:0;
int YELLOW_BULB_ON = response.indexOf("YELLOW_BULB>TRUE")>0?1:0;

if(RED_BULB_ON==1)
{
  digitalWrite(RED_BULB, LOW);
}
else
{
  digitalWrite(RED_BULB, HIGH);
}
if(YELLOW_BULB_ON==1)
{
  digitalWrite(YELLOW_BULB, LOW);
}
else
{
  digitalWrite(YELLOW_BULB, HIGH);
}
}
esp.println("AT+CIPCLOSE");

}
}
}

void loop() {
  httpget();
}
